MCLU10H010802.11b WLAN USB Adapter

Wireless USB Adapter User Manual Contents Chapter 1 About the WirelessUSB Adapter.........................3 1-1 Features...........................................................................................................3 1-2 Applications.....................................................................................................3 1-3 Product Kit......................................................................................................4 Chapter 2 Network Configuring and Planning...................5 2-1 Network Topology...........................................................................................5 2-2 Roaming..........................................................................................................6 Chapter 3 Installation............................................................................7 3-1 System Requirements......................................................................................7 3-2 Inserting the Wireless Card.............................................................................7 3-3 Installation and Uninstall Process...................................................................7 Chapter 4 Wireless Utility and Configuration..................13 4-1 Windows 98/2000 Wireless Utility................................................................13 4-2 Windows XP Wireless Utility........................................................................17 Appendix A Troubleshooting....................................................................................23 Appendix B Glossary................................................................................................24 Appendix C Specifications for Wireless Card..........................................................25 Chapter 1 About the Wireless USB Adapter This IEEE 802.11b Wireless is compatible with computer USB Adapter. As a Plug-and-Play device, Windows 95/98/2000/ME/XP will automatically recognize the wireless USB Adapter and initiate the installation process. Upon successful installation, the wireless USB Adapter will communicate seamlessly with other IEEE 802.11b wireless products. 1-1 Features 1. Supports up to 11 Mbps data rate. 2. Working range up to 800 ft. in an open environment enhances mobility. 3. Supports point-to-point and point-to-multipoint access provides increased flexibility. 4. Seamless connectivity to wired Ethernet and PC network LAN’s offers quick, trouble-free integration with existing networks. 5. Direct Sequence Spread Spectrum (DSSS) technology provides secure wireless connection. 6. Wireless connections eliminate the hassle and cost of cabling. 7. Supports a wide range of LAN (Local Area Network) Network Operating Systems (NOS) including Windows 98/2000/NT/ME/XP 8. Easy Plug and Play installation. 9. Omni - directional antenna provides wide range of reception. 10. Greater flexibility to locate or move networked PC’s 1-2 Applications This wireless USB Adapter offer a fast, reliable, cost-effective solution for wireless client access to the network. Refer below for examples : ??Remote access to corporate network information ??E-mail, file transfer and terminal emulation ??Difficult-to-wire environments ??Historic or older buildings without Ethernet wiring. ??Buildings with asbestos insulation ??Open areas where wiring is difficult to employ ??Re-layout frequently environments ??Retailers, manufacturers or other organizations that frequently rearrange the workplace or relocate ??Temporary LANs for special projects or peak time usage ??Trade shows, exhibitions and construction sites that employ temporary networks. ??Retailers, airline and shipping companies that need additional workstations for a peak period and auditors that require workgroups at customer sites. ??Access to database for mobile workers ??Medical, technical and retail specialists that require roaming access to a database or other network resources. ??SOHO (Small Office and Home Office) users ??Perfect for users that need a small, easy-to-install network that deploys rapidly. 1-3 Product Kit The wireless USB Adapter includes the following items. Ensure that the items in the following list have been included. If any of the listed items are missing, please contact your local dealer. ??One wireless USB Adapter ??One Compact Disk. The CD includes 98/2000/NT/ME/XP driver, utility, and this user manual Chapter 2 Network Configuring and Planning The wireless USB Adapter supports legacy Ethernet LAN network configuration options as defined by the IEEE 802.11b. The wireless USB Adapter can be configured as: . Ad-Hoc mode for no Access Point wireless environment. . Infrastucture mode for wireless environment with Access Point. 2-1 Network Topology An Ad-Hoc wireless LAN is a group of computers. Each computer is equipped with a wireless USB Adapter that is configured to the same radio channel in order to communicate with others. Ad-Hoc wireless LAN configurations are appropriate for branch level departments or SOHO operations. A group of wireless users and an Access Point compose a Basic Service Set (BSS). Wireless clients can talk to any computer in both wired and wireless LAN network via the Access Point. 2-2 Roaming Infrastructure mode also supports roaming capabilities for mobile users. More than one BSS can be configured as an Extended Service Set (ESS). The continuous network allows users to roam freely within an ESS. All wireless USB Adapter and Access Point within one ESS must be configured with the same ESSID in order to utilize the roaming function. Proper Access Point positioning with a clear radio signal can greatly enhance wireless performance. Chapter 3 Installation 3-1 System Requirements In order to install and use the wireless USB Adapter in your notebook computer, your notebook system must meet the following requirements: ??USB interface ??CD-ROM Drive 3-2 Inserting the Wireless Card 1. Locate an available USB Adapter. 2. With the USB AD…

Text truncated - open the document above for the full version.

