MXF-C4000BGResidential Gateway Products

C4000BG USER GUIDE Version 1.0 2 NOTICE This document contains confidential information, which is proprietary toCenturyLink. No part of its contents can be used, copied, disclosed, or conveyed to any party in any manner whatsoever without prior written permission fromCenturyLink. Copyright ©2020CenturyLink Inc. All Rights Reserved. 3 Contents 1Introduction........................................................................................................................................................................................................................4 2Overview.............................................................................................................................................................................................................................4 3Setup...................................................................................................................................................................................................................................4 4Internet Connection Setup (CenturyLink Home Router side).............................................................................................................................................7 4.1Automatic Connection...............................................................................................................................................................................................7 4.2Manual Connection....................................................................................................................................................................................................7 5Setting up a wireless network............................................................................................................................................................................................9 5.1Using WPS (Wireless Protected Setup)......................................................................................................................................................................9 5.2Setting up a wireless network manually....................................................................................................................................................................9 6Getting to know theC4000BG..........................................................................................................................................................................................10 7Technical Specifications:...................................................................................................................................................................................................11 7.1General Specifications..............................................................................................................................................................................................11 7.2Dimensions and weight............................................................................................................................................................................................11 7.3Environmental Parameters......................................................................................................................................................................................11 8FCC:...................................................................................................................................................................................................................................12 4 1Introduction Please read through this user guide prior to using this product and retain the manual for future use. Only operate this device upon the full understanding of the devices basic operation as described in this manual. Any deviation or alteration of this product, it's appearance or specification are withoutconsentor further notice of the company. 2Overview TheC4000BGis a high performance2x2Wi-Fi 6 router (802.11ax)with abondedVDSL2 integrated access device (IAD)anda four-port built-in it Gigabit Ethernet switch. TheC4000BGallows wired and wireless clients to safely access the Internet. Additionally, theC4000BGincludes a Gigabit Ethernet LAN port that can also serve as a WAN connection to support a either a WAN or LAN function. 3Setup 1.Insertthepower connector intotheC4000BG. 5 2.Plugthepower adapter intoa poweroutlet. 3.Plugphonecable(green)intotheC4000BG 6 4.Plug other end ofphonecable intotheyour home phone line. 5.Continue to the Internet connection Setup. 7 4Internet ConnectionSetup (CenturyLink Home Routerside) YourC4000BGcan automatically detect and configure your Internet(section 4.1), or done manually (section 4.2). 4.1Automatic Connection 1.Open your web browser to a website. Wait while your device tries to detect your DSL connection to your ISP. This may take a few minutes. 2.After it detects the connection, theLED Ring willshowgreenon yourC4000BGwhen the Internet is readyfor you to use. If you have a PPPoE connection, you will have toenter the user name and password provided by your ISP. 3.Go to Set Up a Wireless Network if you wish to configure yourwireless settings. 4.If the automatic connection is not successful, check your connectionsand restart the Device. Also, make sure you have entered the username and password correctly. If you still cannot access the Internet,follow the steps in the next section to manually configure the Internetconnection. 4.2Manual Connection You canalso manually loginto the router’s Web UI toconfigure your Internetconnection 1.In your browser, if the Device does not automatically re-direct you tothe login screen, go tohttp://192.168.0.1 2.Enter the default user name admin and password (see thelabel on the bottom of the device). ClickApply. If the login screen does not open, make sure you allow webbrowser pop-upwindows, JavaScripts and Java permissions. Your computer should b…

Text truncated - open the document above for the full version.

Project No.: 082201 Page No. : 1 of 19 Photographs of EUT Project No.: 082201 Page No. : 2 of 19 Project No.: 082201 Page No. : 3 of 19 Project No.: 082201 Page No. : 4 of 19 Project No.: 082201 Page No. : 5 of 19 Project No.: 082201 Page No. : 6 of 19 Project No.: 082201 Page No. : 7 of 19 Project No.: 082201 Page No. : 8 of 19

