N9BSV-5005Walkie Talkie

• The test results reported in this report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization form Intertek Testing Services Limited FCC ID: N9BSV-5005 Silver Manufactory Holdings Co., Ltd. Application For Certification 40MHz and 49MHz Walkie Talkie (FCC ID:N9BSV-5005) WO# 9807835 CKL/at October 27, 1998 INTERTEK TESTING SERVICES FCC ID: N9BSV-5005 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1:General Description EXHIBIT 2:System Test Configuration EXHIBIT 3:Emission Results EXHIBIT 4:Frequency Deviation EXHIBIT 5:Band Edges Emission EXHIBIT 6:Equipment Photographs EXHIBIT 7:Product Labelling EXHIBIT 8:Technical Specifications EXHIBIT 9:Instruction Manual INTERTEK TESTING SERVICES FCC ID: N9BSV-5005 ii MEASUREMENT/TECHNICAL REPORT Silver Manufactory Holdings Co., Ltd. - MODEL: 5005 FCC ID: N9BSV-5005 This report concerns (check one:)Original Grant X Class II Change Equipment Type: Walkie Talkie (example: computer, modem, transmitter, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)?Yes No X If yes, defer until : date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37?Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [10-1-96 Edition] provision. Report prepared by:C. K. Lam Intertek Testing Services. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone:852-2746-8211 Fax:852-2785-5487 INTERTEK TESTING SERVICES FCC ID: N9BSV-5005 iii Table of Contents 1.0 General Description ................................................................................................................. 2 1.1 Product Description.............................................................................................................. 2 1.2 Related Submittal(s) Grants .................................................................................................3 1.3 Test Methodology ................................................................................................................ 3 1.4 Test Facility.......................................................................................................................... 3 2.0 System Test Configuration ...................................................................................................... 5 2.1 Justification .......................................................................................................................... 5 2.2 EUT Exercising Software.....................................................................................................5 2.3 Support Equipment List and Description.............................................................................. 6 2.4 Equipment Modification ......................................................................................................6 3.0 Emission Results ....................................................................................................................... 8 3.1 Field Strength Calculation .................................................................................................... 9 3.2 Radiated Emission Configuration Photograph ................................................................... 11 3.3 Radiated Emission Data ..........................................................................................................13 4.0 Frequency Deviation .............................................................................................................. 15 5.0 Band Edges Emission ..................................................................................................................19 6.0 Equipment Photographs ........................................................................................................ 21 7.0 Product Labelling ................................................................................................................... 23 8.0 Technical Specifications ......................................................................................................... 25 9.0 Instruction Manual ......................................................................................................................27 INTERTEK TESTING SERVICES FCC ID: N9BSV-5005 iv List of attached file Exhibit typeFile Descriptionfilename Cover LetterLetter of Agencyletter.pdf Test ReportTest Reportreport.doc Test Setup PhotoRadiated Emissionradiated.jpg Test ReportBand Edges Emission Plotemission.pdf External PhotoExternal Photoophoto1.jpg, ophoto4 .jpg Internal PhotoInternal Photoiphoto1.jpg to iphoto8.jpg Block DiagramBlock Diagramblock.pdf SchematicsCircuit Diagramcircuit.pdf ID Label/LocationLabel Artwork and Locationlabel.pdf User ManualUser Manualmanual.pdf INTERTEK TESTING SERVICES FCC ID: N9BSV-5005 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: N9BSV-5005 2 1.0 General Description 1.1Product Description The CM5 Mission Communicator, model: 5005, is a 40MHz and 49MHz Walkie Talkie. It is a duplex transceiver and operated with 40.68MHz and 49.86MHz. It was powered by 9Vdc battery. The walkie talkie only have a volume switch for volume control and on/off function. The brief circuit description is listed in the following: -Q 6 (9018H) and associated circuit act as Tx amplifier and modulator. -Q 5 (9018H) and associated circuit act as Oscillator. -Q 4 (C1815) and associated circuit act as audio amplifier for transmitter. -Q 1 (9018H) and associated circuit act as Rx amplifier. -U 1 (LA1600) and associated circuit act as IF amplifier and mixer. -Q 2 (C1815), Q 3 (C1815) and associated circuit act as audio amplifier for receiver. INTERTEK TESTING SERVICES FCC ID: N9BSV-5005 3 1.2Related Submittal(s) Grants This is an …
