MYF-G11FNFPCExtended Range Wireless LAN

USER’S MANUAL INFORMATION (Preliminary) The User’s Manual is in preparation. The following material will be contained in the manual: FCC ID: MYF-G11FNFPC IC: 2837A-G11FNFPC Interference Statement This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressively approved by the party responsible for compliance could void the user’s authority to operate the equipment. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. Information to the User / Installer NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the distance between the equipment and the receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications of equipment not expressly approved by the manufacturer could void the user’s authority to operate the equipment and the company’s warranty. NOTE: THE ANTENNA SYSTEM SHALL BE INSTALLED ONLY BY EXPERIENCED ANTENNA INSTALLERS WHO ARE FAMILIAR WITH LOCAL BUILDING AND SAFETY CODES, AND WHEREVER NECESSARY HAVE BEEN LICENSED BY APPROPRIATE GOVERNMENT REGULATORY BODIES. FAILURE TO DO SO MAY VOID THE PRODUCT WARRANTY, AS WELL AS EXPOSE THE END-USER TO LEGAL AND/OR FINANCIAL LIABILITIES. HYPERLINK TECHNOLOGIES, IT’S AGENTS, RESELLERS OR DISTRIBUTORS, ARE NOT LIABLE FOR INJURY, DAMAGE, OR VIOLATION OF GOVERNMENT REGULATIONS THAT MAY ARISE FROM FAILING TO COMPLY WITH THE GUIDELINES DESCRIBED IN THIS DOCUMENT. NOTE: FIXED, POINT-TO-POINT OPERATION EXCLUDES THE USE OF POINT-TO- MULTIPOINT SYSTEMS, OMNIDIRECTIONAL APPLICATIONS, AND MULTIPLE CO- LOCATED INTENTIONAL RADIATORS TRANSMITTING THE SAME INFORMATION. THE INSTALLER IS RESPONSIBLE FOR ENSURING THAT THE SYSTEM IS USED EXCLUSIVELY FOR FIXED, POINT-TO-POINT OPERATIONS. (I.E. THE DEVICE AND ITS ANTENNA MUST NOT BE CO-LOCATED OR OPERATING IN CONJUNCTION WITH ANY OTHER ANTENNA OR TRANSMITTER). (REFERENCE FCC PART 15.247(B)(4)(III)) The table on the following page identifies which antennas are considered “fixed” and which are “mobile”. When this device is installed as a fixed-mount application there is a minimum required separation distance of one (1) meter between the antenna and all persons during normal operation. For mobile mounted antennas, the required separation distance is a minimum of twenty (20) cm between the antenna and all persons during normal use. Card Alone 1000 800 630 500 400 250 200 100 60 50 25 (mW) - as labeled Antenna Model Antenna Type Gain (dBi) 29.2 29 28 27 26 24 23 20 18 17 14 17.5 (dBm) HG2401U whip/monopole 1 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2402RD whip/monopole 2 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2403RD whip/monopole 3 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2403UR whip/monopole 3 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - Channel HG2404CU whip/monopole 3 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 1 RE05E whip/monopole 5 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 2 RE05U whip/monopole 5 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 1-11 3 HG2405 whip/monopole 5 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 4 HG2406U whip/monopole 6 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 5 HG2407U whip/monopole 7 N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 6 HG2408U whip/monopole 8 N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 7 HG2409U whip/monopole 8.5 N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 8 HGV-2409U whip/monopole 8.5 N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 9 HG2410U whip/monopole 10 N/A N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 10 HG2412U whip/monopole 12 N/A N/A N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 11 HG2415U-PRO whip/monopole 15 N/ A N/ A N/ A N/ A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2409P patch 8 N/A 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 - HG2408P patch 8 N/A 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 - HG2412P patch 12 N/A N/A 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 - HG2414P patch 14 N/A N/A N/A 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 - HG2416P patch 16 N/ A N/ A N/ A N/ A 4-6 4-6 4-6 4-6 4-6 4-6 4-6 - HG2409Y Yagi-Uda 9 N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2412Y Yagi-Uda 12 N/A N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2415Y Yagi-Uda 14.5 N/ A N/ A N/ A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - Configurations in BLUE can be used in either MOBILE OR FIXED MOUNTED Installations (NO FILTER REQUIRED)Configurations with "-" are NOT PERMISSIBLE as they do not meet the FCC Part 15 restricted band limits 2417 For Amplifier(s): HA2401GI-XXX, HA2401G-XXX, where XXX stands for the amplifier power rating labeled in mW (see below) Amplifier Power Rating Configurations in BLACK can be used in either MOBILE OR FIXED MOUNTED Installations (FILTER REQUIRED) FCC / IC Compliant Configurations - Channels of Operation 245224572462 Configurations in RED can only be used in FIXED MOUNTED Installations …

Text truncated - open the document above for the full version.

