MCLU98H038Wireless LAN 802.11a/b/g/n Device

U U U s s s e e e r r r ’ ’ ’ s s s    M M M a a a n n n u u u a a a l l l    W W W i i i r r r e e e l l l e e e s s s s s s    L L L A A A N N N    8 8 8 0 0 0 2 2 2 . . . 1 1 1 1 1 1 a a a / / / b b b / / / g g g / / / n n n    D D D e e e v v v i i i c c c e e e    Version 1.0 Wireless LAN 802.11a/b/g/n Device Information in this document is subject to change without notice. Microsoft, Encarta, MSN, and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. PART NUMBER: U98H038 Wireless LAN 802.11a/b/g/n Device 1 Table of Contents 1 INTRODUCTION 2 1.1 INVENTORY CHECKLIST 2 1.2 SUPPORTED SECURITY 2 2 ANTENNAATTACHMENT 3 3 WINDOWSVISTAWLANAUTOCONFIG 5 3.1 L AUNCHING MICROSOFT   WINDOWS   VISTA WLAN AUTOCONFIG 5 3.2 S ETTING THE NETWORK KEY AUTOMATICALLY 5 3.3 S ETTING THE NETWORK KEY MANUALLY 8 3.3.1 No authentication (Open): Setting the Network Key (Network Security) 12 3.3.2 Shared: Setting the Network Key (Network Security) 14 3.3.3 WPA-Personal Or WPA2-Personal: Setting the Network Key (Network Security) 17 3.3.4 WPA-Enterprise Or WPA2-Enterprise: Setting the Network Key (Network Security) 19 3.3.5 802.1X: Setting the Network Key (Network Security) 21 4 APPENDIXA:TROUBLESHOOTING 26 5 APPENDIXB:REGULATORYNOTICES 27 6 APPENDIXC:PRODUCTSPECIFICATIONS 33 Wireless LAN 802.11a/b/g/n Device 2 1 1 I I n n t t r r o o d d u u c c t t i i o o n n   Welcome! Your PC includes a Wireless LAN 802.11a/b/g/n Device. This device allows you to establish a wireless network using your PC as a Wireless Client (Station Mode) if you already have a wireless network running. If you have already established a wireless network with access to the Internet, you can wirelessly connect this HP PC to your wireless network 1 1 . . 1 1 I I n n v v e e n n t t o o r r y y   C C h h e e c c k k l l i i s s t t   Included with your PC should be the following items for your Wireless LAN 802.11a/b/g/n Device:
Antenna (Screws to the connector on the back of your PC. See Chapter 2)
Printed Quick Install Guide 1 1 . . 2 2 S S u u p p p p o o r r t t e e d d   S S e e c c u u r r i i t t y y   In order to secure your network from passive or active intrusion, key features are enabled on Windows   Vista WLAN AutoConfig :
WPA/WPA2 personal security
WEP encryption Please see Chapter 3 for information on security settings for your Wireless LAN 802.11a/b/g/n Device . Wireless LAN 802.11a/b/g/n Device 3 2 2 A A n n t t e e n n n n a a   A A t t t t a a c c h h m m e e n n t t   This chapter contains instructions for antenna installation.   I I m m p p o o r r t t a a n n t t   It is assumed that there is an existing wireless LAN network with an Internet connectionthathasbeensetuponyourcomputerpriortousingWirelessLAN 802.11a/b/g/nDevice.PleaseconsultyourISPforfurtherinformation. If you have already attached the antenna to your PC, please skip to Chapter 3. 1. Figure1showstheantennajacksonthebackofthePCandtheAntenna Connectors. Figure 1: Antenna Jacks on PC Back and Connectors 2. Screwtheantennaconnectorstotheantennajacks. Wireless LAN 802.11a/b/g/n Device 4 Figure 2 Antenna Connectors Screwed to Jacks 3. PlacethePConatableorplacetheantennainanelevatedandopenarea toachievethebestwirelessperformance. Note:Makesurethemiddleconnectorisscrewedtothemiddleantennajackto allow the best performance. The position to which the right and left connectorsarescreweddoesnotaffecttheperformance. Wireless LAN 802.11a/b/g/n Device 5 3 3 W W i i n n d d o o w w s s     V V i i s s t t a a   W W L L A A N N   A A u u t t o o C C o o n n f f i i g g   It is necessary to complete the steps in Chapter 2 Antenna Attachment prior to using Windows   Vista WLAN AutoConfig. If you have already established a wireless network with access to the Internet and you would like to wirelessly connect this PC to your wireless network, use Windows   Vista WLAN AutoConfig. 3 3 . . 1 1 L L a a u u n n c c h h i i n n g g   M M i i c c r r o o s s o o f f t t     W W i i n n d d o o w w s s     V V i i s s t t a a W W L L A A N N   A A u u t t o o C C o o n n f f i i g g     To launch Windows   Vista WLAN AutoConfig: 1. IntheSystemsTrayfindtheWirelessNetworkingicon. Figure3:WirelessNetworkIcon 2. SelectConnect to a networkandtheWirelessNetworkConnectiondialogbox willappear. 3 3 . . 2 2 S S e e t t t t i i n n g g   t t h h e e   N N e e t t w w o o r r k k   K K e e y y   A A u u t t o o m m a a t t i i c c a a l l l l y y   The PC will begin functioning in Station Mode (as a Client) with your Wireless LAN Network as soon as the Network Key is set-up. Note:Itisassumedthatthereisanexistingwirelessnetworkwithconnectionto the Internet. If not, please consult your ISP for further information on establishinganInternetconnection.  Note: Theremaybemultiple Networkiconsinthe systemtray.Choose theoneforWireless NetworkConnection asshown. Wireless LAN 802.11a/b/g/n Device 6 I I m m p p o o r r t t a a n n t t   Ifyoudonothaveanexistingwirelessnetworkyouwillneedtosetupyour WirelessRouterorAccessPointpriortousingyourPCinStationMode. 1. FindtheNetworkKey(WEPKeyorWPA/WPA2Key)foryourWirelessNetwork. 2. SelectView Available Wireless NetworksfromtheWirelessNetworkiconmenu. 3. TheWirelessNetworkConnectiondialogboxwillappear.  Figure4:WirelessNetworkConnectiondialogbox 4. SelecttheWirelessNetworkofyourchoicebyclickingonitsnameandthe entireblockwillbecomehighlighted. 5. SelectConnectinth…

