MCLJ20H085802.11abgn/BT3.0 Wireless Module

1 Project Name MT7650 IEEE802.11a/b/g/n 1×1 + Bluetooth3.0, WiFi+BT module Approval Sheet Rev. 1.0 Foxconn Part No. J20H085.00 J20H085.01 Sony Part No. 1-458-765-31 (J20H085.00) 1-458-765-21 (J20H085.01) Prepared by Reviewed by Approved by Clon Liu Eddie Huang Ambit Microsystems (Shanghai) LTD. No 1925, Nanle Road Songjiang Export Processing Zone Shanghai, China Tel :86-21-61206688 Ext:22165 FAX:86-21-57749230 J20H085 User Manual 2 CONTENTS 1 REVISION HISTORY ................................ ................................................................ ................................................................ ................................................................ .................................... ........ .... 4 44 4 2 MANUFACTURING INFORMATION ................................ ................................................................ ....................................................... .............................................. ....................... 5 55 5 3 PRODUCT OVERVIEW ................................ ................................................................ ................................................................ ................................................................ .................................. .... .. 6 66 6 3.1 APPLICATION SCOPE .................................................................... 6 3.2 REGULATION OF EACH COUNTRIES ......................................................... 7 4 MODULE HARDWARE OVERVIEW ................................ ................................................................ ....................................................... .............................................. ....................... 8 88 8 4.1 BLOCK DIAGRAM ....................................................................... 8 4.2 FEATURES ............................................................................ 8 4.3 INTERFACE AND CONNECTOR ............................................................. 8 5 GENERAL SPECIFICATION ................................ ................................................................ ............................................................. .......................................................... ............................. 10 1010 10 6 ELECTRICAL SPECIFICATION ................................ ................................................................ .......................................................... .................................................... .......................... 11 1111 11 6.1 ABSOLUTE MAXIMUM RATING ............................................................ 11 6.2 RECOMMENDED OPERATING RATING ...................................................... 11 6.3 DC CHARACTERISTICS ................................................................. 11 6.4 ESD INFORMATION .................................................................... 11 6.5 ENVIRONMENT STORAGE CONDITION ...................................................... 11 7 RF SPECIFICATION ................................ ................................................................ ................................................................ ................................................................ .................................... ........ .... 12 1212 12 7.1 IEEE802.11B ........................................................................ 12 7.2 IEEE802.11G ........................................................................ 13 7.3 IEEE 802.11N HT20 .................................................................. 14 7.4 IEEE 802.11A ........................................................................ 15 7.5 IEEE 802.11AN HT20 ................................................................. 16 7.6 IEEE 802.11AN HT40 ................................................................. 17 7.7 BLUETOOTH 3.0 ....................................................................... 18 7.8 ANTENNA ELECTRICAL SPECIFICATION(J20H085.01)......................................... 19 7.9 POWER UP SEQUENCE ................................................................... 8 MECHANICAL SPECIFICATIONS ................................ ................................................................ .......................................................... .................................................... .......................... 8.1 SHIELDING COVER DIMENSION ............................................................. 8.2 PCB ASSEMBLY DIMENSION ............................................................... 8.3 MOUNT POSITION OF MATERIALS ........................................................... 9 SCHEMATICS ................................ ................................................................ ................................................................ ................................................................ ........................................... ...................... ........... 10 LAYOUT PATTERN ................................ ................................................................ ................................................................ ................................................................ ...................................... ............ ...... 10.1 MAIN PCB LAYOUT (TOP VIEW) ............................................................ 10.2 ANTENNA PCB LAYOUT ................................................................... 10.3 PCB SPECIFICATION ..................................................................... 11 BOM (BILL OF MATERIALS) ................................ ................................................................ .............................................................. ............................................................ .............................. 12 OTP CONTENT ................................ .............................................…

Text truncated - open the document above for the full version.

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. Date: 2014-10-14 G E N E R A L D E C L A R A T I O N We, HON HAI PRECISION IND. CO., LTD. declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. FCC ID: MCLJ20H085 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! ---------------------------------------------------- Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. AGENCY AUTHORIZATION LETTER Date: 2014-10-14 FCC ID: MCLJ20H085 To whom it may concern: We, the undersigned, hereby authorize Amanda Wu of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Amanda Wu of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to Contact us. Sincerely yours, ---------------------------------------------------- Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. Date: 2014-10-14 FCC ID: MCLJ20H085 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Software Operating Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ---------------------------------------------------- Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. Federal Communications Commission Authorization and Evaluation Division Date: 2014-10-14 Confidentiality Request FCC ID: MCLJ20H085 Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Test Setup Photos User’s Manual Internal Photo Thank you! Sincerely yours, ---------------------------------------------------- Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