User Manual Model HA2401-G11FNFPC FCC ID: MYF -G11FNFPC IC: 2837A-G11FNFPC Interference Statement This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressively approved by the party responsible for compliance could void the user’s authority to operate the equipment. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. NOTE: This system must be installed by experienced professional installers who are familiar with radio frequency (RF) equipment operation as well as local building and safety codes. Failure to do so may void the Product Warranty, as well as expose the end-user to legal and/or financial liabilities. Information to the user NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the distance between the equipment and the receiver. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications of equipment not expressly approved by the manufacturer could void the user’s authority to operate the equipment and the company’s warranty. NOTE: Certain high gain antennas are intended for point-to-point or point- to-multipoint applications only. These antennas are clearly identified in the table contained in this manual. Note that +36 dBi may only be exceeded for point-to-point applications as given in 15.247(b). It is the installers responsibility that when using these antennas to ensure that the system is used exclusively for point-to-point operations, and that the antenna may not be co-located with other intentional radiators transmitting the same information". The device and its antenna and must not be co-located or operating in conjunction with any other antenna or transmitter. The table contained in this manual identifies which antennas are considered “fixed” and which are “mobile”. When this device is installed as a fixed-mount application there is a minimum required separation distance of one hundred (100) cm between the antenna and all persons during normal operation. All mobile antennas must be mounted at a minimum distance of 20 cm from users. AP Installation: Conduct a Site Survey to determine the best location for the system. Once located, install the Enclosure in an appropriate location. Follow the enclosure mounting instructions for specific mounting and grounding details. Mount the AP Mounting Bracket to the mounting plate in the enclosure using the (3) screws provided. Refer to the figure below for proper positioning. Attach the AC Power Cord to the Power Supply and clip the AP Power Supply into the base of the AP Mounting Bracket. Slide the AP module onto the mounting bracket. Make sure it is properly seated. Slide the PC Card into either Slot A or Slot B. Mount the amplifier into the enclosure as shown in below: Connect the Pigtail Cable between the PC Card and the Amplifier input. Connect the amplifier output to the Filter/ Lightning Protector, as required (see Appendix A). Install the Antenna NOTE: THE ANTENNA SYSTEM SHALL BE INSTALLED ONLY BY EXPERIENCED ANTENNA INSTALLERS WHO ARE FAMILIAR WITH LOCAL BUILDING AND SAFETY CODES, AND WHEREVER NECESSARY HAVE BEEN LICENSED BY APPROPRIATE GOVERNMENT REGULATORY BODIES. FAILURE TO DO SO MAY VOID THE PRODUCT WARRANTY, AS WELL AS EXPOSE THE END-USER TO LEGAL AND/OR FINANCIAL LIABILITIES. HYPERLINK TECHNOLOGIES, ITS AGENTS, RESELLERS OR DISTRIBUTORS, ARE NOT LIABLE FOR INJURY, DAMAGE, OR VIOLATION OF GOVERNMENT REGULATIONS THAT MAY ARISE FROM FAILING TO COMPLY WITH THE GUIDELINES DESCRIBED IN THIS DOCUMENT. Mount the antenna according to the specific installation instructions for the model you are installing. When choosing the antenna site you must observe the following exposure limits: The table contained in Appendix A of this manual identifies which antennas are considered “fixed” and which are “mobile”. When this device is installed as a fixed-mount application there is a minimum required separation distance of one hundred (100) cm between the antenna and all persons during normal operation. All mobile antennas must be mounted at a minimum distance of 20 cm from users. Once the antenna is installed connect the antenna to the amplifier and signal filter (as applicable) using the antenna cable. Connect the Ethernet cable to the AP. For configuration, use an Ethernet crossover and connect directly to a PC. Apply power to the Access Point unit. Check the diagnostic lights to ensure proper connection. You should now be ready to configure the Access Point. Use the Scan Tool to determine the MAC and IP Address for the AP Install the Scan Tool program on the PC you will be using to configure the AP over the Ethernet segment. Run the Scan Tool to determine the MAC Address and default IP Address for the AP. You can use the Change Screen to change the IP Ad…

Text truncated - open the document above for the full version.

