August 7, 2001 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Type Acceptance Application under FCC CFR 47, Parts 2 and 90 (Subpart I) - Non-Broadcast Radio Transceivers Operating in the frequency band 450 - 466 MHz (12.5 kHz Channel Spacing) Applicant: WaveNet International Inc. Product: Transceiver Module Model: WL7412-450 FCC ID: MTHWL7412-450 Dear Sir/Madam, As appointed agent for WaveNet International Inc., we would like to submit the application to Federal Communications Commission for certification of the above product for Modular Approval. Please review all necessary files uploaded to FCC OET site. This radio module is only used with WaveNet Base and Mobile wireless systems. It is not sold to the OEM manufacturer as a module. For mobile operation a unity antenna is required and be located at a minimum distance of 25 cm away from the users. This distance is specified in the Product Guide. If you have any queries, please do not hesitate to contact us by our TOLL FREE number: OUR TELEPHONE NO.: 1-877-765-4173 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/DH 2 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] UltraTech Group of Labs

June 12, 2001 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Authority to Act as an Agent to FCC Applicant: WaveNet International Inc Product: Transceiver Module Model: WL7412-450 FCC ID: MTHWL7412-450 Dear Sir/Madam, I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application to F.C.C. for authorization of equipment under F.C.C. Rules. I also certify that the information provided, properly described the device or system for which authorization is required. Regards (V.Sondhi) 5825 Kennedy Road, M ississauga, Ontario, Canada L4Z 2G 3 Te l : (9 0 5 ) 7 1 2 4 7 0 0 Fax : (905) 712 4703 e-m ail : w a v e n e t@ w a v e n e t-rf.com w w w .w a v e n e t-rf.c o m WaveNet International, Inc

June 12, 2001 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Request for withholding from public disclosure the schematic diagrams and system block diagrams pursuant to an application for certification. Applicant: WaveNet International Inc Product: Transceiver Module Model: WL7412-450 FCC ID: MTHWL7412-450 Dear Sir/Madam, We, WaveNet International Inc., would like to request that the schematic diagrams, submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission's Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. The detailed confidential materials are listed as follows: No. Title Drawing No. Sheet No. 1 Transceiver schematic 001-3474-001 1 2 EFJ Interface schematic 622-0008-00 1 3 4 5 If you have any queries, please do not hesitate to contact us. OUR TELEPHONE NO.: (905) 712-4700 Yours truly, (V.Sondhi) 5825 Kennedy Road, M ississauga, Ontario, Canada L4Z 2G 3 Te l : (9 0 5 ) 7 1 2 4 7 0 0 Fax : (905) 712 4703 e-m ail : w a v e n e t@ w a v e n e t-rf.com w w w .w a v e n e t-rf.c o m WaveNet International, Inc

ANNEX 3 – EXTERNAL EUT PHOTOS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A3 - 1 ANNEX 3 – EXTERNAL EUT PHOTOS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A3 - 2

Label for Radio Transceiver Module Location of the Label on Transceiver Module Back Product Name: Transceiver Module Model: WL7412-450 FCC ID: MTHWL7412-450 CANADA FCC/IC ID Label Label for a unit containing Radio Transceiver Module Wavenet International Inc. Model 5000 Serial No. XXXXXX Contains Radio Transceiver Module Model: WL7412-450 FCC ID: MTHWL7412-450 CANADA ________________________________ This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

ANNEX 4 – INTERNAL EUT PHOTOS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A4 - 1 ANNEX 4 – INTERNAL EUT PHOTOS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A4 - 2 ANNEX 4 – INTERNAL EUT PHOTOS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A4 - 3 ANNEX 4 – INTERNAL EUT PHOTOS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A4 - 4 ANNEX 4 – INTERNAL EUT PHOTOS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A4 - 5 ANNEX 4 – INTERNAL EUT PHOTOS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A4 - 6

FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Page 11 Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 ULTRATECH GROUP OF LABS File #: WIC15-FTX 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 August 7, 2001 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST 6.6. RF EXPOSURE REQUIREMENTS @ 1.1310 & 2.1091 MPE EVALUATION FCC 1.1310:- The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Page 12 Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 ULTRATECH GROUP OF LABS File #: WIC15-FTX 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 August 7, 2001 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST Calculation Method of RF Safety Distance : S = PG/4Πr 2 = EIRP/4Πr 2 ==> r = PG/4ПS = EIRP/4ПS Where: P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power. S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to center of radiation in cm P = 2 W = 2000 mW (power measured at antenna terminal) S = 450/1500 mW/cm 2 (limits for general population/uncontrolled exposure) r = PG/ 4ПS = (2000 x 1) / (4П(450/1500)) = 23 cm The minimum safety distance is 23 cm. In the user manual/product guide, RF exposure statement will specified a safety distance of 25 cm as shown below: RF EXPOSURE WARNING In order to ensure user safety and to satisfy RF exposure requirements for mobile transmitting devices, a minimum separation distance of 25 cm. (10 inches) must be maintained between the transmitting device and the user (or other nearby persons) during device operation. Operation at smaller separation distances is not recommended.

