MKZ0207232XG2.4GHz Transceiver Radio With RS232 Interface

OTC Wireless Document Number: DOC-001-0901 AirEZY2411-RS232 Utility User’s Guide Version 0.2 – Oct 14, 2002 OTC Wireless AirEZY2411-RS232 DIAGNOSTIC AND CONFIGURATION USER’S GUIDE Document Number: DOC-001-0901 Version 0.1 - July 19, 2002 ABSTRACT This document describes the AirEZY2411-RS232 product graphical user interface (GUI) for configuration and monitoring of the product. OTC Wireless Document Number: DOC-001-0901 AirEZY2411-RS232 Utility User’s Guide Version 0.2 – Oct. 14, 2002  Copyright 2000,2002 OTC Wireless OTC Wireless Document Number: DOC-001-0901 AirEZY2411-RS232 Utility User’s Guide Version 0.2 – Oct 14, 2002 3 REVISION HISTORY REV DATE AUTHOR REASON FOR CHANGE 0.1 July 19, 2002 Chau Dang Initial Draft 0.2 October 14, 2002 Yan Zheng Adding FCC warning statement OTC Wireless Document Number: DOC-001-0901 AirEZY2411-RS232 Utility User’s Guide Version 0.2 – Oct 14, 2002 4 NOTICE The information contained in this document is subject to change without notice. OTC Wireless MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF FITNESS AND MERCHANTABILITY FOR A PARTICULAR PURPOSE. OTC Wireless will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material. OTC Wireless assumes no responsibility for the use or reliability of interconnected equipment that is not furnished by them. This document contains proprietary information which is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of OTC Wireless. The information contained herein has been prepared by OTC Wireless solely for use by OTC Wireless, its employees, agents and customers. Dissemination of the information and/or concepts contained herein to other parties is prohibited without the prior written consent of OTC Wireless. Copyright  2000,2001 by OTC Wireless. All rights reserved. OTC Wireless Document Number: DOC-001-0901 AirEZY2411-RS232 Utility User’s Guide Version 0.2 – Oct 14, 2002 5 Regulatory Compliance FCC Part 15 Declaration of Conformity (DoC) The equipment is confirmed to comply with the requirements of FCC Part 15 rules. The operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. FCC Rules and Regulations - Part 15 Warning: This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the Federal Communications Commissions Rules and Regulations. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: . Relocate your WLAN equipped laptop computer. . Increase the separation between the WLAN equipped laptop computer and other electronics. . Connect the WLAN equipped laptop computer into an outlet on a circuit different from that of other electronics. . Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by OTC Wireless could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20cm between the radiator & your body. OTC Wireless Document Number: DOC-001-0901 AirEZY2411-RS232 Utility User’s Guide Version 0.2 – Oct 14, 2002 6 TABLE OF CONTENTS 1. INTRODUCTION...................................................................................................7 1.1 Scope and Objectives...................................................................................................................................7 1.2 About the Program......................................................................................................................................7 2. THE PROGRAM’S DETAILS..............................................................................8 2.1 Protocols:......................................................................................................................................................8 2.2 Main Windows:.............................................................................................................................................8 3. DETAIL FUNCTIONALITY OF THE PROGRAM’S AREAS........................12 3.1 Connection and Overall Status: (Fig 2).................................................................................................12 3.2 Radio Status: (Fig 3)..................................................................................................................................13 3.3 Configuration: (Fig 4)...............................................................................................................................13 3.4 RS232 and WLAN Statistics: (Fig 5)....................................................................................................14 3.5 Security and Advanced Security: (Fig 6 and 7)....................................................................................15 3.6 Testing: (Fig 8)................................…

Text truncated - open the document above for the full version.

