MZR44014401

TM 9V U P L E F T R I G H T D O W N Activation Code / Code d'activation / Código de activación Primary Code / Code primaire / Código Principal QUICK START – UNLOCK WITH MOBILE DEVICE 1. Remove lock & instructions from package. 2. On mobile device, visit app store & download free Master Lock Vault eLocks app. 3. Follow prompts to log into, or create, a Master Lock Vault account. 4. In Master Lock Vault elocks app, touch Add a Lock (+). 5. Enter ACTIVATION CODE shown above to register lock & follow instructions to connect mobile device to lock. 6. Touch any button on lock keypad to wake up lock & prompt it to communicate with your mobile device. Your lock is now in Touch Unlock mode. You can recalibrate the phone-to-lock communication range in the app settings. QUICK START – UNLOCK WITH LOCK KEYPAD 1. Remove lock & instructions from package. 2. Enter PRIMARY CODE above by pressing the corresponding directions on lock keypad. Do not pull on the shackle when entering code. 3. When lock lights green, open within 5 seconds or it will relock. LED KEYPAD INDICATORS BLUEGREENYELLOWRED Locked, Communicating, or Keypad Entry Open or Unlocked & Waiting To Be Opened Low Battery Invalid Keypad Entry HOW TO REPLACE BATTERY 1. Lock will light yellow to indicate a low battery. 2. Unlock & open the lock. 3. Pull out battery drawer & remove old battery. 4. Install a new CR2450 battery with positive (+) side facing the back of the lock. 5. Close battery drawer. Model 4400 Battery Instructions HOW TO UNLOCK WITH EXTERNAL BATTERY 1. If battery dies in locked position, pull battery drawer out part way to expose jump contact point. Do not force the drawer open any further. 2. Hold a new CR2450 battery in the slot with positive (+) side of battery facing the front of the lock. 3. While holding the battery in place, with authorized mobile device within range of lock, press any keypad button on the lock (if in Touch Unlock mode). If lock does not unlock, enter Primary Code on lock keypad. 4. When unlocked, pull out battery drawer & install a new CR2450 battery. HOW TO REPLACE BATTERY 1. Lock will light yellow to indicate a low battery. 2. Unlock & open the lock. 3. Remove bottom cover. 4. Use a coin to turn battery door slot 90 degrees counter clockwise (A). Open battery door & remove old battery. 5. Install a new CR2 battery with positive (+) side facing right. 6. Close battery door, turn slot back 90 degrees clockwise & replace bottom cover. Model 4401 Battery Instructions HOW TO UNLOCK WITH EXTERNAL BATTERY 1. If the battery dies in locked position, remove bottom cover. 2. Hold a 9V battery to jump contacts on bottom of lock. 3. While holding the battery in place, with authorized mobile device within range of lock, press any keypad button on the lock (if in Touch Unlock mode). If lock does not unlock, enter Primary Code on lock keypad. 4. When unlocked, open battery door & install a new CR2 battery. Notice: This padlock and its operating software are subject to U.S. Export Administration Regulation controls. The padlock is subject to ECCN 5A992 and the downloadable app is subject to ECCN 5D992 as mass market software. Exporting this padlock and/or its software contrary to U.S. law is prohibited. Notice: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. 4400/4401 Instructions/Instrucciones For videos, instructions & FAQ’s, visit: Pour des vidéos, directives et FAQ, visitez : Para videos, instrucciones y preguntas frecuentes, visite: masterlock.com/MasterLockVaulteLocks/Support A TM P36572 9V H A U T G A U C H E D R O I T E B A S A R R I B A I Z Q U I E R D A D E R E C H A A B A J O DÉMARRAGE RAPIDE – DÉVERROUILLAGE PAR APPAREIL MOBILE 1. Retirez de l'emballage, le cadenas et les instructions. 2. Sur l'appareil mobile, visitez la boutique d'applications et téléchargez l'application Master Lock Vault eLocks gratuite. 3. Suivez les commandes pour ouvrir une session, ou créer un compte Master Lock Vault. 4. Dans l'application Vault eLock de Master Lock, appuyez sur Ajouter un cadenas (+). 5. Entrez le CODE D'ACTIVATION indiqué ci-dessus pour enregistrer un cadenas et suivez les directives pour lier l'appareil mobile au cadenas. 6. Touchez n'importe quel bouton du clavier du cadenas pour l'éveiller et le mettre en communication avec votre appareil mobile. Votre cadenas est maintenant en mode de déverrouillage par mode tactile. Vous pouvez étalonner de nouveau la portée de communication du téléphone de verrouillage à partir des réglages de l'application. INICIO RÁPIDO - DESBLOQUEAR CON UN DISPOSITIVO MÓVIL 1. Saque el candado y las instrucciones del paquete. 2. En un dispositivo móvil, visite la tienda de aplicaciones y descargue gratuitamente la aplicación móvil Master Lock Vault eLocks. 3. Siga las indicaciones para iniciar sesión o crear una cuenta de Master Lock Vault. 4. En la aplicación móvil elocks de Master Lock Vault, toque Add a Lock (+). 5. Ingrese el CÓDIGO DE ACTIVACIÓN que se muestra arriba para registrar el candado y siga las instrucciones para conectar el dispositivo móvil al candado. 6. Presione cualquier botón del teclado numérico del candado para activarlo y comunicarlo al dispositivo móvil. Su candado se encuentra ahora en modo de desbloqueo táctil. Usted puede reajustar el rango de comunicación candado-teléfono en la configuración de la aplicación. INICIO RÁPIDO – ABRIR EL CANDADO CON EL TECLADO 1. Saque el candado y las instrucciones del paquete. 2. Capture el CÓDIGO PRINCIPAL desde el frente presionando las direcciones correspondientes en el teclado del candado. No jale el gancho mientras captura el código. 3. Cuando el candado se ponga en luz verde ábralo en menos de 5 segundos o se volverá a cerrar. DÉMARRAGE RAPIDE – DÉVERROUILLAGE PAR CLAVIER DU CADEN…

