N7KF2V2Bluetooth Speaker

Waterproof Wireless Speaker User’s Manual F2 Introduction Thank you for choosing the F2 as your source for entertainment, you can use this item with iPads,iPhones, iPods and many types of smart-phone to stream music , and enjoy hands-free calling.In order to get the best results when using the device,please read this manual first before using. Included: 1.Speaker 2.USB Micro Charging Cable 3.3.5 mm Micro-USB Cable 4.User Manual Specifications Supported Profiles:A2DPV1.2 ,AVRCPV1.4, HFPV1.5,HSP1.2,GAVDP1.2 Bluetooth Range:33ft (10m) Dimensions: 208*80*80 mm Battery: Li-Ion 3.7V/2000mAh Charging: 5V @ 1 A Feartures -Volume and song control directly on speaker unit -Stunning sound clarity -Ultra portable design -Great for parties, indoor and outdoor -Allow you to make and answer phone calls - 1.Previous / Volume – 2.ON/OFF button 3.Next / Volume + 4.Green LED(AUX) 5.Red LED(Charging) 6.Blue LED(Bluetooth) 7.Phone /play button 8.MIC 9.Micro USB Charging/AUX in Port 1 2 8 9 3 4 5 6 7 Operation Powering On Press and Hold "ON/OFF" button 2 seconds to power ON, the Blue LED will start to flash. If an AUX (3.5 mm) cable is connected to the unit, the Blue LED will turn off , and the Green LED will stay illuminated,notifying you the unit is in Aux-In mode. Powering Off Press and Hold "ON/OFF" button 2 seconds to power OFF Aux-In Mode Plug in the supplied 3.5 mm cable into the unit. The other end is connected to your device. The Green LED will stay illuminated. It means in “Aux” mode. Please note music can be controlled by your device. Charging Attach the USB cable to the unit, and plug into any USB charger. If the unit is completely discharged, it will take approximately 4 hours to fully charge. The Red LED will illuminate during charging, when it has completed, the Red LED will turn off. Note:There will be a beep when the battery is low and needs to be recharged. Bluetooth Mode Pairing The unit will automatically go into “Pairing Mode” when it is powered ON. Go into your Bluetooth device settings menu and look for “F2” After the unit has paired and connected, it will re-connect automatically when the unit is powered on and the device is in range. Note: Bluetooth Timeout :10 minutes Making and Receiving Phone Calls When the unit is connected and paired to your device, the unit allows you to make or receive phone calls with its built-in microphone. Press “ ” to accept a call To end a call press“ ” To place a call, simply dial the number or select a contact form To reject a call, press and hold “ ” for 2 seconds Begin Streaming Music Press “ ” to start playing music. Press and Hold “ ” 2 seconds to play the next track. Press and Hold “ ” 2 seconds to play the previous track. Press either “ ” or “ ” for volume control. LED Status Blue LED solidBluetooth Mode Green LED on solid Red LED Aux Mode Charging Troubleshooting Unit doesn’t connect to device Speaker needs to be connected/ re-paired to device Atone is heard every few secondsSpeaker needs to be charged Unit will not power on Speaker needs to be charged Unit doesn’t control track(s)/volume Speaker needs to be in Bluetooth mode for full control Unit distorts at high volume The devices’ volume needs to be lowered FCC Statement： This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures: - Reorient the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.

Product Name: Bluetooth Speaker Model No.：F2, TY-WPS200, TY-WSP201, OWL-BTSP06, BLG-SPLASH, Pro Sound, EPIC 3 FCC ID：N7KF2V2 All models are electrically identical ,only model no is different <Signature> Name Vick chen Title Sales assistant Company KINGTA TECHNOLOGY CO., LTD

DATE 2021/6/18 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:N7KF2V2 Product Name: Bluetooth Speaker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name Vick chen Title Sales assistant Company KINGTA TECHNOLOGY CO., LTD

DATE: 2021/6/18 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint BlueAsia of Technical Services(Shenzhen) Co.,Ltd.IOT Test Centre of BlueAsia,Building C, No.107, Shihuan Road, Shiyan Sub-District, Baoan District,Shenzhen, Guangdong Province, China(Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with KINGTA TECHNOLOGY CO., LTD/Floor 2,Building 10/ Floor 4, Building 9, Futing industrial zone, Zhucun, Guanlan, Longhua,Shenzhen (Applicant Name and address) <Signature> Name Vick chen Title Sales assistant Applicant Company ：KINGTA TECHNOLOGY CO., LTD

