MCLT60093AMBIT PCI Full Rate ADSL Modem

PCI Full Rate ADSL Modem Driver Installation A2RAI-081699 Date Printed: 12/20/99 Page 1 Man_A2.DOC1 Ambit PCI Full Rate ADSL Modem Installation Manual For Windows  95, 98, and NT4.0 Dec 16, 1999 PCI Full Rate ADSL Modem Driver Installation A2RAI-081699 Date Printed: 12/20/99 Page 2 Man_A2.DOC2 Table of Contents ABOUT THIS GUIDE 1.INTRODUCTION......................................................................................................................................................3 SYSTEM REQUIREMENT..............................................................................................................................................4 Hardware Requirement..........................................................................................................................................4 Software Requirement...........................................................................................................................................4 2.INSTALLING THE AMBIT PCI FULL RATE ADSL MODEM BOARD...............................................6 3.INSTALLING THE AMBIT PCI DEVICE DRIVERS AND UTILITY....................................................7 3.1 WINDOWS 98.........................................................................................................................................................7 3.2 WINDOWS 95........................................................................................................................................................11 3.3 WINDOWS NT4.0 WITH SERVICE PACK 3.......................................................................................................12 3.4 INSTALLING THE AMBIT PCI MODEM ICON UTILITY...................................................................12 4.VERIFYING THE DRIVER INSTALLATION..............................................................................................13 4.1 WINDOWS 95 AND WINDOWS 98......................................................................................................................13 4.2 WINDOWS NT 4.0................................................................................................................................................14 5.CONFIGURING THE ADSL NETWORK FOR ETHERNET OVER ATM (RFC1483)...................14 6.ACTIVATING THE AMBIT PCI ADSL MODEM........................................................................................20 7.MONITORING THE AMBIT PCI ADSL MODEM......................................................................................20 8.UNINSTALLING THE AMBIT PCI ADSL MODEM AND TEST APPLICATION..........................20 PCI Full Rate ADSL Modem Driver Installation