From: Mike Kuo Sent: Friday, November 01, 2002 6:41 PM To: '[email protected]' Subject: FW: Ambit Microsystems Corporation , FCC ID:MCLU10H010, An02T2373 -----Original Message----- From: CERTADM Sent: Friday, November 01, 2002 4:00 PM To: '[email protected]' Subject: Ambit Microsystems Corporation , FCC ID:MCLU10H010, An02T2373 Notice_content ------------- Question #1: The product description in the user manual does not agree the actual product tested. This product is a 802.11b WLAN with external USB interface. Please provide user manual that match with product. Question #2: Section 1.4 of test configuration diagram, the EUT is placed inside the Notebook PC and the description below the diagram indicated the Compaq notebook was used. These description do not match the peripherals and host were used per setup photos. Please make necessary correction. FYI: FCC no longer require Processing gain measurement for Digital Transmission System. In the future DTS submission, please do not provide processing gain data Best Regards Mike Kuo / TCB Certifier

MAX LIGHT Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab MAX LIGHT Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab

MAX LIGHT Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab Label Format: Label Position: This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,and (2) This device must accept any interference received ,including. Interference that may cause undesired operation. Model : K12H006 / U10H010 FCC ID : MCLU10H010 MADE IN TAIWAN Rear View Equipment Lable 1.5cmX2.0cm

MAX LIGHT Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab MAX LIGHT Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab MAX LIGHT Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab

