MCLJ27H002Bluetooth Module

Foxconn Bluetooth Module User Manual -1- Foxconn Bluetooth Module User Manual Revision 1.00 09/25/2006 Foxconn Bluetooth Module User Manual -2- Revision History Revision Date Name Description 1.00 09/25/2006 Zhi-cheng Yu First Release Foxconn Bluetooth Module User Manual -3- 1. Overview....................................................................................................................... 4 1.1 Setup PC.................................................................................................................. 4 1.2 Writing firmware ....................................................................................................... 4 2. Install the Applications .................................................................................................. 4 2.1 Applications.............................................................................................................. 4 2.2 Installation................................................................................................................4 3. Plug-in Bluetooth Module ............................................................................................. 4 3.1 Plug-in...................................................................................................................... 5 3.2 Install USB driver ..................................................................................................... 5 3.3 Starting Bluetool....................................................................................................... 5 3.4 Open USB Interface................................................................................................. 6 3.5 Log window .............................................................................................................. 6 3.6 HCI command transport to Bluetooth module .......................................................... 7 4. Write Nintendo firmware ............................................................................................... 8 4.1. Prepare to write....................................................................................................... 8 4.2. Set download components. .................................................................................. 8 5. Set nintendo module................................................................................................... 10 5.1 Remove USB D+ pull-up........................................................................................ 10 5.2 GPIO Default Status............................................................................................... 10 5.3 Install Nintendo USB driver .................................................................................... 11 Foxconn Bluetooth Module User Manual -4- 1. Overview 1.1 Setup PC Bluetooth module development is necessary to setup your PC. Broadcom Bluetool and Active Peal must be installed your PC. Two USB Drivers must be Installed your PC. This documentation is the support guide for starting your development. 1.2 Writing firmware Bluetooth module must be written the firmware. This documentation is the support guide for writing the firmware. 2. Install the Applications 2.1 Applications ActivePerl 5.8.4.810 only Bluetool 0.9.4.3 (or higher revision) 2.2 Installation First, install ActivePerl at your PC. Select default state. Second, install Bluetool. Select default state. Notice: If first install Bluetool, uninstall Bluetool. Try again. 3. Plug-in Bluetooth Module Foxconn Bluetooth Module User Manual -5- 3.1 Plug-in Plug-in your Bluetooth module. Confirm USB D+ to be pull up. Host PC will detect USB device. 3.2 Install USB driver Install USB driver Nintendo tendered. This USB driver revision is 5.1.0.200. Confirm Bluetooth device at device manager. 3.3 Starting Bluetool From the start menu, select Broadcom Bluetool and then the Bluetool icon. Bluetool displays an empty window the first time that is run. Foxconn Bluetooth Module User Manual -6- 3.4 Open USB Interface From the transport menu, select HCI control Check USB, and select pull-down menu usb0, click OK. 3.5 Log window From the View menu, select Log window. Foxconn Bluetooth Module User Manual -7- 3.6 HCI command transport to Bluetooth module From HCI Control window, click Reset. Foxconn Bluetooth Module User Manual -8- 4. Write Nintendo firmware 4.1. Prepare to write Before writing firmware, from pull-down menu on HCI control window, select 0:Vender-specific Commands. Click “Download Minidriver”. 4.2. Set download components. From the transport menu, select Download and Firmware/Config..... Check USB, and select pull-down menu usb0, click OK. Foxconn Bluetooth Module User Manual -9- From Download menu, click Import. Import Nintendo.btp file. This import file is EEPROM setting files for Nintendo firmware. Confirm device configuration is selected “Nintendo B3 ROM + eeprom 32 byte pages” Set Download minidriver. Select usb.hex file. It is default so, not to change. Set Download configuration record. Select BCM2045B3_002.003.014.0167.0000.cgr file. Set BD_ADDR. BD_ADDR is same as MAC address. Foxconn Bluetooth Module User Manual -10- Click Execute. So Writing firmware will start. 5. Set nintendo module 5.1 Remove USB D+ pull-up USB pull-up must be removed because nintendo module (writing nintendo firmware module) has internal USB pull-up resistor. If not remove, Host PC recognize wrong device. 5.2 GPIO Default Status GPIO must be set as follows table. Foxconn Bluetooth Module User Manual -11- 5.3 Install Nintendo USB driver Nintendo USB driver must be installed. USD Vender ID and product ID of nintendo module is not same as it of Pre-write module. Nintendo USB driver revision is 5.1.0.200(Nintendo). Confirm Bluetooth device at device manager. This device is intended only for OEM integrators under the following conditions: The antenna must be installed such that 20 cm is maintained between the antenna and users. As long as condit…

Text truncated - open the document above for the full version.