A2RAI-081699 Date Printed: 12/20/99 Page 3 Man_A2.DOC3 1. INTRODUCTION The Ambit PCI Full Rate ADSL Modem is an internal ADSL modem, which conveniently plugs into a PC system, eliminating the need for an external modem. The Ambit PCI ADSL Modem connects to a telephone line via a standard RJ-11 connector and fully complies with practices governing the PC world (e.g. Plug 'n Play). The Ambit PCI ADSL Modem supports DMT (Discrete Multi-Tone) modulation to ensure interoperability with the service providers DSL systems. Feature Remote bridging with RFC 1483 encapsulation, both LLC-SNAP and PVC multiplexing options WAN Protocols Supported under Microsoft Operation Systems The following is a list of supported WAN protocols by Ambit PCI ADSL Network Modem. Microsoft Windows Operating Systems RFC 1483 Win95 -- OSR1 and OSR2Yes Win98 – 1 st editionYes Win98 – 2 nd editionYes NT 4.0 – Service Pack 3Yes PCI Full Rate ADSL Modem Driver Installation A2RAI-081699 Date Printed: 12/20/99 Page 4 Man_A2.DOC4 System Requirement The following equipment and information is required (at a minimum) to setup your ADSL network modem. Hardware Requirement The following is the minimum hardware requirement. Please make sure your PC system meets ALL of the following requirements. ̧ IBM PC/AT or its compatibles ̧ CPU speed: Pentium  100Mhz or above ̧ Hard disk space: 6Mbyte space available or above ̧ CD-ROM: 24x CD-ROM drive or above ̧ Main memory: 32Mbyte or above Software Requirement The Ambit PCI ADSL Modem supports most of Microsoft Windows operating systems. Please make sure you have one of the following operating systems in your PC. ♦ Microsoft Windows 95 – OSR1 and OSR2, or ♦ Microsoft Windows 98 – 1 st edition and 2 nd edition, or ♦ Microsoft NT – NT 4.0 service pack 3. NOTE: You need the Windows operating system installation files (CAB files) to complete the installation. PCI Full Rate ADSL Modem Driver Installation A2RAI-081699 Date Printed: 12/20/99 Page 5 Man_A2.DOC5 Before you start: Insert Ambit ADSL card Connect the card to ADSL network Installing driver and application programs Reboot and verify last step Configure ADSL network Monitoring the Ambit ADSL modem Reboot and activating Ambit ADSL modem Ambit ADSL Modem Installation & Configuration Flow Chart PCI Full Rate ADSL Modem Driver Installation A2RAI-081699 Date Printed: 12/20/99 Page 6 Man_A2.DOC6 2. INSTALLING THE ADSL NETWORK MODEM BOARD To install the Ambit PCI Full Rate ADSL Modem in your PC and connect it to ADSL network, follow these steps: Insert ADSL Network Interface Card – Step 1 1) Open the shipping container and inspect each item for damage. 2) Remove all jewelry from your hands and wrists. Use only insulated or nonconductive tools. 3) Unplug the PC and disconnect all cables. 