MNJ-MO173TXBaby Monitor

WiFi Baby Monitor You can also:Send Us a Text: 1- 812-203-4747 (US and Canada OnlyCarrier Fees May Apply)Find Us Online: www. safety1st.com Email Us: [email protected] Give Us a Call: 1-800-544-1108 (Toll Free) STRANGULATION HAZARD - Children have STRANGLED in cords. Keep this cord out of reach of children (more than 3 feet (0.9 m) away). Do not remove this tag. Use wall clips provided to secure cord away from baby’s reach. Only use the AC adapter provided by the manufacturer. NEVER use an extension cord with the AC adapter. 5.17.21 4358-8154B MODEL: MO173 WARNING: 1 2 In The Box Please read the following instructions and warnings carefully. Keep these instructions for future reference. Features • Phillips screwdriver • Drill with 3/16” size bit • Hammer • Pencil Tools required for mounting monitor (not included): 7x Drywall Anchors Micro USB Power Port MicrophoneBack of MonitorMicro SD Card Slot (on side of monitor)LensSpeakerIR LEDs (behind faceplate)Reset ButtonStatus LED 7x Screws 5x Wall Clips 1x Reset Tool 1x Power Adapter 1x Wall Mount 1x Micro USB Cable 9’ 10” (3m) long 3x User Manual (English, French, & Spanish) 1x Monitor 3 4 Getting Started Download Safety 1st App Download the Safety 1st Connected app by searching for Safety 1st in the app store. Setup1. Connect the micro USB cable with power adapter to monitor. Staus LED will fl ash red and the device is now ready for pairing. 2. On your mobile device, follow the step by step instructions in the Safety 1st Connected app for setup. 3. Once paired, the status LED will turn blue. 4. Explore the features and functionality within the Safety 1st Connected app. Wi-Fi ConnectivityA 2.4GHz Wireless Internet with > 2Mbps available download/upload speeds is required. Check the Wi-Fi signal strength from your internet service provider. To reduce signal interference or echoes, avoid placing the monitor near major electrical appliances, large metal or concrete surfaces. Cleaning & Disposal CleaningClean product with a slightly damp cloth or with an anti-static cloth. ALWAYS unplug from electrical outlet before cleaning.NEVER USE cleaning agents or abrasive solvents. DO NOT clean any part of the product with thinners or other solvents and chemicals - this may cause permanent damage to the product which is not covered by the warranty.Keep product away from hot, humid areas or strong sunlight, and do not let it get wet. Every effort has been made to ensure high standards of reliability of your product. However, if something does go wrong, please do not try to repair it yourself - contact Consumer Care for assistance. DisposalAt the end of the product life cycle, you should not dispose of this product with normal household waste. Take this product to a collection point for the recycling of electrical and electronic equipment. Some of the product materials can be re-used if you take them to a recycling point. By reusing some parts or raw materials from used products you make an important contribution to the protection of the environment. Please contact your recycling center in case you need more information on the collection points in your area. 5 6 Mounting Monitor Tools required for mounting monitor (not included): Wall MountingBefore Wall Mounting the monitor, download the app and complete the pairing process. This will help ensure optimal placement. The following instructions are for securely mounting to a drywall surface.1. Examine the room and determine the optimal placement on the wall. Mark this location with a pencil. IMPORTANT: Ensure that the baby monitor is at least 3 ft (0.9 m) away from the crib. 2. Place the included wall mount onto the wall at the marked location, ensuring the arrow is pointing upwards. Using a pencil, make a mark through the two screw holes. Put the wall mount to the side for later use. 3. Using a 3/16” drill bit, drill a hole 1.0” (2.54 cm) deep on the pencil marks. DO NOT drill through the wall mount holes. 4. Insert drywall anchor into the hole. If necessary, lightly tap with a hammer until the drywall anchor is fl ush with the wall surface. Note: If mounting to a wall stud, drywall anchors are not required. 5. Align the holes of the wall mount with the drywall anchors and using a screwdriver, hand tighten a screw into each of the drywall anchors. DO NOT over tighten. continued on next page 3’ (0.9 m) STRANGULATION HAZARD - Children have STRANGLED in cords. Keep this cord out of reach of children (more than 3 feet (0.9 m) away). Do not remove this tag. Use wall clips provided to secure cord away from baby’s reach. Only use the AC adapter provided by the manufacturer. NEVER use an extension cord with the AC adapter. WARNING: • Phillips screwdriver • Drill with 3/16” size bit • Hammer • Pencil Flat Surface Mounting1. Determine an optimal monitor placement, keeping the monitor and power cord at least 3 ft (0.9 m) away from crib. The monitor should be placed on a fl at surface, such as a chest of drawers, a desk, or a shelf. 2. Before proceeding to the next step. Ensure that the viewing angle is to your liking by verifying the app. Rotate and tilt the monitor as needed. 