D B A 6 54 3 1 COMPUTER GENERATED PRINT DO NOT SCALE, DO NOT REVISE MANUALLY C 6 54 3 1 2 D B A C REV.MARKDESCRIPTIONSIGNATURE V1 REVISION HISTORY - ALL SHEETS ARE THE SAME REVISION STATUS EC/DC MEMO TOLERANCE (UNLESS OTHERWISE SPEC.) 0 ~ 29.99 120.0 ~ 299.99 300 or GREATER ANGULAR TOL. ± 0.40 ± 0.20 ± 0.15 ± 0.10 30.0 ~ 119.99 THIRD ANGLE PROJECTION Wireless Broadband Anywhere Gemtek Technology Co ., Ltd. 正文科技股份有限公司 Artwork MODEL NAME : UNIT SCALESIZESHEETREV. mmA4 1 V3 DWG TITLE : 42V-120-1580R DWG / PART NO. INFORMATION CONTAINED ON ALL SHEETS OF THIS PRINT CAN NOT BE REPRODUCED OR USED, IN WHOLE OR IN PART, WITHOUT GEMTEK'S CONSENT. THIS NOTICE DOES NOT IMPLY PUBLICATION. DESIGNED BY: Jamie Chou DRAWN BY: APPROVED BY: ± 0.50° OFFICIAL RELEASE. Jamie Chou 2020-9-1 V2 Jamie Chou 2020-11-12 V3 Jamie Chou 2020-11-27 Ø77.70 Ø1.80 90° 1.: 50#+25#(UL) 2.: 3.: 4.: Pantone cool gray 11C+Pantone cool gray 7C + Green(C100Y100) VN LABEL BACK (R3HF) WVDD-147AX472A RONGXIN 3.15 2 6 3 3 FCC ID: MXF-C4000BG

Project No.: 082201 Page No. : 9 of 19 Project No.: 082201 Page No. : 10 of 19 Project No.: 082201 Page No. : 11 of 19 Project No.: 082201 Page No. : 12 of 19 Project No.: 082201 Page No. : 13 of 19 Project No.: 082201 Page No. : 14 of 19 Project No.: 082201 Page No. : 15 of 19 Project No.: 082201 Page No. : 16 of 19 Project No.: 082201 Page No. : 17 of 19 Project No.: 082201 Page No. : 18 of 19 Project No.: 082201 Page No. : 19 of 19

Report No.: FA082201 Page : 1 of 6 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : MXF-C4000BG Equipment : Residential Gateway Products Model No. : C4000BG Brand Name : CenturyLink Applicant : Gemtek Technology Co., Ltd. Address : No. 15-1 Zhonghua Road, Hsinchu Industrial Park, Hukou, Hsinchu, Taiwan, 30352. Standard : 47 CFR FCC Part 2.1091 Received Date : Aug. 22, 2020 Tested Date : Sep. 18 ~ Oct. 20, 2020 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA082201 Page : 2 of 6 Report Version: Rev. 01 Table of Contents 1 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4 1.2 MPE EVALUATION FORMULA ............................................................................................................. 4 1.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 4 1.4 MEASUREMENT UNCERTAINTY ......................................................................................................... 4 1.5 MPE EVALUATION RESULTS .............................................................................................................. 5 1.6 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION ................................................................ 5 2 TEST LABORATORY INFORMATION ................................................................................................. 6 Report No.: FA082201 Page : 3 of 6 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA082201 Rev. 01 Initial issue Dec. 15, 2020 Report No.: FA082201 Page : 4 of 6 Report Version: Rev. 01 1 MPE EVALUATION OF MOBILE DEVICES 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 1.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 1.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 1.4 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)). Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA082201 Page : 5 of 6 Report Version: Rev. 01 1.5 MPE EVALUATION RESULTS Non-beamforming mode Frequency Range (MHz) Maximum Conducted Power (dBm) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) *Ratio Pass / Fail 2412~2462 (Wi-Fi) 29.88 30 2.55 27 0.196 1 0.196 Pass 5180~5240 (Wi-Fi) 29.77 30 3.05 27 0.220 1 0.220 Pass 5745~5825 (Wi-Fi) 29.79 30 4.60 27 0.315 1 0.315 Pass *Ratio = Power density / Limit. Beamforming mode Frequency Range (MHz) Maximum Conducted Power (dBm) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) *Ratio Pass / Fail 2412~2462 (Wi-Fi) 29.65 30 5.17 27 0.359 1 0.359 Pass 5180~5240 (Wi-Fi) 29.66 30 5.47 27 0.385 1 0.385 Pass 5745~5825 (Wi-Fi) 29.15 29.5 6.73 27 0.458 1 0.458 Pass *Ratio = Power density / Limit. For 2412 ~ 2462 MHz, Directional Gain=10 * log((10 1.75/20 +10 2.55/20 ) 2 /2) =5.17 dBi For 5180 ~ 5240 MHz , Directional Gain =10 * log((10 1.83/20 +10 3.05/20 ) 2 /2) =5.47 dBi; For 5745 ~ 5825 MHz, Directional Gain =10 * log((10 2.73/20 +10 4.6/20 ) 2 /2) =6.73 dBi 1.6 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION Mode Max Ratio of Each Mode Non-beamforming Beamforming mode Wi-Fi 2.4 GHz 0.196 0.359 Wi-Fi 5 GHz 0.315 0.458 Sum (Wi-Fi 2.4 GHz+ Wi-Fi 5 GHz) 0.511 0.817 Limit 1 1 Pass / Fail Pass Pass Report No.: FA082201 Page : 6 of 6 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corp (EMC and Wireless Communication Laboratory), it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan District. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Kwei Shan Site II Tel: 886-2-2601-1640 Tel: 886-3-271-8666 Tel: 886-3-271-8640 No. 30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan, R.O.C. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan District, Tao Yuan City 333, Taiwan, R.O.C. No. 14-1, Lane 19, Wen San 3rd St., Kwei Shan District, Tao Yuan City 333, Taiwan, R.O.C.. If you have any suggestion, please feel free to contact us as below information Tel: 886-3-271-8666 Fax: 886-3-318-0155 Email: [email protected] ══END══