4) Remove the PC cover. 5) Choose an empty bus mastering PCI slot. 6) Unscrew the screw holding the PCI slot’s backplate and remove it. 7) Insert the Ambit PCI ADSL Modem into an empty PCI slot. 8) Secure the NIC with the screw you removed earlier. 9) Replace the PC cover and reconnect all previously connected cables. 10) Turn on the power to the PC. 11) Proceed to the next section, “Connecting to the ADSL Network.” Connect NIC to ADSL Network – Step 2 Connect the telephone cable to the RJ-11 port on the Ambit P…

Text truncated - open the document above for the full version.

RJ11 line in Hybrid CKT Transmit & Receive I80134 Analog Front End I90135 DMT Modem & ATM Framer PCI Interface I90188 PCI To UTOPIA Interface Ambit PCI Full Rate ADSL Modem T60M093.00 BLOCK DIAGRAM Memory Power Management

AMBIT Microsystems Corporation Headquarters: 5F-1, 5 Hsin-An Road, Hsinchu Taipei Branch: 11F,100-1 Min-Chuan Road, Science-Based Industria Park Taiwan, R.O.C. Hsin-Tien, Taiwan, R.O.C. TEL: +886 3 5784975 TEL:+886-2-218 9800 MESSERS: Max Light Technology Co.,LtdDATE: 12/15/1999 POWER OF ATTORNEY SUBJECT: FCC APPLICATION We, the undersigned, hereby authorize Max Light Technology Co.,Ltd. To act on our behalf in all matters relating to application for equipment authorization of our model: T60M093.00 including the signing of all documents relating to these matters. Any and all acts carried out by Max Light Technology Co.,Ltd. On our behalf shall have the same effect as acts of our own. Applicant: AMBIT Microsystems Corporation. By: Roger Wu Signature Printed Title: Manager(Communication B. D. R&D)

MAX LIGHT Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab MAX LIGHT Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab MAX LIGHT Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab

MAX LIGHT Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab Label Format: Label Position: This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,and (2) This device must accept any interference received ,including. Interference that may cause undesired operation. Model: T60M093.00 FCC ID: MCLT60093 MADE IN TAIWAN Equipment Lable 2.5CMX3.5CM Rear View

123456 A B C D 654321 D C B A Title Doc.No. Data: File: REV Rev.Note View Page of 24-Dec-1999 H:\PUBLIC\ §£≠n± ̨ \ADSL\ADSL_A2.SCH Time 17:32:27 Schematic AMBIT Prepared Checked Approved 24-Dec-1999 Bobby U01.033.C.00 GPIO0 TXADDR0 TXADDR1 TXD0 TXD1 TXD2 TXD3 TXD4 TXD5 TXD6 TXD7 TXENB RXENB TXSOC TXCLAV TXCLK RXD7 RXD6 RXD5 RXD4 RXD3 RXD2 RXD1 RXD0 RXCLAV RXSOC RXCLK RXADDR1 RXADDR0 SRESET_ SAD0 SAD1 SAD2 SAD3 SAD4 SAD5 SAD6 SAD7 SAD8 SAD9 SAD10 SAD11 SAD12 SAD13 SAD14 SAD15 BE1 ALE WR_ CS_ READY_ INT_ RESET_0# RINCDET P1B/AD31 P1A/AD0 P1B/AD1 P1A/AD2 