N2ARSB-D421-W2.1 wireless sound bar

> Package Contents Wir eless Subwoofer Power cable for Soundbar Power cable for Subwoofer Remote Contr ol and Batt er ies Soundbar stands & screws (pre-installed) (2) RCA ster eo cable User Manual (download from www.aurasound.c om) Quick Start Guide 1 The soundbar operates in unison with the wireless subwoofer and they come paired from the factory. Follow the Pairing Procedure in the User Manual if pairing is needed. Audio Connections + Instructions Input 1 Input 2 Connect Equipment 2. Connect one end of the audio cable (white and red connectors) to the analog audio 1 . Turn off power to the soundbar and the connected device(TV,DVD,Blu-ray Player etc). outputs on the device. 3. Connect the other end of the audio cable (White and red connectors) to the Input 1 in jacks on the soundbar. 4. Tur n on the power to the soundbar and the device. 5. Select the associated input by pressing INPUT on the top of the soundbar or pressing INPUT on the remote contr ol . For best performance, use the optical jack on your soundbar if your TV, set-top box, DVD player, home theater system, etc. has an optical digital output. Turn off power to the soundbar and the device. Connect one end of the optical (S/PDIF) cable (Sold Separately) to the Digital audio output on the device. * CAUTION: Remove Optical Cable protection before inserting into the soundbar. Connect the other end of the optical (S/PDIF) cable to the Optical jacks on the soundbar. Turn on the power to the soundbar and the device. Select the Optical input by pressing INPUT on the top of the soundbar or pressing OPTICAL on the remote control. Connect Equipment Digital Connection Input 1 Input 2 Iput 1 Iput 2 -Not Included 1. Turn off power to the soundbar and the MP3 player. 2. Connect one end of the audio cable to the analog audio output on the MP3 docking unit. 3. Connect the other end of the audio cable (white and red connectors) to the Input 1 in jacks on the soundbar. 4. Turn on the power to the soundbar and MP3 player. 5. Select the associated input by pressing INPUT on the top of the soundbar or pressing INPUT on the remote control. -Most MP3 players commonly use a 1/8” stereo Mini-Jack. In this case, use a 1/8” stereo mini-jack-to-RCA (AV) cable (Sold Separately) -Refer to your MP3 player user manual for more information about the audio output setting and connections of the product. -Do not connect the MP3 player headphone output directly to the soundbar. This can result in damage to the devices. 1. Connect one end of the AC adapter into the 24V DC jack on the back of the soundbar. 2. Connect one end of the AC adapter into the 100-240V AC jack on the back of the subwoofer. Input 1 Input 2 1. Connect audio and video cables to your soundbar. (See Connecting Equipment for Details) 2. Connect the power cord to the power cord connector on the back of your soundbar. 3. Mark and drill holes in the desired location on the wall. Use anchors (not included) if you are not drilling into studs. 4. Insert screws (not included), leaving room for your soundbar stands. 5. Hang your soundbar on the screws. The soundbar can either be kept on the stand or mounted on the wall. If you choose to mount the soundbar on the wall, follow the instructions Connect Power SoundBar Subwoofer Understanding the Remote Contr ol Power: Press to turn your Soundbar on or off Volume: Press to turn the speak er volume up or down Sub: Press to increas e or descr eas e the volume output of the subwoofer relative to the over all system volume Bas s: Press to increas e or decreas e the bas s output of the over all system SRS TVOL: Pres s to contr ol the level of the audio out to prevent commercials from being louder than the volume of the program being viewed. Mute: Pres s to turn the sound on and off Note: This will not mute any connected headphones Treb: Pres s to increas e or decreas e the treble output of the over all system. SRS TSHD: Pres s to turn SRS TruSurround HD or SRS WOW HD on or off. Input, Optical: Press these buttons to select the desired input FCC Notice 10 > This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct The interference by one or more of the following measures: FCC Statement Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note: “Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.” The Ultimate Vision in Sound

Address: Unit 06, 39/F, Metroplaza Tower II,223 Hing Fong Road, Kwai Fong, N.T. Hong Kong Phone: (852) 3743-0923 Fax no: (852)3743-0920 Website: www.aurasound.com Federal Communications Commission Authorization and Evaluation Division Date: Jun.20,2012 Confidentiality Request regarding application for certification of FCC ID: N2ARSB-D421-W Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1.Schematic 2.Theory of Operation 3.Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, We do not want these documents to be accessible to the general public. Sincerely, Ian Yang Project Manager AuraSound (Hong Kong) Limited Tel:86-755-82548866 Fax: 0755-82548686 Website: www.aurasound.com Email: [email protected]

