Block Diagram The figure below shows a functional block diagram. The following sections describe each block separately. 18.432MHz Crystal Add/Data Buss Control Buss 44MHz 44MHz Radio Buss TxInt Tx LINK & ACTIVITY LEDs NC 7529 Processor 4.1 FLASH Memory 4.3 SDRAM 4.4 Radio FPGA/ A/D Converter 4.8 JTAG Connector 4.2 User Interface Connector 4.7 Antenna Connector 4.9.4 802.11 Power Amp 4.9.5 44MHz Osc 4.9.7 Radio Voltage Regulator 4.9.6 Antenna Switch, BALUN. Saw Filter 4.9.2 LEDs 4.14 Rx 802.11 2.4 GHz Xceiver 4.9.1 Digi Wi-EM Block Diagram

TCB TÜV America Inc 10040 Mesa Rim Road San Diego CA 92121 RE: FCC ID: MCQ-50M879 submittal as modular device 1. The modular transmitter must have its own RF shielding. This is intended to ensure that the module does not have to rely upon the shielding provided by the device into which it is installed in order for all modular transmitter emissions to comply with Part 15 limits. It is also intended to prevent coupling between the RF circuitry of the module and any wires or circuits in the device into which the module is installed. Such coupling may result in non-compliant operation. The entire RF section of the product is protected by a metal shield. This shield is a one piece metal "clam shell" design that slides over the RF section of the PCB (see Figure 5). The PCB is inserted into the "open" end of the shield. The reverse SMA antenna connectors fit through holes in the "closed" end of the shield. There are three solder tabs on each side (top and bottom) of the shield that are aligned such that when the clam shell is closed, each pair of tabs will fit though one of three mounting holes in the PCB. As each tab pair enters the PCB mounting hole, they will slide past each other (forming a lap joint) and will be soldered to the PCB. The shield is tied to ground through the three tab pairs and an interference fit between the antenna SMA connectors and the holes in the "closed end of the shield. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The transmitter has buffered modulation / data inputs. 3. The modular transmitter must have its own power supply regulation. This is intended to ensure that the module will comply with Part 15 requirements regardless of the design of the power supplying circuitry in the device into which the module is installed. The transmitter has its own power supply regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). Any antenna used with the module must be approved with the module, either at the time of initial authorization or through a Class II permissive change. The “professional installation” provision of Section 15.203 may not be applied to modules. The transmitter complies with the antenna requirements of Section 15.203 & 15.204(c). The antenna connection implements a unique "reverse thread" sma connector. The antenna that ships with the product was the one tested with it. The professional installation provision of section 15.203 does not apply. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified or commercially available (see Section 15.31(i)). The transmitter was tested in a stand-alone configuration and complies with the Part 15 emission requirements. The power lines and I/O lines do not contain ferrites. The power lines are length typical of actual use. The support equipment connected during testing was unmodified. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. FCC ID is on the product label. Labeling instructions for the end user are in the product manual. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. The transmitter complies with all applicable requirements. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require…

Text truncated - open the document above for the full version.

Wi-EM - Top View Wi-EM - Bottom View Wi-EM - Assembly Edge View Wi-EM - Top with shield (view 1) Wi-EM - Top with shield (view 2) Wi-EM - Top with shield (open) Wi-EM - Bottom with shield (View 1) Wi-EM - Bottom with shield (View 2) Wi-EM - Bottom with shield (open) Wi-EM - Shield

FCC ID: MCQ-5ØM879 The FCC ID will be silkscreened on the device. Compliance statement will be placed on host device along with "Contains FCC ID: MCQ-50M879" and in manual. See other exhibits for details.

Wi-EM - Top View Wi-EM - Bottom View Wi-EM - Assembly Edge View Wi-EM - Top with shield (view 1) Wi-EM - Top with shield (view 2) Wi-EM - Top with shield (open) Wi-EM - Bottom with shield (View 1) Wi-EM - Bottom with shield (View 2) Wi-EM - Bottom with shield (open) Wi-EM - Shield

