N6YUT-2006Audio and Video Transmitter

TIU - 200A Before operating the system, please read this manual thoroughly and keep it for future reference. 2.4GHz 2.4GHz WIRELESS TRANSMITTER & WIRELESS RECEIVER N6YUT-2006 UTEL CO.,LTD TIU-200A THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Caution: Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. CONTENTS 1. SUB - ASSY'S IN THIS UNIT - - - - - - - - - - - - - - - - - - - - - 1 2. CONTROLS AND FUNCTIONS - - - - - - - - - - - - - - - - - - - - - - - 2 3. INSTALLATION - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 3-1. INSTALLATION OF WIRELESS TRANSMITTER - - - - - - - - - - - - 6 3-2. INSTALLATION OF WIRELESS RECEIVER - - - - - - - - - - - - - - 14 4. MULTIPLE CHANNEL OPERATION - - - - - - - - - - - - - - - - - - - - 19 5. TROUBLESHOOTING - - - - - - - - - - - - - - - - - - - - - - - - - 23 6. SPECIFICATIONS - - - - - - - - - - - - - - - - - - - - - - - - - 24 SUB - ASSY'S IN THIS UNIT Standard package TIU-200A 1- Transmitter 1- UL Approved AC adaptor 1- RCA A/V cable 1- User's manual RIU-100AN / 100AP 1- Receiver 1- UL approved AC adaptor 1- RCA A/V cable 1- RF cable Optional Items Extra wireless transmitter (Not included) Extra wireless receiver CCD Video Camera Extra RCA A/V cable Extra RF cable Warranty registration card CHECK LIST PRIOR TO USE CHECK THESE INSTRUCTIONS BELOW BEFORE OPERATING THIS UNIT. 1. Keep distance at least 10 feet between the transmitter and receiver when you install it because high frequency radio waves of 2.4GHz may cause an interfering problem between channels, which is the reason of the distorted picture on the monitor. 2. Turn and adjust the antenna of the transmitter and receiver in order to optimize the picture condition. Be aware that maximum scope of turning the antenna is 90° towards right and left. Therefore, Do not turn it over 90°to prevent breakage. 3. Be sure to adjust the adaptor correctly to the exact power (120V or 220V you are using) before installation. FOR EFFICIENT USE 1. External radio waves may cause an interfering problem and geographical features may affect the communication distance. 2. Keep in mind the usage of instructions for effective maintenance of your camera. CONTROLS AND FUNCTIONS WIRELESS TRANSMITTER FRONT VIEW REAR VIEW 1 2 3 4 5 6 7 1. 2.4GHz A/V ANTENNA The high gain directional dipole antenna sends the A/V modulated RF signal to the receiver. 2. POWER SWITCH Controls power on/off. Be sure to set the switch to "OFF" before plugging the AC adaptor into the unit and AC outlet. 3. CHANNEL SELECTOR Push button switch for channel selection 4. LED CHANNEL INDICATORS Indicators of selected channel 5. VIDEO INPUT JACK (Yellow) RCA jack for video input source connection 6. AUDIO INPUT JACKS (Left : White, Right : Red) RCA L/R jacks for Audio input source connection 7. DC IN JACK Connect the supplied 12V 500mA AC adaptor CONTROLS AND FUNCTIONS WIRELESS RECEIVER FRONT VIEW REAR VIEW 2 3 4 5 6 7 8 9 1. 