P1A/AD4 P1A/AD6 P1A/AD8 P1A/AD10 P1A/AD12 P1A/AD14 P1A/AD16 P1A/AD18 P1A/AD20 P1A/AD22 P1A/AD24 P1A/AD26 P1A/AD28 P1A/AD30 P1B/AD3 P1B/AD5 P1B/AD7 P1B/AD9 P1B/AD11 P1B/AD13 P1B/AD15 P1B/AD17 P1B/AD19 P1B/AD21 P1B/AD23 P1B/AD25 P1B/AD27 P1B/AD29 P1B/C/BE3# P1B/C/BE2# P1B/C/BE1# P1A/C/BE0# P1A/PAR P1A/FRAME# P1B/IRDY# P1A/TRDY# P1B/DEVSEL# P1A/STOP# P1A/IDSEL P1B/REQ# P1A/GNT# P1B/PERR# P1B/SERR# P1A/INTA# P1A/RST# P1B/PCICLK P1A/PME# UT_BRIDG UT_BRIDG.SCH CLKM CLWD RX0 RX1 RX2 RX3 TXD0 TXD1 TXD2 TXD3 TXD4 TXD5 TXD6 TXD7 TXADDR0 TXADDR1 TXCLK TXSOC TXENB RXADDR0 RXADDR1 RXCLK RXENB SAD0 SAD1 SAD2 SAD3 SAD4 SAD5 SAD6 SAD7 SAD8 SAD9 SAD10 SAD11 SAD12 SAD13 SAD14 SAD15 WR_ CS_ ALE BE1 SRESET_ CTRLIN PDOWN TXE0 TXE1 TXE2 TXE3 TX0 TX1 TX2 TX3 TXCLAV RXSOC RXCLAV RXD0 RXD1 RXD2 RXD3 RXD4 RXD5 RXD6 RXD7 PCICLK READY_ INT_ DIGITAL DIGITAL.SCH INTA_ GNT_ RST_ REQ_ PME_ AD30 AD28 AD26 AD24 IDSEL AD22 AD20 AD18 AD16 FRAME_ IRDY_ TRDY_ DEVSEL_ STOP_ PAR AD15 AD13 AD11 AD9 C/BE0_ AD6 AD4 AD2 AD0 PCICLK AD31 AD29 AD27 AD25 C/BE3_ AD23 AD21 AD19 C/BE2_ PERR_ SERR_ C/BE1_ AD14 AD12 AD10 AD8 AD7 AD5 AD3 AD1 PCI_CON PCI_CON.SCH J14/3 J14/2 J14/7 J14/6 J14/1 J14/4 J14/5 J14/8 TX_HYBRIDP TX_HYBRID_N HYBRID_RXP HYBRID_RXN HYBRID HYBRID.SCH HYBRID_RXN HYBRID_RXP LP_RXN LP_RXP GPIO0 RINCDET RECEIVE RECEIVE.SCH PW PW.SCH TX_HYBRIDP TX_HYBRIDN ADSLC_TXP ADSLC_TXN TRANSMIT TRANSMIT.SCH CLKM CLWD ADSLC_TXP ADSLC_TXN RX0 RX1 RX2 RX3 LP_RXP LP_RXN TX0 TX2 TX1 TX3 TXE0 TXE1 TXE2 TXE3 CTRLIN PDOWN RESET_0# CLNIB XTALI XTALO CTRL XTALI XTALO CTRL AFE AFE.SCH TSPOINT1 TSPOINT1.SCH TSPOINT2 TSPOINT2.SCH SCHEMATIC T60M093.00 22-NOV-1999 ADSL_A2.SCH Jean Yen 12:00:00 LO 111 123456 A B C D 654321 D C B A Title Doc.No. Data: File: REV Rev.Note View Page of 24-Dec-1999 H:\PUBLIC\ §£≠n± ̨ \ADSL\UT_BRIDG.SCH Time 17:32:30 Schematic AMBIT Prepared Checked Approved 24-Dec-1999 Bobby U01.033.C.00 PWRLOSS# 52 EPROM_DI 53 EPROM_CLK 54 EPROM_CS 55 EPROM_DO 56 EPROM_SEL 58 TXADDR0 59 TXADDR1 60 TXD0 61 TXD1 62 TXD2 64 TXD3 65 TXD4 66 TXD5 67 TXD6 69 TXENB# 71 RXENB# 76 TXD7 70 TXSOC 73 TXCLAV 72 TXCLK 75 RXD7 84 RXD6 85 RXD5 86 RXD4 88 RXD3 89 RXD2 90 RXD1 91 RXD0 92 RXCLAV 77 RXSOC 78 RXCLK 79 RXADDR1 82 RXADDR0 83 SRESET# 93 SAD0 119 SAD1 118 SAD2 117 SAD3 116 SAD4 115 SAD5 114 SAD6 113 SAD7 111 SAD8 110 SAD9 109 SAD10 108 SAD11 107 SAD12 106 SAD13 104 SAD14 103 SAD15 102 BE1 101 ALE 100 WR/RD# 98 CS# 99 READY# 97 INT# 96 ARESET# 95 XOUT 132 XIN 134 TMODE0 49 PME# 48 V35_AC97 138 V35_AC97 141 ACRESET# 136 SYNC 137 SDATA_IN 139 BIT_CLK 140 SDATA_OUT 142 SCANTEST 122 SCANMODE 123 TXRXON 124 OHK 125 DSL_V90# 127 RINGDET 128 LCDET 129 PILTONE 130 GND 155 GND 143 GND 131 GND 126 GND 120 GND 112 GND 94 GND 81 GND 74 GND 63 GND 46 GND 40 GND 30 GND 20 GND 11 