3. Follow Step 9 a-d of Wall Mounting: WALL CLIPS. Use the included wall clips to secure the cord at least 3 ft (0.9 m) away from the crib. This will help reduce the chance of the monitor slipping, sliding, rotating or falling over. 7 8 6. Locate the hole underneath the base of the monitor and place it on the wall mount. 7. Applying light pressure to the base, slide the monitor DOWN on the wall mount until it clicks fi rmly into place. DO NOT pull on the monitor head. Rotate and tilt the monitor to ensure it is fully attached to the wall mount.a. To remove the monitor from the wall, push up on the base until it releases from the mount. NEVER leave the monitor hanging on the wall mount without clicking in place. 8. Before proceeding to the next step. Ensure that the viewing angle is to your liking by verifying the app. Rotate and tilt the monitor…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 6 External Photos for SZCR2103000015AT FCC ID:MNJ-MO173TX SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 6 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 6

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 7 Internal Photos for SZCR2103000015AT FCC ID: MNJ-MO173TX SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 7 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 7 Antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 7 of 7

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001502 Page: 1 of 7 Keny Xu EMC Laboratory Manager 1 Cover page RF Exposure Evaluation Report Application No.: SZCR2103000015AT(GZHL2103006421IP) Applicant: Dorel Juvenile Group Address of Applicant: 2525 State Street Columbus Indiana 47201-7494 United States Vendor: Shenzhen Longzhiyuan Manufacture： Shenzhen Longzhiyuan Technology co., Ltd Address of Manufacture： Floor 5, Building B, Zhuangbian Second Industrail Zone, Hezhou Industrial District, Hangcheng Street, Boan District, Shenzhen, Guangdong, China Equipment Under Test (EUT): Product Name: Baby Monitor Model No.: MO173 Country of Origin: China Country of Destination: The USA FCC ID: MNJ-MO173TX Standards: 47 CFR Part 1.1307 47 CFR Part 1.1310 47 CFR Part 2.1091 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2021-03-09 Date of Test: 2021-03-11 to 2021-03-19 Date of Issue: 2021-03-19 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001502 Page: 2 of 7 2 Version Revision Record Version Chapter Date Modifier Remark 01 2021-03-19 Original Authorized for issue by: Damon Su/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001502 Page: 3 of 7 3 Contents Page 1 COVER PAGE .............................................................................................................................................. 1 2 VERSION ...................................................................................................................................................... 2 3 CONTENTS .................................................................................................................................................. 3 4 GENERAL INFORMATION .......................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF EUT ................................................................................................................. 4 4.2 TEST LOCATION .......................................................................................................................................... 5 4.3 TEST FACILITY ............................................................................................................................................ 5 4.4 DEVIATION FROM STANDARDS ..................................................................................................................... 5 4.5 ABNORMALITIES FROM STANDARD CONDITIONS ............................................................................................ 5 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER ................................................................................. 5 5 RF EXPOSURE EVALUATION .................................................................................................................... 6 5.1 RF EXPOSURE COMPLIANCE REQUIREMENT ................................................................................................ 6 5.1.1 Limits ................................................................................................................................................ 6 5.1.2 Test Procedure ................................................................................................................................ 6 4.1.3 EUT RF EXPOSURE EVALUATION ............................................................................................................... 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001502 Page: 4 of 7 4 General Information 4.1 General Description of EUT Power supply: DC 5V. Adapter Model:KA06E-0501000AU Input: AC 100-240V 50/60Hz 0.25A Output: DC 5V 1A. Cable(s): usb cable, unshield 3.0m Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz; 802.11n(HT40): 2422MHz to 2452MHz Operating Bandwidth: 802.11b/g/n(HT20): 20MHz; 802.11n(HT40): 40MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK); 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11; 802.11n(HT40):7 Channel Spacing: 5MHz Antenna Type: PCB Antenna Antenna Gain: 3dBi SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001502 Page: 5 of 7 4.2 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 No tests were sub-contracted. 