MCLT77H462802.11abgn+BT4.0 module

HON HAI Precision Ind. Co., Ltd.
802.11abgn+BT4.0 module - FCC ID MCLT77H462 - HON HAI Precision Ind. Co., Ltd.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Sep 08, 2013
Application Purpose
Original Equipment
Date of Application
Sep 08, 2013
Equipment Note
802.11abgn+BT4.0 module
Frequency Range
5745.00000000 - 5825.00000000
Company
HON HAI Precision Ind. Co., Ltd.
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗

Cover Letter(s)

↗
↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Operational Description

↗

RF Exposure Info

↗

Test Report

↗
↗
↗
↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

COMPANY CONFIDENTIAL 1 ! Prepared by Reviewed by Approved by Jason Hu Gary Su Chang-fu Lin ! TotalPagesProductRev.DateSales 3901S120130725EagleWei PartName802.11a/g/n+BT4.0Module RevisionNoteRev.3.2 FoxconnPartNo.T77H462.02 LenovoPartNo. HONHAIPRECISIONIND.CO.,LTD. 5F1,5HsinAnRoad,Hsinchu, ScienceBasedIndustrialPark 300,Taiwan Tel:+88635784975  Revision Note (Specification Sheet) COMPANY CONFIDENTIAL 2 ! Index 1. REVISION HISTORY ................................................................................................................................................... 3 2. INTRODUCTION .......................................................................................................................................................... 4 2.1 SCOPE ...................................................................................................................................................................... 4 2.2 FUNCTION ................................................................................................................................................................. 4 3. PRODUCT SPECIFICATION ..................................................................................................................................... 5 3.1 HARDWARE CHARACTERISTIC ................................................................................................................................. 5 3.2 HARDWARE ARCHITECTURE .................................................................................................................................... 5 3.3 ELECTRICAL SPECIFICATION .................................................................................................................................... 6 3.4 WLAN RF CHARACTERISTICS ................................................................................................................................. 7 3.4.1 IEEE802.11b .................................................................................................................................................. 7 3.4.2 IEEE802.11g .................................................................................................................................................. 8 3.4.4 IEEE802.11a ................................................................................................................................................ 12 3.5 BLUETOOTH RF SPECIFICATIONS .......................................................................................................................... 18 3.6 INTERFACE TIMING .................................................................................................................................................. 23 3.6.1 SDIO INTERFACE TIMING .................................................................................................................................... 23 3.6.2 UART INTERFACE TIMING ................................................................................................................................... 25 3.7 LGA PIN DEFINITION .............................................................................................................................................. 26 4. MECHANICAL DRAWING ....................................................................................................................................... 30 5. SCHEMATIC REFERENCE DESIGN ..................................................................................................................... 33 6. PCB STACK ............................................................................................................................................................... 34 7. SOFTWARE SUPPORT ............................................................................................................................................ 35 8. REGULATORY ........................................................................................................................................................... 36 9. ENVIRONMENTAL REQUIREMENTS AND SPECIFICATIONS ....................................................................... 37 9.1 TEMPERATURE ....................................................................................................................................................... 37 9.2 PCB BENDING ........................................................................................................................................................ 37 9.3 HANDLING ENVIRONMENT ....................................................................................................................................... 37 9.4 STORAGE CONDITION ............................................................................................................................................. 37 9.5 BAKING CONDITION ................................................................................................................................................ 37 9.6 SOLDERING AND REFLOW CONDITION .................................................................................................................... 38 10 PACKAGE INFORMATION ..................................................................................................................................... 39 COMPANY CONFIDENTIAL 3 ! 1. Revision History Date Change Note Rev. 2012-12-26 Initial release 1.0 2013-01-18 Modify the Pin definition to PCIeM.2_Rev0.7a and RF connector information 1.1 2013-04-08 Modify Section 3.2: Hardware Architecture Section 3.4: WLAN RF Characteristics Section 3.6: LGA Pin Definition: add note to some pins Chapter 4: add note to the mechanical drawing 2.0 2013-04-12 Modify Section 3.2: Hardware Architecture Section 3.4: WLAN RF Characteristics Section 3.6: LGA Pin Definition Section 5: Schematics reference design 2.1 2013-04-26 Add Section…

Text truncated - open the document above for the full version.