Text truncated - open the document above for the full version.

  HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C.  Date: 2007/05/29  GENERAL DECLARATION We, HON HAI PRECISION IND. CO., LTD. declares that device does not have “Ad Hoc on non-US frequencies” and/or “on DFS frequencies” while applying for the follow product. FCC ID: MCLU98H038 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Signature: Jason Lin Compliance Engineer HON HAI PRECISION IND. CO., LTD. TEL:(02) 22676511 FAX: (02) 22676512 E-mail: [email protected]

  HON HAI PRECISION IND. CO., LTD. 5F-1, 5 Hsin-An Road, Hsinchu, Science-Based Industrial Park, Taiwan, R.O.C.  $*(1&<$ 87+25,=$7,21/(77(5 Date: 2007-05-29 To whom it may concern: We, the undersigned, HON HAI PRECISION IND. CO., LTD. hereby authorize Advance Data Technology Corporation (ADT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C+15E approval and any communication needed with the national authority. Any and all acts carried out by ADT on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Note: Product name: Wireless LAN 802.11n Device Model name: U98H038 Sincerely yours, Signature: Jason Lin Compliance Engineer HON HAI PRECISION IND. CO., LTD. TEL:(02) 22676511 FAX: (02) 22676512 E-mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

07/06/14 1/1 1 OF 1 PTT LABEL U98H038.00 U98H038.00 V Jian-xia Mylar#25+PP(light) Notes: 1. " " 5mm jianxia Cai jun 500.XXXXX.XXX 0336 FCC ID: MCLU98H038 IC: 2878D-U98H038 Hon Hai Precision Ind.Co.,Ltd. Model: U98H038. 2:1 1:1 0336 FCC ID: MCLU98H038 IC: 2878D-U98H038 Hon Hai Precision Ind.Co.,Ltd. Model: U98H038.

