N6N2012061802HEVM-850Tx

VM-810/VM-850 Pipe and Cable Locator User Handbook (English Edition) Version 1.1 Table of Content General Safety & Care Information ........................................................................................................... 1 1.1 Who Can Use This Equipment ................................................................................................... 1 1.2 Work-site Safety ......................................................................................................................... 1 1.3 Equipment Safety ....................................................................................................................... 1 1.4 Batteries and Environmental Safety ........................................................................................... 1 1.4.1 Alkaline Batteries (Non Rechargeable) ................................................................................ 1 1.4.2 Nickel Metal Hydride Batteries (Rechargeable) ................................................................... 1 1.4.3 Lithium-Ion Batteries (Rechargeable) .................................................................................. 2 1.4.4 Lithium Metal Batteries (Non Rechargeable) ....................................................................... 2 1.4.5 General Rules Regarding Disposal of Batteries ................................................................... 2 1.4.6 Transportation of Lithium-ion and Lithium Metal Batteries ................................................... 2 1.5 Care of Equipment ...................................................................................................................... 2 1.6 Care When Interpreting the Information Provided by the Locator ............................................... 3 1.7 American & Canadian Safety Notices ......................................................................................... 3 Service & Support ..................................................................................................................................... 4 2.1 Serial Number and Software Revision Number .......................................................................... 4 2.2 Distributors and Service Centers Closest to You: ....................................................................... 5 Introduction ............................................................................................................................................... 6 3.1 VM-810/VM-850 ......................................................................................................................... 6 3.2 VM-810/VM-850 Receiver Controls and Indicators ..................................................................... 7 3.3 VM-810/VM-850 Transmitter Controls and Indicators ................................................................. 8 Check Out Procedure ............................................................................................................................. 10 4.1 Introduction ............................................................................................................................... 10 Operation ................................................................................................................................................ 12 5.1 Transmitter – Direct Connection ............................................................................................... 12 5.2 Transmitter – Inductive Coupling .............................................................................................. 13 5.3 Transmitter – Inductive Method ................................................................................................ 14 5.4 Using the Receiver ................................................................................................................... 15 5.5 Determining the Depth and Signal Current applied to a Conductor .......................................... 16 5.6 Conductor Identification using a Second Signal Clamp ............................................................ 17 5.7 Marking the Conductor ............................................................................................................. 18 Ground Survey Procedure ...................................................................................................................... 19 6.1 Applications .............................................................................................................................. 19 6.2 Locating Conductors ................................................................................................................. 19 6.3 Subdividing Large Search Areas .............................................................................................. 19 Tracing Techniques and Helpful Information ........................................................................................... 20 7.1 Soil Conditions.......................................................................................................................... 20 7.2 Adjacent Conductors ................................................................................................................ 20 7.3 Signal Clamp: Ground Requirements ....................................................................................... 20 7.4 Grounding: Safety ..................................................................................................................... 20 7.5 Distribution Systems ................................................................................................................. 20 7.6 Deep Conductor ....................................................................................................................... 20 7.7 What is Field Strength of the Signal? ....................................................................................... 20 7.8 “Ghost” Conductor Due to Adjacent Conductor ...................…

Text truncated - open the document above for the full version.

Declaration about FCC approval American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: We, ______Vivax-Metrotech (Shanghai) Ltd._____ are aware of the fact the device under 15.213 shall be verified pursuant to the procedures in Subpart J of part 2. Nevertheless, certification is chosen as the approval method of this product. Thank you, Print name: Snow yang On behalf of Vivax-Metrotech (Shanghai) Ltd. July 30, 2012

1 ivanwen 发件人: [email protected] 发送时间: 2012年7月28日星期六 5:26 收件人: hotline 主题: Response to Inquiry to FCC (Tracking Number 219242) (TCB) 重要性: 高 类别: 红色类别 右键单击此处可下载图片。为帮助保护您的隐私，Outlook 禁止自动从In ter n et 下载此图片。 Link to F ederal C ommu nications C ommission Home Page FCC Home | Search | RSS | Updates | E-Filing | Initiatives | Consumers | Find People 右键单击此处可下载图片。为帮助保护您的隐私，Outlook 禁止自动从In ter n et 下载此图片。 Office of Engineering and Tech nology Office of Engineering and Technology Inquiry: Dear Gentleman: As specified in 15.201(a), Intentional radiators operated as carrier current systems, devices operated under the provisions of §§15.211, 15.213, and 15.221, and devices operating below 490 kHz in which all emissions are at least 40 dB below the limits in §15.209 shall be verified pursuant to the procedures in Subpart J of part 2 of this chapter prior to marketing, also attached TCB workshop in 2007 states that don't certify devices in 15.213 section. From the rules, it seems verification only for a 15.213 device. However the manufacturer wants to use more stringent route ?certification? for a cable locating equipment. Now we are seeking FCC if you can permit the certification for this 15.213 device? Thank you very much! Ivan Wen/ACB Response: You can apply for certification for this device under the condition that you file an attestation statement that clearly states that this device only requires verification and by electing certification Page from 2007 TCB worshop 2 Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry.