GND 1 V3 121 V3 105 V3 80 V3 68 V3 57 V5 51 V35_PCI 160 V35_PCI 149 V35_PCI 41 V35_PCI 35 V35_PCI 25 V35_PCI 16 V35_PCI 6 GPIO0 50 PCICLK 146 PCIRST# 145 INTA 144 SERR# 22 PERR# 21 GNT# 147 REQ# 148 IDSEL 2 STOP# 19 DEVSEL# 18 TRDY# 17 IRDY# 15 FRAME# 14 PAR 23 C/BE1# 24 C/BE0# 36 C/BE2# 13 C/BE3# 159 AD0 47 AD1 45 AD2 44 AD3 43 AD4 42 AD5 39 AD6 38 AD7 37 AD8 34 AD9 33 AD10 32 AD11 31 AD12 29 AD13 28 AD14 27 AD15 26 AD16 12 AD17 10 AD18 9 AD19 8 AD20 7 AD21 5 AD22 4 AD23 3 AD24 158 AD25 157 AD26 156 AD27 154 AD28 153 AD29 152 AD30 151 AD31 150 V5 87 V5 133 V5 135 U10 I90188-2 EPROM_CS EPROM_CLK EPROM_DI EPROM_DO 1 2 R114 R/4.75K/0603/1% D3V3 12 C172 C/100nF/16V/X7R/0603 12 C171 C/106Z/10V/Y5V/1206 D3V3 1 2 C167 C/100nF/16V/X7R/0603 1 2 C165 C/100nF/16V/X7R/0603 12 L38 L/500nH +5V 5V-PUB D3V3D3V3 1 2 C123 C/100nF/16V/X7R/0603 1 2 C130 C/100nF/16V/X7R/0603 1 2 C131 C/106Z/10V/Y5V/1206 12 L36 L/500nH D3V3 D3V3 TXADDR0 TXADDR1 TXD0 TXD1 TXD2 TXD3 TXD4 TXD5 TXD6 TXD7 TXENB RXENB TXSOC TXCLAV TXCLK RXD7 RXD6 RXD5 RXD4 RXD3 RXD2 RXD1 RXD0 RXCLAV RXSOC RXCLK RXADDR1 RXADDR0 SRESET_ SAD0 SAD1 SAD2 SAD3 SAD4 SAD5 SAD6 SAD7 SAD8 SAD9 SAD10 SAD11 SAD12 SAD13 SAD14 SAD15 BE1 ALE WR_ CS_ READY_ INT_ RESET_0# 12 R5 R/1M/0603/1% 1 2 C144 C/27PF/50V/NPO/0603 1 2 C142 C/27PF/50V/NPO/0603 1 2 R8 R/49.9/0603/1% 12 R6 R/49.9/0603/1% 12 R63 R/49.9/0603/1% 1 2 R14 R/49.9/0603/1% 1 2 R17 R/49.9/0603/1% 12 Y3 CRYSTAL/25MHZ AD31 AD0 AD1 AD2 AD4 AD6 AD8 AD10 AD12 AD14 AD16 AD18 AD20 AD22 AD24 AD26 AD28 AD30 AD3 AD5 AD7 AD9 AD11 AD13 AD15 AD17 AD19 AD21 AD23 AD25 AD27 AD29 C/BE3_ C/BE2_ C/BE1_ C/BE0_ PAR FRAME_ IRDY_ TRDY_ DEVSEL_ STOP_ IDSEL REQ_ GNT_ PERR_ SERR_ INTA_ RST_ PCICLK EPROM_SEL XOUT XINACRESET# BIT_CLK SCANTESTSCANNODE PWELOSS# TXMODE0 IDSEL AD31 AD0 AD1 AD2 AD3 AD4 AD5 AD6 AD7 AD8 AD9 AD10 AD11 AD12 AD13 AD14 AD15 AD16 AD17 AD18 AD19 AD20 AD21 AD22 AD23 AD24 AD25 AD26 AD27 AD28 AD29 AD30 C/BE0_ C/BE1_ C/BE2_ C/BE3_ PAR FRAME_ IRDY_ TRDY_ DEVSEL_ STOP_ REQ_ GNT_ PERR_ SERR_ INTA_ RST_ PCICLKRESET_0# PCI TO UTOPIA BRIDGE A3V3 A3V3 D3V3 DGND +5V 5V-PUB 1 2 CUB1 C/100nF/16V/X7R/0603 1 2 CUB2 C/100nF/16V/X7R/0603 1 2 CUB3 C/100nF/16V/X7R/0603 1 2 CUB4 C/100nF/16V/X7R/0603 1 2 CUB5 C/100nF/16V/X7R/0603 1 2 CUB6 C/100nF/16V/X7R/0603 1 2 CUB7 C/100nF/16V/X7R/0603 1 2 CUB8 C/100nF/16V/X7R/0603 1 2 CUB9 C/100nF/16V/X7R/0603 1 2 CUB10 C/100nF/16V/X7R/0603 1 2 CUB11 C/100nF/16V/X7R/0603 1 2 CUB12 C/100nF/16V/X7R/0603 D3V3 5V-PUB BYPASS CAPCITORS FOR D3V3 (6,160),(16,25),(35,41),(57,68) (80),(105),(121),(149) BYPASS CAPACITORS FOR 5V-PUB (51),(87),(133),(135) 1 2 RE1 R/1k/0603/1% 1Y 4 2Y 7 3Y 9 4Y 12 VCC 16 GND 8 4A 14 G 15 3B 10 3A 11 2B 6 2A 5 1B 3 1A 2 A/B 1 4B …

Text truncated - open the document above for the full version.

