MSJK-2002DW1-WBAM/FM/Weather Band Broadcast Receiver

F F C C C C - - T T E E S S T T R R E E P P O O R R T T REPORT NO.: 45038 FCC – Test Report No. 45038 Date: 2006-05-08 Page 2 of 19 FCC listed testlab acc. to Section 2.948 of the FCC - Rules in compliance with the requirements of ANSI C63.4 - 2003 Product : AM/FM/WB Flashlight Radio & with Dynamo Product Class : Communication Receiver (Super Hetrodyne) Brand Name : - Model : K-2002DW1-WB Importer : KIN SUN ELECTRONICS LIMITED FCC – Test Report No. 45038 Date: 2006-05-08 Page 3 of 19 TABLE OF CONTENTS 1. Cover sheet 2. Introduction 3. Table of Contents 4. Laboratory Report 5. Test Location and Summary of Test Results 6. Test Equipment List 7. Radiated Emission Test Configuration (> 30MHz) 8. Test Results 9-12. Measurement Data 13. Notes for Radiated Emission Measurement (acc. to ANSI C63.4 – 2003) 14-19. Photographs FCC – Test Report No. 45038 Date: 2006-05-08 Page 5 of 19 Test Location International Electrical Certification Centre Ltd. Unit 602-605, 31 Lok Yip Road, On Lok Tsuen, Fanling, N.T., Hong Kong Summary of Test Results Radiated Emission: Test result: O.K. Test data: See attached data sheet Conducted Emission: Test result: N.A. Test data: N.A. FCC – Test Report No. 45038 Date: 2006-05-08 Page 6 of 19 TEST EQUIPMENT LIST Equipment Manufacturer Model Serial No. Remark Test Receiver Rohde & Schwarz ESVP 860688/022 20MHz – 1,300 MHz Antenna Schaffner CBL6111C 2791 30MHz – 1000MHz Antenna Schwarzbeck BBA 9106 / UHALP 9107 -- 30MHz – 1000MHz Antenna Mast System Schwarzbeck AM9104 -- Max. 4 meters height Loop Antenna Rohde & Schwarz HFH2-Z2 871336/48 9KHz-30MHz Turntable with Controller Drehtisch DT312 -- φ120 cm FCC – Test Report No. 45038 Date: 2006-05-08 Page 7 of 19 Radiated Emission Testprocedure (> 30MHz) Equipment under test (on turntable) Test receiver ESVP Rohde & Schwarz Required test distance: 3m Antenna system Schwarzbeck BBA 9106/ UHALP 9107 FCC – Test Report No. 45038 Date: 2006-05-08 Page 8 of 19 Test Results Radiated Emission : Test Requirement: FCC Part 15 Subpart B Section 15.109 Test Method: ANSI C63.4 : 2003 Frequency Range: 30MHz – 1000MHz Measurement Distance: 3 m Class: Class B Detector: Quasi-Peak Sample Operation and Measurement : The sample was tested under normal operation for various modes (receiving FM / Weather Band signals) with supply from new batteries. An initial pre-scan was performed in the Open Aera Test Site to find out the maximum emission level. Final measurement was then performed and the measurement data were shown on page 9 -12. Refer to page 13 for notes for radiation measurement. 