N7KA1V2Bluetooth Speaker
KINGTA TECHNOLOGY CO., LTD
Click to zoom
Application Details
- Equipment Class
- DSS - Part 15 Spread Spectrum Transmitter
- Date of Grant
- Jan 03, 2021
- Application Purpose
- Original Equipment
- Date of Application
- Jan 03, 2021
- Equipment Note
- Bluetooth Speaker
- Frequency Range
- 2402.00000000 - 2480.00000000
- Company
- KINGTA TECHNOLOGY CO., LTD
- Country
- China
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
Waterproof Wireless Speaker User’s Manual Introduction Thank you for choosing the A1 as your source for entertainment, you can use this item with iPads,iPhones, iPods and many types of smart-phone to stream music , and enjoy hands-free calling.In order to get the best results when using the device,please read this manual first before using. Included: 1.Speaker 2.USB Micro Charging Cable 3.3.5 mm Micro-USB Cable 4.User Manual Specifications Supported Profiles:A2DPV1.2 ,AVRCPV1.4, HFPV1.5,HSP1.2,GAVDP1.2 Bluetooth Range:33ft (10m) Dimensions: 120.6 *75 *82.9 mm Battery: Li-Ion 3.7V/2000mAh Charging: 5V @ 1 A Feartures -Volume and song control directly on speaker unit -Stunning sound clarity -Ultra portable design -Great for parties, indoor and outdoor -Allow you to make and answer phone calls 1.Next/Volume+ 2.ON/OFF/Play/Pause/Phone button 3.Previous/Volume – 4.Blue LED(Bluetooth) 5.Red LED(Charging) 6.MIC 7.Micro USB Charging/AUX in Port 2 3 7 6 1 4 5 A1 Operation Powering On Press and Hold "ON/OFF" button 2 seconds to power ON, the Blue LED will start to quick flash. If an AUX cable is connected to the unit, the Blue LED will becomes slow flash ,notifying you the unit is in Aux-In mode. Powering Off Press and Hold "ON/OFF" button 2 seconds to power OFF Aux-In Mode Plug in the supplied 3.5 mm cable into the unit. The other end is connected to your device. The Blue LED will becomes slow flash. It means in “Aux” mode. Please note music and volume can be controlled by your device. Charging Attach the USB cable to the unit, and plug into any USB charger. If the unit is completely discharged, it will take approximately 4 hours to fully charge. The Red LED will illuminate during charging, when it has completed, the Red LED will turn off. Note:There will be a beep when the battery is low and needs to be recharged. Bluetooth Mode Pairing The unit will automatically go into “Pairing Mode” when it is powered ON. Go into your Bluetooth device settings menu and look for “ A1”After the unit has paired and connected, it will re-connect automatically when the unit is powered on and the device is in range. Note: Bluetooth Timeout :10 minutes Making and Receiving Phone Calls When the unit is connected and paired to your device, the unit allows you to make or receive phone calls with its built-in microphone. Press “ ” to accept a call To end a call press“ ” To place a call, simply dial the number or select a contact from To reject a call, press and hold “ ” for 2 seconds To press the button “ ” twice to redial the last dialed number Begin Streaming Music Press “ ” to start playing music. Press and Hold “ ” 2 seconds to play the next track. Press and Hold “ ” 2 seconds to play the previous track. Press either “ ” or “ ” for volume control. LED Status Blue LED solidBluetooth Mode Blue LED become slow flash Red LED Aux Mode Charging Troubleshooting Unit doesn’t connect to device Speaker needs to be connected/ re-paired to device A tone is heard every few secondsSpeaker needs to be charged Unit will not power on Speaker needs to be charged Unit doesn’t control track(s)/volume Speaker needs to be in Bluetooth mode for full control Unit distorts at high volume The devices’ volume needs to be lowered FCC Statement： Th is device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Th is equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures: -Reo rient the receiving antenna. -In crease the separation between the equipment and receiver. -Co nnect the equipment into and outlet on a circuit different from that to which the receiver is connected. -Cons ult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
Attestation Statements
Product Name : Bluetooth Speaker Model No. :A1, TY-WSP100, TY-WSP101, BLG-SUBMARINE FCC ID:N7KA1V2 All models are electrically identical, Only model no is different. Sincerely, Name: Vick Chen Title:Manager Company: KINGTA TECHNOLOGY CO., LTD
