N6AFJEE0406ENERGY SAVING LAMP

User’s Manual This light device has been tested and found to comply with the limits for Consumer RF Lighting Device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. 1 Use only on 120V/60Hz. 2 Never disassemble or modify-any changes could void the user’ authority to operate this device. 3 Not for use in totally enclosed recessed fixtures. 4 Risk of electric shock-do not use with where directly exposed to water. 5 This device is not intended for use with emergency exit fixtures or emergency exit lights. 6 This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30MHz. 7 To prevent burns, do not touch the bulb during operation or immediately after switching off. 8 Not for use with dimmers, or photocell devices or occupancy sensor.

F IGURE 1 E NERGY S AVING L AMP (M/N: R30 T3S 15W) G ENERAL A PPEARANCE F IGURE 2 E NERGY S AVING L AMP (M/N: A-T YPE T3S 15W) G ENERAL A PPEARANCE F IGURE 3 E NERGY S AVING L AMP (M/N: G LOBE T3S 15W) G ENERAL A PPEARANCE F IGURE 4 E NERGY S AVING L AMP (M/N: T UBULAR T3S 15W) G ENERAL A PPEARANCE

Label Location Information Refer to the below red arrow: (For example)

Label Drawing JOINLUCK FCC ID: N6AFJEE0406

F IGURE 1 E NERGY S AVING L AMP (M/N: R30 T3S 15W) C OVER R EMOVED F IGURE 2 E NERGY S AVING L AMP (M/N: R30 T3S 15W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 3 E NERGY S AVING L AMP (M/N: R30 T3S 15W) M AIN B OARD (S OLDERED S IDE ) F IGURE 4 E NERGY S AVING L AMP (M/N: A-T YPE T3S 15W) C OVER R EMOVED F IGURE 5 E NERGY S AVING L AMP (M/N: A-T YPE T3S 15W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 6 E NERGY S AVING L AMP (M/N: A-T YPE T3S 15W) M AIN B OARD (S OLDERED S IDE ) F IGURE 7 E NERGY S AVING L AMP (M/N: G LOBE T3S 15W) C OVER R EMOVED F IGURE 8 E NERGY S AVING L AMP (M/N: G LOBE T3S 15W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 9 E NERGY S AVING L AMP (M/N: G LOBE T3S 15W) M AIN B OARD (S OLDERED S IDE ) F IGURE 10 E NERGY S AVING L AMP (M/N: T UBULAR T3S 15W) C OVER R EMOVED F IGURE 11 E NERGY S AVING L AMP (M/N: T UBULAR T3S 15W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 12 E NERGY S AVING L AMP (M/N: T UBULAR T3S 15W) M AIN B OARD (S OLDERED S IDE )

Schematics APPENDIX F ORM OF C OMPONENTS COMPONENT LIST FOR R30 T3S 15W, Globe T3S 15W, A-Type T3S 15W, Tubular T3S 15W CODE MATERIAL NAME SPECIFICATION QUANTITY TR1 、 TR2 TRANSISTOR Ic ≥ 1.5A Vceo ≥ 200V Pcm ≥ 20W Tj=150 °C 2 D1 〜 D5 DIODE PRV=1000V Io=1.0A 5 DB3 TRIGGER DIODE Vbo=28V~36V Itrm=2A Tj= -40 °C ~+100 °C 1 R1 、 R4 RESISTOR 330K Ω , 1/4W 2 R2 、 R3 RESISTOR 10 Ω , 1/4W 2 PTC THERMISTOR MAX. VOLTAGE ≥ 600V SWITH TEMP.=75 °C 1 C1 、 C7 CAPACITOR 100nF, 250V 2 C2 ELECTROLYTIC CAPACITOR 15 μ F , 200V 105 °C 1 C3 CAPACITOR 22nF, 100V 1 C4 CAPACITOR 2.2nF, 1000V 1 C5 CAPACITOR 3.3nF, 1000V 1 C6 CAPACITOR 4.7nF , 1000V 1 L1 INDUCTOR Φ 6×8 NO. OF TURNS=240T, 1.4mH~1.6mH 1 L2 INDUCTOR EE16 NO. OF TURNS=206T, 1.95mH~2.10mH 1 T1 、 T2 、 T3 MAGNETIC RING Ф 9×5×3 1 S SOCKET E26 BRASS PLATED WITH NICKEL 1 T GLASS TUBE 15W 1 C GLASS COVER 1 W1 ENAMELLED COPPER WIRES FOR L1 Φ 0.15mm 130 °C 1 W2 ENAMELLED COPPER WIRES FOR MAGNETIC RING Φ 0.27mm 130 °C 1 W3 ENAMELLED COPPER WIRES FOR L2 Φ 0.27mm 130 °C 1 W4 LEAD WIRE AWG 24 105 °C 600V 1 FUSE FUSE 125V 1A 1 B2 MAGNETIC RING BASE (OPTIONAL) 1 I INSULATION TUBING 9 JL-0451 PCB 1 P PLASTIC ENCLOSURE 1