Product : AMBIT PCI Full Rate ADSL Modem Manufacture : Ambit Microsystems Corporation. FCC ID : MCLT60093 Model : T60M093.00 Report No. : MLT9912P15001 Test Date : December 18.1999 Test By Max Light Technology Co.,Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 T T h h e e t t e e s s t t r r e e p p o o r r t t c c o o n n s s i i s s t t s s o o f f 2 2 1 1 p p a a g g e e s s i i n n t t o o t t a a l l . . I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . MAX LIGHT MEASUREMENT REPORT Page: 2/21 Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab Table of Contents : I. General 4. II. Conducted Emissions Requirements 9. III. Radiated Emissions Requirements 14. Appendix I (EUT Test Setup) 20. MAX LIGHT MEASUREMENT REPORT Page: 3/21 Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-1992. All test were conducted by MLT(Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with Class B radiated and conducted emission limit of FCC Rules Part 15 Subpart B. EUT: AMBIT PCI Full Rate ADSL Modem Applicant: Ambit Microsystems Corporation. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Manufacturer: Ambit Microsystems Corporation. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Model No: T60M093.00 FCC ID: MCLT60093 Prepared by :Approved by : Country Huang Roger Chen MAX LIGHT MEASUREMENT REPORT Page: 4/21 Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Ambit Microsystems Corporation. In support of a Class B Digital Device certification in accordance with Part2 Subpart J and Part 15 Subpart A And B of the Commission’s and Regulations. 1.2 Description of EUT EUT: AMBIT PCI Full Rate ADSL Modem Applicant: Ambit Microsystems Corporation. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Manufacturer: Ambit Microsystems Corporation. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Model No: T60M093.00 FCC ID : MCLT60093 Power Type: Powered by PC Phone Cable: RJ-11Cx1(Nonshielded, 7’ long ,Plastic hoods) During testing the EUT was operated at Tx or Rx mode for each emission measured. This was done in order to ensure that maximum emission levels were attained. MAX LIGHT MEASUREMENT REPORT Page: 5/21 Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab 1.3 Description of Support Equipment In order to construct the minimum system which required by the ANSI C63.4-1991, following equipments were used as the support units. Computer: COMPAQ Model No.: 3284 Serial No.: L708BKTB4154 FCC ID: EJH3284 Keyboard: COMPAQ Model No.: KPQ-E99ZC-13 Serial No.: 237743-334 FCC ID: CMYKPQ7285 Monitor: COMPAQ Model No.: 303U Serial No.: 704AG19TG099 FCC ID: BJMCM14UH Mouse: COMPAQ Model No.: 196694-301 Serial No.: 1SH67CHE03360 FCC ID: EMJMUSJJ Printer: PANASONIC Model No.: KX-P1080I Serial No.: 7CKAKE98933 FCC ID: ACJ5Z6KX-P10801 ADSL Simulator: Alcatel Model No.: MTB-2013-2EB Serial No.: N/A P.S The ADSL Simulator is ATU-C. ATU-C (ADSL Transceiver Unit, Central office end) MAX LIGHT MEASUREMENT REPORT Page: 6/21 Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab Modem: Askey (External Fax / Data Modem) Model No.: WS1414SV Serial No.: IAH-10811 FCC ID: H8N1414VE MAX LIGHT MEASUREMENT REPORT Page: 7/21 Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab 1.4 Configuration of System Under Test During testing the EUT(AMBIT PCI Full Rate ADSL Modem card) install in the Compaq PC. So there is no need for additional I/O card. A mouse was connected to the mouse port and a printer was connected to the parallel port. There is one serial port. A external modem connected the serial port and the external modem connected with two unterminated telephone cables on the line and phone jack. The Line Jack of EUT was connected to a simulator of ADSL. 1.5 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4-1992 "Measurement of unIntentional Radiators." Power Supply PC Monitor Printer Keyboard Mouse EUT RS-232RS-232 To ADSL Simulator Modem MAX LIGHT MEASUREMENT REPORT Page: 8/21 Report Number: MLT9912P15001 FCC ID: MCLT60093 Technology Lab 1.6 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests was chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. The system's radiated and conducted emissions were investigated while the computer alternately transferred data to the EUT as well as to the monitor and printer. Using a test program which sent a continuous stream of “H” characters to monitor and transferred data to and from the EUT was proven to wor…