(Fig. 1) FCC ID: MCLU98H038 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9

Report No.: SA960524H05 1 Issued: June 08, 2007 RF EXPOSURE REPORT REPORT NO.: SA960524H05 MODEL NO.: U98H038 FCC ID: MCLU98H038 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Hon Hai PRECISION IND.CO.,LTD ADDRESS: 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. Report No.: SA960524H05 2 Issued: June 08, 2007 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Report No.: SA960524H05 3 Issued: June 08, 2007 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device Report No.: SA960524H05 4 Issued: June 08, 2007 6 Test Results 6.1 Antenna Gain There are three antennas provided to this EUT, please refer to the following table: Gain(dBi) Transmitter Circuit Antenna Type Antenna Connector 2412~2462 (MHz) 5150~5250 (MHz) 5725~5850 (MHz) Chain(0) 1.5 0.5 -0.86 Chain(1) -2.5 -11.4 -7.31 Chain(2) Printed Reverse SMA 1.28 1.09 -0.43 6.2 Output Power Into Antenna & RF Exposure value: For 2.4GHz For Part 802.11b: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 64.269 0.018 1.0 6 2437 80.910 0.023 1.0 11 2462 65.464 0.018 1.0 For Part 802.11g: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 54.200 0.015 1.0 6 2437 128.825 0.036 1.0 11 2462 70.795 0.020 1.0 DRAFT 802.11n (20MHz) OFDM modulation: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 64.421 0.018 1.0 6 2437 176.208 0.050 1.0 11 2462 86.050 0.024 1.0 Report No.: SA960524H05 5 Issued: June 08, 2007 DRAFT 802.11n (40MHz) OFDM modulation: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2422 27.565 0.008 1.0 4 2437 53.827 0.015 1.0 7 2452 33.943 0.010 1.0 For 5GHz Operated in 5150MHz ~ 5350MHz: (15.407) For Part 802.11a: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5180 7.046 0.0018 1.0 4 5240 23.281 0.0060 1.0 DRAFT 802.11n (20MHz) OFDM modulation: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5180 18.719 0.005 1.0 4 5240 27.673 0.007 1.0 DRAFT 802.11n (40MHz) OFDM modulation: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5190 17.696 0.005 1.0 3 5230 49.908 0.013 1.0 Report No.: SA960524H05 6 Issued: June 08, 2007 Operated in 5725 ~ 5850MHz band: (15.247) For Part 802.11a: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5745 100.00 0.0181 1.0 3 5785 100.00 0.0180 1.0 5 5825 75.858 0.0137 1.0 DRAFT 802.11n (20MHz) OFDM modulation: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5745 164.120 0.033 1.0 3 5785 164.120 0.033 1.0 5 5825 155.908 0.031 1.0 DRAFT 802.11n (40MHz) OFDM modulation: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5755 193.223 0.038 1.0 3 5795 155.677 0.031 1.0

Report No.: RF960524H05 1 Report Format Version 2.0.5 FCC TEST REPORT (15.407) REPORT NO.: RF960524H05 MODEL NO.: U98H038 RECEIVED: May 24, 2007 TESTED: June 04 to 07, 2007 ISSUED: June 07, 2007 APPLICANT: Hon Hai PRECISION IND.CO.,LTD ADDRESS: 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation TEST LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. This test report consists of 101 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. No. 2177-01 Report No.: RF960524H05 2 Report Format Version 2.0.5 Table of Contents 1. CERTIFICATION..........................................................................................4 2. SUMMARY OF TEST RESULTS..................................................................5 2.1 MEASUREMENT UNCERTAINTY...........................................................................6 3. GENERAL INFORMATION..........................................................................7 3.1 GENERAL DESCRIPTION OF EUT..........................................................................7 3.2 DESCRIPTION OF TEST MODES..........................................................................10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.........................................14 3.4 DESCRIPTION OF SUPPORT UNITS....................................................................15 3.5 CONFIGURATION OF SYSTEM UNDER TEST.....................................................15 4. TEST TYPES AND RESULTS....................................................................16 4.1 CONDUCTED EMISSION MEASUREMENT..........................................................16 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT...........................16 4.1.2 TEST INSTRUMENTS...............................................................................16 4.1.3 TEST PROCEDURES................................................................................17 4.1.4 DEVIATION FROM TEST STANDARD......................................................17 4.1.5 TEST SETUP.............................................................................................18 4.1.6 EUT OPERATING CONDITIONS...............................................................18 4.1.7 TEST RESULTS........................................................................................19 4.2 RADIATED EMISSION MEASUREMENT...............................................................25 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................25 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS26 4.2.3 TEST INSTRUMENTS...............................................................................27 4.2.4 TEST PROCEDURES................................................................................28 4.2.5 DEVIATION FROM TEST STANDARD......................................................28 4.2.6 TEST SETUP.............................................................................................29 4.2.7 EUT OPERATING CONDITION.................................................................29 Below 1GHz Test Data.........................................................................................................30 4.2.8 TEST RESULTS........................................................................................30 Above 1GHz Test Data.........................................................................................................31 4.2.9 TEST RESULTS........................................................................................31 4.3 PEAK TRANSMIT POWER MEASUREMENT........................................................49 4.3.1 LIMITS OF PEAK TRANSMIT POWER MEASUREMENT.........................49 4.3.2 TEST INSTRUMENTS...............................................................................49 4.3.3 TEST PROCEDURE..................................................................................50 Report No.: RF960524H05 3 Report Format Version 2.0.5 4.3.4 DEVIATION FROM TEST STANDARD......................................................50 4.3.5 TEST SETUP.............................................................................................50 4.3.6 EUT OPERATING CONDITIONS...............................................................50 4.3.7 TEST RESULTS........................................................................................51 4.4 PEAK POWER EXCURSION MEASUREMENT.....................................................64 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT......................64 4.4.2 TEST INSTRUMENTS...............................................................................64 4.4.3 TEST PROCEDURE..................................................................................65 4.4.4 DEVIATION FROM TEST STANDARD......................................................65 4.4.5 TEST SETUP.............................................................................................65 4.4.6 EUT OPERATING CONDITIONS...............................................................65 4.4.7 TEST RESULTS........................................................................................66 4.5 PEAK POWER SPECTRAL DENSITY MEASUREMENT.......................................74 4.5.1 LIMITS OF PEAK POWER SPECTRAL DENSITY MEASUREMENT........74 4.5.2 TEST INSTRUMENTS...............................................................................74 4.5.3 TEST PROCEDURES........................................................................…