Report No.: FR082201AC Page : 1 of 95 Report Version: Rev. 01 FCC Test Report FCC ID : MXF-C4000BG Equipment : Residential Gateway Products Model No. : C4000BG Brand Name : CenturyLink Applicant : Gemtek Technology Co., Ltd. Address : No. 15-1 Zhonghua Road, Hsinchu Industrial Park, Hukou, Hsinchu, Taiwan, 30352. Standard : 47 CFR FCC Part 15.247 Received Date : Aug. 22, 2020 Tested Date : Sep. 18 ~ Oct. 20, 2020 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FR082201AC Page : 2 of 95 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 9 1.3 Test Setup Chart .................................................................................................................................. 10 1.4 The Equipment List .............................................................................................................................. 11 1.5 Test Standards ..................................................................................................................................... 13 1.6 Reference Guidance ............................................................................................................................ 13 1.7 Deviation from Test Standard and Measurement Procedure ............................................................... 13 1.8 Measurement Uncertainty .................................................................................................................... 13 2 TEST CONFIGURATION ..................................................................................................................... 14 2.1 Testing Facility...................................................................................................................................... 14 2.2 The Worst Test Modes and Channel Details ....................................................................................... 14 3 TRANSMITTER TEST RESULTS ........................................................................................................ 15 3.1 Conducted Emissions ........................................................................................................................... 15 3.2 6dB and Occupied Bandwidth .............................................................................................................. 18 3.3 RF Output Power .................................................................................................................................. 26 3.4 Power Spectral Density ........................................................................................................................ 30 3.5 Unwanted Emissions into Restricted Frequency Bands ...................................................................... 38 3.6 Emissions in Non-Restricted Frequency Bands ................................................................................... 74 4 TEST LABORATORY INFORMATION ............................................................................................... 95 Report No.: FR082201AC Page : 3 of 95 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR082201AC Rev. 01 Initial issue Dec. 15, 2020 Report No.: FR082201AC Page : 4 of 95 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions [dBuV]: 1.040MHz 40.01 (Margin –15.99dB) - QP Pass 15.247(d) 15.209 Radiated Emissions [dBuV/m at 3m]: 4824.00MHz 53.87 (Margin -0.13dB) – AV Pass 15.247(b)(3) Maximum Output Power Max Power [dBm]: Non-beamforming mode 29.88 Beamforming mode 29.65 Pass 15.247(a)(2) 6dB Bandwidth Meet the requirement of limit Pass 15.247(e) Power Spectral Density Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FR082201AC Page : 5 of 95 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) Data Rate / MCS 2400-2483.5 b 2412-2462 1-11 [11] 2 1-11 Mbps 2400-2483.5 g 2412-2462 1-11 [11] 2 6-54 Mbps 2400-2483.5 n (HT20) 2412-2462 1-11 [11] 2 MCS 0-15 2400-2483.5 n (HT40) 2422-2452 3-9 [7] 2 MCS 0-15 2400-2483.5 ac (VHT20) 2412-2462 1-11 [11] 2 MCS 0-9 2400-2483.5 ac (VHT40) 2422-2452 3-9 [7] 2 MCS 0-9 2400-2483.5 ax (HE20) 2412-2462 1-11 [11] 2 MCS 0-11 2400-2483.5 ax (HE40) 2422-2452 3-9 [7] 2 MCS 0-11 Note 1: RF output power specifies that Maximum Conducted (Average) Output Power. Note 2: DSSS-DBPSK, DQPSK, CCK modulation OFDM/OFDMA- BPSK, QPSK, 16QAM, 64QAM, 256QAM and 1024QAM modulation. Note 3: 802.11an / ac / ax supports beamforming functi…

Text truncated - open the document above for the full version.

Report No.: FR082201 Page: : 1 of 5 Report Version: Rev. 01 Photographs of the Test Configuration Conducted Emission Test Report No.: FR082201 Page: : 2 of 5 Report Version: Rev. 01 Radiated Emission Below 1GHz Test Report No.: FR082201 Page: : 3 of 5 Report Version: Rev. 01 Radiated Emission Below 1GHz Test Report No.: FR082201 Page: : 4 of 5 Report Version: Rev. 01 Radiated Emission Above 1GHz Test Report No.: FR082201 Page: : 5 of 5 Report Version: Rev. 01 Radiated Emission Above 1GHz Test