Ûâá³ÛÔܳãåØÖÜæÜâá³Üá×Á³ÖâÁ¿³ßç×Á Date:10/17/2006 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Testing Division of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS Testing Division as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, ________________________________ Ýô
³ßü
Öÿüô
öø³Ø
úü
øø Ûâá³ÛÔܳãåØÖÜæÜâá³Üá×Á³ÖâÁ¿³ßç×Á

Ûâá³ÛÔܳãåØÖÜæÜâá³Üá×Á³ÖâÁ¿³ßç×Á  0RGXODU$SSURYDO5HTXHVW/HWWHU 2FWREHU &RPSOLDQFH&HUWLILFDWLRQ6HUYLFHV )0RQWHUH\5G 0RUJDQ+LOO&$86$ 7R:KRP,W0D\&RQFHUQ 3OHDVHEHDGYLVHGWKDW Bluetooth Module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́&RQWDLQV)&&,'MCLJ27H002μLQWKHH QGSURGXFW  7KHPRGXODUWUDQVPLWWHUPXVWFRPSO\ZLWKDQ\VSHFLILFUXOHRURSHUDWLQJUHTXLUHPHQWV DSSOLFDEOHWRWKHWUDQVPLWWHUDQGWKHPDQXIDFWXUHUPXVWSURYLGHDGHTXDWHLQVWUXFWLRQV DORQJZLWKWKHPRGXOHWRH[SODLQDQ\VXFKUHTXLUHPHQWV 5HSO\7KH(87LVFRPSOLDQWZLWKDOODSSOLFDEOH)&&UXOHV'HWDLOL QVWUXFWLRQVIRUPDLQWDLQLQJ FRPSOLDQFHDUHJLYHQLQWKH8VHUV0DQXDO  BBBBBBBBBBBBBBBBBBBBBBBB Ýô
³ßü
³ Öÿüô
öø³Ø
úü
øø³ Ûâá³ÛÔܳãåØÖÜæÜâá³Üá×Á³ÖâÁ¿³ßç×Á 8. The modular transmitter must comply with any applicable RF exposure requirements: Reply: RF Exposure is addressed in the RF exposure exhibition. Should you have any question, please don’t hesitate to ask us. Best regards, ________________________