1 TM AN9633 Processing Gain for Direct Sequence Spread Spectrum Communication Systems and PRISM® Introduction This application note addresses the concept of processing gain (PG) of Direct Sequence Spread Spectrum (DSSS) systems. The PRISM chipset is used to implement DSSS radio designs. The processing gain provides the unique properties to the DSSS waveform primarily in terms of interference tolerance. The PG of a DSSS system is centered around the utilization of random codes which are used in conjunction with the data. These random codes are referred as Pseudo Noise (PN) codes. The HSP3824 provides this coding capability for the PRISM. Description In a DSSS system random binary data with a bit rate of r b bits per sec (bps) is multiplied (Exclusive Ored) by a pseudorandom binary waveform, which is at much higher rate and it provides the frequency spreading operation. This pseudorandom (PN) binary source outputs symbols called chips at a constant chip rate r C chips per sec (cps). This is a random, noise like signal and hence the name PN signal. The chip rate is always higher than the bit rate, and the ratio of the chip rate to the bit rate is defined as the processing gain (PG) [3]. The PG is a true signal to jammer (interference) ratio at the receiver after the despreading operation (removal of PN). The rate of the PN code is the one that defines the bandwidth of the transmitted spread waveform. The receiver of a DSSS system must remove the spreading as the first step in the demodulation process. During the despreading operation the receiver must generate a phase locked exact replica of the pseudorandom spreading waveform to match the transmitted signal. This is achieved by the code acquisition, and code tracking loops embedded in the HSP3824. The receiver PN sequence must be exactly in phase with the transmitted PN sequence, and this is achieved by correlation techniques. DSSS Transceiver A DSSS transmitter is shown in Figure 1. The data is denoted by d(t), the spreading signal is denoted by c(t), and the spread waveform q(t) is fed to the BPSK modulator operating at a carrier frequency f C , and the transmitted signal is denoted by x(t). A text book conceptual block diagram of a DSSS receiver is depicted in Figure 2. Note that PRISM is architected to perform the despreading function at baseband (HSP3824) rather than at RF as shown on Figure 2. This example is used for illustration of the concept and not to reflect the actual PRISM implementation. The received signal for this text book example is the combination of the transmitted spread spectrum signal and a narrow band jammer x J (t). The locally generated despreading sequence is denoted by c’(t), and should be equal to c(t). The despread signal is then band pass filtered before data demodulation and d’(t) should be equal to d(t). PG Benefits The primary benefit of processing gain is its contribution towards jamming resistance to the DSSS signal. The PN code spreads the transmitted signal in bandwidth and it makes it less susceptible to narrowband interference within the spread BW. The receiver of a DSSS system can be viewed as unspreading the intended signal and at the same time spreading the interfering waveform. This operation is best illustrated on Figure 3. Figure 3 depicts the power spectral density (psd) functions of the signals at the receiver input, the despread signal, the bandpass filter power transfer function, and the band pass filter output. Figure 3 graphically describes the effect of the processing gain on a jammer. The jammer is narrow, and has a highly peaked psd, while the psd of the DSSS is wide and low. The despreading operation spreads the jammer power psd and lowers its peak, and the BPF output shows the effect on the signal to jammer ratio. FIGURE 16. DSSS TRANSMITTER d(t) q(t) c(t) x(t) COS(ω O t) CODE GENERATOR FIGURE 17. DSSS RECEIVER d’(t)y(t) c’(t) x(t) + x j (t) COS(ω O t) PN GENERATOR BPF H(f) x’(t) LPF Application NoteAugust 1996 Authors: John Fakatselis Title N96 ) ub- t o- s- in rect quen read ec- m m- ni- ion s- ms d IS utho ey- rds ter- rpo- ion, mi- n- ctor, IS re- s m- CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures. 1-888-INTERSIL or 321-724-7143 |Intersil (and design) is a trademark of Intersil Americas Inc. Copyright © Intersil Americas Inc. 2001. All Rights Reserved PRISM® is a registered trademark of Intersil Americas Inc. PRISM and design is a trademark of Intersil Americas Inc. 2 If for example, BPSK modulation is used and an Eb/No of lets say 14dB is required to achieve a certain BER performance, when this waveform is spread with a processing gain of 10dB then the receiver can still achieve its required performance with the signal having a 4dB power advantage over the interference. This is derived from the 14dB required minus the 10dB of PG. The higher the processing gain of the DSSS waveform the more the resistance to interference of the DSSS signal. The classical definition of processing gain is the 10 Log number [r C /r B ] in dB. By this definition a system that has a data rate of 1MBPS and a chip rate (rate of PN code) of 1MCPS will have a PG of 10.41dB. Using the PRISM chip set each data bit is x-ored with an 11 bit sequence for this particular example. The processing gain can be then viewed as the 10Log[11]dB where 11 is the length of the PN code. If a code with a length of 16 bits is to be used then the processing gain is equivalent to 10 Log[16] dB or 12.04dB. To this end these PN signals must posses certain mathematical properties to be useful as part of a DSSS system. Primarily the PN codes that are useful must have very good autocorrelation and crosscorrelation properties as well as maintaining some randomness properties. The DSSS receiver is utilizing a reference PN sequence which is a replica to the transmitted sequence and when it detects correlation between the reference and the incoming sequences it declares initial a…

Text truncated - open the document above for the full version.

MAX LIGHT MEASUREMENT REPORT Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab M M a a x x i i m m u u m m P P e e r r m m i i s s s s i i b b l l e e E E x x p p o o s s u u r r e e EUT : Wireless USB Dongle Card Applicant : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Manufacturer : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Model No : K12H006 / U10H010 FCC ID : MCLU10H010 Basis of Calculations: E^2/3770 = S, mW/cm2 E, V/ m = (Pwatts*Ggai n*30)^.5/d, meters d = ((Pwatts*G*30)/3770*S))^0.5 Pwatts*Ggain = 10^(PdBm-30+GdBi)/10) Test Result: Max RF Power (dBm) TX Antenna Gain (dBi) MPE Safe Distance(cm) 11.92 1.72 1.4 NOTE: For mobile or fixed location transmitters, minimum separation distance is 20cm, even if calculations indicate MPE distance is less.

