File E187189 Project 98NK26136Page 1 of 9 EMC – TEST REPORT Issue Date: July 22, 1998 Test Report File No.:E187189 Project No.:98NK26136 Model / Type: CTL, CTU, CDU, CTT,CGOB,CPO, CGO-1 & CGO-2 Kind of Product:Energy Saving Lamp Applicant:Corso Ltd. License Holder:Corso Ltd. Address:1425 Louis Ave. :Elk Grove, IL 60007 : Manufacturer:Same as Applicant : : : Test Result : COMPLIANT This report without appendices consists of 9 pages. Appendix A contains test photos, and Appendix B contains original test data. The data contained in this report reflects only the items tested in the configurations and mode of operations described. An attempt has been made to arrange the EUT, with the equipment provided, into a test configuration which maximizes the observed emissions of the EUT while simulating, as close as practical, a typical end-use installation. Underwriters Laboratories Inc. authorizes the above company to reproduce this report provided it is reproduced in its entirety. Underwriters Laboratories Inc.333 Pfingsten Rd. Northbrook, IL 60062 Tel: (847) 272-8800 or (800) USE-ULEMCFax: (847) 272-8864 www.ul.com/services/emc EMISSIONS IMMUNITY File E187189 Project 98NK26136Page 2 of 9 REPORT DIRECTORY SECTIONTITLE GENERAL 1.0 General Product Description 1.1 Model Differences 1.2 Environmental Conditions in Test Lab 1.3 Calibration Details of Equipment Used for Measurement 1.4 EUT (Equipment Under Test) Configuration 1.5EUT Operating Mode 1.6Device Modifications EMISSIONS 2.0Emissions Test Regulations Conducted Voltage Radiated Electric Field Emissions Radiated Magnetic Field Emissions Conducted Power Discontinuous Interference (Clicks) Harmonic Current Emissions and Voltage Fluctuations / Flicker IMMUNITY 3.0Immunity Test Regulations 3.1Performance Criteria CONCLUSION 4.0General Remarks 4.1Summary APPENDICIES ATest Setups (Photos, Diagrams and Drawings) BTest Data File E187189 Project 98NK26136Page 3 of 9 1.0GENERAL PRODUCT DESCRIPTION Energy saving lamp, Florescent type with standard lamp holder screw shell base assembly. 1.0.1Equipment Mobility: Fixed 1.0.2Test Voltage and Frequency: Voltage (V)Frequency (Hz) 12060 1.1MODEL DIFFERENCES Any other model(s) represented by the models tested in this investigation will be documented by the manufacturer. 1.2ENVIRONMENTAL CONDITIONS IN TEST LAB Temperature:20-25 °C Relative Humidity:30-60% RH Atmospheric Pressure:680-1060 mbar 1.3CALIBRATION OF EQUIPMENT USED FOR MEASUREMENT All test equipment and test accessories are calibrated on a regular basis. The maximum time between calibrations is one year or what is recommended by the manufacturer, whichever is less. File E187189 Project 98NK26136Page 4 of 9 1.4EUT CONFIGURATION(s) See Appendix A for individual set-up configuration(s). In addition to the EUT, the following peripheral devices and/or cables were connected during the measurement: DeviceManufacturerModelSerial #FCC ID N/A CableManufacturerLengthTypeShield Type Shield Termination N/A BLOCK DIAGRAM & ELECTRICAL SCHEMATIC File E187189 Project 98NK26136Page 5 of 9 1.5 EUT OPERATING MODE(s) The equipment under test was operated during the measurements under the following conditions: 'ON' Continuous operation 1.6DEVICE MODIFICATIONS The