4.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1178 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Designation Number: CN1178. Test Firm Registration Number: 406779. • Innovation, Science and Economic Development Canada SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized by ISED as an accredited testing laboratory. CAB identifier: CN0006. IC#: 4620C. 4.4 Deviatio…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 1 of 143 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2103000015AT(GZHL2103006421IP) Applicant: Dorel Juvenile Group Address of Applicant: 2525 State Street Columbus Indiana 47201-7494 United States Vendor: Shenzhen Longzhiyuan Manufacture： ：： ： Shenzhen Longzhiyuan Technology co., Ltd Address of Manufacture： ：： ： Floor 5, Building B, Zhuangbian Second Industrail Zone, Hezhou Industrial District, Hangcheng Street, Boan District, Shenzhen, Guangdong, China Equipment Under Test (EUT): EUT Name: Baby Monitor Model No.: MO173 Country of Origin: China Country of Destination: The USA FCC ID: MNJ-MO173TX Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2021-03-09 Date of Test: 2021-03-11 to 2021-03-19 Date of Issue: 2021-03-19 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 2 of 143 Revision Record Version Chapter Date Modifier Remark 01 2021-03-19 Original Authorized for issue by: Damon Su/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 3 of 143 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Emission Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 4 of 143 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1 2 TEST SUMMARY ................................................................................................................................. 3 3 CONTENTS ......................................................................................................................................... 4 4 GENERAL INFORMATION .................................................................................................................. 6 4.1 DETAILS OF E.U.T. ......................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 6 4.3 MEASUREMENT UNCERTAINTY ......................................................................................................... 7 4.4 TEST LOCATION ............................................................................................................................. 8 4.5 TEST FACILITY ............................................................................................................................... 8 4.6 DEVIATION FROM STANDARDS ......................................................................................................... 8 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 8 5 EQUIPMENT LIST ............................................................................................................................... 9 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................13 6.1 ANTENNA REQUIREMENT ................................................................................................................13 6.1.1 Test Requirement: ..................................................................................................................13 7 RADIO SPECTRUM MATTER TEST RESULTS .................................................................................14 7.1 CONDUCTED PEAK OUTPUT POWER ................................................................................................14 7.1.1 E.U.T. Operation .....................................................................................................................14 7.1.2 Test Mode Description ............................................................................................................14 7.1.3 Test Setup Diagram ................................................................................................................15 7.1.4 Measurement Procedure and Data .........................................................................................15 7.2 MINIMUM 6DB BANDWIDTH .............................................................................................................16 7.2.1 E.U.T. Operation .....................................................................................................................16 7.2.2 Test Mode Description .......................