MS3UFM2003Wireless MP3 adapter

Ever Win International Corporation UFM2003 Wireless MP3 adapter User guide Setup Instructions: The UFM2003 Wireless MP3 adapter is your own personal FM broadcast station intended for use exclusively inside an automobile with a 12v cigarette lighter outlet. 1. Plug the UFM2003 Wireless MP3 adapter to the headphone jack of your MP3 player. 2. Plug the UFM2003 Wireless MP3 adapter to your automobile 12v cigarette lighter outlet. 3. Set the UFM2003 Wireless MP3 adapter to desired FM channel by setting the slide switch to the desired frequency. Note that there are four (4) Frequency selections available: 88.1mhz, 88.3mhz, 88.5mhz, and 88.7mhz. For best results, set the frequency to a vacant spot on the FM band. 4. Tune your FM radio to the same frequency as selected on the UFM2003. 5. Select an album on the MP3 player and set it to playback. Adjust MP3 player volume control to normal volume setting like when using a headset. 6. Adjust FM radio volume control to desired level. 7. If audio seems loud and distorted, decrease MP3 player volume control. If audio seems weak and noisy, increase MP3 player volume control. The volume control on your MP3 player behaves like the volume control on a disc jockey console in a real broadcast station. There is an optimum setting for best FM audio fidelity. Once you have found that optimum setting, do not adjust any further and leave it alone. Use the volume control on you FM radio for normal adjustments of volume level inside the automobile. 8. When traveling, you may observe that reception may become noisy or altogether displaced by a commercial FM broadcast station. This is because you may be approaching the location of an FM broadcast station operating on the same frequency as the UFM2003 wireless MP3 player adapter. In such a case, change the frequency of the UFM2003 wireless MP3 player (step-3 above). Warranty does not include malfunction caused by accident, misuse, contact with solvent chemicals or malfunction caused by tampering or modification. This warranty excludes all incidental or consequential damages. Some states do not allow the exclusion or limitation of consequential damages so the above limitation may not apply to you. For Warranty Service, the product must be returned at your expense to place of purchase. Return policies may vary. If you cannot reasonably do this, please contact us stating the nature of the defect and date of purchase. Include a copy of your sales slip or proof of purchase. Your repaired or replacement equipment will be returned to you at our expense. This warranty gives you specific rights: you may also have other legal rights which vary from state to state. FCC Notice: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: changes or modifications not expressly approved by Monster Cable Products Inc. may void the users authority to operate this device. Note: This equipment has been tested and found to comply with the limits for a class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z Reorient or relocate the receiving antenna z Increase the separation between the equipment and receiver z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected z Consult the dealer or an experienced radio/TV technician for help. Ever Win International Corporation 17579 Railroad Street City of Industry CA 91748 Phone 626-810-8218 FCC ID : MS3UFM2003

Ever Win International Corp. 17579 Railroad Street * City of Industry, CA 91748 Tel: (626) 810-8218 Fax: (626) 810-6628 Web-site: www.everwin.com Request for Confidentiality June 11, 2004 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification of Application FCC ID: MS3UFM2003 Please be advised that the following information is to be held confidential and behalf of Ever Win International Corporation. * Schematics * Block Diagrams The application contains technical information, which Ever Win International Corporation deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Ever Win International Corporation By: Alex Samson R&D Engineer Ever Win International Corp. Chatsworth Engineering Dept 17579 Railroad Street City of Industry CA 91748 USA ph (626) 810-8218 ph (818) 709-3786

Ever Win International Corp. 17579 Railroad Street * City of Industry, CA 91748 Tel: (626) 810-8218 Fax: (626) 810-6628 Web-site: www.everwin.com Letter of Authorization June 11, 2004 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that Ever Win International Corporation authorizes JMR Electronics to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Board, Inc (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Ever Win International Corporation By: Alex Samson R&D Engineer Ever Win International Corp. Chatsworth Engineering Dept 17579 Railroad Street City of Industry CA 91748 USA ph (626) 810-8218 ph (818) 709-3786