Bluetooth Declaration Per FCC 15.247 Requirements 1 Output power and channel separation of a Bluetooth device in the different operating modes: The different operating modes (data-mode, acquisition-mode) of a Bluetooth device don’t influence the output power and the channel spacing. There is only one transmitter which is driven by identical input parameters concerning these two parameters. Only a different hopping sequence will be used. For this reason the check of these RF parameters in one op-mode is sufficient. 2 Frequency range of a Bluetooth device: Hereby we declare that the maximum frequency of this device is: 2402 – 2480 MHz. This is according the Bluetooth Core Specification V 1.0B (+ critical errata) for devices which will be operated in the USA. This was checked during the Bluetooth Qualification tests (Test Case: TRM/CA/04-E). Other frequency ranges ( e.g. for Spain, France, Japan) which are allowed according the Core Specification are not supported by this device. 3 Co-ordination of the hopping sequence in data mode to avoid simultaneous occupancy by multiple transmitters: Bluetooth units which want to communicate with other units must be organized in a structure called piconet. This piconet consist of max. 8 Bluetooth units. One unit is the master the other seven are the slaves. The master co-ordinates frequency occupation in this piconet for all units. As the master hop sequence is derived from it’s BD address which is unique for every Bluetooth device, additional masters intending to establish new piconets will always use different hop sequences. 4 Example of a hopping sequence in data mode: Example of a 79 hopping sequence in data mode: 40, 21, 44, 23, 42, 53, 46, 55, 48, 33, 52, 35, 50, 65, 54, 67, 56, 37, 60, 39, 58, 69, 62, 71, 64, 25, 68, 27, 66, 57, 70, 59, 72, 29, 76, 31, 74, 61, 78, 63, 01, 41, 05, 43, 03, 73, 07, 75, 09, 45, 13, 47, 11, 77, 15, 00, 64, 49, 66, 53, 68, 02, 70, 06, 01, 51, 03, 55, 05, 04 5 Equally average use of frequencies in data mode and behaviour for short transmissions: The generation of the hopping sequence in connection mode depends essentially on two input values: 1. LAP/UAP of the master of the connection 2. Internal master clock The LAP (lower address part) are the 24 LSB’s of the 48 BD_ADDRESS. The BD_ADDRESS is an unambiguous number of every Bluetooth unit. The UAP (upper address part) are the 24 MSB’s of the 48 BD_ADDRESS. The internal clock of a Bluetooth unit is derived from a free running clock which is never adjusted and is never turned off. For synchronisation with other units only offset are used. It has no relation to the time of the day. Its resolution is at least half the RX/TX slot length of 312.5 μs. The clock has a cycle of about one day (23h30). In most case it is implemented as 28 bit counter. For the deriving of the hopping sequence the entire LAP (24 bits), 4 LSB’s (4 bits) (Input 1) and the 27 MSB’s of the clock (Input 2) are used. With this input values different mathematical procedures (permutations, additions, XOR-operations) are performed to generate the sequence. This will be done at the beginning of every new transmission. Regarding short transmissions the Bluetooth system has the following behaviors: The first connection between the two devices is established, a hopping sequence was generated. For transmitting the wanted data the complete hopping sequence was not used. The connection ended. The second connection will be established. A new hopping sequence is generated. Due to the fact that the Bluetooth clock has a different value, because the period between the two transmission is longer (and it cannot be shorter) than the minimum resolution of the clock (312.5 μs). The hopping sequence will always differ from the first one. 6 Receiver input bandwidth and behaviors for repeated single or multiple packets: The input bandwidth of the receiver is 1 MHz. In every connection one Bluetooth device is the master and the other one is the slave. The master determines the hopping sequence (see chapter 5). The slave follows this sequence. Both devices shift between RX and TX time slot according to the clock of the master. Additionally the type of connection (e.g. single or multislot packet) is set up at the beginning of the connection. The master adapts its hopping frequency and its TX/RX timing according to the packet type of the connection. Also the slave of the connection will use these settings. Repeating of a packet has no influence on the hopping sequence. The hopping sequence generated by the master of the connection will be followed in any case. That means, a repeated packet will not be send on the same frequency, it is send on the next frequency of the hopping sequence. 7 Dwell time in data mode The dwell time of 0.3797s within a 30 second period in data mode is independent from the packet type (packet length). The calculation for a 30 second period is a follows: Dwell time = time slot length * hop rate / number of hopping channels *30s Example for a DH1 packet (with a maximum length of one time slot) Dwell time = 625 μs * 1600 1/s / 79 * 30s = 0.3797s (in a 30s period) For multislot packet the hopping is reduced according to the length of the packet. Example for a DH5 packet (with a maximum length of five time slots) Dwell time = 5 * 625 μs * 1600 * 1/5 *1/s / 79 * 30s = 0.3797s (in a 30s period) This is according the Bluetooth Core Specification V 1.0B (+ critical errata) for all Bluetooth devices. There for all Bluetooth devices comply with the FCC dwell time requirement in data mode. This was checked during the Bluetooth Qualification tests. The Dwell time in hybrid mode is measured and stated in the test report. 8 Channel Separation in hybrid mode The nominal channel spacing of the Bluetooth system is 1Mhz independent of the operating mode. The maximum “initial carrier frequency tolerance” which is allowed for Bluetooth is fcenter = 75 kHz. This was checked during the Bluetooth Qualification tests (Test Case:…

Text truncated - open the document above for the full version.