Re: Certification for Hyperlink DSS System Model: HA2401GI, HA2401G FCC ID: MYF-G11FNFPC IC: 2837A-G11FNFPC POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested. Re: Certification for Hyperlink DSS System Model: HA2401GI, HA2401G FCC ID: MYF-G11FNFPC IC: 2837A-G11FNFPC REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, Hyperlink requests that a part of the subject application be held confidential. This comprises Exhibits (4) Block Diagram (Part of Exhibit only) (5) Schematics (10) Parts List (Part of Exhibit only) Hyperlink has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan February 12, 2004 Re: Certification for Hyperlink DSS System Model: HA2401GI, HA2401G FCC ID: MYF-G11FNFPC IC: 2837A-G11FNFPC STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. However, the number of channels used in any particular configuration was adjusted if necessary so as to meet the FCC and IC limits in restricted bands. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for Hyperlink DSS System Model: HA2401GI, HA2401G FCC ID: MYF-G11FNFPC IC: 2837A-G11FNFPC GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: Hyperlink Technologies Inc 1200 Clint Moore Road, Suite 14 Boca Raton, Florida 33487 Peter Roth Tel: (561) 995-2256 Fax: (561) 995-2432 It will be manufactured by: Hyperlink Technologies Inc 1200 Clint Moore Road, Suite 14 Boca Raton, Florida 33487 Peter Roth Tel: (561) 995-2256 Fax: (561) 995-2432 Canadian Contact: Guy Simard 619 Ermitage Rosemere, Quebec Canada J7A 4Y8 450-621-0491

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 March 10, 2004 RE: Hyperlink Technologies FCC ID: MYF-G11FNFPC I have a few comments on the above referenced Application. 1) Please note that the FCC no longer desires that the safe distance for mobile devices be calculated in the RF exposure exhibit if the safe distance is < 20 cm, but instead prefers the power density results to be calculated and compared to the power density limit. Given the nature of this application it is convenient to leave the information provided, however please provide a separate table that also calculated power denstiy @ 20 cm for the mobile devices and @ 1 meter for the fixed devices. 2) Please clarify table 6-2 to show whether the power was measured at the output of the amplifier or amplifier + filter (antenna input connector). It is believed that it was measured from the combination amplifier + filter from previous discussions. Please clarify. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

2402RD 2403UR 2404CU 2405 HG2406U HG2407U HG2408U HG2409U HG2410U HG2412U HG2408P HG2409P HG2412P HG2414P HG2416P 2412Y

Proxim Radio (top) Proxim Radio (bottom) Filter (top) HyperLink Power Injector (Top) HyperLink Power Injector (Bottom)

Card Alone 1000 800 630 500 400 250 200 100 60 50 25 (mW) - as labeled Antenna Model Antenna Type Gain (dBi) 29.2 29 28 27 26 24 23 20 18 17 14 17.5 (dBm) HG2401U whip/monopole 1 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2402RD whip/monopole 2 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2403RD whip/monopole 3 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2403UR whip/monopole 3 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - Channel HG2404CU whip/monopole 3 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 1 RE05E whip/monopole 5 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 2 RE05U whip/monopole 5 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 1-11 3 HG2405 whip/monopole 5 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 4 HG2406U whip/monopole 6 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 5 HG2407U whip/monopole 7 N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 6 HG2408U whip/monopole 8 N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 7 HG2409U whip/monopole 8.5 N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 8 HGV-2409U whip/monopole 8.5 N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 9 HG2410U whip/monopole 10 N/A N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 10 HG2412U whip/monopole 12 N/A N/A N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - 11 HG2415U-PRO whip/monopole 15 N/ A N/ A N/ A N/ A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2409P patch 8 N/A 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 - HG2408P patch 8 N/A 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 - HG2412P patch 12 N/A N/A 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 - HG2414P patch 14 N/A N/A N/A 4-6 4-6 4-6 4-6 4-6 4-6 4-6 4-6 - HG2416P patch 16 N/ A N/ A N/ A N/ A 4-6 4-6 4-6 4-6 4-6 4-6 4-6 - HG2409Y Yagi-Uda 9 N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2412Y Yagi-Uda 12 N/A N/A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - HG2415Y Yagi-Uda 14.5 N/ A N/ A N/ A 4-8 4-8 4-8 4-8 4-8 4-8 4-8 4-8 - Configurations in BLUE can be used in either MOBILE OR FIXED MOUNTED Installations (NO FILTER REQUIRED)Configurations with "-" are NOT PERMISSIBLE as they do not meet the FCC Part 15 restricted band limits 2417 For Amplifier(s): HA2401GI-XXX, HA2401G-XXX, where XXX stands for the amplifier power rating labeled in mW (see below) Amplifier Power Rating Configurations in BLACK can be used in either MOBILE OR FIXED MOUNTED Installations (FILTER REQUIRED) FCC / IC Compliant Configurations - Channels of Operation 245224572462 Configurations in RED can only be used in FIXED MOUNTED Installations (FILTER REQUIRED)Configurations with N/A are NOT PERMISSIBLE, via. FCC 15.247(b)(4)(i) Frequency (MHz) 2412242224272432243724422447

