N7F1998DX001

Dynamic Telecommunications Inc.

Click to zoom

Application Details

Equipment Class: CSR - Scanning Receiver
Date of Grant: May 03, 1999
Application Purpose: Original Equipment
Date of Application: Dec 03, 1998
Frequency Range: 925.00000000 - 960.00000000
Company: Dynamic Telecommunications Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Test Report

FCC CLASS B 3M RADIATED EMISSIONS DATA - SITE 2 CLIENT:Dynamic Telecommunications, Inc. MODEL NO:SeeGull-DXFCC ID: N7F1998DX001 DATE:4/21/99 BY:Herb Meadows JOB #:4957X CONFIGURATION: GSM900 Unit was tuned to 925MHz, 942MHz, and 960MHz. Testing was also performed with unit scanning. Worst case emissions are recorded. FrequencyPolarityAzimuthAntennaSA LevelAFcE-FieldE-FieldLimitMargin Height(QP) MHzH/VDegreemdBuVdB/mdBuV/muV/muV/mdB 199.73V270.0121.612.233.848.7150.0-9.8 266.30V180.018.015.023.014.1200.0-23.1 266.30H180.03.55.815.020.810.9200.0-25.3 719.04V135.0116.025.841.8123.7200.0-4.2 719.04H135.03.511.525.837.373.7200.0-8.7 835.18V180.0111.727.238.988.1200.0-7.1 1178.40V180.0150.5-9.940.6107.4500.0-13.4 1243.50V180.0141.2-9.331.939.4500.0-22.1 1265.00V135.0146.7-9.137.675.9500.0-16.4 1264.80H135.0144.4-9.135.358.2500.0-18.7 CONFIGURATION: DX-AMPS Unit was tuned to 869.04MHz, 879.96MHz, and 894MHz. Testing was also performed with unit scanning. Worst case emissions are recorded. FrequencyPolarityAzimuthAntennaSA LevelAFcE-FieldE-FieldLimitMargin Height(QP) MHzH/VDegreemdBuVdB/mdBuV/muV/muV/mdB 199.73V90.0122.312.234.552.8150.0-9.1 266.30V180.019.215.024.216.2200.0-21.9 1038.60H180.0148.2-11.336.970.1500.0-17.1 1078.52H180.0150.8-10.939.999.3500.0-14.0 1105.16H180.0148.4-10.637.877.7500.0-16.2 1118.40V180.0150.0-10.539.594.8500.0-14.4 1132.00H180.0151.8-10.341.5118.5500.0-12.5 1198.40H180.0150.4-9.740.7108.4500.0-13.3 1238.30H180.0154.1-9.344.8173.1500.0-9.2 1238.30V180.0153.4-9.344.1159.7500.0-9.9 1265.00H135.0153.2-9.144.1160.4500.0-9.9 1265.00V135.0153.2-9.144.1160.4500.0-9.9 1318.20H180.0154.2-8.645.6189.7500.0-8.4 1318.20V180.0153.2-8.644.6169.0500.0-9.4 1358.70H135.0148.0-8.339.796.5500.0-14.3 1358.70H135.0147.7-8.339.493.3500.0-14.6 1398.20H135.0149.2-8.041.2115.0500.0-12.8 1398.20V135.0152.0-8.044.0158.7500.0-10.0 1864.30V135.0143.0-4.838.281.3500.0-15.8 1864.30H135.0143.2-4.838.483.2500.0-15.6 CONFIGURATION: DX-RAMPS Unit was tuned to 824.04MHz, 834.96MHz, and 849MHz. Testing was also performed with unit scanning. Worst case emissions are recorded. FrequencyPolarityAzimuthAntennaSA LevelAFcE-FieldE-FieldLimitMargin Height(QP) MHzH/VDegreemdBuVdB/mdBuV/muV/muV/mdB 199.73V90.0126.012.238.280.9150.0-5.4 266.30V180.0117.115.032.140.1200.0-14.0 1118.40V180.0142.4-10.531.939.5500.0-22.0 1118.40H180.0144.5-10.534.050.3500.0-19.9 1198.40H180.0145.4-9.735.761.0500.0-18.3 1238.30V180.0151.3-9.342.0125.4500.0-12.0 1238.30H180.0148.7-9.339.493.0500.0-14.6 1265.00V135.0153.2-9.144.1160.4500.0-9.9 1265.00H135.0142.6-9.133.547.3500.0-20.5 1318.20V180.0146.3-8.637.776.4500.0-16.3 1318.20H180.0144.1-8.635.559.3500.0-18.5 1398.20V135.0144.3-8.036.365.4500.0-17.7 1398.20H135.0145.4-8.037.474.2500.0-16.6 1864.30V135.0143.0-4.838.281.3500.0-15.8