2.4GHz A/V ANTENNA The high gain directional dipole antenna receives the RF signal. 2. POWER SWITCH Controls power on/off. Be sure to set the switch to "OFF" before plugging the AC adaptor into the unit and AC outlet. 3. CHANNEL SELECTOR Push button switch for channel selection 4. LED CHANNEL INDICATORS Indicators of selected channel 1 5. VIDEO OUTPUT JACK (Yellow) RCA jack for video output 6. AUDIO OUTPUT JACK (Left : White, Right: Red) RCA L/R jacks for Audio output 7. RF CHANNEL SELECTOR Channel 3,4 selector to operate with TV(NTSC Standard) 8. RF OUTPUT CONNECTOR Connector for TV connection 9. DC IN JACK Power supply for 12V 500mA AC adaptor INSTALLATION WIRELESS TRANSMITTER DC 12V 500mA AC ADAPTOR Transmitting From 1. Place the wireless transmitter on or near the A/V source unit. 2. Connect the 500mA AC adaptor to the DC IN jack on the receiver and plug it into the 120V AC outlet. WIRELESS RECEIVER DC 12V 500mA AC ADAPTOR .Satellite Receiver .Camcorder .Cable TV .Surveillance Camera .VCR .Computer .Laser Disc Player (convertible card required) .Wireless Cable .A/V Receiver .Digital Video Disc .CD Player Connects to ·TV ·Monitor ·Computer (convertible card required ) ·Speakers 1. Place the wireless receiver on or near the TV, monitor or other A/V unit. 2. Connect the 500mA AC adaptor to the DC IN jack on the receiver and plug it into the 120V AC outlet. INSTALLATION ADJUSTING ANTENNA OF UNIT RF ANTENNA WARNING! Please do not turn the antenna towards the same way more than 90 degrees. TRANSMITTER IMPORTANT NOTE FOR CHANNEL SELECTION Search the CH 1-CH 4 and select the best one for optimum reception in your area. Both transmitter and receiver must be set to the same channel. INSTALLATION OF WIRELESS TRANSMITTER THE MAXIMUM RANGE IS 300 FT WITHOUT LOSS OF ANY PICTURE / SOUND QUALITY 12V 500mA AC Adaptor TRANSMITTER RCA cable(Optional) Rear OF VCR Rear of TV RF Cable Note: Be sure to set the power on the transmitter to "OFF" before following steps below. 1. Connect one end (triple plugs) of the RCA cable to the A/V jacks on the transmitter, and the other end to the Audio/Video Out jacks on your VCR. Be sure to match the color of the plugs in both connection. If your VCR has only one audio out jack (mono sound), connect the white plug(Audio-L) to your VCR. 2. If you want to use the system with a nearby TV, connect one end of the supplied RF cable to the VHF Out jack on your VCR, and the other end to the antenna In jack on your TV. 3. To receive cable transmission on your TV without the cable converting box, connect the cable TV input source to the VHF In jack on your VCR. 4. Turn on the transmitter and search the channel 1-4 by pressing the Channel selector, and th…

