NAGSCVT-991102TeleEye Pro Transmission Unit
Signal Communications Limited
Click to zoom
Application Details
- Equipment Class
- JBP - Part 15 Class B Computing Device Peripheral
- Date of Grant
- Jan 23, 2000
- Application Purpose
- Original Equipment
- Date of Application
- Dec 20, 1999
- Equipment Note
- TeleEye Pro Transmission Unit
- Country
- Hong Kong
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Test Report
• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited FCC ID: NAGSCVT-991102 Signal Communications Limited Application For Certification (FCC ID: NAGSCVT-991102) TeleEye Pro Transmission Unit December 17, 1999 WO# 9912566 Ben W. K. Ho/at December 17, 1999 INTERTEK TESTING SERVICES FCC ID: NAGSCVT-991102 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1:General Description EXHIBIT 2:System Test Configuration EXHIBIT 3:Emission Results EXHIBIT 4:Equipment Photographs EXHIBIT 5:Product Labelling EXHIBIT 6:Technical Specifications EXHIBIT 7:Instruction Manual INTERTEK TESTING SERVICES FCC ID: NAGSCVT-991102 ii MEASUREMENT/TECHNICAL REPORT Signal Communications Limited - MODEL: TeleEye Pro PTA8-B1 TeleEye Pro PTA8-C1 FCC ID: NAGSCVT-991102 December 17, 1999 This report concerns (check one:)Original Grant X Class II Change Equipment Type: Computer Peripheral (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)?Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37?Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [10-1-96 Edition] provision. Report prepared by:Wilbur Ng Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, HONG KONG Phone: 852-2713-8502 Fax:852-2745-8306 INTERTEK TESTING SERVICES FCC ID: NAGSCVT-991102 iii Table of Contents 1.0 General Description................................................................................................................. 2 1.1 Product Description.............................................................................................................. 2 1.2 Related Submittal(s) Grants ......................................................................................................3 1.3 Test Methodology ................................................................................................................ 4 1.4 Test Facility.......................................................................................................................... 4 2.0 System Test Configuration.................................................................................................................6 2.1 Justification .......................................................................................................................... 6 2.2 EUT Exercising Software.....................................................................................................6 2.3 Special Accessories.............................................................................................................. 7 2.4 Equipment Modification ...........................................................................................................8 2.5 Support Equipment List and Description..................................................................................8 3.0 Emission Results................................................................................................................................10 3.1 Field Strength Calculation ..................................................................................................11 3.2 Radiated Emission Configuration Photograph .......................................................................12 3.3 Radiated Emission Data .....................................................................................................13 3.4 Line Conducted Configuration Photograph ........................................................................ 15 3.5 Line Conducted Emission Configuration Data ................................................................... 16 4.0 Equipment Photographs........................................................................................................ 20 5.0 Product Labelling................................................................................................................... 23 6.0 Technical Specifications......................................................................................................... 25 7.0 Instruction Manual................................................................................................................ 27 INTERTEK TESTING SERVICES FCC ID: NAGSCVT-991102 iv List of attached file Exhibit typeFile Descriptionfilename Cover LetterLetter of Agencyletter.pdf Test ReportTest Reportreport.doc Operation DescriptionTechnical Descriptiondescri.pdf Test Setup PhotoRadiated Emissionradiated1.jpg, radiated2.jpg Test Setup PhotoConducted Emissionconduct1.jpg to conduct3.jpg Test ReportConducted Emission Test Resultconduct.pdf External PhotoExternal Photoophoto1.jpg, ophoto2.jpg Internal PhotoInternal Photoiphoto1.jpg, iphoto2.jpg Block DiagramBlock Diagramblock.pdf SchematicsCircuit Diagramcircuit.pdf ID Label/LocationLabel Artwork and Locationlabel.pdf User ManualUser Manualmanual.pdf INTERTEK TESTING SERVICES FCC ID: NAGSCVT-991102 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: NAGSCVT-991102 2 1.0General Description 1.1Product Description The Equipment Under Test (EUT) is a TeleEye Pro Transmission Unit. The EUT is powered by AC120V 60Hz input, DC 9-12V output adaptor. It is a video monitoring system which can transmit B/W video frames or color video frames from up to 8 CCTV cameras to the PC monitor. Also it has multiple alarm inputs with independent NC/NO trigger contacts. Besides, it enables remote control through 2 relay switches. For electronic filing, the brief circuit description is saved a filename: descri.pdf. INTERTEK TESTING SERVICES FCC ID: NAGSCV…