/UB B2 /LB A1 /WE G5 /OE A2 /CE B5 A0 A3 A1 A4 A2 A5 A3 B3 A4 B4 A5 C3 A6 C4 A7 D4 A8 H2 A9 H3 A10 H4 A11 H5 A12 G3 A13 G4 A14 F3 A15 F4 A16 E4 VSS D1 VSS E6 NC H1 NC H6 I/O0 B6 I/O1 C6 I/O2 C5 I/O3 D5 I/O4 E5 I/O5 F5 I/O6 F6 I/O7 G6 I/O8 B1 I/O9 C1 I/O10 C2 I/O11 D2 I/O12 E2 I/O13 F2 I/O14 F1 I/O15 G1 VCC E1 VCC D6 NC G2 NC E3 NC D3 NC A6 U1U/IS62LV12816LL/TF-BGA48 MA1MA2MA3MA4MA5MA6MA7MA8MA9MA10MA11MA12MA13MA14MA15MA16MA17 MD0MD1MD2MD3MD4MD5MD6MD7MD8MD9MD10MD11MD12MD13MD14MD15 RAMCS* RAMCS* MOE* MOE* MWEL* MWEL* MLBE* MLBE* MWEH MA0 MWEH MA0 MWEH MA0NVCS* NVCS* MOE*MWEL* MA1MA2MA3MA4MA5MA6MA7MA8MA9MA10MA11MA12MA13MA14MA15MA16MA17 VCCA VCCS VCCS_D A11 1 A9 2 A8 3 A13 4 A14 5 NC 6 WE 7 VCC 8 NC 9 A16 10 A15 11 A12 12 A7 13 A6 14 A5 15 A4 16 A3 17 A2 18 A1 19 A0 20 CE 30 A10 31 OE 32 I/O0 21 I/O1 22 I/O2 23 GND 24 I/O3 25 I/O4 26 I/O5 27 I/O6 28 I/O7 29 U2 U/SSTA39VF010/128K*8/TSOP32 MA15MA14MA13MA12MA11MA10MA9MA8MA7MA6MA5MA4MA3MA2MA1MA16 MD0MD1MD2MD3MD4MD5MD6MD7 VCCS TXQ+TXQ-TXI+TXI-RXQ+RXQ-RXI+RXI-SCLKT/R_SWT/R_SW*ANTSELANTSEL* MD(0..15) MD(0..15) MA(1..17)MA(0..17) MA(1..17) PA_PEPE2PE1LE_RFRADIO_PETX_DETBB_AGC-BB_AGC+ TXQ+TXQ-TXI-TXI+RXQ+RXQ-RXI+RXI-SCLK 1.2V REF 12 R12 R/499/0402/1% TX_DET RADIO_PE LE_RF PE1PE2 SD PA_PE 12 R14 NI R/10K/0402/5% 12 R17 R/10K/0402/5% 12 C21 C/104K/16V/X7R/0402 12 C20 C/104K/16V/X7R/0402 12 C10 C/104K/16V/X7R/0402 12 C2 C/104K/16V/X7R/0402 12 C4 C/104K/16V/X7R/0402 12 C48 C/104K/16V/X7R/0402 12 C5 C/104K/16V/X7R/0402 12 C3 C/104K/16V/X7R/0402 1 2 C7 C/104K/16V/X7R/0402 1 2 C122 C/104K/16V/X7R/0402 1 2 C1 C/104K/16V/X7R/0402 12 R9 R/19.1K/0402/1% 12 R10 R/19.1K/0402/1% 12 C22 C/104K/16V/X7R/0402 12 C18 C/104K/16V/X7R/0402 R19 R/10K/0402/5% 1 2 R22 R/10M/0402/5% 12 R57R/220K/0603/5% 12 C73C/100J/50V/COG/0402 12 C77 C/221K/50V/X7R/0402 HOE* HCE1*HWE*HCE2* HIORD*HIOWR* HRESET HREG* VCCS VCCS MA18 174 MA17 175 MA16 176 MA15 177 MA14 181 MA13 182 MA12 183 MA11 184 MA10 185 MA9 186 MA8 187 MA7 188 MA6 189 MA5 190 MA4 193 MA3 194 MA2 195 MA1 