MIVGSM2428GSM/ GPRS Personal Tracker

- 1 - Mini MT User Guide GSM2428UG001 Version:1.01 13 June, 2011 - I - General TERMS OF USE OF NEW MATERIALS - PLEASE READ CAREFULLY From time to time, Enfora, in its sole discretion, may make available for download on its website (www.enfora.com), or may transmit via mail or email, updates or upgrades to, or new releases of, the firmware, software or documentation for its products (collectively, 'New Materials'). Use of such New Materials is subject to the terms and conditions set forth below, and may be subject to additional terms and conditions as set forth in Enfora's Technical Support Policy (posted on its website) and/or any written agreement between the user and Enfora. All New Materials are provided AS IS. Enfora makes no warranty or representation with respect to the merchantability, suitability, functionality, accuracy or completeness of any such New Materials. The user of such New Materials assumes all risk (known or unknown) of such use. Enfora reserves all rights in such New Materials. The user shall have only a revocable and limited license to use such New Materials in connection with the products for which they are intended. Distribution or modification of any New Materials without Enfora's consent is strictly prohibited. IN NO EVENT WILL ENFORA BE RESPONSIBLE FOR ANY INCIDENTAL, INDIRECT, CONSEQUENTIAL OR SPECIAL DAMAGES AS A RESULT OF THE USE OF ANY NEW MATERIALS. ENFORA'S MAXIMUM LIABILITY FOR ANY CLAIM BASED ON THE NEW MATERIALS SHALL NOT EXCEED FIFTY U.S. DOLLARS ($50). Copyright © 2011 Enfora, Inc. All rights reserved. Complying with all applicable copyright laws is the responsibility of the user. Without limiting the rights under copyright, no part of this document may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means (electronic, mechanical, photocopying, recording or otherwise), or for any purpose, without the express written permission of Enfora, Inc. Enfora and the Enfora logo are either registered trademarks or trademarks of Enfora, Inc. in the United States. 251 Renner Pkwy Richardson, TX 75080 USA Phone: (972) 633-4400 Fax: (972) 633-4444 Email: [email protected] www.enfora.com - II - Warranty Information [Revised: 11/11/2010] This warranty applies to (a) products sold directly by Enfora, unless a different warranty is specified in a written agreement between Enfora and the purchaser; and (b) products sold to end users through a distributor authorized by Enfora, but only where the authorized distributor does not provide a separate warranty on such products, and Enfora has agreed to provide this warranty to such end users. If you purchased the product from an authorized distributor, please check whether this warranty from Enfora, or a separate warranty from the distributor, applies to your purchase. This warranty does not apply to any (i) accessories or batteries for the products; or (ii) demonstration samples or prototypes of the products. Unless otherwise provided in a written agreement between Enfora and the purchaser, all such accessories, batteries, samples or prototypes are provided by Enfora AS IS without any warranty of any kind. Enfora warrants to the original purchaser of the product from Enfora or its authorized distributor (as applicable) that, for a period of one (1) year from the date of shipment of the product from Enfora, the product hardware will be substantially free from defects in material or workmanship under normal operation, and the product firmware will perform substantially in accordance with the product documentation provided by Enfora. Enfora does not warrant that (a) the product hardware or firmware will meet the purchaser's requirements; (b) the operation of the product hardware or firmware will be uninterrupted or error-free; or (c) the product, when integrated in, or combined with, other products or software not supplied by Enfora, will continue to perform substantially in accordance with the product documentation. This limited warranty is for the benefit of the original purchaser, and is not transferable. During the warranty period, Enfora, at its expense and in its sole discretion, will repair the product, or replace the product with a corresponding or equivalent product, if it is determined to have a covered defect, provided that the purchaser first notifies Enfora (directly or through its authorized distributor from which the product was purchased) of any such defect, furnishes Enfora with a proof of purchase (if required), requests and obtains a return merchandize authorization (RMA) number from Enfora, and returns the product under that RMA to Enfora (or, at Enfora's option, to its authorized distributor), with the shipping charges being prepaid by purchaser.If, upon reasonable examination of the returned product, Enfora does not substantiate the defect claimed by purchaser, or determines that the defect is not covered under this limited warranty, Enfora will not be required to repair or replace the product, but may instead reship the product to the purchaser (or, at Enfora's option, to its authorized distributor where the product can be made available to purchaser), in which case the purchaser shall be responsible for paying Enfora's cost for reshipping the product to purchaser (or to Enfora's authorized distributor), and Enfora's usual charges for unpacking, testing, and repacking the product for reshipment to purchaser (or to Enfora's authorized distributor). Purchaser shall bear the risk of loss or damage in transit to any product returned by purchaser to Enfora, or any returned product not found to be defective or covered under this warranty, and reshipped by Enfora to purchaser (or to Enfora's authorized distributor). In the event Enfora repairs or replaces a defective product covered by this limited warranty, the repaired or replacement product will be covered under this limited warranty for the remainder of the original warranty period on the defective - III - p…