Text truncated - open the document above for the full version.

Report No.: RF960524H05 64 Report Format Version 2.0.5 4.4 PEAK POWER EXCURSION MEASUREMENT 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT Frequency Band Limit 5.15 – 5.25 GHz 13dB 5.25 – 5.35 GHz 13dB 5.47 – 5.725GHz 13dB 5.725 – 5.825 GHz 13dB 4.4.2 TEST INSTRUMENTS Description & Manufacturer Model No. Serial No. Calibrated Until ADVANTEST SPECTRUM ANALYZER U3772 160100280 April. 10.2008 NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. Report No.: RF960524H05 65 Report Format Version 2.0.5 4.4.3 TEST PROCEDURE 1. The transmitter output was connected to the spectrum analyzer. 2. Set the spectrum bandwidth span to view the entire spectrum. 3. Using peak detector and Max-hold function for Trace 1 (RB=1MHz, VB=3MHz) and 2 (RB=1MHz, VB=300KHz). 4. The largest difference between Trace 1 and Trace 2 in any 1MHz band on any frequency was recorded. 4.4.4 DEVIATION FROM TEST STANDARD No deviation 4.4.5 TEST SETUP 4.4.6 EUT OPERATING CONDITIONS The software provided by client to enable the EUT under transmission condition continuously at specific channel frequencies individually. EUT SPECTRUM Report No.: RF960524H05 66 Report Format Version 2.0.5 4.4.7 TEST RESULTS 802.11a OFDM modulation MODULATION TYPE BPSK TRANSFER RATE 6Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 22deg.C, 68%RH, 972hPa TESTED BY Phoenix Huang CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER EXCURSION (dB) PEAK to AVERAGE EXCURSION LIMIT (dB) PASS/FAIL 1 5180 10.17 13 PASS 4 5240 9.73 13 PASS CH1 Report No.: RF960524H05 67 Report Format Version 2.0.5 CH4 Report No.: RF960524H05 68 Report Format Version 2.0.5 DRAFT 802.11n (20MHz) OFDM MODULATION: MODULATION TYPE BPSK TRANSFER RATE 6.5Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 22deg.C, 68%RH, 972hPa TESTED BY Phoenix Huang PEAK POWER EXCURSION (dB) CHANNEL CHANNEL FREQUENCY (MHz) Chain (0) Chain(2) PEAK to AVERAGE EXCURSION LIMIT (dB) PASS/FAIL 1 5180 9.76 10.15 13 PASS 4 5240 10.66 10.04 13 PASS Report No.: RF960524H05 69 Report Format Version 2.0.5 For Chain (0): CH1 CH4 Report No.: RF960524H05 70 Report Format Version 2.0.5 For Chain (2): CH1 CH4 Report No.: RF960524H05 71 Report Format Version 2.0.5 DRAFT 802.11n (40MHz) OFDM MODULATION: MODULATION TYPE BPSK TRANSFER RATE 13.5Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 22deg.C, 68%RH, 972hPa TESTED BY Phoenix Huang PEAK POWER EXCURSION (dB) CHANNEL CHANNEL FREQUENCY (MHz) Chain (0) Chain(2) PEAK to AVERAGE EXCURSION LIMIT (dB) PASS/FAIL 1 5190 9.42 9.62 13 PASS 3 5230 9.77 9.94 13 PASS Report No.: RF960524H05 72 Report Format Version 2.0.5 For Chain (0): CH1 CH3 Report No.: RF960524H05 73 Report Format Version 2.0.5 For Chain (2): CH1 CH3 Report No.: RF960524H05 74 Report Format Version 2.0.5 4.5 PEAK POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF PEAK POWER SPECTRAL DENSITY MEASUREMENT Frequency Band Limit 5.15 ~ 5.25GHz 4dBm 5.25 ~ 5.35GHz 11dBm 5.47 – 5.725GHz 11dBm 5.725 ~ 5.825GHz 17dBm 4.5.2 TEST INSTRUMENTS Description & Manufacturer Model No. Serial No. Calibrated Until ADVANTEST SPECTRUM ANALYZER U3772 160100280 April. 