NI3-IS30V122Wireless 11g Broadband Router

WSR-3018 Wireless 11g Broadband Router User’s Guide FCC Caution 1.The device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2.FCC RF Radiation Exposure Statement: The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. 3.This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 4.Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residen- tial installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Important Safety Precautions Always read and follow these basic safety precautions carefully when handling any piece of electronic component. 1.Keep this User’s Guide for future reference. 2.Keep this equipment away from humidity. 3.Lay this equipment on a reliable flat surface before setting it up. 4.The openings on the enclosure are for air convection hence protects the equipment from overheating. 5.All cautions and warnings on the equipment should be noted. 6.Never pour any liquid into the opening that could damage or cause electrical shock. 7.If any of the following situations arises, get the equipment checked by a service personnel: Liquid has penetrated into the equipment The equipment has been exposed to moisture The equipment has not work well or you can not get it work according to User’s Manual The equipment has dropped and damaged If the equipment has obvious sign of breakage 8.DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT UNCONDITIONED, STORAGE TEMPERATURE ABOVE 60 O C OR BELOW -20 O C, IT MAY DAMAGE THE EQUIPMENT. How to Use This Guide This User’s Guide provides instructions and illustrations on how to install and use your WSR-3018 - the Wireless 11g Broadband Router. Chapter 1, Introduction, provides a general information on the product you bought, including its application, specification, and requirements. Chapter 2, Hardware Installation, tells you how to install the product into your system. Chapter 3, Configuration, describes the Configuration Utility that lets you configure your product to connect the network quickly and easily. Appendix, includes the instructions of assigning a fixed IP address and resuming the firmware. Please note that the setting diagrams or values in this guide are FOR YOUR REFER- ENCE ONLY. The actual settings and values depend on your system and network. If you are not sure about these information, please ask your network administrator or MIS staff for help. Technical Support Visit the MSI website for FAQ, technical guide, driver and software updates, and other information: http://www.msi.com.tw/. Contact our technical staff at: [email protected]. Table of Contents 1. Introduction ......................................................................................................... 1 1.1 WSR-3018 - Wireless 11g Residential Gateway ....................................... 1 1.2 Networking Options....................................................................................... 2 1.3 Features and Benefits ..................................................................................... 3 1.4 Package Contents ............................................................................................ 4 1.5 System Requirements ..................................................................................... 4 1.6 Specifications.................................................................................................. 5 2. Hardware Installation ......................................................................................... 8 2.1 Product View .................................................................................................. 8 2.2 Connections Ports .......................................................................................... 9 2.3 LEDs ............................................................................................................... 10 2.4 Installing Your WSR-3018 .................................................................................11 2.4.1 Positioning.............................................................................................. 11 2.4.2 Connecting Cables.................................................................................. 11 2.4.3 To Power Up.......................................................................................... 12 3. Configuration...................................................................................................... 13 3.1 Configuration Utility .......................................…

Text truncated - open the document above for the full version.

Company : SENAO INTERNATIONAL CO., LTD. Page : 1 of 11 Product : Wirless 11g Broadband Router Model : WSR-3018 Company : SENAO INTERNATIONAL CO., LTD. Page : 2 of 11 Product : Wirless 11g Broadband Router Model : WSR-3018 Company : SENAO INTERNATIONAL CO., LTD. Page : 3 of 11 Product : Wirless 11g Broadband Router Model : WSR-3018 Company : SENAO INTERNATIONAL CO., LTD. Page : 4 of 11 Product : Wirless 11g Broadband Router Model : WSR-3018 Company : Dee Van Enterprise Co., Ltd. Page : 5 of 11 Product : Wirless 11g Broadband Router-Adapter Model : DV-1280-3 Company : Dee Van Enterprise Co., Ltd. Page : 6 of 11 Product : Wirless 11g Broadband Router-Adapter Model : DV-1280-3 Company : Dee Van Enterprise Co., Ltd. Page : 7 of 11 Product : Wirless 11g Broadband Router-Adapter Model : DV-1280-3 Company : Dee Van Enterprise Co., Ltd. Page : 8 of 11 Product : Wirless 11g Broadband Router-Adapter Model : DV-1280-3 Company : Dee Van Enterprise Co., Ltd. Page : 9 of 11 Product : Wirless 11g Broadband Router-Adapter Model : DV-1280-3 Company : Dee Van Enterprise Co., Ltd. Page : 10 of 11 Product : Wirless 11g Broadband Router-Adapter Model : DV-1280-3 Company : Dee Van Enterprise Co., Ltd. Page : 11 of 11 Product : Wirless 11g Broadband Router-Adapter Model : DV-1280-3

Company: SENAO INTERNATIONAL CO., LTD. Model: WSR-3018 Product : Wireless 11g Broadband Router Wireless 11g Residential Gateway Model No: WSR-3018 FCC IDNI3-IS30V122 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: [1] this device may not cause harmful interference and [2] this device must accept any interference received, including interference that may cause undesired operation. S/N Made in Taiwan

Company : SENAO INTERNATIONAL CO., LTD. Page : 1 of 4 Product : Wireless 11g Broadband Router Model : WSR-3018 Company : SENAO INTERNATIONAL CO., LTD. Page : 2 of 4 Product : Wireless 11g Broadband Router Model : WSR-3018 Company : SENAO INTERNATIONAL CO., LTD. Page : 3 of 4 Product : Wireless 11g Broadband Router Model : WSR-3018 Company : SENAO INTERNATIONAL CO., LTD. Page : 4 of 4 Product : Wireless 11g Broadband Router Model : WSR-3018