FCC ID LABEL

FCC CFR47 PART 15 CERTIFICATION TEST REPORT FOR 2.4 GHz TRANSCEIVER RADIO with RS232 INTERFACE MODEL: WiSER, WiSER2000, WiSER2100, WiSER2200, WiSER2300, AND WiSER2400 BRAND NAME: OTC FCC ID: MKZ0207232XG REPORT NUMBER: 02U1319-1 ISSUE DATE: JULY 10, 2002 Prepared for OTC WIRELESS, INC. 48507 MILMONT DRIVE FREMONT, CA 94538 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561 F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02U1319-1 DATE: JULY 10, 2002 EUT: 2.4GHz Transceiver Radio with RS232 Interface FCC ID: MKZ0207232XG Page 2 of 47 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. TEST RESULT CERTIFICATION.................................................................................................3 2. EUT DESCRIPTION.........................................................................................................................4 3. TEST METHODOLOGY..................................................................................................................4 4. TEST FACILITY...............................................................................................................................4 5. ACCREDITATION AND LISTING................................................................................................4 5.1. LABORATORY ACCREDITATIONS AND LISTINGS..........................................................................5 6. CALIBRATION AND UNCERTAINTY.........................................................................................6 6.1. MEASURING INSTRUMENT CALIBRATION.....................................................................................6 6.2. MEASUREMENT UNCERTAINTY....................................................................................................6 6.3. TEST AND MEASUREMENT EQUIPMENT.......................................................................................7 7. SUPPORT EQUIPMENT / EUT SETUP.........................................................................................7 8. APPLICABLE RULES AND BRIEF TEST RESULT.................................................................10 9. TEST SETUP, PROCEDURE AND RESULT..............................................................................15 9.1. PEAK POWER OUTPUT..........................................................................................................15 9.2. 6 DB BANDWIDTH MEASUREMENT...................................................................................15 9.3. CONDUCTED SPURIOUS EMISSION...................................................................................20 9.4. PEAK POWER SPECTRAL DENSITY....................................................................................24 9.5. RESTRICTED BAND EDGE MEASUREMENT.....................................................................28 9.6. RADIATED EMISSION............................................................................................................31 9.6.1. RADIATED EMISSION AND RESTRICTED BANDS........................................................31 9.7. POWER LINE CONDUCTED EMISSION...............................................................................42 9.8. SETUP PHOTOS.......................................................................................................................44 REPORT NO: 02U1319-1 DATE: JULY 10, 2002 EUT: 2.4GHz Transceiver Radio with RS232 Interface FCC ID: MKZ0207232XG Page 3 of 47 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: OTC WIRELESS, INC. 48507 MILMONT DRIVE FREMONT, CA 94538 USA CONTACT PERSON: YAN ZHENG / PRODUCTION ENGINEER TELEPHONE NO: (510) 490-8288 extension 215 EUT DESCRIPTION: TRANSCEIVER RADIO WITH RS232 INTERFACE MODEL NUMBER: WiSER, WiSER2000, WiSER2100, WiSER2200, WiSER2300, AND WiSER2400 DATE TESTED: MAY 28, 2002-JUNE 28, 2002 TYPE OF EQUIPMENT INTENTIONAL RADIATOR EQUIPMENT TYPE 2.4GHz TRANSCEIVER MEASUREMENT PROCEDURE ANSI 63.4 / 1992, TIA/EIA 603 PROCEDURE CERTIFICATION FCC RULE CFR 47 PART 15 Subpart C Compliance Certification Services, Inc. tested the above equipment for compliance with the requirement set forth in CFR 47, PART 15 Subpart C. The equipment in the configuration described in this report, shows the measured emission levels emanating from the equipment do not exceed the specified limit. Note: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. Approved & Released For CCS By: Tested By: STEVE CHENG KERWIN CORPUZ EMC ENGINEERING MANAGER ASSOCIATE EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 02U1319-1 DATE: JULY 10, 2002 EUT: 2.4GHz Transceiver Radio with RS232 Interface FCC ID: MKZ0207232XG Page 4 of 47 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full,…

Text truncated - open the document above for the full version.

REPORT NO: 02U1319-1 DATE: JULY 10, 2002 EUT: 2.4GHz Transceiver Radio with RS232 Interface FCC ID: MKZ0207232XG Page 44 of 47 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9.8. SETUP PHOTOS Radiated Emission below 1 GHz measurement REPORT NO: 02U1319-1 DATE: JULY 10, 2002 EUT: 2.4GHz Transceiver Radio with RS232 Interface FCC ID: MKZ0207232XG Page 45 of 47 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Conducted Emission measurement REPORT NO: 02U1319-1 DATE: JULY 10, 2002 EUT: 2.4GHz Transceiver Radio with RS232 Interface FCC ID: MKZ0207232XG Page 46 of 47 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Radiated Emission above 1 GHz measurement Radiated Emission above 18 GHz measurement REPORT NO: 02U1319-1 DATE: JULY 10, 2002 EUT: 2.4GHz Transceiver Radio with RS232 Interface FCC ID: MKZ0207232XG Page 47 of 47 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Antenna Port Terminal measurement END OF REPORT