Text truncated - open the document above for the full version.

TIU-200A BLOCK DIAGRAM EXTERNALVIDEO / AUDIOSOURCE 6.0MHz 6.5MHzPRE -EMPHASIS AUDIO RAUDIO LVIDEO CPU PLL IC SP5055S SDA SCL SUB CARRIERGENERATOR SUB CARRIERGENERATOR FILTER6.0MHz FILTER6.5MHz AMPLIFIER VCO2411-2473MHz AMPLIFIER RF FILTER MODULATINGSIGNAL VCOCONTROLVOLTAGE

EXTERNAL FRONT SIDE EXTERNAL REAR SIDE FCC ID : N6YUT-2006 EXTERNAL BOTTOM SIDE FCC ID : N6YUT-2006 FCC ID : N6YUT-2006

EXTERNAL FRONT SIDE EXTERNAL REAR SIDE FCC ID : N6YUT-2006 EXTERNAL BOTTOM SIDE FCC ID : N6YUT-2006 FCC ID : N6YUT-2006

INTERNAL TOP SIDE INTERNAL BOTTOM SIDE FCC ID : N6YUT-2006 FCC ID : N6YUT-2006

INTERNAL TOP SIDE INTERNAL BOTTOM SIDE FCC ID : N6YUT-2006 FCC ID : N6YUT-2006

2.4GHZ TRANSMITTER 1.0 TIU-200A B 11 Friday, March 12, 1999 TitleSize Document Number Rev Date: Sheet of Sub Board +8.7V F1 1A250V D21N4002R32.2K X 4EAR4 R2 R1 SW2CH J1 +12V INPUT CON1 POWER 1 2 SW1 POWER ON/OFF CON4 123456 CON2 12345 C1 470U/25V + C2 0.1U C3 2200U/10V + C4 0.1U J2 VIDEO J3 AUDIO LEFT J4 AUDIO RIGHT C5 33P C6 33P C7 33P C8 33P C9 33P C1033P C1133P C1233P C1733P C1533PC1633P LED4 RED LED3RED LED2 RED LED1RED U1SEC7808IN 1 OUT 3 GND 2 D1 1N4002 C13 NONE C14NONE CON3 12345 2.4GHZ TRANSMITTER MODULE 1.0 UTM201A UTEL2F DAECHANG B/D 1662-13BONGCHUN 7-DONG,KWANAK-GU,SEOULT:02-875-8171, F:02-875-3203 D 11 Friday, March 12, 1999 TitleSize Document Number Rev Date: Sheet of CH SWLED 4LED 3LED 2LED 1 1234 6 123 46 10.8mm 1.4mm 11.4mm 19mm 9mm 1mm1.3mm 5.1mm 9.1mm 13.3mm VIDEOVCCAUDIO RAUDIO LGND R1 100 R3 100 R8 0 R9 75 R10 4.7K R1310K C51000P U1 NE592 12 7 3 4 8 6 ANT1 R26820 R2815K U2 LA7058R 9 9 7 7 5 5 3 3 1 1 2 2 4 4 6 6 8 8 R29 2.2K U3 LA7058R 9 9 7 7 5 5 3 3 1 1 2 2 4 4 6 6 8 8 U4SP5055S 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 15 15 16 16 R44 R45 330 X 2EA R46 10K R48220 R47 10K C39100P C22 100P R38 2.2K C14 2P D3 R51 3.3K R5210K R5410K C34N.C L2 0 C11 330P R537.5K CON1 12345 C8 N0NE R16 10K D1 1SV245 C40 0.5P R22270 R23 18 R24270 R2 390 R575 R675 R25 7.5K R34 7.5K C3182P R39 220 R31270 R32330 C25N.C R30390 R11 4.7K R1210K R4 300 R14 0 R1515K Q1 2N3904S R20 15K R21 22K R41180 R42100 R19 47 TC1 D30047 TC2 D30047 D25.1V ZENER C91P C42 10UF/10V T/T + C71P R27 4.7K R36 4.7K C1633P C4 10UF/10V T/T + C38 10UF/10V T/T + CON2 12345 R55200 C3 0.1U C10 0.022U C12 0.01U C13 0.1U C15 1000P C41 1000P C181.5U C17 0.047U C370.1U C360.1U C35 1000P R5010K C33 0.1U C32 0.01U C300.01U C290.01U C28 1.5U C19 1.5U C200.01U C230.01U C21 0.01U C24 0.1U C260.1U C27 0.1U C1 NONE C2 470P R33 2.7K R40 2.7K R3715K R35820 VCC +8.7V VCC +8.7V VCC +8.7V VCC +8.7V VCC +8.7V R4318P VCC +8.7V VCC +8.7V VCC +8.7V C6 0.1U VR1 4.7K R17 10K R181K Q2 BFG540/X C60 1000P X1 H4_000MHZ 1 2 L1 JUMPER R7 18 U5 PIC16F84-04/SO 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 15 15 16 16 17 17 18 18 R4910K CF1SFSH6.0MCB 1 2 3 CF2SFSH6.5MCB 1 2 3

