MCLTTC509Cisco Telepresence Touch 10

The Cisco TelePresence Touch 10 has an Ethernet port with support for PoE *. • The LAN socket in your wall (network switch) or router can have support for PoE. Contact your IT administrator to check if PoE is available. • The TelePresence endpoint can have an Ethernet port with support for PoE. Check the user documentation of your endpoint to find if it supplies power over one of its Ethernet ports. • If none of the above options apply use the Cisco Aironet Power Injector; which can be ordered separately (CTS-PWR-AIR-INJ5). First connect the Ethernet cable to the Touch device, then choose option A, B or C: If Power over Ethernet (PoE) is supported by the endpoint, connect the Ethernet cable from the Touch to the Ethernet (PoE) port ( ) on the TelePresence endpoint. If Power over Ethernet (PoE) is available in the room, connect the Ethernet cable from the Touch to the Ethernet (PoE) port in the wall/router. If using a power injector, connect the Ethernet cable from the Touch to the injector, and then choose one of the two options: • Either, connect the Ethernet cable from the injector to the Ethernet port ( ) on the TelePresence endpoint. • Or; connect the Ethernet cable from the injector to the Ethernet port in the wall/router. Installing the Touch 10 The Cisco TelePresence Touch 10 can be used with a wide range of Cisco TelePresence video conferencing systems (also named codec or endpoint). Box contentsOptional • Cisco TelePresence Touch 10• Ethernet cable, 12.5 m • Ethernet cable, 4.0 m *• Power injector with cables • Cleaning cloth * Starting up the Touch controller Select language Choose a language and tap Next. Select codec to pair with If the Touch device is connected directly to the endpoint the pairing process is run automatically in the background. Wait for 10 minutes to allow for automatic setup. If the Touch device is connected through LAN you must select which endpoint (codec) to pair with: Choose your endpoint from the list and tap Start Pairing or Select codec manually. Select codec manually The address* of the TelePresence endpoint is announced on its main screen. Enter the IP address or hostname and tap Start Pairing. Connecting the cables * When ordering the Cisco TelePresence Touch 10 as a spare part the Ethernet cable and cleaning cloth is not included. * The PoE source (network switch) must be located in the same building as the Cisco TelePresence Touch 10. Otherwise the Cisco Aironet Power Injector must be used. The Ethernet cable (Cat5) can be up to 100 m (330 ft). Logging on to the endpoint You may need to log on to the endpoint. If required, contact your system adminstrator for the username and password. Enter the username and password and tap Ok to finish. Sound bar for audio adjustments The Touch screen is adjustable to accommodate individual ergonomic needs * The endpoint address: An IPv4 address may look like 192.168.0.1, an IPv6 address may look like 2001:DB8:1:0:ABCD::1, and a hostname may look like: [email protected]. A B C Light indicator A B C First connect the Ethernet cable to the Touch, then choose option A, B or C. To the endpoint To a PoE socket (in wall or router) To a PoE injector (no PoE in wall or router) On our web site you can find an overview of the worldwide Cisco contacts. Go to: http://www.cisco.com/web/siteassets/contacts Corporate Headquarters Cisco Systems, Inc. 170 West Tasman Dr. San Jose, CA 95134 USA China RoHS Hazardous Substance Table NoteThis Table is a regulatory document required for products shipped to the People’s Republic of China. Where to find additional support and information for your Cisco TelePresence product User documentation For more information about Cisco TelePresence Touch 10 see the user documentation that is available on our web site: http://www.cisco.com/en/US/products/ps11336/tsd_products_support_series_home.html Support For support, go to: http://www.cisco.com/support Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list ofCiscotrademarks, go to this URL: www.cisco.com/go/trademarks. Third- party trademarks mentioned are the property of their respective owners.The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1110R) Cisco TelePresence Touch 10 InStALLAtIOn gUIde 78-100157-01 | SEPTEMBER 2013. Copyright © 2013 Cisco Systems, Inc. All rights reserved. Call, share and control video meetings with a touch of a finger.

