N27BS322Trinity323TDD,Trinity300TDD,BS340,BS342,BS320,BS322

RepeatIT ABTel: +46 8 570 106 66 Hamngatan 33Fax: +46 8 570 106 67 172 66 SundbybergE-mail: [email protected] Swedenwww.repeatit.se Product manual Product name: Trinity323TDD, Trinity300TDD, BS340,BS342,BS320,BS322 Model: 801-3230 and 801-3231, 801-3000 and 801-3001, 803-3400,803-3420, 803-320, 803-3220 Revision 1.1 Page2of14 Installation The Repeatit Base Station (BS) should always be mounted on the highest possible place with its antenna having clear line of sight to all clients. Together with the BS, the following equipment is provided in your box: •Base Station •Power over Ethernet adaptor •Mounting kit •Installation Guide Hardware setup Figure 1 - Hardware setup The BS should be connected to the Power over Ethernet (POE) adaptor’s P+DATA OUTsocket. Since both data and power is fed over the cable, all eight conductors should be used, and the Ethernet cable shall be straight. To the POE’s DATA INsocket, external equipment can be connected. When configuring the BS, a computer usually is used, and then the cable between the POE and the computer should be crossed. If the BS is connected to for example a network switch, the cable between the switch and the POE adaptor usually is straight. The BS unit is configured in a browser window. Start your browser and type the following line in the address field: http://10.0.0.1 Press Enter. A login window is shown. The default login settings are: User name: admin Password: public Type the user name and the password in the fields provided and press OK. In the browser window. Page3of14 Base station configuration The BS is intended to be used together with the Radio Control Software (RCS) developed by Repeatit. The configurations that can be made directly on the BS are overridden by the RCS as soon as a connection between the BS and the RCS is established and the BS is synchronized. Note: The settings shown in the web interface might not reflect the settings made in the RCS. BS100, BS200 and BS300 Series requires RCS with at least version 2.7.1.0 This Manual describes how the BS is configured through the Web interface. For RCS configuration please refer to the RCS manual. 1.2.1 Main window Figure 2 - The main window. Regulatory settings ETSI or ETSI-UK can be set depending on which regulatory domain the equipment is intended to be used. It controls which channels are available for selection. Radio Devices Configuration of the radio device is described in section 1.2.2 and section 1.2.3. The Status tabis described in section 1.2.4. Ethernet devices This is the Ethernet interface of the base station. It can not be configured. Settings Network settingsare described in section 1.2.5.Password settingsare described in section 1.2.8.Access control settingsare described in section 1.2.9. Page4of14 Utilities Here, the firmware can be upgraded. Usually, this is done from the RCS. Restore to Default Pressing this button restores the unit to factory defaults. The unit will automatically reboot when Restore to Default is performed. Reboot device Reboots the device. 3DJHRI  &RQILJXUHWDE–0DVWHUPRGH$UDGLRLQWHUIDFHFDQEHFRQILJXUHGLQWZRGLIIHUHQWZD\VHLWKHUDVDPDVWHURUDV DFOLHQW7KH0DVWHUPRGHLVVKRZQLQ)LJXUH7RVWRUHDQGDSSO\FKDQJHVSUHVV$SSO\ ,I%6LVFRQILJXUHGWREHXVHGZLWKDQ5&6VHUYHUWKHUHZLOOEHDZDUQLQJLQUHGVD\LQJWKDWLWLVFRQILJXUHGE\DQ5&6 VHUYHU7KHVHWWLQJVVKRZQPLJKWQRWUHIOHFWWKHDFWXDOVHWWLQJVXVHGE\WKH%6  )LJXUH5DGLRGHYLFHLQ0DVWHUPRGH  Page6of14 Basic settings Radio mode:Master/Slave. SSID:Wireless network name. This is the name that the customers will see when they perform a scan from their CPEs (Client Premise Equipment). Broadcast SSID:Tells whether the SSID should be visible when a scan is performed or not. Advanced settings Preamble:What type of preamble should be used for the radio transmission. Some old 802.11b units only supports long preamble so this parameter is available to support also these clients. The normal setting for this parameter is short. Note: This setting is only valid when mode is 802.11bg AP Bridge:Should the BS bridge between clients or not. If disabled two Clients connected to the same radio interface will not be able to communicate directly with each other. Flood unknown:Enabling this will make the BS send packets addressed to unknown receivers to all associated clients instead of dropping them. . Frequency:The frequency band to use. 802.11A, In this mode the BS will work as a standard 802.11A BS, it will only use the modulations specified for 802.11 use. 802.11N, In this mode the BS will work in both 11Aand 11N mode. It will accept both types of units at the same time. 802.11G, if a radiocard supporting also 2.4 GHz channels is used in the BS this choise is also valid. The BS will work on 2.4 GHz channels accepting both 11N and 11G clients. Channel:Within each frequency band, a number of different channels are available. Radar detection:Mandatory for the 5 GHz bands in most European countries. Check your national regulations. DFS CAC Policy:This controls how the BS should handle the mandatory Radar Scan time. Regulatory = use the time stated by the regulatories, normaly 1min scan time before a new channel can be used. Custom = You can specify your own time. Off = do not perform any Radar scan before using the channel. Note: The radar scan is mandatory in most Countries. Scan time on ch 120-128 is 10min. Custom CAC wait time: If DFS CAC Policy is configured as custom the time specified here will be used as the scan time before starting to use the channel configured. Guard intervalWhen running on 802.11N the guard time between consecutive OFDM symbols can be choosen to be short or long. BS will support both long and short when receiving, this parameter controls if short or long should be used when transmitting. Note: If 20MHz channel bandwidth is used only long…