KTL Korea Testing Laboratory Page 1 of 17 TEST REPORT This test report only responds to the tested sample and shall not be reproduced except in full without written approval of the the Korea Testing Laboratory. Tested and reported by Reviewed by Soun-Kweon Seol , Senior Engineer Seok-Jin Kim , EMC Team Leader KOREA TESTING LABORATORY FG101-01-02-00 222-13, Guro-Dong Guro-Gu Seoul Korea 152-053 ht tp://www.ktl.re.kr Ref. Report No. 99-341-024 Name and address of the applicant Utel Co., Ltd. 1662-13, Daechang B/D 2F, Bongchun 7-dong, Kwamak-ku, Seoul, Korea 151-057 Standard / Test regulation FCC Part 15, Subpart C Test result Pass Incoming date : April 23, 1999 Test item(s) ; Low Power Wireless Transmitter Model/type ref. ; TIU-200A Manufacturer ; Utel Co., Ltd. Additional information ; -Required Authorization :Certification -FCC ID. : N6YUT-2006 Test date : June 3, 1999 Issue date : June 14, 1999 Ref. Report No. 99 - 341 – 024 Page 2 of 17 TABLE OF CONTENTS I. GENERAL INFORMATION .........................................................................................................3 1. Grantee Name and Mailing Address 2. Manufacturer's Name and Mailing Address 3. Equipment Descriptions 4. Rules and Regulations 5. Measuring Procedure 6. Place of Measurement 7. Date of Measurement . GENERAL REQUIREMENTS OF THE EUT ..............................................................4 1. Labelling Requirement (Section 15.19) 2. Information to User (Sections 15.21) 3. Special Accessories (Section 15.27) . CONDUCTED EMISSION MEASUREMENT (Section 15.107)............................................................ 5 - 8 1. Test Procedure 2. Photograph for the worst case configuration 3. Sample Calculation 4. Measurement Data . RADIATED EMISSION MEASUREMENT (Section 15.249) .......................................................9 -14 1. Test Procedure 2. Photograph for the worst case configuration 3. Sample Calculation 4. Measurement Data . OCCUPIED BANDWITH MEASUREMENT (Section 15.249).....................................................15 -16 1. Bottom : 2411MHz Tuning (ch4) 2. Top : 2473MHz Tuning (ch3) . TEST EQUIPMENTS USED FOR . FCC COMPLIANCE TESTING ....................................17 Ref. Report No. 99 - 341 – 024 Page 3 of 17 . GENERAL INFORMATION 1. Grantee Name and : Utel Co., Ltd. Mailing Address 1662-13, Daechang B/D 2F, Bongchun 7-dong, Kwamak-ku, Seoul, Korea 151-057 2. Manufacturer's Name and: Utel Co., Ltd Mailing Address1662-13, Daechang B/D 2F, Bongchun 7-dong, Kwamak-ku, Seoul, Korea 151-057 3. Equipment Descriptions 3.1 Operating Frequency : 2411.0 MHz ~ 2473.0 MHz 3.2 Type of Emission : 3.3 Power Supply : DC 12V (AC Adapter) 3.4 Additional Information; - Oscillator used : VCO Transistor(BFG540/X, 2411~2473MHz), Crystal(4MHz) PLL IC(SP5055S) 4. Rules and Regulations: FCC Part 15, Subpart C 5. Measuring Procedure: ANSI C63.4-1992 6. Place of Measurement : Absorber-lined room(3-Meter) of KAITECH 7. Date of Measurement 6.1 Line Conducted: May 28, 1999 6.2 Radiated Emission : June 3, 1999 Ref. Report No. 99 - 341 – 024 Page 4 of 17 . GENERAL REQUIREMENTS OF THE EUT 1. Labelling Requirement (Section 15.19) This device complies with Part 15 of the FCC Rules. Operation is subject to following two condition : this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 1.1 Location on Enclosure : Bottom side 1.2 How Applied : By Ink-printing on Adhesive Label 2. Information to User (Section 15.21) The following or similar statements were provided in the manual for user instruction. Please refer page 2 of the attached manual for details. CAUTION : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 3. Special Accessories (Section 15.27) 3.1 Were the special Accessories provided? [ ] yes, [ x ] no 3.2 If yes, details for the special accessories are as follows : 3.3 If yes, were the appropriate instructions provided on the first page of the text concerned with the device? [ ] yes, [ ] no 3.4 Are these accessories provided of the type which can be readily obtained from multiple retail outlets ? [ ] yes, [ ] no And therefore does the manual specify what additional components or accessories are required to used in order to comply with the Rules? [ ] yes, [ ] no Ref. Report No. 99 - 341 – 024 Page 5 of 17  . CONDUCTED EMISSION MEASUREMENT (Section 15.107) 1. Test Procedure This transmitter(EUT) is designed to operate in the frequency band 2411.0 to 2473.0 MHz. But, Testing was performed with test-sample which is fixed to 4 channels(2434.0MHz,2453.0MHz,2473.0MHz,2411.0MHz) in operating frequency ranges 2411.0~2473.0MHz. Therefore measurements were performed with the equipment operating on three frequencies, which were the top, middle(second), and bottom in the band, as per Section 15.31(m). Conducted emission measurements on the EUT were performed by "AC Power Line Conducted Emissions Testing" procedure as per ANSI C63.4. The EUT was set up on a wooden table 0.8 meters height, 1.0 by 1.5 meters in size, placed in the shielded enclosed with a side of wall of which constituted a vertical conducting surface of 2.2m X 3.1m in size to maintain 40Cm from the rear of EUT 2. LISN's(Line Impedance Stabilization Network, EMCO, 3825/2, 50ohm/50uH) were installed and electrically boned to the conducting ground plane. The EUT was connected to one LISN. One of two 50ohm output terminals of the LISN was connected to the Spectrum Analyzer(HP, 8566B, 10kHz to 22GHz) with the Quasi-Peak Adapter (HP, 85650A, 10kHz to 1.0GHz) and the other was terminated in 50 ohms. Measurements were again performed after interchanging such a connection oppositely. The frequency range from 450kHz to 30MHz was examined and the peak values that are within 6dB of the limit would be co…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS RADIATED EMISSION CONDUCTED EMISSION