Card Alone Antenna Model Gain (dBi) 29.2 27 24 20 18 17 14 17.5 HG2401U 1 30.2 28.0 25.0 21.0 19.0 18.0 15.0 HG2402RD 2 31.2 29.0 26.0 22.0 20.0 19.0 16.0 HG2403RD 3 32.2 30.0 27.0 23.0 21.0 20.0 17.0 HG2403UR 3 32.2 30.0 27.0 23.0 21.0 20.0 17.0 HG2404CU 3 32.2 30.0 27.0 23.0 21.0 20.0 17.0 RE05E 5 34.2 32.0 29.0 25.0 23.0 22.0 19.0 RE05U 5 34.2 32.0 29.0 25.0 23.0 22.0 19.0 22.5 HG2405 5 34.2 32.0 29.0 25.0 23.0 22.0 19.0 HG2406U 6 35.2 33.0 30.0 26.0 24.0 23.0 20.0 HG2407U 7 36.2 34.0 31.0 27.0 25.0 24.0 21.0 HG2408U 8 37.2 35.0 32.0 28.0 26.0 25.0 22.0 HG2409U 8.5 37.7 35.5 32.5 28.5 26.5 25.5 22.5 HGV-2409U 8.5 37.7 35.5 32.5 28.5 26.5 25.5 22.5 HG2410U 10 39.2 37.0 34.0 30.0 28.0 27.0 24.0 HG2412U 12 41.2 39.0 36.0 32.0 30.0 29.0 26.0 HG2415U-PRO 15 44.2 42.0 39.0 35.0 33.0 32.0 29.0 HG2409P 8 37.2 35.0 32.0 28.0 26.0 25.0 22.0 HG2408P 8 37.2 35.0 32.0 28.0 26.0 25.0 22.0 HG2412P 12 41.2 39.0 36.0 32.0 30.0 29.0 26.0 HG2414P 14 43.2 41.0 38.0 34.0 32.0 31.0 28.0 HG2416P 16 45.2 43.0 40.0 36.0 34.0 33.0 30.0 HG2409Y 9 38.2 36.0 33.0 29.0 27.0 26.0 23.0 HG2412Y 12 41.2 39.0 36.0 32.0 30.0 29.0 26.0 HG2415Y 14.5 43.7 41.5 38.5 34.5 32.5 31.5 28.5 Card Alone Antenna Model Gain (dBi) 29.2 27 24 20 18 17 14 17.5 HG2401U 1 29.2 27.0 24.0 20.0 18.0 17.0 14.0 HG2402RD 2 29.2 27.0 24.0 20.0 18.0 17.0 14.0 HG2403RD 3 29.2 27.0 24.0 20.0 18.0 17.0 14.0 HG2403UR 3 29.2 27.0 24.0 20.0 18.0 17.0 14.0 HG2404CU 3 29.2 27.0 24.0 20.0 18.0 17.0 14.0 RE05E 5 29.2 27.0 24.0 20.0 18.0 17.0 14.0 RE05U 5 29.2 27.0 24.0 20.0 18.0 17.0 14.0 17.5 HG2405 5 29.2 27.0 24.0 20.0 18.0 17.0 14.0 HG2406U 6 29.2 27.0 24.0 20.0 18.0 17.0 14.0 HG2407U 7 29.1 27.0 24.0 20.0 18.0 17.0 14.0 HG2408U 8 28.8 27.0 24.0 20.0 18.0 17.0 14.0 HG2409U 8.5 28.6 27.0 24.0 20.0 18.0 17.0 14.0 HGV-2409U 8.5 28.6 27.0 24.0 20.0 18.0 17.0 14.0 HG2410U 10 28.1 26.7 24.0 20.0 18.0 17.0 14.0 HG2412U 12 27.5 26.0 24.0 20.0 18.0 17.0 14.0 HG2415U-PRO 15 26.5 25.0 23.0 20.0 18.0 17.0 14.0 HG2409P 8 28.8 27.0 24.0 20.0 18.0 17.0 14.0 HG2408P 8 28.8 27.0 24.0 20.0 18.0 17.0 14.0 HG2412P 12 27.5 26.0 24.0 20.0 18.0 17.0 14.0 HG2414P 14 26.8 25.3 23.3 20.0 18.0 17.0 14.0 HG2416P 16 26.1 24.7 22.7 20.0 18.0 17.0 14.0 HG2409Y 9 28.5 27.0 24.0 20.0 18.0 17.0 14.0 HG2412Y 12 27.5 26.0 24.0 20.0 18.0 17.0 14.0 HG2415Y 14.5 26.6 25.2 23.2 20.0 18.0 17.0 14.0 Amplifier(s): HA2401GI-XXX, HA2401G-XXX, where XXX stands for the amplifier power rating in mW NOTE: This table does not necessarily indicate compliant configurations, as FCC 15.247(b)(3)(i) has not yet been considered. Please see the Approved Configurations exhibit for a complete listing of FCC/IC compliant configurations and the channels in which they may operate.NOTE: This table does not necessarily indicate compliant configurations, as FCC 15.247(b)(3)(i) has not yet been considered. Please see the Approved Configurations exhibit for a complete listing of FCC/IC compliant configurations and the channels in which they may operate. Configurations in RED must have Amplifier Power Reduced to the values indicated Amplifier Power Rating (dB) Configurations in RED have an EIRP > 36 dBm Maximum Permissable Amplifier Power Rating Table per FCC Part 15.247(b)(3)(i) Amplifier Power Rating (dB) Initially Compliant EIRP Table (not considering FCC Part 15.247(b)(3)(i))