Transceiver Module Model No.: WL7412-450 FCC ID: MTHWL7412-450 Applicant: WaveNet International Inc. 5825 Kennedy Road Mississauga, Ontario Canada, L4Z 2G3 Tested in Accordance With Federal Communications Commission (FCC) CFR 47, PARTS 2 and 90 (Subpart I) UltraTech's File No.: WIC15-FTX This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: ........................... Report Prepared by: Dan Huynh Tested by: Hung Trinh, RFI/EMI Technicain Issued Date: August 7, 2001 Test Dates: May 28-29, 2001 The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Contents i Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 ULTRATECH GROUP OF LABS File #: WIC15-FTX 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 August 7, 2001 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST TABLE OF CONTENTS EXHIBIT 1. SUBMITTAL CHECK LIST...................................................................................................................... 1 EXHIBIT 2. INTRODUCTION ....................................................................................................................................... 2 2.1. SCOPE ......................................................................................................................................................................... 2 2.2. RELATED SUBMITTAL ( S )/ GRANT ( S ) ............................................................................................................................. 2 2.3. NORMATIVE REFERENCES ........................................................................................................................................... 2 EXHIBIT 3. PERFORMANCE ASSESSMENT ............................................................................................................ 3 3.1. CLIENT INFORMATION ................................................................................................................................................. 3 3.2. EQUIPMENT UNDER TEST ( EUT ) INFORMATION ............................................................................................................ 3 3.3. EUT ’ S TECHNICAL SPECIFICATIONS ............................................................................................................................. 4 3.4. LIST OF EUT ’ S PORTS ................................................................................................................................................... 4 3.5. ANCILLARY EQUIPMENT .............................................................................................................................................. 5 EXHIBIT 4. EUT OPERATION CONDITIONS AND CONFIGURATIONS DURING TESTS ............................. 6 4.1. CLIMATE TEST CONDITIONS ......................................................................................................................................... 6 4.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS ...................................................................... 6 EXHIBIT 5. SUMMARY OF TEST RESULTS ............................................................................................................. 7 5.1. LOCATION OF TESTS .................................................................................................................................................... 7 5.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS ................................................................................... 7 5.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES .................................................................. 8 5.4. DEVIATION OF STANDARD TEST PROCEDURES ............................................................................................................. 8 EXHIBIT 6. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS............................. 9 6.1. TEST PROCEDURES ...................................................................................................................................................... 9 6.2. MEASUREMENT UNCERTAINTIES ................................................................................................................................. 9 6.3. MEASUREMENT EQUIPMENT USED :..............................................................................................................................9 6.4. ESSENTIAL / PRIMARY FUNCTIONS AS DECLARED BY THE MANUFACTURER ................................................................... 9 6.5. RF POWER OUTPUT @ FCC 2.1046 & 90.205 ...........................................................................................................10 6.5.1. Limits @ FCC 90.205 ...................................................................................................................................... 10 6.5.2. Method of Measurements................................................................................................................................. 10 6.5.3. Test Equipment List ......................................................................................................................................... 10 6…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 1 Plot # 1 99% Occupied Bandwidth Carrier Frequency: 450 MHz Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 2 Plot # 2 99% Occupied Bandwidth Carrier Frequency: 458 MHz Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 3 Plot # 3 99% Occupied Bandwidth Carrier Frequency: 466 MHz Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 4 Plot # 4 Emission Mask D Carrier Frequency: 450 Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 5 Plot # 5 Emission Mask D Carrier Frequency: 458 Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 6 Plot # 6 Emission Mask D Carrier Frequency: 466 Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 7 Plot # 7 Spurious Emissions at Antenna Terminals Carrier Frequency: 450 MHz Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 8 Plot # 8 Spurious Emissions at Antenna Terminals Carrier Frequency: 450 MHz Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 9 Plot # 9 Spurious Emissions at Antenna Terminals Carrier Frequency: 458 MHz Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 10 Plot # 10 Spurious Emissions at Antenna Terminals Carrier Frequency: 458 MHz Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 11 Plot #11 Spurious Emissions at Antenna Terminals Carrier Frequency: 466 MHz Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 12 Plot # 12 Spurious Emissions at Antenna Terminals Carrier Frequency: 466 MHz Power: 2 W Modulation: FM with internal 7200 bps random data ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 13 Plot # 13 Transient Frequency Behavior Carrier Frequency: 450 MHz, 12.5 kHz Channel Spacing Power: 2 W Modulation: Unmodulated Description: Carrier On Time ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 14 Plot # 14 Transient Frequency Behavior Carrier Frequency: 450 MHz, 12.5 kHz Channel Spacing Power: 2 W Modulation: Unmodulated Description: Carrier Off Time ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 15 Plot # 15 Transient Frequency Behavior Carrier Frequency: 450 MHz, 12.5 kHz Channel Spacing Power: 2 W Modulation: FM with internal 7200 bps random data Description: Carrier On Time ANNEX 1 - TEST DATA PLOTS WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A1 - 16 Plot # 16 Transient Frequency Behavior Carrier Frequency: 450 MHz, 12.5 kHz Channel Spacing Power: 2 W Modulation: FM with internal 7200 bps random data Description: Carrier Off Time

ANNEX 2 - TEST SETUP PHOTOS (Radiated Emissions at 3 Meters Distance) WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A2 - 1 ANNEX 2 - TEST SETUP PHOTOS (Radiated Emissions at 3 Meters Distance) WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A2 - 2 ANNEX 2 - TEST SETUP PHOTOS (Radiated Emissions at 3 Meters Distance) WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A2 - 3 ANNEX 2 - TEST SETUP PHOTOS (Radiated Emissions at 3 Meters Distance) WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A2 - 4 ANNEX 2 - TEST SETUP PHOTOS (Radiated Emissions at 3 Meters Distance) WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A2 - 5 ANNEX 2 - TEST SETUP PHOTOS (Radiated Emissions at 3 Meters Distance) WaveNet International Inc. Transceiver Module, Model WL7412-450 FCC ID: MTHWL7412-450 A2 - 6