Text truncated - open the document above for the full version.

251 Renner Pkwy, Richardson, Texas 75080 | 972.633.4400 Tel | 972.633.4444 Fax | www.enfora.com May 15, 2011 AGENCY AUTHORIZATION Telecommunication Certification Body RFI Global Services Ltd. Pavilion A Ashwood Park Basingstoke Hampshire RG23 8BG United Kingdom To whom it may concern This is to certify that Enfora, Inc. authorises RFI Global Services Ltd. to act on our behalf for the application of the GSM2428 to RFI Global Services Ltd. Telecommunication Certification Body. We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Sincerely Rob Holden Director Compliance Engineering Enfora, Inc. 972‐633‐4400

251 Renner Pkwy, Richardson, Texas 75080 | 972.633.4400 Tel | 972.633.4444 Fax | www.enfora.com June 15, 2011 REQUEST FOR CONFIDENTIALITY Telecommunication Certification Body RFI Global Services Ltd. Subject: Certification Application FCC ID: MIVGSM2428 Pursuant to Sections 0.457 and 0.459 of CFR 47 Enfora, Inc., requests confidentiality with regard to the following documents in the filing for equipment approval identified by FCC ID MIVGSM2428, Enfora PN GSM2428. (1) Schematic diagram located in electronic files – GSM2428_Schematic.pdf; GSM0408_Schematic.pdf (2) Block Diagram located in electronic file – GSM2428_BlockDiagram.pdf; GSM0408_BlockDiagram.pdf (3) Bill of Materials (BOM) located in electronic file – GSM2428_BOM.pdf; GSM0408_BOM.pdf (4) Operational Description located in electronic files – GSM2428_OperationalDescription.pdf It is the opinion of Enfora, Inc., that disclosure of this information would result in significant loss of revenue as it contains Enfora Intellectual Property. As such this information should be kept confidential indefinitely. Sincerely Rob Holden Director Compliance Engineering Enfora, Inc. 972‐633‐4400

Mini-MTr Barcode Label GSM2428MGXXX Rev. A Notes: 1. Label is not to scale. Refer to LAB-0002-0001 documentation for dimensions. 2. Label text to be printed using Zebra Technologies 5100 resin ribbon, P/N 05100BK06407 (Black), or Enfora Engineering approved equivalent. Revision History Date Rev Author Description 5/6/11 1 R Holden Initial release 5/17/2011 A R Holden Updated per IC requirement Serial Number And Bar Code IMEI Number And Bar Code FCC ID Number Industry Canada # xxxxxxxxxxxxx FCC ID: MIVGSM2428 123456789102345 IC: 4160A-GSM2428 Yyyyyyyyyyyyy Model: GSM2428 12345678901234 Enfora Part number and stock number