Text truncated - open the document above for the full version.

Repeatit AB Date: 2012-12-21 Federal Communications Commission Authorization and Evaluation Division FCC ID: N27BS322 U ATTESTATION FCC ID: N27BS322 Product: Trinity323TDD, Trinity300TDD，BS340,BS342,BS320,BS322 Model: 801-3000 and 801-3001, 801-3230 and 801-3231，803-320， 803-3220，803-3400，803-3420 For US market, manufacturer will lock the operation frequency band 2.4G，5.2G and 5.5G, they will be switched off via software. The users can not be able to configure frequency range or channels out of ranges through website. Sincerely, Magnus Bergsten / Director Repeatit AB

Repeatit AB Date: 2013‐01‐30 Hamngatan 33, 172 66 Sundbyberg, Sweden Subject: Professional installation statement for FCC ID: N27BS322 Product: Trinity323TDD, Trinity300TDD，BS340,BS342,BS320,BS322 Model: 801-3000 and 801-3001, 801-3230 and 801-3231，803-320， 803-3220，803-3400，803-3420 Please be notified that we, the undersigned Repeatit AB, about our product listed above, we state that our device requires professional installation based on the following reasons: 1) This device will not be sold to the general public, it will be sold to dealers only. 2) This device requires controlled installation location and installed by licensed professionals. 3) This device requires professional configuration for use. 4) This device is intended for industry and commercial use. Sincerely, Magnus Bergsten / Director Repeatit AB

External Photo (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (9) EUT Photo (17dBi Antenna) (10) EUT Photo (17dBi Antenna) (11) EUT Photo (16dBi Antenna) (12) EUT Photo (16dBi Antenna) (13) EUT Photo (23dBi Antenna) (14) EUT Photo (23dBi Antenna) (15) EUT Photo (16) EUT Photo (17) EUT Photo (18) EUT Photo

Internal photo (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo

RF Exposure Evaluation Declaration Product Name : Trinity323TDD, Trinity300TDD, BS340, BS342, BS320, BS322 Model No. : 801-3000 and 801-3001, 801-3230 and 801-3231, 803-320, 803-3220, 803-3400, 803-3420 FCC ID : N27BS322 Applicant : Repeatit AB Address : Hamngatan 33, 172 66 Sundbyberg, Sweden Date of Receipt : 19/10/2012 Issued Date : 03/12/2012 Report No. : 12AS018R-RF-US Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, CNAS or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No: 12AS018R-RF-US Page: 2 of 5 Test Report Certification Issued Date: 03/12/2012 Report No.: 12AS018R-RF-US Product Name : Trinity316TDD Plus Applicant : Repeatit AB Address : Hamngatan 33, 172 66 Sundbyberg, Sweden Manufacturer : Repeatit AB Address : Hamngatan 33, 172 66 Sundbyberg, Sweden Model No. : 801-3000 and 801-3001, 801-3230 and 801-3231, 803-320, 803-3220, 803-3400, 803-3420 FCC ID : N27BS322 EUT Voltage : AC 120V/ 60Hz Trade Name : Repeatit AB Applicable Standard : FCC OET 65 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392 Documented By : ( Engineering ADM: Alice Ni ) Reviewed By : (Senior Engineer: Jame Yuan) Approved By : (Manager: Marlin Chen) Report No: 12AS018R-RF-US Page: 3 of 5 Laboratory Information We, QuieTek Corporation , are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. : BSMI, NCC, TAF Germany : TUV Rheinland Norway : Nemko, DNV USA : FCC, NVLAP Japan : VCCI China : CNAS Report No: 12AS018R-RF-US Page: 4 of 5 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No: 12AS018R-RF-US Page: 5 of 5 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. 1.3. Test Result of RF Exposure Evaluation Product : BS322 Antenna Gain: The following list antenna may be used with this wireless module card. Antenna Manufacturer Model No. Peak Gain Sector Antenna Lanbowan Communications Ltd. ANT4958D17D-90DP 5GHz: 17dBi Panel Antenna REPEATIT N/A 5GHz: 16dBi Panel Antenna REPEATIT N/A 5GHz: 23dBi RF Exposure Measurement Results: Operation Mode Frequency Range (MHz) Maximum Conducted Power (dBm) Limit of Power Density S(W/m 2 ) Safety Distance r (cm) 802.11a/n(20MHz) 5745~5825 26.17 10 81.08 802.11n(40MHz) 5755~5795 26.36 10 82.87 So the safety distance should be kept with above table for different antenna installed, and Trinity323TDD, Trinity300TDD, BS340, BS342, BS320, BS322 shall be installed without any other radio equipment.