E l e c t r o n i c s Inc June 14, 2004 FCC ID: MS3UFM2003 American Telecommunications Body, Inc Attention: Applications Examiner Applicant: Ever Win International Corporation 17579 Railroad Street City of Industry CA 91748 Applicant FRN :0011064656 Equipment: Low power audio FM Transmitter for personal use FCC ID: MS3UFM2003 Specification: 47 CFR Part 15 Subpart C (15.239) unlicensed Certification Dear Examiner: The following application for Grant of Equipment Authorization is presented on behalf of Ever Win International Corporation. for the unlicensed Certification of their Model: UFM2003. Enclosed, please find a complete data and documentation package demonstrating that this device complies with the technical requirements of 47 CFR, Part 15 Subpart C If you have any questions, please contact the undersigned, who is authorized to act as Agent. Sincerely, Leon Kogan Technical Director JMR Electronics [email protected] <mailto:[email protected]> Phone: (818) 739-1122 Fax: (818) 727-2215 20400 Plummer Street Chatsworth, CA 91311 Tel (818) 993-4801 Fax (818) 993-9173 Internet; www.jmr.com

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 17, 2004 RE: FCC ID: MS3UFM2003_ATCB001432 Attention: Leon Kogan I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please provide the users manual or users guide with all of the appropriate FCC part 15 statements (i.e. 15.19, 15.21 etc). 2. Please note that for part 15 devices 47CFR 2.1033(a)(6) states that “The report shall include sample calculations showing how the measurement results were converted for comparison with the technical requirements.” Please note that only the end results are shown in the report. Please provide the required sample calculations and information on how the measurement factors (i.e. antenna factor, cable factor and preamp factor is included in the measurement results. 3. Please note that 15.239(a) states, “(a) Emissions from the intentional radiator shall be confined within a band 200 kHz wide centered on the operating frequency.” Please note that, while the plots labeled for bandwidth appear to be compliant, the plots on pages 18 and 20 indicate that the bandwidth is greater than 200 kHz. The plots on pages 18 and 29 use a video bandwidth of 3kHz while the plots of the bandwidth on pages 28 through 30 use 30kHz. Generally, the lower video bandwidth would reduce side band emissions as it begins to average (please note that averaging does not actually begin to have meaning until the video bandwidth is no greater than 1/10 the resolution bandwidth). Please note that as the lower video bandwidth would begin to reduce the side bands and as these plots seem to be greater than 200kHz bandwidth, the plots on pages 18 and 20 of the report would seem to disagree with the bandwidth plots on pages 28 through 30. Please explain. 4. Please note that the antenna should not to be laid on wooden table tops. The antenna should be supported by nonconductive material (foamed-polystyrene blocks for example) above the table. As the antenna is part of the cable, please verify that the device is still compliant when the antenna is properly placed above the wooden table top. Alternately, please provide evidence that the EUT setup as shown is the worse case antenna placement. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

From: Leon Kogan [mailto:[email protected]] Sent: Wednesday, July 07, 2004 9:53 AM To: [email protected] Cc: Alex Samson (E-mail) Subject: RE: MS3UFM2003_ATCB001432 Importance: High Dennis, Below you will find the information that was requested Leon Kogan Technical Director JMR Electronics [email protected] <mailto:[email protected] > Phone: (818) 739-1122 Fax: (818) 727-2215 -----Original Message----- From: dward ATCB [mailto:[email protected]] Sent: Wednesday, July 07, 2004 8:47 AM To: Leon Kogan Subject: RE: MS3UFM2003_ATCB001432 Hi Leon Please address items 1 and 2 of the comments 1. Please provide the users manual or users guide with all of the appropriate FCC part 15 statements (i.e. 15.19, 15.21 etc). This has not been fully addressed as it lists Monster Cable in the non- modification statement in the manual. As Monster Cable is not the grantee, this is not appropriate. [Leon Kogan] This is a typo and it will be corrected 2. Please note that for part 15 devices 47CFR 2.1033(a)(6) states that "The report shall include sample calculations showing how the measurement results were converted for comparison with the technical requirements." Please note that only the end results are shown in the report. Please provide the required sample calculations and information on how the measurement factors (i.e. antenna factor, cable factor and preamp factor is included in the measurement results. This has not been properly addressed in that the report does not explain how the transducer factors are accounted for in the final results. Are they added, subtracted, are the feed into the analyzer software, etc? [Leon Kogan] The field strength (FS) is calculated by adding the antenna factor (AF) cable losses (CL) and subtracting the amplifier gain (AG) from the measured reading (SA). The basic equation is as follows: FS = SA + AF + CL - AG Once these have been properly addressed the grant can be issued rapidly. A statement saying the manual will be changed and showing the actual statement on non modification would be sufficient and a statement indicating how the transducers are accounted for in the report would also be sufficient. Thanks Dennis From: dward ATCB [mailto:[email protected]] Sent: Wednesday, July 07, 2004 8:26 AM To: 'Leon Kogan' Subject: RE: MS3UFM2003_ATCB001432 HI Leon Please note that as Monster Cable is not the grantee it thus has no authority related to the device granted. This means that unless evidence can be provided that Monster Cable is Ever Win International Corporation or has authority from Win International, then the non modification statement in the manual is wrong and needs to be changed. The easiest thing is to remove Monster Cable and put 'the party responsible for compliance'. Otherwise Win International Corporation will have to be in the statement. Please correct the manual as needed. Dennis From: Leon Kogan [mailto:[email protected]] Sent: Tuesday, July 06, 2004 1:50 PM To: [email protected] Subject: RE: MS3UFM2003_ATCB001432 Importance: High Dear Mr. Ward: An additional information and corrections that were requested in your letter on June 17, 2004 are uploaded to ATCB web. Please review revised Test Report, Test setup photographs and User's Manual. I hope these answers are sufficient. If there are any further questions, please feel free to email me or call me back . Sincerely, Leon Kogan Technical Director JMR Electronics [email protected] <mailto:[email protected]> Phone: (818) 739-1122 Fax: (818) 727-2215

