1 Waterproof Wireless Speaker User Manual BS01 Introduction Thank you for purchasing this product. You can use this item with iPads , iPhones, iPods and many types of Smart phone to stream music, and enjoy hands-free calling. In order to get the best results when using the device, please read this manual first before using. Features IP66 Waterproof Bluetooth Speaker Perfect fabric speaker with rubber control panel Rich and powerful sound output ( 5W*2=10W output ) Stable base with silicone Unique and patent design Support TWS function Type-C jack With LED light Removable stake Support AUX function Specifications Bluetooth version: 5.0  Loudspeaker: 4Ω/ 5W 45mm *2 Built-in battery: Li-ion 2000mAh  Speaker Dimensions:φ70.00mm*H178.80mm  Stake Dimensions:φ21.00mm*H197.80mm +φ20.00mm*H197.80  SNR: >80dB Bluetooth Frequency: 2.402-2.480 Ghz Wireless Transmission Distance: up to 10m 2 Chargingtime:Approx.3hours Weight:kg Charging:5V,500mA Packagecontents 1*WaterproofIP66speaker 1*USBtoType-Cchargingcable-50cm 1*3.5mmto3.5mmAUXcable-50cm 2*Removablestakes 1*Usermanual ImportantSafetyPrecautions WhenusingyourBluetoothMobileSpeaker,basicsafetyprecautionsshouldalwaysbefollowed,including thefollowing: •Keepthisproductanditsaccessoriesawayfromexcessiveheat. •Donotoperatethisdevicewithadamagedcableorafterithasmalfunctionedorhasbeendamagedin anymanner. •Nosharpobjectshouldbesubjectedtothespeaker/speaker-driversasitmaydamagethespeakers. •Onlyuseasoftcloth,noharshabrasivesorchemicalstoclean,asitmaydamagethesurfacefinishing. •Ensurethespeakeriswaterproofbyremovingalltheconnectedcablesandthecapistightlyclosed beforeexposingthespeakertoliquid. •Donotexposethespeakertowaterwhilecharging,asdoingsomayresultindamagetothespeakeror thepowersource. ChargingyourSpeaker 1.ConnectoneendoftheincludedUSBChargingCabletotheChargingPortonyourspeaker.Thenplugthe otherendoftheUSBChargingCableintoasuitableUSBportonyourcomputer,notebookorpowerbank torechargeyourspeaker'sinternalrechargeablebattery. 2.Whencharging,aredLEDlightwillilluminatetoindicatethattheunitischarging.Theredlightwillturn offwhenyourunitisfullycharged(underbothturn-on/offspeakerstatus) 3 AQuickLookAtYourSpeaker 1.PhoneButton: A)Acceptingorendingacall(duringmusicplaybackincluded):Uponhearingtheincomingcalltone, pressthePhoneButtononcetoanswerthecall.Thiswillalsopauseyourmusic.PressthePhoneButton againtoendthecall.Musicwillresume. B)Makingacall(duringmusicplaybackincluded):PressandholdthePhoneButtontwicetoredialthe lastnumbercalled.Thisfeaturemayvarybasedonthemobiledevice. C)Rejectingacall(duringmusicplaybackincluded):Uponhearingtheincomingcalltone,pressthe On/OffButtonfor1secondtorejectthecall. D)PressthePhoneButtonfor1secondwhenmusicisplayingtopausethemusic. E)PressthePhoneButtonfor1secondwhenmusicispausedtobeginplayingagain. 2.LightButton: 1 2 3 4 5 67 8 4 Settingthelightingmode:ShortpressontheLightingEffectsbuttoncyclesthespeakerlightingbetween Offand5effectmodes. A)SlowtransitionforallLEDcolors B)Solidwhite(LEDcolor) C)Dancingmodetothemusic D)EachLEDcoloronitsown E)Blinkingwhite 3.Previoussong/Vol-Button:Togobacktheprevioustrack,presstheVolumeDownButtonfor1 second.Tolowerthevolume,pressandholdtheVolumeDownButtonformorethan1second. 4.Poweron/offButton:Topoweronyourspeaker,pressandholdtheOn/OffButton.Topoweroffyour speaker.PressandholdtheOn/OffButton. 5.Nextsong/Vol+Button:Toskiptothenexttrack,presstheVolumeUpButtonfor1second.Toraise thevolume,pressandholdtheVolumeUpButtonformorethan1second. 6.AUXinport:Usetheattached3.5mmto3.5mmaudiocabletoconnectthespeakerandananalog audiosource. 7.Type-Cchargingport:UsetheattachedType-CtoUSBchargingcabletochargingyourspeaker. 8.Removablestakeport:Usetheattachedremovablestaketoconnectthespeakerandthestake. BluetoothPairingProcedure 1.TurnonyoumobiledeviceandgototheBluetoothmenu. 2.Makesurethespeakeriswithinthreemetersfromthemobiledevice. 3.PressandholdtheOn/OffButtononyourspeakertopoweron.TheLEDlightwillblinkblueto indicatethatyouhaveenteredparingmode. 4.Select'IJOYTIKI+'ontheBluetoothdevicemenu.Ensurethatthedeviceshows'Connected'inthe statusdisplay.(IfaPINisrequired,enter0000.) 5.PressandholdthePhoneButtononyourspeakertoenterBluetoothparingmode. Reconnectingtoadisconnecteddevice 1.IfpreviouslyconnectedtoaBluetoothdevice,theIJOYTIKI+willautomaticallyreconnectwiththe devicewhenpoweredon. 2.Thespeakerwillnotautomaticallyreconnectifthethreemetersdistanceisexceeded. 5 Connectionwaitingmode 1.IfthespeakerispoweredonandnoBluetoothdeviceisavailableforpairing,thespeakerwillenter 'ConnectionWaitingMode'.IfaBluetoothdevicebecomesavailable,presstheOn/Offbuttontoconnect automatically. 2.IfnoBluetoothdevicebecomesavailable,thespeakerwillpoweroffautomaticallyafterten minutes. TrueWirelessStereo(TWS)Function IfyouhavetwoIJOYTIKI+,youcanusethembothinsynctolisteninTrueWirelessStereo(Onespeaker willplayonlytheLeftChannel,theotherwillplayonlytheRightChannel). 1.MakesurebothIJOYTIKI+'sarewithoutanyBluetoothconnection. 2.PoweronbothunitsandpressOn/Offbuttononthespeaker.Thetwospeakerswillconnect automaticallyandyoushouldheartheindicatingtone.WhentheblueLEDblinksquicklyononeunitand blinksslowlyontheother,theTWShasconnectedsuccessfully. 3.Underconnection,searchBluetoothdeviceandselect'IJOYTIKI+'. 4.Hands-freefunctionisonlyavailableonthemasterspeaker. 5.ThePausemusicfunctionisnotavailable.IfyoupressthePhoneButtontopausethemusic,the speakerwillbemuted. Connectiontoananalogaudiosource 1.Usethe3.5mmto3.5mm(included)toconnecttothe3.5mmAnaloginputjackonthespeaker. 2.Connecttheotherendtotheanalogaudiosource. 3.Setthedesiredvolumeontheattacheddevice.TheLEDlightwillbeturntoGreen. 4.Pressshortly'Vol+button'toincreasethevolume 5.Pressshortly'Vol+button'tolowerthevolume 6.Pressshortly'Phonebutton'tomutethespeaker Removablestake Includedintheboxisaremovableplasticstake.Justattachittoenjoyfreestandingmusicintheground,sandorsnow. Listeninthegarden,onthebeachoratafestival,butwhenyou’vehadenoughoftheoutdoors,justremovethestakeand continueth…
