N7F1998SG001

Dynamic Telecommunications Inc.

Click to zoom

Application Details

Equipment Class: CSR - Scanning Receiver
Date of Grant: May 03, 1999
Application Purpose: Original Equipment
Date of Application: Dec 03, 1998
Frequency Range: 917.01250000 - 949.98750000
Company: Dynamic Telecommunications Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Test Report

FCC CLASS B 3M RADIATED EMISSIONS DATA - SITE 2 CLIENT:Dynamic MODEL NO:SeeGull FCC ID: N7F1998SG001 DATE:4/21/99 BY:Herb Meadows JOB #:4756X CONFIGURATION: EAMPS Unit was tuned to 869.04MHz, 881.505MHz, and 893.97MHz. Testing was also performed with unit scanning. Worst case emissions are recorded. FrequencyPolarityAzimuthAntennaSA LevelAFcE-FieldE-FieldLimitMargin Height(QP) MHzH/VDegreemdBuVdB/mdBuV/muV/muV/mdB 112.64V180.001.019.412.732.140.1150.0-11.5 281.60V90.001.09.315.524.817.3200.0-21.2 337.90V90.001.010.917.128.025.2200.0-18.0 394.26H90.003.013.618.532.140.3200.0-13.9 394.26V90.001.010.818.529.329.2200.0-16.7 450.56V180.001.08.219.727.924.9200.0-18.1 450.56H270.003.57.119.726.821.9200.0-19.2 563.21V90.001.04.922.627.523.8200.0-18.5 1125.30V180.001.049.2-10.438.887.2500.0-15.2 1178.10V90.001.043.1-9.933.245.8500.0-20.8 1308.80V180.001.046.6-8.737.978.3500.0-16.1 1374.50V180.001.048.9-8.240.7108.7500.0-13.3 1374.50H135.001.044.8-8.236.667.8500.0-17.4 1439.50V167.501.043.9-7.736.264.8500.0-17.7 CONFIGURATION: iDEN Unit was tuned to 851.0125MHz, 858.5125MHz, and 866.0125MHz. Testing was also performed with unit scanning. Worst case emissions are recorded. FrequencyPolarityAzimuthAntennaSA LevelAFcE-FieldE-FieldLimitMargin Height(QP) MHzH/VDegreemdBuVdB/mdBuV/muV/muV/mdB 112.64V180.001.017.412.730.131.8150.0-13.5 281.60V90.001.09.115.524.616.9200.0-21.4 337.92V90.001.011.417.128.526.7200.0-17.5 450.56V67.501.013.119.732.843.7200.0-13.2 450.56H90.003.59.419.729.128.6200.0-16.9 563.20V180.001.06.222.628.827.7200.0-17.2 1182.60V67.501.039.4-9.829.630.1500.0-24.4 1126.40V225.001.038.1-10.427.724.3500.0-26.3 CONFIGURATION: ETACS Unit was tuned to 917.0125MHz, 933.5MHz, and 949.9875MHz. Testing was also performed with unit scanning. Worst case emissions are recorded. FrequencyPolarityAzimuthAntennaSA LevelAFcE-FieldE-FieldLimitMargin Height(QP) MHzH/VDegreemdBuVdB/mdBuV/muV/muV/mdB 45.00V225.001.016.816.132.944.2100.0-7.1 112.64V180.001.020.312.733.044.5150.0-10.6 149.30V180.001.022.610.232.843.7150.0-10.7 337.90V90.001.011.517.128.627.0200.0-17.4 394.26H90.002.515.218.533.748.5200.0-12.3 450.56V225.001.09.419.729.128.6200.0-16.9 675.90V180.001.011.525.036.567.1200.0-9.5 1125.30V180.001.045.7-10.435.358.3500.0-18.7 1178.10V180.001.041.1-9.931.236.4500.0-22.8 1308.80V180.001.045.3-8.736.667.5500.0-17.4 1374.50V180.001.045.9-8.237.776.9500.0-16.3