Ûâá³ÛÔܳãåØÖÜæÜâá³Üá×Á³ÖâÁ¿³ßç×Á Date:10/17/2006 Federal Communications Commission Authorization and Evaluation Division FCC ID: MCLJ27H002 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ________________________________ Ýô
³ßü
³ Ö  ÿüô
öø³Ø
úü
øø  ³ Ûâá³ÛÔܳãåØÖÜæÜâá³Üá×Á³ÖâÁ¿³ßç×Á

Compliance Certification Services Inc. Report No.: 61003002 Date of Issue: October 26, 2006 Page 1 Total Page: 2 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT

Contains RF module FCC ID: MCLJ27H002

Compliance Certification Services Inc. Report No.: 61003002 Date of Issue: October 26, 2006 Page 2 Rev.00 INTERNAL PHOTOGRAPHS OF EUT

BlueTooth Antenna Test Report Choro.Chung 2006/09/19 Frequency(MHz) Horizontal (dBi) Vertical (dBi) Max. 1.06 -5.9 Avg. -3.72 -11.12 Max. 2.05 -5.88 Avg. -3.31 -11.02 Max. 1.33 -5.47 Avg. -4.23 -11.00 240224412480 Test Setup I (DUT lie down) Summary Frequency(MHz) Horizontal (dBi) Vertical (dBi) Max. -2.42 1.29 Avg. -7.67 -3.16 Max. -4.00 2.22Avg. -8.22 -2.42 Max. -3.95 1.55 Avg. -8.66 -3.00 240224412480 Test Setup II (DUT stand up) P.S. The loss of W.FL RF cable not included, and estimated -0.5dB loss. Chamber Setup Test Setup I (DUT lie down) Turn Table 0 degree 90 degree 180 degree 270 degree Test Setup II (DUT stand up) Turn Table 0 degree 90 degree 180 degree 270 degree Test Setup I --- Horizontal @2402MHz 0 Degree Test Setup I --- Horizontal @2441MHz 0 Degree Test Setup I --- Horizontal @2480MHz 0 Degree Test Setup I --- Vertical @2402MHz 0 Degree Test Setup I --- Vertical @2441MHz 0 Degree Test Setup I --- Vertical @2480MHz 0 Degree Test Setup II --- Vertical @2402MHz 0 Degree Test Setup II --- Vertical @2441MHz 0 Degree Test Setup II --- Vertical @2480MHz 0 Degree Test Setup II --- Horizontal @2402MHz 0 Degree Test Setup II --- Horizontal @2441MHz 0 Degree Test Setup II --- Horizontal @2480MHz 0 Degree

Compliance Certification Services Inc. Report No.: 61003002-RP1 FCC ID: MCLJ27H002 Date of Issue: October 25, 2006 Page 40 Rev. 00 APPENDIX I RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUT Bluetooth Module Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5.825GHz Others: Bluetooth: 2.402GHz ~ 2.480GHz Device category Portable (<20cm separation) Mobile (>20cm separation) Others __________________________ Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 4.010dBm (2.518mW) Antenna gain (Max) 2.22 dBi (Numeric gain: 1.667) Evaluation applied MPE Evaluation* SAR Evaluation N/A Remark: 1. The maximum output power is 4.010dBm (2.518mW) at 2480MHz (with 1.667 numeric antenna gain.) 2. DTS device is not subject to routine RF evaluation; MPE estimate is used to justify the compliance. 3. For mobile or fixed location transmitters, no SAR consideration applied. The maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger. TEST RESULTS No non-compliance noted. Compliance Certification Services Inc. Report No.: 61003002-RP1 FCC ID: MCLJ27H002 Date of Issue: October 25, 2006 Page 41 Rev. 00 Calculation Given d GP E ×× = 30 & 3770 2 E S= Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 3770 30 d GP S ×× = Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields () () 2 2 0796.0 100/3770 1000/30 d GP d GP S × ×= × ×× = Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Maximum Permissible Exposure EUT output power = 2.518mW Numeric Antenna gain = 1.667 Substituting the MPE safe distance using d = 20 cm into Equation 1: Yields GPS××=000199.0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Æ Power density = 0.00084 mW / cm 2 (For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.)

