MJYMPJHand Held Transmitter

3132 Brown Street Boise, ID 83714 Phone (208) 344-2015 Fax (208) 344-2103 February 10, 2008 RE : Circuit Description for MPJ Series Transmitter Author : Darrell Downam Users interface with the transmitter through a keypad on the front of the transmitter. By pressing a button on the keypad a signal is sent to the microprocessor. That signal in turn is converted into a number that is compiled with an address code, that is pre-selected and set by jumpers. This compiled number is the sent serially at 2.4KB/s to TX module. This signal is then processed by the tx module and radiated at 315.0 Mhz at a level not to exceed FCC standards. The tx module has an onboard 9.84 Mhz crystal oscillator that is used to generate the RF signal. The radiated signal is modulated at the 2.4KB/s rate in a Frequency Shift Modulation manor. The unit is battery powered and is controlled by an on/off switch. The battery voltage is obtained from 4 AA batteries that are converted to 5 VDC by a boost/buck DC-DC converter. This converter operates at 19Khz (approx.) and should not radiate any detrimental signals. Low battery conditions are indicated by a LED mounted in the case of the transmitter. The indicator will flash red when a button is pushed on the transmitter keypad. Under normal operation the LED will be a constant green indication. Applied Electronics Company

Applied Electronics Co. 3132 Brown St. Boise ID 83714 Phone (208) 344-2015 F A D NE JH K B C M L Applied Electronics Co. 3132 Brown St. Boise ID 83714 Phone (208) 344-2015 Applied Electronics Co. 3132 Brown St. Boise ID 83714 Phone (208) 344-2015

Report Number: B80212D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Hand Held Transmitter Model: MP4JSB-TX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15, SUBPART B and C TEST REPORT for HAND HELD TRANSMITTER Model: MP4JSB-TX Prepared for APPLIED ELECTRONICS COMPANY 3132 BROWN STREET BOISE, IDAHO 83714 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: MARCH 12, 2008 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 12 11 45 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B80212D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Hand Held Transmitter Model: MP4JSB-TX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCIRPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 Radiated Emissions (Spurious and Harmonics) Test 13 7.2 Radiated Emissions (Spurious and Harmonics) Test (Continued) 14 7.3 Bandwidth of the Fundamental 15 8. CONCLUSIONS 16 Report Number: B80212D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Hand Held Transmitter Model: MP4JSB-TX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of 3 Meter Radiated Test Site Report Number: B80212D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Hand Held Transmitter Model: MP4JSB-TX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Hand Held Transmitter Model: MP4JSB-TX S/N: B06s4-161 Product Description: See Expository Statement Modifications: The EUT was not modified during the testing. Manufacturer: Applied Electronics Company 3132 Brown Street Boise, Idaho 83714 Test Date: February 12, 2008 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209 and 15.231 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz This test was not performed because the EUT operates on battery power only and cannot be plugged into the AC public mains. 2 Radiated RF Emissions, 10 kHz – 3.15 GHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.231. Report Number: B80212D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Hand Held Transmitter Model: MP4JSB-TX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Hand Held Transmitter, Model: MP4JSB-TX. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.231. Report Number: B80212D1 FCC Part 1…