Attestation Statements

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. Date: 2013/7/30 GENERAL DECLARATION We, HON HAI PRECISION IND. CO., LTD. declare that the device does not support any non-US channels in all the operational mode(s) for the following product. FCC ID: MCLT77H462 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Signature: Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

Attestation Statements

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. Declaration for DFS client devices Date: 2013/7/30 FCC ID: MCLT77H462 Dear Examiner: Per KDB# 848637, We, Hon Hai PRECISION IND.CO.,LTD declare that following description truly represent our product in consideration. Please do not hesitate to contact us, if further info is required. Thanks. a). A channel/frequency plan for the device showing the channels that have active scanning or passive scanning. Active scanning is where the device can transmit a probe (beacon) and passive scanning is where the device can listen only without probes. Below is the channel / frequency plan for the device b). For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) or in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies), or modular devices that configure the modes of operations through software; the applicant must provide in the application software and operations description that discuss how the software and / or hardware is implemented to ensure that proper operations modes cannot be modified by an end user or an installer. Also, include an attestation that the device complies with the requirements for software configuration control as discussed in KDB #594280. On DFS channels, the WLAN driver on the device operates under the control of an AP at all times, except when in ad-hoc mode, on US non-DFS channels. As described in the answer to question a, CH 1 2 3 4 5 6 7 8 9 10 11 Frequency (MHz) 2412 2417 2422 2427243224372442 2447 2452 2457 2462 Scan Type Active Active Active Active Active Active Active Active Active Active Active CH 36 40 44 48 52 56 60 64 Frequency (MHz) 5180 5200 5220 5240526052805300 5320 Scan Type Active Active Active Active Passive Passive Passive Passive CH 100 104 108 112 116 132 136 140 Frequency (MHz) 5500 5520 5540 5560558056605680 5700 Scan Type Passive Passive Passive Passive Passive Passive Passive Passive CH 149 153 157 161 165 Frequency (MHz) 5745 5765 5785 58055825 Scan Type Active Active Active Active Active the device passively scans DFS frequencies until a master device is detected. The control of this functionality is not accessible to anyone under any conditions. Furthermore, the firmware is locked by proprietary password and cannot be changed or modified by end user. If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! Signature: Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

Cover Letter(s)

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. Federal Communications Commission Authorization and Evaluation Division Date: September 2, 2013 Confidentiality Request FCC ID: MCLT77H462 Pursuant to DA 04-1705 of the Commission’s Rules, we request short-term confidential treatment for the following information until Oct. 15, 2013 of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Test Setup Photos User’s Manual Internal Photo Thank you! Sincerely yours, ------------------------------------------------------- Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

Cover Letter(s)

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. Date:2013/7/30 FCC ID: MCLT77H462 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

Cover Letter(s)

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. AGENCY AUTHORIZATION LETTER Date: 2013/7/30 To whom it may concern: We, the undersigned, , HON HAI PRECISION IND. CO., LTD. hereby authorize Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C+15E approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, Signature: Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

Cover Letter(s)

FCC ID: MCLT77H462 Report No.: RF130710E11 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch September 5, 2013 Dear Application Examiner, Hon Hai PRECISION IND.CO.,LTD., 802.11abgn+BT4.0 module, FCC ID: MCLT77H462, would like to have your authorization as a modular approval specific to the mobile RF exposure condition. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip BCM43241. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is BCM43241. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a USB extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Hank Chung Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

External Photos

Report No.: 130710E11 1 of 3 CONSTRUCTION PHOTOS OF EUT Rev 1.0 Report No.: 130710E11 3 of 3 Rev 1.0

ID Label/Location Info

(Fig. 1) FCC ID: MCLT77H462 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label 13.08.13 Taim Huang Sunny Wu 500.xxxxx.005 T77H462.02 PTT label Taim Huang 00 XF581 3mm XXXXXXXXXXXXXX 1.5mm 1.7mm Notes: 1.Material:XF581 2.Printing color:black 3.Shipment:roll FOXCONN Model: T77H462 IC: 2878D-T77H462 CSA - 188227 FCC ID: MCLT77H462 5 mm 10mm FOXCONN Model: T77H462 FCC ID: MCLT77H462 5 mm 10mm Scale: 1:1

Internal Photos

Report No.: 130710E11 2 of 3 Rev 1.0

Operational Description

FCC ID: MCLT77H462 Report No.: RF130710E11 Operational Description This device is a 802.11abgn+BT4.0 module, which operates in both of the 5GHz and 2.4GHz bands and can’t transmitting simultaneously, the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered DC 3.3V. The antennas provided to the EUT, please refer to the following table: The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