Compliance Certification Services Inc. Report No.: 61003002-RP1 FCC ID: MCLJ27H002 Date of Issue: October 25, 2006 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 43 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Bluetooth Module Model: J27H002 Tr a d e Na me : H o n Ha i Issued to HON HAI Precision Ind. Co., Ltd. 5F-1, 5 Hsin-An Road, HsinChu Science-Based Industrial Park, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. http://www.ccsemc.com.tw [email protected] Compliance Certification Services Inc. Report No.: 61003002-RP1 FCC ID: MCLJ27H002 Date of Issue: October 25, 2006 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION.................................................................................................3 2. EUT DESCRIPTION ........................................................................................................................4 3. TEST METHODOLOGY .................................................................................................................5 3.1 EUT CONFIGURATION.....................................................................................................................5 3.2 EUT EXERCISE.................................................................................................................................5 3.3 GENERAL TEST PROCEDURES..........................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.....................................................6 3.5 DESCRIPTION OF TEST MODES........................................................................................................7 4. INSTRUMENT CALIBRATION.....................................................................................................8 4.1 MEASURING INSTRUMENT CALIBRATION...................................................................................8 4.2 MEASUREMENT EQUIPMENT USED......................................................................................8 5. FACILITIES AND ACCREDITATIONS .......................................................................................9 5.1 FACILITIES 9 5.2 EQUIPMENT.....................................................................................................................................9 5.3 TABLE OF ACCREDITATIONS AND LISTINGS..................................................................................10 6. SETUP OF EQUIPMENT UNDER TEST ....................................................................................11 6.1 SETUP CONFIGURATION OF EUT....................................................................................................11 6.2 SUPPORT EQUIPMENT ............................................................................................................11 7. FCC PART 15.247 REQUIREMENTS..........................................................................................12 7.1 PEAK POWER.................................................................................................................................12 7.2 BAND EDGES MEASUREMENT .............................................................................................13 7.3 PEAK POWER SPECTRAL DENSITY.................................................................................................18 7.4 FREQUENCY SEPARATION....................................................................................................21 7.5 NUMBER OF HOPPING FREQUENCY ...................................................................................23 7.6 TIME OF OCCUPANCY (DWELL TIME)................................................................................25 7.7 SPURIOUS EMISSIONS .............................................................................................................27 7.8 POWERLINE CONDUCTED EMISSIONS............................................................................................37 APPENDIX I RADIO FREQUENCY EXPOSURE ............................................................................40 APPENDIX I PHOTOGRAPHS OF TEST SETUP............................................................................41 Compliance Certification Services Inc. Report No.: 61003002-RP1 FCC ID: MCLJ27H002 Date of Issue: October 25, 2006 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: HON HAI Precision Ind. Co., Ltd. 5F-1, 5 Hsin-An Road, HsinChu Science-Based Industrial Park, Taiwan, R.O.C. Equipment Under Test: Bluetooth Module Trade Name: Hon Hai Model: J27H002 Date of Test: October 14 ~ 19, 2006 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Gavin Lim Amanda Wu Section Manager Section Manager Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No.: 61003002-RP1 FCC ID: MCLJ27H002 Date of Issue: October 25, 2006 Page 4 Rev. 00 2. EUT DESCRIPTION Product Bluetooth Module Trade Name Hon Hai Model Number J27H002 Model Discrepancy N/A Power Supply P…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 61003002-RP1 FCC ID: MCLJ27H002 Date of Issue: October 25, 2006 Page 41 Rev. 00 APPENDIX II PHOTOGRAPHS OF TEST SETUP Conducted Emission Setup Photo Compliance Certification Services Inc. Report No.: 61003002-RP1 FCC ID: MCLJ27H002 Date of Issue: October 25, 2006 Page 42 Rev. 00 Radiated Emission Setup Photos Compliance Certification Services Inc. Report No.: 61003002-RP1 FCC ID: MCLJ27H002 Date of Issue: October 25, 2006 Page 43 Rev. 00 Powerline Conducted Emissions Setup Photos