196 MWEH-MA0 197 MD14 203 MD0 23 MD1 22 MD2 21 MD3 20 MD4 19 MD5 18 MD6 15 MD7 14 MD8 13 MD9 12 MD10 11 MD11 206 MD12 205 MD13 204 MD15 198 MLBE 207 MWEL 10 RAMCS 6 NVCS 208 VRFE 73 IRFE 74 LAN_H/L 48 BBOVLD 89 BBAGC- 93 RXI+ 76 RXI- 77 RXQ+ 79 RXQ- 80 TXI+ 82 TXI- 83 TXQ+ 86 TXQ- 87 BBAGC+ 92 ANT_SEL 47 ANT_SEL 46 HD0 121 HD1 119 HD2 117 HD3 172 HD4 171 HD5 167 HD6 160 HD7 158 HD8 120 HD9 118 HD10 116 HD11 170 HD12 166 HD13 159 HD14 157 HD15 149 HOE 147 HREG 127 HIORD 146 HIOWR 144 HCE1 150 HCE2 148 HINPACK 129 HRDY/HIREQ 138 HSTSCHG 124 HWAIT 133 HWE 139 RESET 52 TESTMODE 55 TCLKIN(CS) EEPROM 29 PJ2(MISO) EEPROM 32 PJ6(LED1) 35 PJ0(SCLK) EEPROM 30 PJ1(SDATA) EEPROM 31 COMPCAP1Q 64 COMPCAP2Q 65 COMPCAP1I 68 COMPCAP2I 69 CLKIN 25 LFXTALI 26 LFXTALO 24 MCLK 141 USB_DET 165 USB- 162 USB+ 163 PK3(PA_PE) 45 PK2(SYNTHDATA) 41 PK4(PE2) 42 PJ4(PE1) 33 PK0(LE_RF) 39 PJ5(LE_IF) 34 PJ7(RADIO_PE) 36 PK7(CAL_EN) 49 TXAGC 98 PL3(TR_SW) 50 PL7(TR_SW) 51 PK1(SYNTHCLK) 40 HA0 125 HA1 126 HA2 128 HA3 130 HA4 134 HA5 135 HA6 136 HA7 137 HA8 143 HA9 145 COMPCAPIQ 84 COMPCAPRX 94 COMPCAPTX 97 FSADOFF 67 FSADIQ 85 IO_GND 16 IO_GND 37 IO_GND 114 IO_GND 122 IO_GND 142 IO_GND 161 COREGNDD 8 COREGNDD 27 COREGNDD 43 COREGNDD 112 COREGNDD 131 COREGNDD 151 COREGNDD 168 COREGNDD 191 COREGNDD 201 GNDD 58 GNDD 101 VSUB 60 VSUB 100 VSUB 59 GNDA 66 GNDA 78 GNDA 88 GNDA 99 QOFFSET- 62 QOFFSET+ 63 IOFFSET+ 70 IOFFSET- 71 VCO_SELECT 56 TXDET 90 IO_VDD 17 IO_VDD 38 IO_VDD 115 IO_VDD 123 IO_VDD 140 IO_VDD 164 IO_VDD 180 COREVDDD 9 COREVDDD 28 COREVDDD 44 COREVDDD 113 COREVDDD 132 COREVDDD 152 COREVDDD 169 COREVDDD 192 COREVDDD 202 VDDA 61 VDDA 72 VDDA 75 VDDA 81 VDDA 91 (PLL) VDDA 105 VDDD 57 VDDD 102 FSADRX 95 FSADTX 96 FILTER 107 IO_VDD 200 PL4 173 MOE 7 IO_GND 178 IO_GND 199 TEST7 156 TEST6 155 TEST5 154 TEST4 153 TEST3 111 TEST2 110 TEST1 109 TEST0 108 CLKOUT 179 DBG4 5 DBG3 4 DBG2 3 DBG1 2 DBG0 1 GNDA(PLL) 106 U5ISL3871 VDD 4 ENB 1 GND 2 OUT 3 U13U/OSC/44MHz 12 R4 R/0/0402/5% 1 2 R7 R/1.5K/0402/1% 