MVABH102-AT0-1-NBluetooth Headset

ADD: No. 6 Building, 173#, Dunhe Road, Haizhu District, Guangzhou City, Guangdong Province, China Telephone: +86-020-66319168 Mobile Phone: +86-13450 382195 Web: http://artiste.en.alibaba.com/ 广州雅天科技有限公司 ARTISTE TECHNOLOGY LTD. Dear customer: Thank you for purchasing our high quality electronic product. This product uses international advanced Bluetooth wireless audio transmission technology, which has stable signal ( high frequency modulation, easily to avoid other signal interference), stereo Hi-Fi sound quality, strong versatility etc.. The scope of product: audio devices with Bluetooth , including PC, mobile phone, MP3, notebook, etc.. Note: 1. When pair with the mobile phone ,function of the headset may change according to type of the mobile phone. 2. Some of the equipments , especially those without the Bluetooth Technology Alliance (SIG) testing or approval, may not be compatible with this product. 1. USB charging cable 2. The LINE IN line 3. Bluetooth headset Product Overview 1 1 3 On/Off R L MIC Set the Power switch on the headset to ON to turn on the headset. The headset will have a Beeping sound , Charging LED ( blue) will be on. 1. It will automatically connect to the last connected Bluetooth device. 2. If there is no device paired with headset, it will automatically enter the standby mode, and turn off after 10 minutes. 2 You must establish the connection between the headset and a compatible device by pairing before you can start using. Pair 2 Accessories list: Use instructions Warranty card Bluetooth headset The LINE IN line Product Introduction USB&line in Jack LED(Blue) On/Off On Play/Pause LED(Blue) Set the Power switch on the headset to OFF to turn off the headset. Off 4 Low battery alarm function: When the battery power is low, the headset will issue a "beep" sound warning to turn off theheadset. Automatically turn off function: If the headset is not connected with any equipment in about 10 minutes, it will automatically shut down for power saving Headset reset function:If the headset stop working, you need to reset the headset, please connect the headset to a charging wire /adapter , then it will reset successfully;If it is in working , when you connect it to a charging wire /adapter ,the headset will automatically shut down, at this time please reset it for normal work. LINE IN function : When the USB MIRCO is connected to the audio line (3.5MM TO USB MIRCO B/M), it will automatically disconnect Bluetooth function and change to LINE IN, used as a wired headset. When wearing headset, please pay attention to distinguish between left and right side of the headband. Headset on both sides has a telescopic headband design, you can adjust the headband length for more comfortable .Stretch length was 30 ±1mm Wearing 30±1mm 3 Play/Pause LED(Blue) MIC 1. Ensure that the mobile device or a music player is on and the headset is closed. 2. Turn on the headset, Press the Pair button on the headset for 5 seconds until the Pairing LED (blue) starts to flash quickly. 3. Activate the Bluetooth setting of your PC/Laptop, and select “ABH102”(ABH102 is the Bluetooth Headphone identity number of this sample). 4. When prompted and request for passkey, enter “0000” to make the connection of your PC/Laptop to the ABH102 headphone. 5. Once both devices were linked, the Pairing LED (blue) of ABH102, headset will starts to flash slowly. 6. Plays the music with your computer and you can start enjoy the music with the headphone. Press the control panel on the headset to control the audio streaming (Fast Forward, Fast Backward, Pause/Play, Volume Up/Down) Volume Up Volume Down Fast Backward Fast Forward Lock/Unlock buttons: Press the PLAY/PAUSE button quickly twice to lock the other buttons and there will be a warning tone. In locked state, only PLAY/PAUSE button is effective ,the other buttons are not effective. To unlock buttons, Press the PLAY/PAUSE button quickly twice again. Answer: Press the play / pause button to pick up the call Hung: Press the play / pause button to hung off the call .when you don`t want to answer the call,press the play / pause for 3 seconds. Buttons Warning: Using the headset will weaken your ability to hear outside sounds. Therefore, please do not use headset in the condition which may threaten your safety . 5 6 Charging 1.When it is charging , the green lights. 2.When the charging is completed, the green indicator light is extinguished, charging adapter/wire can be removed. 3.If the battery is completely run out , it may take several minutes for charging light to indicate the state of charge; When the charging cable is not in use, please disconnect it with the device. Excessive charging will shorten battery life. 4.If you have a fully charged battery without using , the battery will discharge by itself after a period of time; 5.The headset can be used when charging. Note: The headset is built with non removable and rechargeable battery inside, do not remove the battery or so as not to damage the headset . When charging for first time ,it should be charged for more than 12 hours and less than 24 hours, which can activate the battery in best status. After that, charging only needs 2-3 hours (do not charge more than 24 hours, or it will damage the battery life) USB Charging Specifications A: Not successfully matched : 1. Confirm the connection device with Bluetooth function has been opened and work; 2. Check whether the headset battery power is insufficient; 3. Do not open the too many Bluetooth headsets or Bluetooth devices at the same time, to prevent interference; 4. Confirm the headset is in pairing state and input Bluetooth headset the password correctly; 5. If the above method still can not solve this problem, reset the headset, pair it by description B.Cannot listen to music or call by headset: 1. Increase the headset volume; 2. Confirmed the device has been successfully connected Troubles Safety In order to obtain the best sound effects, please pay attention to di…

