NH3P-20201RF Modulator

Users Manual RF Adaptor w/Antenna Transfer Switch for Use with The Sega Dreamcast, Sega Saturn, 16 Bit, Nintendo 64 and Sony Playstations Model: P-20-201 The adaptor must be connected with your Sega Dreamcast A/V port, and the output RF signal answer NTSC area CH3 and CH4. The adaptor's TV port connects to TV. The antenna port connects to CATV.

PROPOSED FCC ID LABEL AND LOCATION YUEHUA ELECTRON CO., LTD. OF ZHUHAI This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: NH3P-20201 FCC ID LABEL

FCC CFR47 PART 15 TV INTERFACE DEVICE TEST REPORT FOR RF ADAPTOR W/ ANTENNA TRANSFER SWITCH FOR USE WITH THE SEGA DREAMCAST, SEGA SATURN, SEGA 16 BIT, NINTENDO 64 AND SONY PLAYSTATIONS MODEL : P-20-201 FCC ID: NH3P-20201 REPORT NUMBER: 99C0436-1 ISSUE DATE: AUGUST 06, 1999 Prepared for YUEHUA ELECTRON CO.,LTD. OF ZHUHAI 30 BLDG., CHUIZHU INDUSTRIAL DISTRICT ZHUHAI, GUANGDONG PRC 519000 Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO:99C0436-1 DATE:AUGUST 06, 1999 FCC ID:NH3P-20201 EUT: RF ADAPTOR W/ ANTENNA TRANSFER SWITCH FOR USE WITH THE SEGA DREAMCAST, SEGA SATURN, SEGA 16 BIT, NINTENDO 64 AND SONY PLAYSTATIONS 1OF14 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4027B 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1.VERIFICATION OF COMPLIANCE.......................................................................2 2.PRODUCT DESCRIPTION......................................................................................3 3.TESTED SYSTEM DETAILS...................................................................................3 4.TEST FACILITY.....................................................................................................4 5.ACCREDITATION AND LISTING..........................................................................4 6.MEASUREMENT INSTRUMENTATION.................................................................4 7.MEASURING INSTRUMENT CALIBRATION.........................................................5 8.UNITS OF MEASUREMENT...................................................................................5 9.ANTENNAS.............................................................................................................6 10.CONDUCTED EMISSION TEST PROCEDURE.......................................................6 11.RADIATED EMISSION TEST PROCEDURE...........................................................6 12.AMBIENT CONDITIONS........................................................................................7 13.EQUIPMENT MODIFICATIONS.............................................................................7 14.EUT SETUP PHOTOS.............................................................................................8 15.TEST EQUIPMENT LIST.......................................................................................9 16.TEST RESULT SUMMARY...................................................................................10 Exhibits 1. Proposed FCC ID Label Format 2. Authorization Letter 3. Modification Report 4. User’s Manual 5. Schematic Diagram 6. EUT Photographs REPORT NO:99C0436-1 DATE:AUGUST 06, 1999 FCC ID:NH3P-20201 EUT: RF ADAPTOR W/ ANTENNA TRANSFER SWITCH FOR USE WITH THE SEGA DREAMCAST, SEGA SATURN, SEGA 16 BIT, NINTENDO 64 AND SONY PLAYSTATIONS 2OF14 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4027B 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1.VERIFICATION OF COMPLIANCE COMPANY NAME: YUEHUA ELECTRON CO., LTD. OF ZHUHAI 30 BLDG., CHUIZHU INDUSTRIAL DISTRICT ZHUHAI, GUANGDONG CHINA 519000 CONTACT PERSON: JIANG HANXIONG / MANAGER TELEPHONE NO:(0756) 861-0916 MODEL NO/NAME: P-20-201 SERIAL NO:N/A DATE TESTED:AUGUST 06, 1999 TYPE OF EQUIPMENT:TV INTERFACE DEVICE MEASUREMENT DISTANCE:(X) 3 METER ( ) 10 METER FCC RULES:PART 15.115 MEASUREMENT PROCEDUREANSI C63.4:92 EQUIPMENT AUTHORIZATION PROCEDURE CERTIFICATION MODIFICATIONS MADE ON EUT YES NO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 21 for comments) NO TEST RESULTPASSED The above equipment was tested by Compliance Consulting Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Reviewed By MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE CONSULTING SERVICES REPORT NO:99C0436-1 DATE:AUGUST 06, 1999 FCC ID:NH3P-20201 EUT: RF ADAPTOR W/ ANTENNA TRANSFER SWITCH FOR USE WITH THE SEGA DREAMCAST, SEGA SATURN, SEGA 16 BIT, NINTENDO 64 AND SONY PLAYSTATIONS 3OF14 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4027B 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2.PRODUCT DESCRIPTION EUT is an RF adapter made for use with a game station. It is designed to operate at Channels 3 and 4 of TV, and serves as an interface device between TV and Game stations. By installing this device, the user can use TV as a monitor. The EUT is connected to TV via F jack. CHASSIS TYPEPLASTIC NUMBER OF PCB LAYERS1 LAYER POWER SUPPLY/NAME/MODEL NO.BUILT-IN POWER REQUIREMENTS120 V AC, 60 Hz NO. OF EXTERNAL I/O CONNECTORS2 External I/O Cable Construction Description CABLE NO: 1 I/O Port: Controller PortNumber of I/O ports of this type: 1 Number of Conductors: 5 Connector Type: Special Capture Type: Snap-in Type of Cable used: Unshielded Cable Connector Type: Molded Cable Length: 1.5 M Bundled During Tests: Yes Data Traffic Generated: No Remark: N/A CABLE NO: 2 I/O Port: Output of Game St.Number of I/O ports of this type: 1 Number of Conductors: 5 Connector Type: Special Capture Type: Snap-in Type of Cable used: Unshielded Cable Connector Type: Molded Cable Length: 1.5 M Bundled During Tests: Yes Data Traffic Generated: No Remark: One ferrite bead on Game station side. CABLE NO: 3 I/O Port: RCA JackNumber of I/O ports of this type: 1 Number of Conductors: 1 Connector Type: RCA Jack Capture Type: Snap-in Type of Cable used: Shi…