12 L2 L/0.56UH/1008 VCCS 1 2 L21B/MPZ2012S300AT 12 C30 C/220J/50V/COG/0402 44MHZ_CW R58 R/560/0402/5% 12 C15 C/102K/50V/X7R/0402 LFXTALOLFXTALI 12 R8 R/9.53K/0402/1% 12 R6 NI R/7.68K/0402/1% 12 C24 C/104K/16V/X7R/0402 FSADOFF 12 C29 C/104K/16V/X7R/0402 12 C26 C/104K/16V/X7R/0402 12 C32 NI C/104K/16V/X7R/0402 12 C35 C/104K/16V/X7R/0402 SD TX_AGC TX_AGC BB_AGC-BB_AGC+BB_OVLD BB_OVLD LNA_HL LNA_HL IOFFSET- IOFFSET-IOFFSET+ IOFFSET+QOFFSET+QOFFSET- QOFFSET+QOFFSET- 12 R16 R/12.1K/0402/1% 1.2V REF MD0MD1MD2MD3MD4MD5MD6MD7MD8MD9MD10MD11MD12MD13MD14MD15 12 C19 C/104K/16V/X7R/0402 12 C8 C/104K/16V/X7R/0402 12 C110 C/106M/6.3V/X5R/0805 12 C49 C/104K/16V/X7R/0402 12 C51 C/104K/16V/X7R/0402 12 C52 C/104K/16V/X7R/0402 12 C46 C/104K/16V/X7R/0402 12 C47 C/104K/16V/X7R/0402 1 2 L10 B/MPZ2012S300AT 1 2 L1 B/MPZ2012S300AT VCCA 12 C74 C/104K/16V/X7R/0402 12 C25 C/104K/16V/X7R/0402 12 C27 C/104K/16V/X7R/0402 12 C39 C/104K/16V/X7R/0402 12 C44 C/104K/16V/X7R/0402 12 C45 C/104K/16V/X7R/0402 12 C33 C/104K/16V/X7R/0402 12 C36 C/104K/16V/X7R/0402 44MHZ_CW SCLK SD LE_RF PE1 WLANWLAN.Sch VCCA 12 R1 R/1.13K/0402/1% A0 1 A1 2 A2 3 GND 4 SDA 5 SCL 6 WP 7 VCC 8 U9 NI U/AT24C08A 1 2 R2 NI R/1K/0402/5% 12 C12 NI C/104K/16V/X7R/0402 12 R18 NI R/10K/0402/5% 12 R15 R/10K/0402/5% 12 R21 NI R/10K/0402/5% VCCS 1 2 L17 B/MPZ2012S300AT +3.3V 1 TP20PAD 1 TP21PAD 12 C14 C/104K/16V/X7R/0603 12 C31 C/104K/16V/X7R/0603 1 2 L3 B/MPZ2012S300AT 12 C9 C/106M/6.3V/X5R/0805 12 C34 C/106M/6.3V/X5R/0805 12 C80 C/104K/16V/X7R/0603 12 C76 C/106M/6.3V/X5R/0805 3.3V IN 2 GND 5 OUT 3 GND 6 GND 7 GND 8 ENABLE 1 BYPASS 4 U17MIC5209-3.3BM 12 C13 C/471K/50V/X7R/0402 12 C91 C/104K/16V/X7R/0603 12 C88 C/106M/6.3V/X5R/0805 TP14 TESTPOINT TP6 TESTPOINT TP13 TESTPOINT TP5 TESTPOINT TP12 TESTPOINT TP7 TESTPOINT TP23 TESTPOINT TP24 TESTPOINT TP8 T TP1 T TP2 T TP10 T TP11T TP4 T TP25 TESTPOINT TP26 TESTPOINT TP27 TESTPOINT 12 R43 NI R/47K/0402/5% 12 R40 NI R/47K/0402/5% 12 R39 NI R/47K/0402/5% 12 R38 NI R/47K/0402/5% 12 R37 NI R/47K/…