Text truncated - open the document above for the full version.

FCC INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

Uni-Art Precise Products Ltd 1 1-12/F,Yue Xiu Industrial Building,87 Hung To Road,Kowloon,Hong Kong FCC Confidentiality Request Number: CF303 Version: V01 Date: 01-02-2010 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Uni-Art Precise Products Ltd Addresss 11-12/F,Yue Xiu Industrial Building,87 Hung To Road,Kowloon,Hong Kong City Hongkong Country request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: MVA BH102-AT0-1-N of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) Operational Description Block Diagrams Schematics Diagrams Part list Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Hongkong November 21, 2013 Simon Chan Sales Manager

Uni-Art Precise Products Ltd 11-12/F,Yue Xiu Industrial Building,87 Hung To Road,Kowloon,Hong Kong FCC Authorization Letter Number: CF304 Version: V01 Date: 01-02-2010 We, (the approval holder) Company name Uni-Art Precise Products Ltd Address 11-12/F,Yue Xiu Industrial Building,87 Hung To Road,Kowloon,Hong Kong City Hongkong Country declare that the following representative (agent): Name (person) Ruby zhang Function Supervisor Company name Compliance Certification Services (Shenzhen) Inc. Addresss No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Bluetooth Headset Type or Model(s) ABH102/BH102 Tradename or Brand(s) ARTISTE/ARKON We also authorize Teleconformity, Mr. M. Koop, (address: Rietven 31, 7534NH Enschede, Netherlands) to process this application. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Hongkong November 21, 2013 Simon Chan Sales Manager

Report No: C130918Z01-RP1 Page 1 / 2 External Photos of EUT Report No: C130918Z01-RP1 Page 2 / 2

Label and Location

Report No: C130918Z01-RP1 Page 1 / 4 Internal Photos of EUT Report No: C130918Z01-RP1 Page 2 / 4 Report No: C130918Z01-RP1 Page 3 / 4 Report No: C130918Z01-RP1 Page 4 / 4

FCC RF Exposure FCC ID: MVABH102-AT0-1-N Frequency: 2402-2480 MHz (79 channels) Mid-Channel: 2.441 GHz (channel 39) Mid-Channel Peak Power, Conducted: 3.66 dBm == 2.32 mW Antenna Gain: G = 2 dBi Peak, Radiated = 3.66 dBm + 2 dBi = 5.66 dBm = 3.68 mW SAR Test Exclusion Thresholds specified in KDB447498 Appendix A: Evaluation: The Calculated Radiated Peak output power is taken as worst case, and this emission level appears to be under the maximum allowed emission level at even the closest distance for 2.4G device specified in this table. Conclusion: The emitted power appears to be (far) below the required limit, so PASS.