External Photos of the EUT EUT: AUDIO FM TRANSMITTER. MODEL : UFM-2003

Location of FCC ID Label on product: View showing entire product (less FCC label):

Internal photo of EUT EUT: AUDIO FM TRANSMITTER. MODEL : UFM-2003 FM Modulator Open enclosure EUT: AUDIO FM TRANSMITTER. MODEL : UFM-2003 FM Modulator PCB components side EUT: AUDIO FM TRANSMITTER. MODEL : UFM-2003 FM Modulator PCB solder side

FCC ID: MS3UFM2003 Circuit Description Please refer to schematic for reference. 1) U2 is a complete FM stereo transmitter IC. This circuit has a stereo audio input and a 75-ohm RF output. 2) Frequency of operation is determined by hard-contact switch selection made by the Channel selector slide switch. 3) There are four (4) channel selections available for transmit frequency. 4) There is no ON/OFF switch for this product. Circuit goes ON when product is plugged to automobile cigarette lighter outlet. Product is exclusively designed for in-automobile use only so that user can listen to MP3 player via the automobile FM radio system. 5) Power consumption of FM transmitter IC is 20ma typical at 5v. Antenna: 1) Wires connecting to MP3 player are used as the antenna. 2) RF schematic of antenna is shown below:

Report No.: 040437 rev.02 US FCC ID: MS3UFM2003 Client: Ever Win International Corp. 023 NVLAP LAB CODE: 200413-0 July 1, 2004 Test Record Product Verification According to FCC Part 15 Subparts C for Ever Win International Corp. MODEL: UFM-2003 This report contains confidential information. The owner of this report may make duplicates of it, provided all pages are copied. Report No.: 040437 rev.02US FCC ID: MS3UFM2003 Client: Ever Win International Corp. Page 2 of 31 TABLE OF CONTENTS Revision history 3 Introduction – Test Plan 3 1.0 Certification of Test Record 4 2.0 General Information 5 2.1 Client Information 5 2.2 Administrative Data 5 3.0 Description of Equipment Under Test (EUT) 6 3.1 Brief Description of the EUT 6 3.2 Test Run 6 3.3 Block-Diagram of the Test Setup 7 3.4 Support Equipment 7 3.5 Cabling Configuration 7 3.6 Photographs of the EUT 8 3.7 EUT Modifications 12 3.8 Photographs of EUT Modifications 12 4.0 Test equipment used 13 5.0 Field Strength of Fundamental and Emissions within permitted band 14 5.1. Channel 88.1 MHz 15 5.2. Channel 88.3 MHz 17 5.3. Channel 88.7 MHz 19 5.4 Photographs of Test Set-Up 22 6.0 Radiated Emissions. 23 6.1. Channel 88.1 MHz 24 6.2. Channel 88.3 MHz 25 6.3. Channel 88.7 MHz 26 6.4 Photographs of Test Set-Up 27 7.0 Occupied channel bandwidth 28 7.1. Channel 88.1 MHz 28 7.2. Channel 88.3 MHz 29 7.3. Channel 88.7 MHz 30 7.4 Photographs of Test Set-Up 31 Report No.: 040437 rev.02US FCC ID: MS3UFM2003 Client: Ever Win International Corp. Page 3 of 31 Revision History Revision Date Description of Changes Author 0.1 June 9. 2004 Initial document S. Sohn 0.2 July 1,2004 Revised pages:: S. Sohn Introduction – Test Plan This report describes the results of all measurements made on portable FM transmitter which falls under the class of intentional radiator by the FCC Part 15 Subpart C Rules and Regulations. This EUT is designated: Wireless Audio FM Transmitter for personal use. Model : UFM-2003 The EUT was tested in full compliance with the FCC Regulations using the methods of FCC Part 15 Subpart C “Intentional Radiators”; ANSI C63.4: 2000 and Part 2 “Frequency Allocations and Radio Treaty Matters; General Rules and Regulations”. The results of the testing indicate that the MSF0001 met the Part 15 C limits and requirements. Report No.: 040437 rev.02US FCC ID: MS3UFM2003 Client: Ever Win International Corp. Page 4 of 31 1.0 CERTIFICATION OF TEST DATA Verification