Hyperlink Extended Range Wireless LAN Product Description The Hyperlink Extended Range Wireless LAN Kit is a direct sequence spread spectrum wireless transceiver providing 54 Mbit/sec data rate to support wireless connections in an IEEE 802.3 LAN. Equipped with a Hyperlink Extended Range Amplified Antenna System, this product offers a high-performance long-range building-to-building wireless networking solution. This kit incorporates state-of-the-art direct sequence spread spectrum technology to implement robust 54 Mbps transmission, and offers true “Plug and Play” installation. This system has the following features: • IEEE 802.11b/g Compatibility. • Wireless 54 Mbps maximum data rate. • State-of-the-art spread spectrum technology provides reliable, secure, long range, radio link operation. • True “Plug and Play” installation for compatibility with all 802.3 and Ethernet II LAN devices, all operating systems and all protocol stacks. • PCMCIA Form Factor • Bi-directional amplifier with Automatic Gain Control to optimize transmit power and eliminate the effects of system cable losses.

RF Exposure Information The following table summarizes the minimum separation distance as calculated following FCC OET Bulletin 65. NOTE: THE ONLY PERMISSIBLE SYSTEM CONFIGURATIONS ARE THOSE LISTED ON THE FOLLOWING PAGE. The following equations were used in calculating the operating distance (R). 10 )( 10)()( dBGain mWPomWEIRP˜ and )/(4 )( 2 cmmWS mWEIRP R ˜3˜ , S = 1mW/cm 2 The following equations were used in calculating the RF Exposure (S) 2 2 )(4 )( )/( cmR mWEIRP cmmWS ˜3˜ , R = 100 cm (fixed), 20 cm (mobile) Card Alone Antenna Model Gain (dBi) 29.2 29 28 27 26 24 23 20 18 17 14 17.5 HG2401U 1 9.1 8.9 8.0 7.1 6.3 5.0 4.5 3.2 2.5 2.2 1.6 - HG2402RD 2 10.2 10.0 8.9 8.0 7.1 5.6 5.0 3.6 2.8 2.5 1.8 - HG2403RD 3 11.5 11.2 10.0 8.9 8.0 6.3 5.6 4.0 3.2 2.8 2.0 - HG2403UR 3 11.5 11.2 10.0 8.9 8.0 6.3 5.6 4.0 3.2 2.8 2.0 - HG2404CU 3 11.5 11.2 10.0 8.9 8.0 6.3 5.6 4.0 3.2 2.8 2.0 - RE05E 5 14.5 14.1 12.6 11.2 10.0 8.0 7.1 5.0 4.0 3.6 2.5 - RE05U 5 14.5 14.1 12.6 11.2 10.0 8.0 7.1 5.0 4.0 3.6 2.5 3.8 HG2405 5 14.5 14.1 12.6 11.2 10.0 8.0 7.1 5.0 4.0 3.6 2.5 - HG2406U 6 16.2 15.9 14.1 12.6 11.2 8.9 8.0 5.6 4.5 4.0 2.8 - HG2407U 7 N/A 17.8 15.9 14.1 12.6 10.0 8.9 6.3 5.0 4.5 3.2 - HG2408U 8 N/A 20.0 17.8 15.9 14.1 11.2 10.0 7.1 5.6 5.0 3.6 - HG2409U 8.5 N/A 21.2 18.9 16.8 15.0 11.9 10.6 7.5 6.0 5.3 3.8 - HGV-2409U 8.5 N/A 21.2 18.9 16.8 15.0 11.9 10.6 7.5 6.0 5.3 3.8 - HG2410U 10 N/A N/A 22.4 20.0 17.8 14.1 12.6 8.9 7.1 6.3 4.5 - HG2412U 12 N/A N/A N/A 25.1 22.4 17.8 15.9 11.2 8.9 8.0 5.6 - HG2415U-PRO 15 N/A N/A N/A N/A 31.7 25.1 22.4 15.9 12.6 11.2 8.0 - HG2409P 8 N/A 20.0 17.8 15.9 14.1 11.2 10.0 7.1 5.6 5.0 3.6 - HG2408P 8 N/A 20.0 17.8 15.9 14.1 11.2 10.0 7.1 5.6 5.0 3.6 - HG2412P 12 N/A N/A 28.2 25.1 22.4 17.8 15.9 11.2 8.9 8.0 5.6 - HG2414P 14 N/A N/A N/A 31.7 28.2 22.4 20.0 14.1 11.2 10.0 7.1 - HG2416P 16 N/A N/A N/A N/A 35.5 28.2 25.1 17.8 14.1 12.6 8.9 - HG2409Y 9 N/A 22.4 20.0 17.8 15.9 12.6 11.2 8.0 6.3 5.6 4.0 - HG2412Y 12 N/A N/A 28.2 25.1 22.4 17.8 15.9 11.2 8.9 8.0 5.6 - HG2415Y 14.5 N/A N/A N/A 33.5 29.9 23.7 21.2 15.0 11.9 10.6 7.5 - Configurations with N/A are not permissible, via. FCC 15.247(b)( 4 )(i) Card Alone Antenna Model Gain (dBi) 29.2 29 28 27 26 24 23 20 18 17 14 17.5 HG2401U 1 0.208 0.199 0.158 0.126 0.100 0.063 0.050 0.025 0.016 0.013 0.006 - HG2402RD 2 0.262 0.250 0.199 0.158 0.126 0.079 0.063 0.032 0.020 0.016 0.008 - HG2403RD 3 0.330 0.315 0.250 0.199 0.158 0.100 0.079 0.040 0.025 0.020 0.010 - HG2403UR 3 0.330 0.315 0.250 0.199 0.158 0.100 0.079 0.040 0.025 0.020 0.010 - HG2404CU 3 0.330 0.315 0.250 0.199 0.158 0.100 0.079 0.040 0.025 0.020 0.010 - RE05E 5 0.523 0.500 0.397 0.315 0.250 0.158 0.126 0.063 0.040 0.032 0.016 - RE05U 5 0.523 0.500 0.397 0.315 0.250 0.158 0.126 0.063 0.040 0.032 0.016 0.035 HG2405 5 0.523 0.500 0.397 0.315 0.250 0.158 0.126 0.063 0.040 0.032 0.016 - HG2406U 6 0.659 0.629 0.500 0.397 0.315 0.199 0.158 0.079 0.050 0.040 0.020 - HG2407U 7 N/A 0.792 0.629 0.500 0.397 0.250 0.199 0.100 0.063 0.050 0.025 - HG2408U 8 N/A 0.997 0.792 0.629 0.500 0.315 0.250 0.126 0.079 0.063 0.032 - HG2409U 8.5 N/A 0.045 0.889 0.706 0.561 0.354 0.281 0.141 0.089 0.071 0.035 - HGV-2409U 8.5 N/A 0.045 0.889 0.706 0.561 0.354 0.281 0.141 0.089 0.071 0.035 - HG2410U 10 N/A N/A 0.050 0.997 0.792 0.500 0.397 0.199 0.126 0.100 0.050 - HG2412U 12 N/A N/A N/A 0.063 0.050 0.792 0.629 0.315 0.199 0.158 0.079 - HG2415U-PRO 15 N/A N/A N/A N/A 0.100 0.063 0.050 0.629 0.397 0.315 0.158 - HG2409P 8 N/A 0.997 0.792 0.629 0.500 0.315 0.250 0.126 0.079 0.063 0.032 - HG2408P 8 N/A 0.997 0.792 0.629 0.500 0.315 0.250 0.126 0.079 0.063 0.032 - HG2412P 12 N/A N/A 0.080 0.063 0.050 0.792 0.629 0.315 0.199 0.158 0.079 - HG2414P 14 N/A N/A N/A 0.100 0.080 0.050 0.040 0.500 0.315 0.250 0.126 - HG2416P 16 N/A N/A N/A N/A 0.126 0.080 0.063 0.792 0.500 0.397 0.199 - HG2409Y 9 N/A 0.050 0.997 0.792 