RF_160, Issue 02 Declaration of Authorization We Name: HON HAI Precision Ind. Co., Ltd. Address: 5F-1, 5, Hsin-An Road, Hsinchu Science-Based Industrial Park City: Hsinchu Country: Taiwan Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification, completing and signing of the RF-731 form for Certification of the following product(s): Product description: Cisco TelePresence Touch 10 Type designation: TTC5-09 Trademark: Cisco on our behalf. Date: 2013-10-28 City: Hsinchu Name: Mrs. Rio Chen Function: Compliance Deputy Manager Signature: .............................. . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 10-Aug-09 RF_501, Issue 5 Page 1 of 1 Company Name: HON HAI Precision Ind. Co., Ltd. Address : 5F-1, 5, Hsin-An Road, Hsinchu Science-Based Industrial Park City: Hsinchu Country: Taiwan To: Telefication B.V ., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: MCLTTC509 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2013-10-28 Name and signature of applicant: Mrs. Rio Chen Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Neutron Engineering Inc. Project No.: 1309C142 Page 2 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 3 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 4 of 15

R1 37.0 50.0 3.0+/-0.5 3.0+/-0.5 CUTTING LINE UPDATE DESCRIPTION * + 0.2 CRITICAL DIM. MARK DRAFT TOLERANCE FE D C 1 2 3 4 MATERIAL (SPEC.) Dim. 30~120 120~300 300~450 450~600 0.15 0.20 0.25 0.10 0.05 Tol. A 0.20 0.30 0.40 B 0.15 0.05 6~30 0~6 0.300.50 FINISH Select 15.00 10.00 5.00 3.00 BAG 20.00 2.00 0.50 1.00 0.50 EPE 2.00 0.50 0.50 EPS 1.00 0.30 0.40 0.50 0.20 0.10 C 3.003.00 0.60 0.20 0.25 0.30 0.50 0.20 Label CTN 3.00 2.00 5.00 USR 0.80 5.00 UNIT PART NAME CUSTOMER MODEL mm SIZE A4 MODEL SHEET SCALE F E D VER. 01 ECR/ECN NO. MARK C First Release DATE B A APPROVED DESIGNED CUSTOMER PART NO. PART NO. 1 2 3 4 BA SIGNATURE HON HAI PRECISION IND. CO., LTD. NOTES:(UNlESS OTHERWISE SPECIFIED) 1. ALL MATERIALS, FINISHES AND PROCESS MUST COMPLY WITH ROHS DIRECTIVER 2. LABEL COLOR SHALL MEET CISCO REQUEST, CISCO OSOLO SNOW FOR BACKGROUND COLOR AND P COOL GREY 3 FOR TEXTS AND LINES COLOR 3. TEXT FONT SHALL BE CISCOSANSTT REGULAR 4. LABEL MATERIAL: (a) SURFACE MATERIAL: 50# POSITIVE VOID POLYSTER (b) SURFACE GLOSSINESS: MATTE LIKE MT-11510 (c) SURFACE MATERIAL COLOR: CISCO OSLO SNOW (d) PRINTING TEXT COLOR: PANTONE COOL GREY 3 (e) ADHESIVE: TBD (f) ADHESIVE THICKNESS: TBD (g) ADHESIVE TO STELL(180 DEGREE ADHESION): TBD (h) INITIAL TACK: TBD (i) RELEASE POWER(90 DEGREE): TBD (j) HOLDING POWER: TBD IDEFIX Product Label 2012/05/30 Sally Liao Ken Hung Sally Liao U58V213.00 504.00951.005 IDEFIX 1/1 1/1 SEE NOTES SEE NOTES v 03 Change label content, text color and surface finish. 