RF Exposure Info

Report No.: SA130710E11 1 of 6 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA130710E11 MODEL NO.: T77H462 FCC ID: MCLT77H462 RECEIVED: July 10, 2013 TESTED: Aug. 05, 2013 ISSUED: Aug. 30, 2013 APPLICANT: Hon Hai PRECISION IND.CO.,LTD ADDRESS: 8 F., No. 94, Baozhong Rd., Xindian,Taipei, Taiwan 231 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA130710E11 2 of 6 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 6 Report No.: SA130710E11 3 of 6 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA130710E11 Original release Aug. 30, 2013 Report No.: SA130710E11 4 of 6 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: 802.11abgn+BT4.0 module BRAND NAME: FOXCONN MODEL NO.: T77H462 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Hon Hai PRECISION IND.CO.,LTD TESTED DATE: Aug. 05, 2013 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: T77H462) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: July 24, 2012 ( Lori Chung, Specialist ) APPROVED BY : , DATE: July 24, 2012 ( May Chen, Manager ) Report No.: SA130710E11 5 of 6 Report Format Version 5.0.0 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA130710E11 6 of 6 Report Format Version 5.0.0 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For WLAN: 15.247(2.4GHz) FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 320.877 -0.6 20 0.05560 1.00 For WLAN: 15.247(2.4GHz, BT(LE MODE)) FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 6.592 -0.6 20 0.00114 1.00 For WLAN: 15.247(5GHz) FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 - 5825 166.674 -2.3 20 0.01953 1.00 For WLAN: 15.407(5GHz) FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180 -5240, 5260 - 5320, 5500 – 5580, 5660 - 5700 104.513 -2.3 20 0.01224 1.00 For Bluetooth: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2402-2480 9.484 -0.6 20 0.00164 1.00 --- END ---

Test Report

Report No.: RF130710E11 1 of 96 Report Format Version 5.2.0 FCC TEST REPORT (15.247) REPORT NO.: RF130710E11 MODEL NO.: T77H462 FCC ID: MCLT77H462 RECEIVED: July 10, 2013 TESTED: July 25 to Aug. 05, 2013 ISSUED: Aug. 30, 2013 APPLICANT: Hon Hai PRECISION IND.CO.,LTD ADDRESS: 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF130710E11 2 of 96 Report Format Version 5.2.0 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 5 1. CERTIFICATION .................................................................................................... 6 2. SUMMARY OF TEST RESULTS ............................................................................ 7 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 9 3. GENERAL INFORMATION ................................................................................... 10 3.1 GENERAL DESCRIPTION OF EUT ..................................................................... 10 3.2 DESCRIPTION OF TEST MODES ....................................................................... 12 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 13 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 16 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................. 17 3.5 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 17 4. TEST TYPES AND RESULTS (FOR 2.4GHZ, 2.400 ~ 2.4835GHZ BAND)........... 18 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 18 4.1.2 TEST INSTRUMENTS .......................................................................................... 18 4.1.3 TEST PROCEDURES .......................................................................................... 19 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 19 4.1.5 TEST SETUP ....................................................................................................... 19 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 20 4.1.7 TEST RESULTS (WLAN MODE) .......................................................................... 21 4.1.8 TEST RESULTS (BT<LE> MODE) ....................................................................... 23 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 25 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 25 4.2.2 TEST INSTRUMENTS .......................................................................................... 26 4.2.3 TEST PROCEDURES .......................................................................................... 28 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 28 4.2.5 TEST SETUP ....................................................................................................... 29 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 29 4.2.7 TEST RESULTS (WLAN MODE) .......................................................................... 30 4.2.8 TEST RESULTS (BT <LE> MODE) ...................................................................... 40 4.3 6DB BANDWIDTH MEASUREMENT ................................................................... 44 4.3.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT ................................................. 44 4.3.2 TEST INSTRUMENTS .......................................................................................... 44 4.3.3 TEST PROCEDURE ............................................................................................. 44 4.3.4 DEVIATION FROM TEST STANDARD ................................................................. 44 4.3.5 TEST SETUP .................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF130710E11-1 1 of 74 Report Format Version 5.2.0 FCC TEST REPORT (15.407) REPORT NO.: RF130710E11-1 MODEL NO.: T77H462 FCC ID: MCLT77H462 RECEIVED: July 10, 2013 TESTED: July 31 to Aug. 05, 2013 ISSUED: Aug. 30, 2013 APPLICANT: Hon Hai PRECISION IND.CO.,LTD ADDRESS: 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Mrs. Rio Chen(Compliance Deputy Manager)
[email protected]+886-3-5784975Fax: +886-3-5775100

Test Firm

Bureau Veritas CPS (H.K.) Ltd., Taoyuan BranchRichard Chen
[email protected]+886-3-2600884Fax: +886-3-2115834

Technical Specifications

#Rule PartsFrequency RangePower Output
315C5.75 GHz - 5.83 GHz167.00 mW
Modular Type
Single Modular Approval
Confidentiality
Long Term
Grant Notes
Power listed is the maximum combined conducted output power. Single modular approval for mobile RF Exposure conditions. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Approval is limited to OEM installations only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end users must be provided with transmitter operating conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter.