Test Report FCC Part15 Subpart C Product Name : Trinity323TDD, Trinity300TDD, BS340, BS342, BS320, BS322 Model No. : 801-3000 and 801-3001, 801-3230 and 801-3231, 803-320, 803-3220, 803-3400, 803-3420 FCC ID : N27BS322 Applicant : Repeatit AB. Address : Hamngatan 33, 172 66 Sundbyberg, Sweden Date of Receipt : 19/10/2012 Test Date : 19/10/2012~28/11/2012 Issued Date : 03/12/2012 Report No. : 12AS018R-RF-US-P05V01 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, CNAS or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No: 12AS018R-RF-US-P05V01 Page: 2 of 103 Test Report Certification Issued Date : 03/12/2012 Report No. : 12AS018R-RF-US-P05V01 Product Name : Trinity323TDD, Trinity300TDD, BS340, BS342, BS320, BS322 Applicant : Repeatit AB Address : Hamngatan 33, 172 66 Sundbyberg, Sweden Manufacturer : Repeatit AB Address : Hamngatan 33, 172 66 Sundbyberg, Sweden Model No. : 801-3000 and 801-3001, 801-3230 and 801-3231, 803-320, 803-3220, 803-3400, 803-3420 FCC ID : N27BS322 EUT Voltage : AC 120V/ 60Hz Brand Name : Repeatit AB Applicable Standard : FCC CFR Title 47 Part 15 Subpart C: 2012 ANSI C63.4: 2009; ANSI C63.10: 2009 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392 Documented By : (Engineering ADM: Alice Ni) Reviewed By : (Senior Engineer: Jame Yuan) Approved By : (Manager: Marlin Chen) Report No: 12AS018R-RF-US-P05V01 Page: 3 of 103 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI China :CNAS Report No: 12AS018R-RF-US-P05V01 Page: 4 of 103 TABLE OF CONTENTS Description Page 1. General Information ....................................................................................................... 6 1.1. EUT Description ......................................................................................................... 6 1.2. Mode of Operation ..................................................................................................... 8 1.3. Tested System Details ................................................................................................ 9 1.4. Configuration of Tested System ............................................................................... 10 1.5. EUT Exercise Software ............................................................................................ 11 2. Technical Test .............................................................................................................. 12 2.1. Summary of Test Result ........................................................................................... 12 2.2. Test Environment ..................................................................................................... 13 3. Conducted Emission .................................................................................................... 14 3.1. Test Equipment ........................................................................................................ 14 3.2. Test Setup ................................................................................................................ 14 3.3. Limit .......................................................................................................................... 15 3.4. Test Procedure ......................................................................................................... 15 3.5. Uncertainty ............................................................................................................... 15 3.6. Test Result ............................................................................................................... 16 4. Radiated Emission ....................................................................................................... 18 4.1. Test Equipment ........................................................................................................ 18 4.2. Test Setup ................................................................................................................ 19 4.3. Limit .......................................................................................................................... 20 4…

Text truncated - open the document above for the full version.

Test Setup Photograph Test Mode: Transmitting Description: Front View of Conducted Emission Test Setup Test Mode: Transmitting Description: Back View of Conducted Emission Test Setup Test Mode : Transmitting Description : Radiated Emission Test Setup for Below 1GHz Test Mode : Transmitting Description : Radiated Emission Test Setup for 1~18GHz Test Mode : Transmitting Description : Radiated Emission Test Setup for Above 18GHz