Text truncated - open the document above for the full version.

September 3, 2015 Subject: Confidentiality Request for: MZR4401 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentialitv Requested Exhibit 0 Short Term 0 Permanent Block Diagrams 0 Short Term External Photos 0 Short Term 0 Permanent Internal Photos 0 Short Term 0 Permanent Operation Description/Theory of Operation 0 Short Term 0 Permanent Parts List & Placement/BOM 0 Short Term 0 Permanent Tune-Up Procedure 0 Short Term 0 Permanent Schematics 0 Short Term Test Setup Photos 0 Short Term 0 Permanent User's Manuals Master Lock Company LLC has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Best regards, ~ d~ By: D. Scott Kalous www.masterlock.com Master Lock Company U.C, 137 W. Forest Hill Avenue P.O. Box 927, Oak Creek, WI 53154, 414-571-5625

4401 Outdoor Padlock Finished Lock: Front Finished Lock: Back

R THIS DRAWING PRODUCED IN ACCORDANCE OF ASME Y14.5 - 2009 THIS DRAWING AND THE INFORMATION IT CONTAINS IS THE PROPRIETARY PROPERTY OF THE MASTER LOCK COMPANY, INC. AND MAY NOT BE REPRODUCED WITHOUT WRITTEN PERMISSION FROM MASTER LOCK COMPANY PRODUCT ENGINEERING MANAGEMENT. PROD FAMDRAWING NO.REV. MILWAUKEE, WISCONSIN 4401ART-000109B2 TITLE 4401 - LASER - ID MARKING MATERIAL LASER PLATING/FINISHLIMITS NOT SPECIFIED NATURAL IN[MM] X.XXX
# 0.005 [0.13] X.XX
# 0.010 [0.25] HEAT TREATCORNERS
# R0.010 MAXR[0.25] MAX . ANGULAR
# 1 DRAFT 1 THIRD ANGLE PROJECTION ECN NUMBERFILE NAMESHEETSCALESIZE ECO-011636ART-0001091 OF 11.000A B2 2015-09-16 DSKCHANGE FCC TO TEXT FROM LOGO B1 ECO-011636 2015-09-03 ZNADJUST LAYOUT & ADD IC INFO B 2015-08-13 ZNUPDATED PER SALES & MARKETING AECO-011354 2015-03-10 ZN.RELEASED FOR PRODUCTION REVECN #DATEBYAPPDESCRIPTION PLACEMENT SCALE 2.000 NOTES: 1. DATE CODE PER ES399 SECTION VIII