141U1Date : 2006-05-08 Page 9 of 19 Radiated Emission According: FCC Part 15 Subpart B (15.109) IECC Ref:45038 Model:K-2002DW1-WBTest Equipment Applicant:KIN SUN ELECTRONICS LIMITEDReceiver: ESVP Rohde & Schwarz Antenna: Schaffner CBL6111C Ser.Nr.: -- Oper. Mode:FM Mode InterFreq:10.7MHz Receiving - frequency (MHz) Oscillator- frequency (MHz) Har- monics Reading dBμV Polari- zation Correction Factor (dB) Test Result dB(μV/m) Limit dB(μV/m) 89.8100.51<16H9.7<25.743.5 201.02<16H8.2<24.243.5 301.5316H13.029.046.0 402.04<16H15.8<31.846.0 502.55<16H18.0<34.046.0 603.06<16H19.4<35.446.0 703.57<16H20.9<36.946.0 804.08<16H22.1<38.146.0 904.59<16H23.7<39.746.0 98.3109.0116H10.226.243.5 218.0216H8.324.346.0 327.0328H13.641.646.0 436.04<16H16.7<32.746.0 545.05<16H19.6<35.646.0 654.06<16H20.1<36.146.0 763.07<16H22.3<38.346.0 872.08<16H23.4<39.446.0 981.09<16H24.9<40.954.0 108.0118.7122H10.732.743.5 237.4232H10.442.446.0 356.1329H14.543.546.0 474.84<16H17.5<33.546.0 593.55<16H19.3<35.346.0 712.26<16H21.2<37.246.0 830.97<16H22.9<38.946.0 949.68<16H25.6<41.646.0 The measurement results indicate that the test unit meets the FCC requiremen t 141U1Date : 2006-05-08 Page 10 of 19 Radiated Emission According: FCC Part 15 Subpart B (15.109) IECC Ref:45038 Model:K-2002DW1-WBTest Equipment Applicant:KIN SUN ELECTRONICS LIMITEDReceiver: ESVP Rohde & Schwarz Antenna: Schaffner CBL6111C Ser.Nr.: -- Oper. Mode:FM Mode InterFreq:10.7MHz Receiving - frequency (MHz) Oscillator- frequency (MHz) Har- monics Reading dBμV Polari- zation Correction Factor (dB) Test Result dB(μV/m) Limit dB(μV/m) 89.8100.5116V9.725.743.5 201.02<16V8.2<24.243.5 301.53<16V13.0<29.046.0 402.04<16V15.8<31.846.0 502.55<16V18.0<34.046.0 603.06<16V19.4<35.446.0 703.57<16V20.9<36.946.0 804.08<16V22.1<38.146.0 904.59<16V23.7<39.746.0 98.3109.0118V10.228.243.5 218.0218V8.326.346.0 327.0322V13.635.646.0 436.04<16V16.7<32.746.0 545.05<16V19.6<35.646.0 654.06<16V20.1<36.146.0 763.07<16V22.3<38.346.0 872.08<16V23.4<39.446.0 981.09<16V24.9<40.954.0 108.0118.7116V10.726.743.5 237.4216V10.426.446.0 356.1326V14.540.546.0 474.84<16V17.5<33.546.0 593.55<16V19.3<35.346.0 712.26<16V21.2<37.246.0 830.97<16V22.9<38.946.0 949.68<16V25.6<41.646.0 The measurement results indicate that the test unit meets the FCC requiremen t 141U1Date : 2006-05-08 Page 11 of 19 Radiated Emission According: FCC Part 15 Subpart B (15.109) IECC Ref:45038 Model:K-2002DW1-WBTest Equipment Applicant:KIN SUN ELECTRONICS LIMITEDReceiver: ESVP Rohde & Schwarz Antenna: Schaffner CBL6111C Ser.Nr.: -- Oper. Mode:Weather Band InterFreq:10.7MHz Receiving - frequency (MHz) Oscillator- frequency (MHz) Har- monics Reading dBμV Polari- zation Correction Factor (dB) Test Result dB(μV/m) Limit dB(μV/m) 162.4173.101<16H8.8<24.843.5 346.20228H14.242.246.0 519.303<16H18.3<34.346.0 692.404<16H20.6<36.646.0 865.505<16H23.5<39.546.0 162.475173.18129H8.837.843.5 346.35229H14.243.246.0 519.533<16H18.3<34.346.0 692.704<16H20.6<36.646.0 865.885<16H23.5<39.546.0 162.55173.25116H8.824.843.5 346.50229H14.243.246.0 519.753<16H18.3<34.346.0 693.004<16H20.6<36.646.0 866.255<16H23.5<39.546.0 The measurement results indicate that the test unit meets the FCC requiremen t 141U1Date : 2006-05-08 Page 12 of 19 Radiated Emission According: FCC Part 15 Subpart B (15.109) IECC Ref:45038 Model:K-2002DW1-WBTest Equipment Applicant:KIN SUN ELECTRONICS LIMITEDReceiver: ESVP Rohde & Schwarz Antenna: Schaffner …