External Photos

Internal Photos

FCC TEST REPORT 47 CFR FCC Part 15.249 Report Reference No. ..................... : FCC ID. ............................................. : TRE11120060 N2ARSB-D421-W Compiled by ( position+printed name+signature) .. : File administrators Eric Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Tim Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Jun 20, 2012 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : AuraSound (Hong Kong) Limited Address ............................................. : Unit 06, 39/F, Metroplaza Tower II,223 Hing Fong Road, Kwai Fong, N.T. Hong Kong Manufacturer’s name ..................... : Wuhan AuraSound CO.,LTD Address ............................................. : Three layer G building, export processing zone, Zhuankou, wuhan, china Test specification: Standard .......................................... : 47 CFR FCC Part 15 Subpart C & 15.249 ANSI C63.10: 2009 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment Under Test .................. : 2.1 wireless sound bar Trade Mark ....................................... : / Model/Type reference ....................... : RSB-D421 Listed Models .................................. : AS42-210 Result ................................................ : Complied Report No.: TRE11120060 Page 2 of 37 Issued: 2012-06-20 FCC ID: N2ARSB-D421-W Shenzhen Huatongwei International Inspection Co., Ltd T E S T R E P O R T Test Report No. : TRE11120060 Jun 20, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : 2.1 wireless sound bar Model /Type : RSB-D421 Listed Models : AS42-210 Applicant : AuraSound (Hong Kong) Limited Address : Unit 06, 39/F, Metroplaza Tower II,223 Hing Fong Road, Kwai Fong, N.T. Hong Kong Manufacturer : Wuhan AuraSound CO.,LTD Address : Three layer G building, export processing zone, Zhuankou, wuhan, china Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE11120060 Page 3 of 37 Issued: 2012-06-20 FCC ID: N2ARSB-D421-W Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY ............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Adapter information: 5 2.4. Short description of the Equipment under Test (EUT) 5 2.5. EUT operation mode 5 2.6. Related Submittal(s) / Grant (s) 5 2.7. Modifications 5 3. TEST ENVIRONMENT ............................................................... 6 3.1. Address of the test laboratory 6 3.2. Test Facility 6 3.3. Statement of the measurement uncertainty 7 3.4. Summary of standards and result 7 3.5. Environmental conditions 8 3.6. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................. 9 4.1. ANTENNA REQUIREMENT 9 4.2. Conducted Emissions Test 10 4.3. Radiated Emission Test 15 4.4. Out of band emissions 24 4.5. 20dB Bandwidth Measurement 26 5. TEST SETUP PHOTOS OF THE EUT .......................................... 29 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 31 Report No.: TRE11120060 Page 4 of 37 Issued: 2012-06-20 FCC ID: N2ARSB-D421-W Shenzhen Huatongwei International Inspection Co., Ltd 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Rules Part 15.249: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. ANSI C63.10: 2009 – American National Standard for Teating Unlicensed Wireless Devices Report No.: TRE11120060 Page 5 of 37 Issued: 2012-06-20 FCC ID: N2ARSB-D421-W Shenzhen Huatongwei International Inspection Co., Ltd 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Jul 21, 2011 Testing commenced on : Jul 21, 2011 Testing concluded on : Jun 20, 2012 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ● 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ○ Other (specified in blank below) 2.3. Adapter information: ● AC Adapter 1 MODEL:S065BQ2400270 INPUT:100-240V～50/60Hz 1.8A OUTPUT: 24.0V DC 2.7A Power Cable: 200cm ◇ Shielded ◆ Unshielded ● AC Adapter 2 MODEL:YJS05-2402500D INPUT:100-240V～47/63Hz 1.5A OUTPUT: 24.0V DC 2.5A Power Cable: 200cm ◇ Shielded ◆ Unshielded 2.4. Short description of the Equipment under Test (EUT) 2.4 GHz -2483.5GHz (Transceiver) For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.5. EUT operation mode The EUT has been tested under typical operating condition. 2.6. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: N2ARSB-D421-W filing to comply with Section 15.249 of the FCC Part 15, Subpart C Rules. 2.7. Modifications No modifica…

Text truncated - open the document above for the full version.