FCC ID: MCLJ20H085 Report No.: RF140923E06 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch November 12, 2014 Dear Application Examiner, Hon Hai PRECISION IND.CO.,LTD., 802.11abgn/BT3.0 Wireless Module, FCC ID: MCLJ20H085, would like to have your authorization as a modular approval specific to the mobile RF exposure condition. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip MT7650UN. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is MT7650UN. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a USB extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Hank Chung Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

Report No.: 140923E06 1 of 9 CONSTRUCTION PHOTOS OF EUT Report No.: 140923E06 3 of 9 Antenna Set 1 Brand: NA , Model No.: NA PCB Antenna Report No.: 140923E06 4 of 9 Antenna Set 2 Brand: WIESON , Model No.: Z-Y121JT008A-013-S Report No.: 140923E06 5 of 9 Report No.: 140923E06 6 of 9 Antenna Set 3 Brand: FOXCONN , Model No.: FX01K03-SN-EF Report No.: 140923E06 7 of 9 Report No.: 140923E06 8 of 9 Antenna Set 4 Brand: WIESON , Model No.: Y121JT008A-016-S Report No.: 140923E06 9 of 9

(Fig. 1) FCC ID: MCLJ20H085 FCC LABEL LOCATION The FCC ID will be printed on J20H085 PCB board.

(Fig. 1) FCC ID: MCLJ20H085 FCC LABEL LOCATION The FCC ID will be printed on J20H085 PCB board.(Back)

Report No.: 140923E06 2 of 9

Report No.: SA140923E06 1 of 9 Report Format Version 5.0.1 RF EXPOSURE REPORT REPORT NO.: SA140923E06 MODEL NO.: J20H085 FCC ID: MCLJ20H085 RECEIVED:Sep. 23, 2014 TESTED:Sep. 30 to Oct. 01, 2014 ISSUED:Nov. 11, 2014 APPLICANT: Hon Hai PRECISION IND.CO.,LTD ADDRESS: 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA140923E06 2 of 9 Report Format Version 5.0.1 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT ............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN ...................................................................................................... 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER .......................... 7 Report No.: SA140923E06 3 of 9 Report Format Version 5.0.1 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA140923E06 Original release Nov. 11, 2014 Report No.: SA140923E06 5 of 9 Report Format Version 5.0.1 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA140923E06 6 of 9 Report Format Version 5.0.1 5. ANTENNA GAIN The antennas provided to the EUT, please refer to the following table: Set 1 Transmitter Circuit Brand Model Gain (dBi) (Include cable loss) Cable Loss (dB) Antenna Type Connecter Type Cable Length (mm) Frequency range (MHz to MHz) Chain (0) NA NA -0.4 NA PCBNA NA 2400~2483.5 1.12 5150~5850 Chain (1) NA NA 0.28 NA PCBNA NA 2400~2483.5 0.9 5150~5850 Set 2 Transmitter Circuit Brand Model Gain (dBi) (Include cable loss) Cable Loss (dB) Antenna Type Connecter Type Cable Length (mm) Frequency range (MHz to MHz) Chain (0) WIESON Z-Y121JT008A-013-S 2.26 0.5 DipoleIPEX 100 2400~2483.5 3.22 1 5150~5850 Chain (1) WIESON Z-Y121JT008A-013-S 2.26 0.5 DipoleIPEX 100 2400~2483.5 3.22 1 5150~5850 Set 3 Transmitter Circuit Brand Model Gain (dBi) (Include cable loss) Cable Loss (dB) Antenna Type Connecter Type Cable Length (mm) Frequency range (MHz to MHz) Chain (0) FOXCONN FX01K03-SN-EF 1.2 0.87 Dipole IPEX MHF217 2400~2483.5 1.2 NA 5150~5850 Chain (1) FOXCONN FX01K03-SN-EF 1.2 0.87 Dipole IPEX MHF217 2400~2483.5 1.2 NA 5150~5850 Set 4 Transmitter Circuit Brand Model Gain (dBi) (Include cable loss) Cable Loss (dB) Antenna Type Connecter Type Cable Length (mm) Frequency range (MHz to MHz) Chain (0) WIESON Y121JT008A-016-S 1.78 1 DipoleIPEX 200 2400~2483.5 2.78 1.5 5150~5850 Chain (1) WIESON Y121JT008A-016-S 1.78 1 DipoleIPEX 200 2400~2483.5 2.78 1.5 5150~5850 For above antenna set, antenna set 1 & 2 were selected as representative antenna for the test and its data was recorded in this report. Report No.: SA140923E06 7 of 9 Report Format Version 5.0.1 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For WLAN: 15.247(2.4GHz) 802.11b FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 151.356 2.26 20 0.05067 1.00 802.11g FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW…