PRODUCT SERVICE TEST RESULT SUMMARY FCC PART 15 SUBPART C Section 15.247 FCC PART 15 SUBPART C Section 15.207 Conducted Emission Requirements MANUFACTURER'S NAME Digi International NAME OF EQUIPMENT Digi Connect Wi-EM 802.11b radio to 2 serial ports converter module TYPE OF EQUIPMENT 802.11B 11 Mbit 2.4 GHz radio transceiver to dual TTL serial port module MODEL NUMBER 50000879-xx Rev 1P MANUFACTURER'S ADDRESS 11001 Bren Road East Minnetonka, MN 55343 TEST REPORT NUMBER WC402191 TEST DATE 07 May 2004 29 June 2004 According to testing performed at TÜV Product Service Inc, the above-mentioned unit is in compliance with the electromagnetic compatibility requirements defined in FCC Part 15 Subpart C Sections 15.207 and 15.247. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications necessary for compliance made during testing on the above mentioned date(s) must be implemented in all production units for compliance to be maintained. TÜV Product Service Inc, as an independent testing laboratory, declares that the equipment tested as specified above conforms to the requirements of FCC Part 15 Subpart C Sections 15.207 and 15.247. Date: 23 July 2004 Location: Taylors Falls MN J. C. Sausen T. K. Swanson USA Tested By Reviewed By Not Transferable File No. WC402191, Page 1 of 14 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE EMC EMISSION - T E S T R E P O R T Test Report File No. : WC402191 Date of issue: 23 July 2004 Model No. : 50000879-xx Rev 1P Product Name : Digi Connect Wi-EM 802.11b radio to 2 serial ports converter module Product Type : 802.11B 11 Mbit 2.4 GHz radio transceiver to dual TTL serial port module Applicant : Digi International Manufacturer : Digi International License holder : Digi International Address : 11001 Bren Road East : Minnetonka, MN 55343 Test Result : „ Positive † Negative Test Project Number : Reference(s) WC402191 Total pages including Appendices 57 TÜV Product Service Inc is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO/IEC Guide 25 and EN 45001. TÜV Product Service Inc reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. TÜV Product Service Inc shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV Product Service Inc issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the US government. TÜV Product Service Inc and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI File No. WC402191, Page 2 of 14 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE D I R E C T O R Y - EMISSIONS Page(s) A) Documentation Test report 1 - 10 Directory 2 Test Regulations 3 Deviations from standard / Summary 11 Test-setups (Photos) 12 - 14 Test-setup (drawing) Appendix A B) Test data 6 dB Bandwidth [15.247 (a)(2)] 9 Peak Power Out [15.247 (b)] 9 Antenna Directional Gain [15.247 (b)(3)(i)] 9 Peak Power Spectral Density [15.247 (d)] 9 FCC 15.207 - Conducted emissions 150 kHz – 30 MHz 5, 10 Spurious radiated emissions (electric field) (restricted bands) 30 MHz – 25.0 GHz 5, 6, 10 Spurious conducted emissions 30 MHz – 25.0 GHz 10 C) Appendix A Test Data Sheets and Test Setup Drawing(s) A1 – A36 D) Appendix B Constructional Data Form(s) and/or Product Information Form(s) B1 – B5 E) Appendix C Measurement Protocol C1 - C2 File No. WC402191, Page 3 of 14 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: -------------------------------------------------------------------------------- † - EN 50081-1 / 1991 † - EN 55011 / 1998 † - Group 1 † - Group 2 w/Amendment A1:1999 † - Class A † - Class B † - EN 55013 / 1990 † - EN 55014 / 1987 † - Household appliances and similar † - Portable tools † - Semiconductor devices † - EN 55014 / A2:1990 † - EN 55014 / 1993 † - Household appliances and similar † - Portable tools † - Semiconductor devices † - EN 55015 / 1987 † - EN 55015 / A1:1990 † - EN 55015 / 1993 † - EN 55022 / 1987 † - Class A † - Class B „ - FCC Part 15 Subpart C Section 15.247 „ - FCC Part 15 Subpart C Section 15.207 Conducted Emission Requirements File No. WC402191, Page 4 of 14 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE Environmental conditions in the lab: Actual Temperature : 16 - 23 °C Relative Humidity : 28 - 44 % Atmospheric pressure : 99.0 - 100.0 kPa Power supply system : 60 Hz – 115 VAC – 1 Phase Sign Explanations: † - not applicable „ - applicable File No. WC402191, Page 5 of 14 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE Emissions Test Conditions: CONDUCTED EMISSIONS (Interference Voltage) The C ONDUCTED EMISSIONS (INTERFERENCE VOLTAGE) measurements were performed at the following test location: † - Test not applicable „ - Wild River Lab Large Test Site (Open Area Test Site) † - Wild River Lab Small Test Site (Open Area Test Site) † - Oa…

Text truncated - open the document above for the full version.

Test-setup photo(s): Conducted emission 150 kHz - 30 MHz Test-setup photo(s): Radiated emission 30 MHz - 25000 MHz without 12” extension cable with antenna Test-setup photo(s): Radiated emission 30 MHz - 25000 MHz with 12” extension cable with antenna TEST SETUP FOR EMISSIONS TESTING WILD RIVER LAB Large Test Site Notes: 1. Items shown in dotted lines are located on the floor below the test area. It is 5 meters vertically from the ground floor to the test area. 2. 50 Hz, 60 Hz, and 400 Hz are power panels for alternating current. 3. The antenna may be positioned horizontally 3, 10 or 30 meters from the center of the turntable. 4. The circle is a 6.7 meter diameter turntable. 5. A ground plane is in the plane of this sheet. 6. The test sample is shown in the azimuthal position representing zero degrees. EUT 0 90270 180 60 Hz 50 Hz 400 Hz Shielded E ANTENNA TEST SETUP FOR EMISSIONS TESTING WILD RIVER LAB Small Test Site (STS) EUT 180 270 90 0 60 Hz 50 Hz Turntable is 1.2 meters in diameter Enlarged View of Shelter (4 meters square) STS Building Shelter 3 meter antenna 10 meter antenna 30 meter antenna Turntable Control Cable Ground Screen (34 meters long x 12 meters wide) 8 meters