Fujian Joinluck Electronic Enterprise Co., Ltd. FCC ID: N6AFJEE0406 Page 1 of 18 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F04086 Application for FCC Certificate On Behalf of Fujian Joinluck Electronic Enterprise Co., Ltd. Energy Saving Lamp Model No.: R30 T3S 15W A-Type T3S 15W Globe T3S 15W Tubular T3S 15W Serial No.: F04101001 F04101002 F04101003 F04101004 FCC ID: N6AFJEE0406 Prepared For : Fujian Joinluck Electronic Enterprise Co., Ltd. Cangshan Industrial Area, Cangshan District, Fuzhou, Fujian, China. Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel : +86-21-64955500 Fax : +86-21-64955491 Report No. : ACI-F04086 Date of Test : Oct 20, 2004 Date of Report : Oct 25, 2004 Fujian Joinluck Electronic Enterprise Co., Ltd. FCC ID: N6AFJEE0406 Page 2 of 18 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F04086 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 7 2.4 Test Configuration...................................................................................................................... 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures .......................................................................................................................... 7 2.7 Test Results ................................................................................................................................ 8 3 MAGNETIC FIELD EMISSION TEST ...................................................................................... 13 3.1 Test Equipment......................................................................................................................... 13 3.2 Block Diagram of Test Setup ................................................................................................... 13 3.3 Magnetic Field Emission Limit ................................................................................................ 13 3.4 EUT Configuration on Test ...................................................................................................... 14 3.5 Operating Condition of EUT .................................................................................................... 14 3.6 Test Procedures ........................................................................................................................ 14 3.7 Test Results .............................................................................................................................. 14 Fujian Joinluck Electronic Enterprise Co., Ltd. FCC ID: N6AFJEE0406 Page 3 of 18 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F04086 TEST REPORT FOR FCC CERTIFICATE Applicant : Fujian Joinluck Electronic Enterprise Co., Ltd. Manufacturer : Fujian Joinluck Electronic Enterprise Co., Ltd. EUT Description : Energy Saving Lamp (A) Model No.: R30 T3S 15W, A-Type T3S 15W, Globe T3S 15W, Tubular T3S 15W (B) Serial No.: F04101001, F04101002, F04101003, F04101004 (C) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2003.10) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (Please see the EUT Description above), which was tested in 3m anechoic chamber on Oct 20, 2004, to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report contains data that are not covered by the NVLAP accreditation. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Date of Test : Oct 20, 2004 Prepared by : Test Engineer : KATHY WANG (Assistant) HARRY ZHAO (Engineer) Reviewer : Approved Signatory : SAMMY CHEN (Supervisor) BYRON KWO (Deputy Manager) WANG Fujian Joinluck Electronic Enterprise Co., Ltd. FCC ID: N6AFJEE0406 Page 4 of 18 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F04086 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Energy Saving Lamp Type of EUT : ; Production … Pre-product … Pro-type Model Number : R30 T3S 15W, A-Type T3S 15W, Globe T3S 15W, Tubular T3S 15W Serial Number : F04101001, F04101002, F04101003, F04101004 Note : Except the lamp shades, model numbers and serial numbers, they are the same product…