statement. The data, data evaluation and equipment configuration represented herein are a true and accurate representation of the test sample (EUT), and characteristics and measurements obtained as of the dates and the times of the test under the conditions specified and to the methods of FCC Part 15, Subpart C “Intentional Radiators” and Part 2 “Frequency Allocations and radio Treaty Matters; General Rules and regulations” The test results provided with this report, indicate that the equipment tested: WIRELESS AUDIO FM TRANSMITTER FOR PERSONAL USE. MODEL : UFM-2003 is compliant with the following Rules and Regulations A. 47 Code of Federal Regulations, Part 15 Subpart C B. 47 Code of Federal Regulations, Part 2 C. ANSI C63.4: 2000 Report approved by: Leon Kogan Technical Director, JMR Compliance Engineering, 20400 Plummer Street, Chatsworth CA 91311. E-mail:[email protected] Report No.: 040437 rev.02US FCC ID: MS3UFM2003 Client: Ever Win International Corp. Page 5 of 31 2.0 GENERAL INFORMATION 2.1 Client Information Company Name: Ever Win International Corp. Contact: Alex Samson Company Address: 17579 Railroad Street City of Industry, CA 91748 Phone: (818) 709-3786 2.2 Administrative Data Device tested: Wireless Audio FM Transmitter for personal use Model: UFM-2003 Equipment category: Intentional Radiators Accessories: N/A Expository Statement: This device is intended for personal use. Purpose of test: Compliance to FCC Rules and Regulations, Part 15, Subpart C Date of test: 06/29/04 Place of the test: JMR Electronics, Inc. Compliance Engineering Laboratory 20400 Plummer Street Chatsworth, CA 91311 Phone: (818) 993-4801 Report No.: 040437 rev.02US FCC ID: MS3UFM2003 Client: Ever Win International Corp. Page 6 of 31 3.0 Description of Equipment Under Test (EUT) 3.1 Brief Description of the EUT The EUT is a portable FM Transmitter which is designed to connect to a personal MP3 player and allow reception of the transmitted signal using a standard FM radio. There are four (4) available channels. Pressing switch will increment the frequency to the next channel. There is no ON/OFF switch for this product. Circuit goes ON when product is plugged to automobile cigarette lighter outlet. This product also supplies 12v operating power to MP3 player. Power consumption of FM transmitter IC is 20ma typical at 5v. Wires connecting to MP3 player are used as the antenna. Alteration of antenna by user is not possible. The EUT was configured on a table top. device and was tested with standard MP3 player connected. The modulation frequency was provided by external Test Oscillator HP 651B. Operating frequencies : 88.1, 88.3, 88.5, 88.7 MHz. Clock frequencies : 7.6 MHz Power Supply : External 12VDC battery. 3.2 Test Run 1) The EUT was connected through Monster Stubby cigarette lighter connector to the 12VDC battery Apple Ipod, as a standard MP3 player, was connected to the appropriate input/output of the EUT; 2) Test Oscillator HP 651B had been connected to the Aux In input of the docking connector when it was necessary. For test purposes the following three channels were selected for measurements : 88.1 MHz 88.3 MHz 88.7 MHz Each channel had generated its frequency continuously for the duration of the testing. The above mentioned set-up allowed the article to perform sufficiently for the test purposes and required time. Report No.: 040437 rev.02US FCC ID: MS3UFM2003 Client: Ever Win International Corp. Page 7 of 31 3.3 Block Diagram of the Test Setup 3.4 Support Equipment List: No Equipment Model S/N (last 6) Notes 1 HP T…

Text truncated - open the document above for the full version.

Photographs of Test Set-Up