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 71 of 143 Test Mode: 00; Polarity: Horizontal; Modulation:802.11g; Bandwidth:20MHz; Channel:High SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 72 of 143 Test Mode: 00; Polarity: Vertical; Modulation:802.11g; Bandwidth:20MHz; Channel:High SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 73 of 143 Test Mode: 00; Polarity: Horizontal; Modulation:802.11n; Bandwidth:20MHz; Channel:Low SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 74 of 143 Test Mode: 00; Polarity: Vertical; Modulation:802.11n; Bandwidth:20MHz; Channel:Low SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 75 of 143 Test Mode: 00; Polarity: Horizontal; Modulation:802.11n; Bandwidth:20MHz; Channel:middle SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 76 of 143 Test Mode: 00; Polarity: Vertical; Modulation:802.11n; Bandwidth:20MHz; Channel:middle SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 77 of 143 Test Mode: 00; Polarity: Horizontal; Modulation:802.11n; Bandwidth:20MHz; Channel:High SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 78 of 143 Test Mode: 00; Polarity: Vertical; Modulation:802.11n; Bandwidth:20MHz; Channel:High SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 79 of 143 Test Mode: 00; Polarity: Horizontal; Modulation:802.11n; Bandwidth:40MHz; Channel:Low SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 80 of 143 Test Mode: 00; Polarity: Vertical; Modulation:802.11n; Bandwidth:40MHz; Channel:Low SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 81 of 143 Test Mode: 00; Polarity: Horizontal; Modulation:802.11n; Bandwidth:40MHz; Channel:middle SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 82 of 143 Test Mode: 00; Polarity: Vertical; Modulation:802.11n; Bandwidth:40MHz; Channel:middle SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 83 of 143 Test Mode: 00; Polarity: Horizontal; Modulation:802.11n; Bandwidth:40MHz; Channel:High SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 84 of 143 Test Mode: 00; Polarity: Vertical; Modulation:802.11n; Bandwidth:40MHz; Channel:High SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 85 of 143 8 Emission Test Results 8.1 Conducted Emissions at AC Power Line (150kHz-30MHz) Test Requirement: 47 CFR Part 15, Subpart C 15.207 Test Method: ANSI C63.10 (2013) Section 6.2 Limit: Frequency of emission(MHz) Conducted limit(dBμV) Quasi-peak Average 0.15-0.5 66 to 56* 56 to 46* 0.5-5 56 46 5-30 60 50 *Decreases with the logarithm of the frequency. Detector: Peak for pre-scan (9kHz resolution bandwidth) 0.15M to 30MHz 8.1.1 E.U.T. Operation Operating Environment: Temperature: 21.2 °C Humidity: 60.3 % RH Atmospheric Pressure: 1010 mbar 8.1.2 Test Mode Description Pre-scan / Final test Mode Code Description Final test 00 TX mode_Keep the EUT in continuously transmitting mode with all modulation types. All data rates for each modulation type have been tested and found the data rate @ 1Mbps is the worst case of IEEE 802.11b; data rate @ 6Mbps is the worst case of IEEE 802.11g; data rate @ 6.5Mbps is the worst case of IEEE 802.11n(HT20); data rate @ 13.5Mbps is the worst case of IEEE 802.11n(HT40). Only the data of worst case is recorded in the report. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 86 of 143 8.1.3 Test Setup Diagram 8.1.4 Measurement Procedure and Data 1) The mains terminal disturbance voltage test was conducted in a shielded room. 2) The EUT was connected to AC power source through a LISN 1 (Line Impedance Stabilization Network) which provides a 50ohm/50μH + 5ohm linear impedance. The power cables of all other units of the EUT were connected to a second LISN 2, which was bonded to the ground reference plane in the same way as the LISN 1 for the unit being measured. A multiple socket outlet strip was used to connect multiple power cables to a single LISN provided the rating of the LISN was not exceeded. 3) The tabletop EUT was placed upon a non-metallic table 0.8m above the ground reference plane. And for floor-standing arrangement, the EUT was placed on the horizontal ground reference plane. 4) The test was performed with a vertical ground reference plane. The rear of the EUT shall be 0.4 m from the vertical ground reference plane. The vertical ground reference plane was bonded to the horizontal ground reference plane. The LISN 1 was placed 0.8 m from the boundary of the unit under test and bonded to a ground reference plane for LISNs mounted on top of the ground reference plane. This distance was between the closest points of the LISN 1 and the EUT. All other units of the EUT and associated equipment was at least 0.8 m from the LISN 2. 5) In order to find the maximum emission, the relative positions of equipment and all of the interface cables must be changed according to ANSI C63.10 on conducted measurement. Remark: LISN=Read Level+ Cable Loss+ LISN Factor SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 87 of 143 Test Mode: 00; Line: Live line Modulation:802.11b; Bandwidth:20MHz; Channel:Low SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZCR210300001501 Page: 88 of 143 Test Mode: 00; Line: Neutral Line Modulation:802.11b; Bandwidth:20MHz; Channel:Low SGS-C…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 3 Setup Photos for SZCR2103000015AT FCC ID: MNJ-MO173TX SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 3 1 Photographs Conducted Emissions at AC Power Line (150kHz-30MHz) Radiated Spurious Emissions SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 3