Model No.:F2

BluetoothSpeaker Model：F2 FCCID:N7KF2V2

Model No.:F2

RF Exposure Evaluation Statement 1.1 RF Exposure Compliance Requirement 1.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 1.1.2 Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion 1.1.3 EUT RF Exposure Operational Mode: EDR （8-DPSK worst case） Channel Maximum Peak Conducted Output Power (dBm) Tune up tolerance (dB) Maximum tune-up Power Calculated value Exclusion threshold (dBm) (mW) 2402MHZ 4.439 ±1 5.44 3.50 1.08 3.0 2441MHz 4.318 ±1 5.32 3.40 1.06 2480MHz 4.328 ±1 5.33 3.41 1.07 Conclusion: the calculated value ≤3.0, SAR is exempted.

Page 1 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Add: Building C, No. 107, Shihuan Road, Shiyan Sub-District, Baoan District, Shenzhen, Guangdong Province, China Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com TEST REPORT Product Name : Bluetooth Speaker Brand Mark : NA Model No. : F2 Extension Model : TY-WSP200, TY-WSP201, OWL-BTSP06, BLG-SPLASH, Pro Sound, EPIC 3 FCC ID : N7KF2V2 Report Number : BLA-EMC-202106-A0402 Date of Sample Receipt : 2021/6/1 Date of Test : 2021/6/16 to 2021/6/29 Date of Issue : 2021/6/29 Test Standard : 47 CFR Part 15, Subpart C 15.247 Test Result : Pass Prepared for: KINGTA TECHNOLOGY CO., LTD Floor 2,Building 10/ Floor 4, Building 9, Futing industrial zone, Zhucun, Guanlan, Longhua,Shenzhen Prepared by: BlueAsia of Technical Services(Shenzhen) Co.,Ltd. Building C, No. 107, Shihuan Road, Shiyan Sub-District, Baoan District, Shenzhen, Guangdong Province, China TEL: +86-755-23059481 Compiled by: Review by: Approved by: Date: 2021/6/29 Report No.: BLA-EMC-202106-A0402 Page 2 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com REPORT REVISE RECORD Version No. Date Description 00 2021/6/29 Original Report No.: BLA-EMC-202106-A0402 Page 3 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com TABLE OF CONTENTS 1 TEST SUMMARY ........................................................................................................................................6 2 GENERAL INFORMATION .........................................................................................................................7 3 GENERAL DESCRIPTION OF E.U.T. .........................................................................................................7 4 TEST ENVIRONMENT ................................................................................................................................8 5 TEST MODE ................................................................................................................................................8 6 MEASUREMENT UNCERTAINTY ..............................................................................................................8 7 DESCRIPTION OF SUPPORT UNIT...........................................................................................................9 8 LABORATORY LOCATION .........................................................................................................................9 9 TEST INSTRUMENTS LIST ..................................................................................................................... 10 10 ANTENNA REQUIREMENT ..................................................................................................................... 14 10.1 CONCLUSION ....................................................................................................................................................... 14 11 CONDUCTED SPURIOUS EMISSIONS ................................................................................................ .. 15 11.1 LIMITS .............................................................................................................................................................. 15 11.2 BLOCK DIAGRAM OF TEST SETUP ..................................................................................................................... 15 11.3 TEST DATA .......................................................................................................................................................... 16 12 RADIATED EMISSIONS WHICH FALL IN THE RESTRICTED BANDS................................................. 17 12.1 LIMITS .............................................................................................................................................................. 17 12.2 BLOCK DIAGRAM OF TEST SETUP ..................................................................................................................... 18 12.3 PROCEDURE ..................................................................................................................................................... 18 12.4 TEST DATA .......................................................................................................................................................... 20 13 CONDUCTED BAND EDGES MEASUREMENT ..................................................................................... 24 13.1 LIMITS .............................................................................................................................................................. 24 13.2 BLOCK DIAGRAM OF TEST SETUP ..................................................................................................................... 24 13.3 TEST DATA .......................................................................................................................................................... 25 14 DWELL TIME ............................................................................................................................................ 26 14.1 LIMITS .............................................................................................................................................................. 26 14.2 BLOCK DIAGRAM OF TEST SETUP ..................................................................................................................... 26 14.3 TEST DATA .......................................................................................................................................................... 27 15 HOPPING CHANNEL NUMBER .............................................................................................................. 28 Report No.: BLA-EMC-202106-A0402 Page 4 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel:…

Text truncated - open the document above for the full version.

Model No.:F2