10.2008 NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. Report No.: RF960524H05 75 Report Format Version 2.0.5 4.5.3 TEST PROCEDURES 1. The transmitter output was connected to the spectrum analyzer. 2. Set RBW=1MHz, VBW=3MHz. The PPSD is the highest level found across the emission in any 1MHz band. 4.5.4 DEVIATION FROM TEST STANDARD No deviation 4.5.5 TEST SETUP 4.5.6 EUT OPERATING CONDITIONS Same as 4.3.6 EUT SPECTRUM ANALYZER Report No.: RF960524H05 76 Report Format Version 2.0.5 4.5.7 TEST RESULTS 802.11a OFDM modulation MODULATION TYPE BPSK TRANSFER RATE 6Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 22deg.C, 68%RH, 972hPa TESTED BY Phoenix Huang CHANNEL CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 1MHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 1 5180 -2.34 4 PASS 4 5240 2.97 4 PASS CH1 Report No.: RF960524H05 77 Report Format Version 2.0.5 CH4 Report No.: RF960524H05 78 Report Format Version 2.0.5 DRAFT 802.11n (20MHz) OFDM MODULATION: MODULATION TYPE BPSK TRANSFER RATE 6.5Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 22deg.C, 68%RH, 972hPa TESTED BY Phoenix Huang RF POWER LEVEL IN 1MHz BW (dBm) CHANNEL CHANNEL FREQUENCY (MHz) Chain (0) Chain(2) MAXIMUM LIMIT (dBm) PASS/FAIL 1 5180 -1.31 -1.25 4 PASS 4 5240 0.52 0.03 4 PASS Report No.: RF960524H05 79 Report Format Version 2.0.5 For Chain (0): CH1 CH4 Report No.: RF960524H05 80 Report Format Version 2.0.5 For Chain (2): CH1 CH4 Report No.: RF960524H05 81 Report Format Version 2.0.5 DRAFT 802.11n (40MHz) OFDM MODULATION: MODULATION TYPE BPSK TRANSFER RATE 13.5Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 22deg.C, 68%RH, 972hPa TESTED BY Phoenix Huang RF POWER LEVEL IN 1MHz BW (dBm) CHANNEL CHANNEL FREQUENCY (MHz) Chain (0) Chain(2) MAXIMUM LIMIT (dBm) PASS/FAIL 1 5190 -4.74 -4.56 4 PASS 3 5230 0.26 -0.28 4 PASS Report No.: RF960524H05 82 Report Format Version 2.0.5 For Chain (0): CH1 CH3 Report No.: RF960524H05 83 Report Format Version 2.0.5 For Chain (2): CH1 CH3 Report No.: RF960524H05 84 Report Format Version 2.0.5 4.6 FREQUENCY STABILITY 4.6.1 LIMITS OF FREQUENCY STABILITY MEASUREMENT The frequency tolerance of the carrier signal shall be maintained within +/- 0.02% of the operating frequency over a temperature variation of –30 degrees to 50 degrees C at normal supply voltage, and for a variation in the primary supply voltage from 85% to 115% of the rated supply voltage at a temperature of 20 degrees C. 4.6.2 TEST INSTRUMENTS Description & Manufact…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