4401 Outdoor Padlock PCBA Front PCBA Back PCBA In housing

Engineering Test Report No. 1404076-02 Measurement of RF Emissions from the Model Nos. Indoor and Outdoor Master Lock Company Padlocks For Master Lock Company 137 W. Forest Hill Ave. Oak Creek, WI 53154 P.O. Number Y227079 Date Tested December 22, 2014 through December 31, 2014 Test Personnel Dayne Putnam Test Specification FCC "Code of Federal Regulations" Title 47, Part 15, Subpart C, Section 15.247 for Digital Modulation Intentional Radiators Operating within the 2400-2483.5MHz Band Industry Canada RSS-GEN Industry Canada RSS-210 Test Report By: Dayne Putnam EMC Engineer Requested By: Paul Shackett Master Lock Company Approved By: Raymond J. Klouda Registered Professional Engineer of Illinois - 44894 Elite Electronic Engineering, Inc. 1516 Centre Circle Downers Grove, IL 60515 Tel : (630) 495-9770 Fax: (630) 495-9785 www.elitetest.com Engineering Test Report No. 1404076-02 TABLE OF CONTENTS PARAGRAPH DESCRIPTION OF CONTENTS PAGE NO. THIS REPORT SHALL NOT BE REPRODUCED, EXCEPT IN FULL, WITHOUT THE WRITTEN APPROVAL OF ELITE ELECTRONIC ENGINEERING INCORPORATED. Page 2 of 100 1. Introduction ................................................................................................................................................... 5 1.1. Scope of Tests ..................................................................................................................................... 5 1.2. Purpose ............................................................................................................................................... 5 1.3. Deviations, Additions and Exclusions .................................................................................................. 5 1.4. EMC Laboratory Identification ............................................................................................................. 5 1.5. Laboratory Conditions.......................................................................................................................... 5 2. Applicable Documents .................................................................................................................................. 5 3. EUT Setup and Operation ............................................................................................................................ 6 3.1. General Description ............................................................................................................................. 6 3.1.1. Power Input ................................................................................................................................. 6 3.1.2. Peripheral Equipment ................................................................................................................. 6 3.1.3. Signal Input/Output Leads .......................................................................................................... 6 3.1.4. Grounding ................................................................................................................................... 6 3.2. Software ............................................................................................................................................... 6 3.3. Operational Mode ................................................................................................................................ 6 3.4. EUT Modifications ................................................................................................................................ 6 4. Test Facility and Test Instrumentation ......................................................................................................... 6 4.1. Shielded Enclosure .............................................................................................................................. 6 4.2. Test Instrumentation ............................................................................................................................ 6 4.3. Calibration Traceability ........................................................................................................................ 7 4.4. Measurement Uncertainty ................................................................................................................... 7 5. Test Procedures ........................................................................................................................................... 7 5.1. Powerline Conducted Emissions ......................................................................................................... 7 5.1.1. Requirements .............................................................................................................................. 7 5.2. 6dB Bandwidth ..................................................................................................................................... 7 5.2.1. Requirement................................................................................................................................ 7 5.2.2. Procedures .................................................................................................................................. 7 5.2.3. Results ........................................................................................................................................ 7 5.3. Peak Output Power .............................................................................................................................. 8 5.3.1. Requirements .............................................................................................................................. 8 5.3.2. Procedures .................................................................................................................................. 8 5.3.3. Results ........................................................................................................................................ 8 5.4. Radiated Spurious Emissions Measuremen…

Text truncated - open the document above for the full version.

Engineering Test Report No. 1404076-02 Page 16 of 100 Figure 2 Test Setup for Radiated Emissions, 30MHz to 1GHz – Horizontal Polarization Test Setup for Radiated Emissions, 30MHz to 1GHz – Vertical Polarization Engineering Test Report No. 1404076-02 Page 17 of 100 Figure 3 Test Setup for Radiated Emissions, 1GHz to 18GHz – Horizontal Polarization Test Setup for Radiated Emissions, 1GHz to 18GHz – Vertical Polarization Engineering Test Report No. 1404076-02 Page 18 of 100 Figure 4 Test Setup for Radiated Emissions, 18GHz to 25GHz – Horizontal Polarization Test Setup for Radiated Emissions, 18GHz to 25GHz – Vertical Polarization