following modifications were necessary for compliance: None. File E187189 Project 98NK26136Page 6 of 9 2.0EMISSIONS TEST REGULATIONS Emissions testing was performed according to the following regulations: 47 CFR Part 18: 1996 File E187189 Project 98NK26136Page 7 of 9 CONDUCTED VOLTAGE EMISSIONS Test Location Ground Plane (Test Station 3) UL Procedure 4414-LPG-001 Test Instruments Spectrum Analyzer / Quasi-peak Adapter / Preselector Advantest Model 3261A Spectrum Analyzer No. FCA 4001 Model R3551 Preselector No. FCA4005, Last Cal. 11/97 Line Impedance Stabilization Networks (LISNs) SOLAR Model 8602-50-TS-50-N S/N 963903 No. EMC4068, Last Cal. 7/97 SOLAR Model 8602-50-TS-50-N S/N 963904 No. EMC4069, Last Cal. 7/97 Transient Limiter Hewlett Packard Model 11947ANo. EMC 4005 Frequency Range on each line 450kHz to 30 MHz Test Results The requirements are: MET Remarks See App. B for complete test results. File E187189 Project 98NK26136Page 8 of 9 RADIATED ELECTRIC FIELD EMISSIONS Test Location 10 Meter Semi-Anechoic Chamber UL Procedure 4414-LPG-002 Test Instruments Spectrum Analyzer / Quasi-peak Adapter / Preselector Hewlett Packard Model 8566B Spectrum Analyzer Model 85650A Quasi-peak Adapter Model 85685A RF Preselector No. FCA4002, FCA4003, EMC4001, EMC4002 Last Cal. .6/98 Antennas Chase EMC Ltd., Biconical Antenna Model VBA6106A, S/N 1237, Last Cal. 2/98 Chase EMC Ltd., Log Periodic Antenna Model UPA6108, S/N 1120, Last Cal. 2/98 Frequency Range of Measurement 30 MHz – 1000 MHz Measurement Distance 10 meters Test Results The requirements are: MET Remarks See App. B for complete test results. File E187189 Project 98NK26136Page 9 of 9 4.0GENERAL REMARKS Sample Receipt Date: July 17, 1998 Test Dates Start: July 17, 1998 End: July 17, 1998 4.1SUMMARY The requirements according to the technical regulations are: MET Underwriters Laboratories Inc. 333 Pfingsten Road Northbrook, IL 60062 USA Test Engineer:Reviewed by: Mike Ehas (Ext 42351)Mike Windler EMC Engineering AssociateAssociate Managing Engineer International EMC ServicesInternational EMC Services File E187189 Project 98NK26136Page A1 ofA3 APPENDIX A PHOTOS CONDUCTED VOLTAGE FIG. 1 RADIATED EMISSIONS FIG. 2 File E187189 Project 98NK26136Page A2 ofA3 CONDUCTED EMISSIONSFIG. 1 File E187189 Project 98NK26136Page A3 ofA3 RADIATED EMISSIONSFIG. 2 File E187189 Project 98NK26136Page B1 of B7 APP ENDIX B TEST DATA EMISSIONS Conducted Voltage Radiated Electric Field Emissions File E187189 Project 98NK26136Page B2 of B7 File E187189 Project 98NK26136Page B3 of B7 UNDERWRITERS LABORATORIES INC. Conducted Emissions Date Tested: 17 July 1998 Manufacturer: Corso Ltd. Equipment Under Test: CTL, 23W, Base E26 Energy Saving Lamp Requirement: FCC CFR 47, PART 18 Detection Mode: Quasi-peak …
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output | Tolerance |
|---|---|---|---|---|
| 1 | 18 | 0.038 MHz - 0.038 MHz | - | % |

CFL
Equipment Class
8CC - Part 18 Consumer Device
PART 18 CONSUMER DEVICE
Equipment Class
8CC - Part 18 Consumer Device
PART 18 CONSUMER DEVICE
Equipment Class
8CC - Part 18 Consumer Device
PART 18 CONSUMER DEVICE
Equipment Class
8CC - Part 18 Consumer Device
Electronic Adapter
Equipment Class
8CC - Part 18 Consumer Device