Text truncated - open the document above for the full version.

P P a a r r t t 1 1 5 5 S S u u b b p p a a r r t t B B & & C C ( ( 1 1 5 5 . . 2 2 4 4 7 7 ) ) Product : Wireless USB Dongle Card Manufacture : AMBIT Microsystems Corporation. FCC ID : MCLU10H010 Model : K12H006 / U10H010 Report No. : MLT0210P15001 Test Date : October 31.2002 Test By Max Light Technology Co.,Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 T T h h e e t t e e s s t t r r e e p p o o r r t t c c o o n n s s i i s s t t s s o o f f 6 6 9 9 p p a a g g e e s s i i n n t t o o t t a a l l . . I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . MAX LIGHT MEASUREMENT REPORT Page: 2/69 Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab Table of Contents : MAX LIGHT MEASUREMENT REPORT Page: 3/69 Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-1992. All test were conducted by MLT(Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with Class B radiated and conducted emission limit of FCC Rules Part 15 Subpart B & C (15.247). EUT : Wireless USB Dongle Card Applicant : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Manufacturer : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Model No : K12H006 / U10H010 FCC ID : MCLU10H010 Prepared by : Approved by : MAX LIGHT MEASUREMENT REPORT Page: 4/69 Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab 1.1 Introduction The following measurement report is submitted on behalf of AMBIT Microsystems Corporation. . In support of a Class B Digital Device certification in accordance with Part2 Subpart J and Part 15 Subpart A And B&C of the Commission’s and Regulations. 1.2 Description of EUT EUT : Wireless USB Dongle Card Applicant : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Manufacturer : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Model No : K12H006 / U10H010 FCC ID : MCLU10H010 Power Type : Powered by PC Frequency of Channel : See Next page Type of Modulation : Direct Sequence Spread Spectrum Type of Antenna : Printed Antenna During testing the EUT was operated at Tx or Rx mode for each emission measured. This was done in order to ensure that maximum emission levels were attained. MAX LIGHT MEASUREMENT REPORT Page: 5/69 Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab Frequency of Each Channel (Working Frequency) Channel No. Frequency (MHz) 01 2412 02 2417 03 2422 04 2427 05 2432 06 2437 07 2442 08 2447 09 2452 10 2457 11 2462 MAX LIGHT MEASUREMENT REPORT Page: 6/69 Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab 1.3 Summary Of Tests 47 CFR Part 15 Subpart C Reference Test Results Note 15.107 AC Power Conducted Emission PASS 15.247(c) Transmitter Radiated Emissions PASS 15.247(b) Max. Output Power PASS 15.247(a)(2) 6dB RF Bandwidth PASS 15.247(d) Max. Power Density PASS 15.247(c) Out of Band Conducted Spurious Emission PASS 15.247(c) Band Edge Measurement PASS 15.247(e) Processing Gain of Direct Sequence PASS Provided by Applicant 15.203 Antenna Requirement PASS MAX LIGHT MEASUREMENT REPORT Page: 7/69 Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab 1.4 Description of Support Equipment In order to construct the minimum system which required by the ANSI C63.4-1991, following equipments were used as the support units. Computer : IBM Model No. : 16W Serial No. : BNC345M FCC ID : FCC DOC Keyboard : IBM Model No. : KB-9930 Serial No. : 09N5395 FCC ID : FCC DOC Monitor : IBM Model No. : 10L6145 030 Serial No. : 23-092079 FCC ID : FCC DOC Mouse : IBM Model No. : 0180-05N Serial No. : 23-96142 FCC ID : EMJMUSJJ Printer : PANASONIC Model No. : KX-P1080I Serial No. : 7CKAKE98933 FCC ID : ACJ5Z6KX-P10801 FCC ID : FCC(DOC) Modem : Askey (External Fax / Data Modem) Model No. : WS1414VE Serial No. : IAH-10811 FCC ID : H8N1414VE MAX LIGHT MEASUREMENT REPORT Page: 8/69 Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab 1.4 Configuration of System Under Test During testing the EUT(USB Wireless)’s USB port connected to the USB port of IBM computer. So there is No need for additional Ethernet card. A mouse was connected to the mouse port of IBM PC. and A keyboard was connected to the mouse port of IBM PC. And a printer was connected to the parallel port. A external modem connected the serial port and the external modem connected with two unterminated telephone cables on the line and phone jack. TEST SITE Power Supply PC Monitor Printer Modem Keyboard Mouse EUT RJ11C Cables RS-232 RS-232 USB Cable MAX LIGHT MEASUREMENT REPORT Page: 9/69 Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab 1.6 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4-1992 "Measurement of unIntentional Radiators." 1.7 General Test Condition The conditions under which the EUT operates were varied to determ…

Text truncated - open the document above for the full version.

MAX LIGHT MEASUREMENT REPORT Page: 11/69 Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab 2.3 Test Configuration: Front View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 12/69 Report Number: MLT0210P15001 FCC ID: MCLU10H010 Technology Lab Rear View of The Test Configuration