5 >>> 1.6 Specifications Standard Compliance- IEEE802.11g/IEEE802.11b/ IEEE802.3/IEEE802.3u Internet ProtocolTCP/IP, NAT, DHCP, HTTP, SupportedPPPoE, PPTP, DNS, LPR, SNTP Operating Temperature0 ~ 55 O C (32 ~ 122 O F) Storage Temperature-30 ~ 70 O C (-22 ~ 158 O F) Operating Humidity0 ~ 85% @ 40 O C (104 O F), non-condensing Wired Data Rates10/100Mbps auto-negotiating (full-duplexing switch) Wireless Data RatesIEEE802.11b (auto-fallback) - CCK: 11, 5.5Mbps - DQPSK: 2Mbps - DBPSK: 1Mbps IEEE802.11g (auto-fallback) - OFDM: 54, 48, 36, 24, 18, 12, 9, and 6Mbps Wireless RangeOpen Space: - ≥ 170m @ 11Mbps - ≥ 50m @ 54Mbps Indoor: - ≥ 120m @ 11Mbps - ≥ 20m @ 54Mbps Wireless Transmission17±1dBm Power General Performance 6 LAN Device Management Number of PortsFour 10/100Mbps switched Ethernet ports (RJ-45) Number of PCsUp to 253 PCs Supported RoutingNAT, TCP/IP Number of PortsOne 10/100Mbps Fast Ethernet port for cable/xDSL modem (RJ-45) Firewall- IP/Port Address Forwarding Filtering - MAC Address Forwarding Filtering - MAC Address Associating Filtering - DoS Prevention - Application Layer Gateway - Virtual DMZ - SPI ToolsWeb-based browser; event log; login password LEDsPower, LAN/WAN/WLAN port activity Dimensions (WxDxH)180 x 127.7 x 32mm Weight295g AntennaDipole type with dual external antenna Input Voltage12VDC (includes AC adapter) WA N Physical Specification 7 U.S.FCC Part 15 class B, Wi-Fi EuropeCE Certifications

Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID NI3-IS30V122 Report No.ER04-07-011FRF Page 1 of 64 TEST REPORT Product Name Wireless 11g Broadband Router Model Number WSR-3018 FCC ID NI3-IS30V122 Applicant SENAO INTERNATIONAL CO., LTD. Address 2FL, NO.531 CHUNG CHENG RD., HSIN-TIEN, TAIPEI, TAIWAN, R.O.C. Received Date July 05, 2004 Tested Date February 09 ~ 24, 2004 Notes 1. This report will be invalid if duplicated or photocopied in part. 2. This report refers only to the specimen(s) submitted to testing, and be invalid as seperately used. 3. This report is invalid without examination stamp and signature of this institute. 4. The tested specimen(s) will be preserved for thirty days from the data issued. 5. The report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. 6. This report is transferred from ER03-12-064. Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID NI3-IS30V122 Report No.ER04-07-011FRF Page 2 of 64 Test Report Certification Product Name Wireless 11g Broadband Router Model Number WSR-3018 FCC ID NI3-IS30V122 Applicant SENAO INTERNATIONAL CO., LTD. Measurement Standard : FCC 47 C.F.R. Part 15, Subpart B and Subpart C (2003) ANSI C63.4 (2001) WE HEREBY CERTIFY THAT: The measurements shown in the attachment were made in accordance with the procedures indicated, and the energy emitted by the equipment was found to be within the limits applicable. We assume full responsibility for the accuracy and completeness of these measurements and vouch for the qualifications of all persons taking them. Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID NI3-IS30V122 Report No.ER04-07-011FRF Page 3 of 64 TABLE OF CONTENTS TITLE PAGE NO. 1. GENERAL INFORMATION ................................................................................................... 5 1.1 General Statement .................................................................................................................................5 1.2 General Description of EUT & Power ..................................................................................................5 1.3 Description of Peripherals.....................................................................................................................6 1.4 EUT & Peripherals Setup Diagram.......................................................................................................7 1.5 EUT Operating Procedure.....................................................................................................................7 1.6 Description of Test Site ........................................................................................................................8 1.7 Summary of Test Results ......................................................................................................................8 2. CONDUCTED POWERLINE TEST....................................................................................... 9 2.1 Test Equipments ...................................................................................................................................9 2.2 Test Setup .............................................................................................................................................9 2.3 Conducted Power Line Emission Limit ................................................................................................10 2.4 Test Procedure ......................................................................................................................................10 2.5 Uncertainty of Conducted Emission .....................................................................................................10 2.6 Conducted RF Voltage Measurement ...................................................................................................11-12 2.7 Photos of Conduction Test....................................................................................................................13 3. RADIATED EMISSION TEST ................................................................................................ 14 3.1 Test Equipments ...................................................................................................................................14 3.2 Test Setup .............................................................................................................................................14 3.3 Radiation Limit .....................................................................................................................................15 3.4 Test Procedures.....................................................................................................................................16 3.5 Uncertainty of Radiated Emission ........................................................................................................16 3.6 Radiated RF Noise Measurement .........................................................................................................17-42 3.7 Photos of Open Site ..............................................................................................................................43-44 4. 6dB BANDWIDTH MEASUREMENT ................................................................................... 45 4.1 Test Equipments ...................................................................................................................................45 4.2 Test Setup .............................................................................................................................…

Text truncated - open the document above for the full version.

Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID NI3-IS30V122 Report No.ER04-07-011FRF Page 43 of 64 3.7 Photos of Open Site Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID NI3-IS30V122 Report No.ER04-07-011FRF Page 44 of 64 Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID NI3-IS30V122 Report No.ER04-07-011FRF Page 13 of 64 2.7 Photos of Conduction Test