0.629 0.397 0.315 0.158 0.100 0.079 0.040 - HG2412Y 12 N/A N/A 0.080 0.063 0.050 0.792 0.629 0.315 0.199 0.158 0.079 - HG2415Y 14.5 N/A N/A N/A 0.112 0.089 0.056 0.045 0.561 0.354 0.281 0.141 - HG2424G 24 N/A N/A N/A N/A N/A 0.502 0.399 0.200 0.126 0.100 0.050 - Configurations with N/A are not permissible, via. FCC 15.247(b)( 4 )(i) Configurations in BLACK Can be used in either MOBILE OR FIXED MOUNTED Installations (RF Exposure computed at 20 cm distance) Configurations in RED can only be used in FIXED MOUNTED Installations (RF Exposure computed at 100 cm distance) RF Exposure (mW/cm^2) Amplifier Power Rating (dB) Configurations in RED can only be used in FIXED MOUNTED Installations Minimum Separation Distance (cm) Amplifier Power Rating (dB) Configurations in BLACK Can be used in either MOBILE OR FIXED MOUNTED Installations

FCC ID: HZB-G11FNFPC Report No.: RF920501R021Issue: May. 16, 2003 ADT No.: 920501R02 FCC TEST REPORT REPORT NO.: RF920501R02 MODEL NO.: G11FNF-PC RECEIVED: May 01, 2003 TESTED: May 08 to 15, 2003 APPLICANT: Proxim Corporation ADDRESS: 935 Stewart Drive, Sunnyvale, CA 94085, USA ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. This test report consists of 101 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. Lab Code: 200376-0 FCC ID: HZB-G11FNFPC Report No.: RF920501R022Issue: May. 16, 2003 ADT No.: 920501R02 Table of Contents 1CERTIFICATION.......................................................................................................4 2SUMMARY OF TEST RESULTS............................................................................5 3GENERAL INFORMATION.....................................................................................6 3.1GENERAL DESCRIPTION OF EUT......................................................................6 3.2DESCRIPTION OF TEST MODES........................................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS...................................7 3.4DESCRIPTION OF SUPPORT UNITS..................................................................8 4TEST TYPES AND RESULTS................................................................................9 4.1CONDUCTED EMISSION MEASUREMENT.......................................................9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT..................................9 4.1.2TEST INSTRUMENTS.............................................................................................9 4.1.3TEST SETUP....…