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Mini-MT (GSM2428) FCC ID: MIVGSM2428 IC Certification Number: 4160A-GSM2428 To: FCC Part 15.107 and 15.109: 2010 Subpart B & RSS-Gen Issue 3 December 2010 Test Report Serial No: RFI-RPT-RP78940JD10A This Test Report Is Issued Under The Authority Of Chris Guy, Head of Global Approvals: Checked By: Ian Watch Signature: Date of Issue: 23 March 2011 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI-RPT-RP78940JD1078940JD10A VERSION NO. 1.0 ISSUE DATE: 23 MARCH 2011 Page 2 of 18 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI-RPT-RP78940JD1078940JD10A VERSION NO. 1.0 ISSUE DATE: 23 MARCH 2011 RFI Global Services Ltd Page 3 of 18 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 5 2.4. Deviations from the Test Specification 5 3. Equipment Under Test (EUT) ....................................................................................................... 6 3.1. Identification of Equipment Under Test (EUT) 6 3.2. Description of EUT 6 3.3. Modifications Incorporated in the EUT 6 3.4. Additional Information Related to Testing 7 4. Operation and Monitoring of the EUT during Testing ............................................................... 8 4.1. Operating Modes 8 4.2. Configuration and Peripherals 8 5. Measurements, Examinations and Derived Results .................................................................. 9 5.1. General Comments 9 5.2. Test Results 10 5.2.1. Receiver/Idle Mode AC Conducted Spurious Emissions 10 5.2.2. Receiver/Idle Mode Radiated Spurious Emissions 13 6. Measurement Uncertainty .......................................................................................................... 17 Appendix 1. Test Equipment Used ................................................................................................ 18 TEST REPORT SERIAL NO: RFI-RPT-RP78940JD1078940JD10A VERSION NO. 1.0 ISSUE DATE: 23 MARCH 2011 Page 4 of 18 RFI Global Services Ltd 1. Customer Information Company Name: Enfora Inc.Enfora Inc Address: 251 Renner Parkway Richardson Texas 75080 United States TEST REPORT SERIAL NO: RFI-RPT-RP78940JD1078940JD10A VERSION NO. 1.0 ISSUE DATE: 23 MARCH 2011 RFI Global Services Ltd Page 5 of 18 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.107 and 47CFR15.109 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2010: Part 15 Subpart B (Unintentional Radiators) - Sections 15.107 and 15.109 Specification Reference: RSS-Gen Issue 3 December 2010 Specification Title: General Requirements and Information for the Certification of Radio Apparatus Site Registration: FCC: 209735; Industry Canada: 3245B-2 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 16 March 2011 to 17 March 2011 2.2. Summary of Test Results FCC Reference (47CFR) IC Reference Measurement Result Part 15.107 RSS-Gen 7.2.4 Receiver/Idle Mode AC Conducted Emissions Part 15.109 RSS-Gen 4.10/6.1 Receiver/Idle Mode Radiated Spurious Emissions Key to Results = Complied = Did not comply 2.3. Methods and Procedures Reference: ANSI C63.4 (2009) Title: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: RFI-RPT-RP78940JD1078940JD10A VERSION NO. 1.0 ISSUE DATE: 23 MARCH 2011 Page 6 of 18 RFI Global Services Ltd 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Brand Name: Enfora Inc Model Name or Number: Mini-MT (GSM2428) Serial Number: Not stated Hardware Version Number: A Software Version Number: 1.1.5 FCC ID: MIVGSM2428 IC Certification Number: 4160A-GSM2428 3.2. Description of EUT The equipment under test was a GSM/GPRS/GPS Mobile tracker that supports GSM850 and PCS1900 bands. 3.3. Modifications Incorporated in the EUT No modifications were applied to the EUT during testing. TEST REPORT SERIAL NO: RFI-RPT-RP78940JD1078940JD10A VERSION NO. 1.0 ISSUE DATE: 23 MARCH 2011 RFI Global Services Ltd Page 7 of 18 3.4. Additional Information Related to Testing Tested Technology: GSM850/PCS1900 Power Supply Requirement: Nominal 3.7V Type of Unit: Transceiver Receive Frequency Range: 869 to 894 MHz Receive Channels Tested: Channel ID Channel Number Channel Frequency (MHz) Bottom 128 869.2 Middle 190 881.6 Top 251 893.8 Receive Frequency Range: 1850 to 1990 MHz Receive Channels Tested: Channel ID Channel Number Channel Frequency (MHz) Bottom 512 1930.2 Middle 660 1959.8 Top 810 1989.8 TEST REPORT SERIAL NO: RFI-RPT-RP78940JD1078940JD10A VERSION NO. 1.0 ISSUE DATE: 23 MARCH 2011 Page 8 of 18 RFI Global Services Ltd 4. Operation and Monitoring of the EUT during Testing 4.1. Operating Modes The EUT was tested in the following operating mode(s): • Receive/Idle Mode. 4.2. Configuration and Peripherals The EUT was tested in the following configuration(s): • Receive/Idle mode with AC ch…

Text truncated - open the document above for the full version.