2013/07/10 Sally Liao Took away the 12V option on label. Reverted from Pantone Cool Grey 9 to Cool Grey 3. This means same color on text as before (P3 build) Sally Liao04 2013/10/08 R1 3.0+/-0.5 3.0+/-0.5 CUTTING LINE 12.0 114.0 CAN ICES-3(B)/NMB-3(B) IC: 2878D-TTC509 FCC ID: MCLTTC509 201-135402 188227 D 13-5099 201 UPDATE DESCRIPTION * + 0.2 CRITICAL DIM. MARK DRAFT TOLERANCE FE D C 1 2 3 4 MATERIAL (SPEC.) Dim. 30~120 120~300 300~450 450~600 0.15 0.20 0.25 0.10 0.05 Tol. A 0.20 0.30 0.40 B 0.15 0.05 6~30 0~6 0.300.50 FINISH Select 15.00 10.00 5.00 3.00 BAG 20.00 2.00 0.50 1.00 0.50 EPE 2.00 0.50 0.50 EPS 1.00 0.30 0.40 0.50 0.20 0.10 C 3.003.00 0.60 0.20 0.25 0.30 0.50 0.20 Label CTN 3.00 2.00 5.00 USR 0.80 5.00 UNIT PART NAME CUSTOMER MODEL mm SIZE A4 MODEL SHEET SCALE F E D VER. 01 ECR/ECN NO. MARK C First Release DATE B A APPROVED DESIGNED CUSTOMER PART NO. PART NO. 1 2 3 4 BA SIGNATURE HON HAI PRECISION IND. CO., LTD. IDEFIX Safety Label 2012/05/30 Sally Liao Ken Hung Sally Liao U58V213.00 500.01494.005 IDEFIX 1/1 1/1 v SEE NOTES SEE NOTES 02 Add P/N, change label material and cutting line 2012/07/13 Sally Liao Sally Liao Sally Liao Keep marks for the countries related to tier 1 2013/10/17 2013/10/30 03 04 NOTES:(UNlESS OTHERWISE SPECIFIED) 1. ALL MATERIALS, FINISHES AND PROCESS MUST COMPLY WITH ROHS DIRECTIVER 2. LABEL COLOR SHALL MEET CISCO REQUEST, CISCO OSLO SNOW FOR BACKGROUND COLOR AND PANTONE COOL GREY 3 FOR TEXTS AND LINES COLOR 3. TEXT FONT SHALL BE CISCOSANSTT REGULAR 4. LABEL MATERIAL: (a) SURFACE MATERIAL: 50# EMBOSSING WHITE MYLAR HTYL50(EB) (b) SURFACE GLOSSINESS: MATTE LIKE MT-11510 (c) SURFACE MATERIAL COLOR: CISCO OSLO SNOW (d) PRINTING TEXT COLOR: PANTONE COOL GREY 3 (e) ADHESIVE: F07D (f) ADHESIVE THICKNESS: 0.033+/-0.003 MM (g) ADHESIVE TO STELL(180 DEGREE ADHESION): 1.20+/-0.35 KG/25MM (h) INITIAL TACK: 1.20+/-0.4 KG/25MM (i) RELEASE POWER(90 DEGREE): 26.00+/-10 G/25MM (j) HOLDING POWER: 10.00+/-6 HR/KG/25MM 2 N/A Update certificate NO. for the country related to tier 1