022311 – 6 Request for Confidentiality Date: ____ 2012-06-18_____ Subject: Confidentiality Request for: ______FCC ID:N6N2012061802HE_____ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term PermanentBlock Diagrams Short Term External Photos Short Term Permanent* 2 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ _____Vivax-Metrotech (Shanghai) Ltd.____ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___160 3 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: _____ ________ __________ Snow yang_________ (Signature/Title 4 ) (Print name) 2 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 3 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 4 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

022311 – 6 Authority to Act as Agent Date: __ 2012-06-18 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: ______Intertek Shanghai_____ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: ____2012.12.30__ By: __________________ ________ __ Snow yang______ (Signature 1 ) (Print name) Title: ________ Quality manager________ On behalf of: ______ Vivax-Metrotech (Shanghai) Ltd._____ (Company Name) Telephone: __ +86-21-5109-9980________ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

FCC ID: N6N2012061802HE Page 1 of 4 External Picture FCC ID: N6N2012061802HE Page 2 of 4 FCC ID: N6N2012061802HE Page 3 of 4 FCC ID: N6N2012061802HE Page 4 of 4 Battery Charger

FCC ID: N6N2012061802HE Page 1 of 11 EMC TEST REPORT No. SH12050254-002 Applicant : Vivax-Metrotech (Shanghai) Ltd. 3F, No. 90, Lane 1122 Qinzhou Rd. (N), Shanghai 200233 China Manufacturer : Vivax-Metrotech (Shanghai) Ltd. 3F, No. 90, Lane 1122 Qinzhou Rd. (N), Shanghai 200233 China Equipment : Pipe and Cable Locator Type/Model : VM-850Tx SUMMARY The equipment complies with the requirements according to the following standard(s): 47CFR Part 15 (2010): Radio Frequency Devices ANSI C63.4 (2009): American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz ANSI C63.10 (2009): American National Standard for Testing Unlicensed Wireless Devices Date of issue: July 19, 2012 Prepared by: Reviewed by: Wakeyou Wang (Project Engineer) Daniel Zhao (Reviewer) FCC ID: N6N2012061802HE Page 2 of 11 Description of Test Facility Name Intertek Testing Service Shanghai Address Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China FCC Registration Number: 236597 Name of contact: Steve Li Tel: +86 21 64956565 ext. 214 Fax: +86 21 54262335 ext. 214 Subcontractor Name: SIMT EMC Lab Address: 716 Yi Shan Road, Shanghai City, China FCC Registration Number: 142171 Name of contact: Gong Zeng Tel: 86-21-6470-1390 Fax: 86-21-6451-4252 FCC ID: N6N2012061802HE Page 3 of 11 Content SUMMARY .......................................................................................................................................................... 1 DESCRIPTION OF TEST FACILITY ......................................................................................................................... 2 1. GENERAL INFORMATION ............................................................................................................................ 4 1.1 Applicant Information ..................................................................................................... 4 1.2 Identification of the EUT ................................................................................................ 4 1.3 Technical specification ................................................................................................... 5 1.4 Mode of operation during the test / Test peripherals used .............................................. 5 2. TEST SPECIFICATION .................................................................................................................................. 6 2.1 Instrument list ................................................................................................................. 6 2.2 Test Standard .................................................................................................................. 6 3. INPUT POWER .............................................................................................................................................. 7 3.1 Test limit ......................................................................................................................... 7 3.2 Test Configuration .......................................................................................................... 7 3.3 Test procedure and test setup .......................................................................................... 7 3.4 Test protocol ................................................................................................................... 8 4. POWER LINE CONDUCTED EMISSION .......................................................................................................... 9 4.1 Limit ................................................................................................................................ 9 4.2 Test configuration ........................................................................................................... 9 4.3 Test procedure and test set up ....................................................................................... 10 4.4 Test protocol ................................................................................................................. 11 FCC ID: N6N2012061802HE Page 4 of 11 1. General Information 1.1 Applicant Information Applicant: Vivax-Metrotech (Shanghai) Ltd. 3F, No. 90, Lane 1122 Qinzhou Rd. (N), Shanghai 200233 China Name of contact: Ms Snow Yang Tel: 86-21-51099980-840 Fax: 86-21-22819562-47 Manufacturer: Vivax-Metrotech (Shanghai) Ltd. 3F, No. 90, Lane 1122 Qinzhou Rd. (N), Shanghai 200233 China Sample received date: May 4, 2012 Sample Identification No: *0120504-13-006* Date of test: May 4, 2012 ~ June 12, 2012 1.2 Identification of the EUT Equipment: Pipe and Cable Locator Type/model: VM-850Tx FCC ID: N6N2012061802HE IC: Not applied FCC ID: N6N2012061802HE Page 5 of 11 1.3 Technical specification Operation Frequency Band: 9.8kHz – 9.8kHz Modulation: PWM Antenna Designation: Integral Rating: Built-in Battery DC 14.4V Description of EUT: There is one model only. The EUT contains two RF output power level setting. Testing for both settings were conducted and marked as “high reading” & “low reading”. Channel Description: There is one channel higher than 9kHz and assessed in this report. 1.4 Mode of operation during the test / Test peripherals used Within this test report, EUT was tested under its rating voltage and frequency. It was set up and tested as its normal use. FCC ID: N6N2012061802HE Page 6 of 11 2. Test Specification 2.1 Instrument list Equipment Type Manu. Internal no. Cal. Date Due date RMS Multimeter Model 189 Fluke EC 2560 2012-3-4 2013-3-3 Test Receiver ESCS 30 R&S EC 2107 2011-10-21 2012-10-20 A.M.N. ESH2-Z5 R&S EC 3119 2012-1-9 2013-1-8 2.2 Test Standard 47CFR Part 15 (2010): Radio Frequency Devices ANSI C63.4 (2009): American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz ANSI C63.10 (2009): American National Standar…

Text truncated - open the document above for the full version.