Neutron Engineering Inc. Project No.: 1309C142 Page 5 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 6 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 7 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 8 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 9 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 10 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 11 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 12 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 13 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 14 of 15 Neutron Engineering Inc. Project No.: 1309C142 Page 15 of 15

Report No.: NEI-FCCE-1-1309C142 Page 1 of 66 Neutron Engineering Inc. FCC TEST REPORT Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Oct. 10, 2013 Date of Test: Oct. 10, 2013 ~ Nov. 01, 2013 NEUTRON ENGINEERING INC. B1, No.37, Lane 365, Yang Guang St., NeiHu District 114., Taipei, Taiwan TEL : (02) 2657-3299 FAX : (02) 2657-3331 Issued Date : Nov. 04, 2013 Project No. : 1309C142 Equipment : Cisco TelePresence Touch 10 Model Name : TTC5-09 Applicant : Hon Hai Precision Ind. Co.,Ltd. Address : 5F-1, 5, Hsin-An Road, Hsinchu Science-Based Industrial Park, Taiwan, R.O.C. Report No.: NEI-FCCE-1-1309C142 Page 2 of 66 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: NEI-FCCE-1-1309C142 Page 3 of 66 Neutron Engineering Inc. Table of Contents Page REPORT ISSUED HISTORY 4 1 . CERIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 9 3.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 3.4 DESCRIPTION OF SUPPORT UNITS 11 4 . EMC EMISSION TEST 12 4.1 CONDUCTED EMISSION MEASUREMENT 12 4.1.1 POWER LINE CONDUCTED EMISSION 12 4.1.2 MEASUREMENT INSTRUMENTS LIST 12 4.1.3 TEST PROCEDURE 13 4.1.4 DEVIATION FROM TEST STANDARD 13 4.1.5 TEST SETUP 13 4.1.6 EUT OPERATING CONDITIONS 13 4.1.7 TEST RESULTS 14 4.2 RADIATED EMISSION MEASUREMENT 15 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 4.2.2 MEASUREMENT INSTRUMENTS LIST 16 4.2.3 TEST PROCEDURE 17 4.2.4 DEVIATION FROM TEST STANDARD 17 4.2.5 TEST SETUP 18 4.2.6 EUT OPERATING CONDITIONS 18 4.2.7 TEST RESULTS-BETWEEN 30MHZ AND 1000MHZ 19 4.2.8 TEST RESULTS-ABOVE 1000MHZ 36 Report No.: NEI-FCCE-1-1309C142 Page 4 of 66 Neutron Engineering Inc. REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCE-1-1309C142 Original Issue Nov. 04, 2013 Report No.: NEI-FCCE-1-1309C142 Page 5 of 66 Neutron Engineering Inc. 1. CERIFICATION Equipment : Cisco TelePresence Touch 10 Brand Name : Cisco Model Name : TTC5-09 Applicant : HON HAI Precision Ind. Co., Ltd. Manufacturer : Cisco Systems, Inc. Address : 170 West Tasman Drive San Jose, CA95134-1706 USA Factory : 1) HONG FU JIN PRECISION INDUSTRY (SHEN ZHEN) CO LTD 2) Foxconn Assembly LLC Address : 1) Bldg. D10,F21, No. 2, 2ND DONGHUAN ROAD, 10TH YOUSONG INDUSTRIAL DISTRICT,LONGHUA TOWN,BAOAN, SHENZHEN, GUANGDONG, CHINA, Postal code: 518109 2) 11177 Compaq Center Drive West,Houston,Tsxas 77070,USA Date of Test : Oct. 10, 2013 ~ Nov. 01, 2013 Test Sample : ENGINEERING SAMPLE Standard(s) : FCC Part 15, Subpart B: 2012 Class B ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. This test report consists of 66 pages in total. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCE-1-1309C142) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Testing Engineer : (Josh Lin) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Report No.: NEI-FCCE-1-1309C142 Page 6 of 66 Neutron Engineering Inc. 2. SUMMARY OF TEST RESULTS EMISSION Standard(s) Test Type ResultRemarks Conducted emission test N/A FCC Part 15, Subpart B: 2012 Class B Radiated emission test PASS Meet the requirement of limit. Minimum passing margin is -7.40 dB at 481.05MHz Report No.: NEI-FCCE-1-1309C142 Page 7 of 66 Neutron Engineering Inc. 2.1 TEST FACILITY The test facilities used to collect the test data in this report is C02/CB08 at the location of 1F., No. 61, Ln. 77, Sing-ai Rd., Neihu Dist., Taipei City 114, Taiwan. C02 : (VCCI RN: C-3477; FCC RN: 614388 & DN: TW1054) CB08 : (VCCI RN: G-91; FCC RN: 614388 & DN: TW1054; IC Assigned Code: 4428C-1) 2.2 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95%。 Measurement Frequency Uncertainty Conducted emissions 150kHz ~ 30MHz 2.59 dB 30MHz ~ 1GHz 3.55 dB Radiated emission Above 1GHz 4.05 dB Report No.: NEI-FCCE-1-1309C142 Page 8 of 66 Neutron Engineering Inc. 3. GENERAL INFORMATION 3.1 GENERAL DESCR…

Text truncated - open the document above for the full version.

Report No.: NEI-FCCE-1-1309C142 Page 55 of 68 Neutron Engineering Inc. 5. EUT TEST PHOTO Radiated Measurement Photos - BETWEEN 30MHz-1000MHz Report No.: NEI-FCCE-1-1309C142 Page 56 of 68 Neutron Engineering Inc. Radiated Measurement Photos- ABOVE 1000MHz
