NKF-DESKFORCEIIDISK ARRAY

Maxtronic International Co Ltd

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Jul 28, 2003
Application Purpose: Original Equipment
Date of Application: Jul 28, 2003
Equipment Note: DISK ARRAY
Frequency Range: 66.00000000 - 100.00000000
Company: Maxtronic International Co Ltd
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Ultra 160 SCSI to IDE Disk Array System User’s Guide VVeerrssiioonn 11..00 FFeebb.. 22000033 P/N. G414239 Arena DeskForce II Ultra 160 SCSI to IDE Disk Array System User’s Guide VVeerrssiioonn 11..00 FFeebb.. 22000033 P/N. G414239 AR-88198 2003 MaxTronic International Co., Ltd. All rights reserved. No part of this written material may be reproduced, stored in a retrieval system, used in any form or by any means, electronic or mechanical, photocopying, recording, or otherwise, without the written permission of MaxTronic International CO., LTD. CCooppyyrriigghhtt NNoottiiccee 1. Before starting, take a few minutes to read this manual, read all of these instructions and save this manual for later reference. 2. Protect the Disk Array from extremely high or low temperatures. Let the Disk Array warm (or cool ) to room temperature before using it. 3. Protect the Disk Array from being bumped or dropped. Do not place this product on an unstable cart, stand, or table. It may fall, causing serious damage to the product. 4. Keep the Disk Array away from magnetic forces. 5. Do not use this product near water. 6. Keep the Disk Array away from dust, sand, or dirt. 7. Gaps and openings in the cabinet and the back are provided for ventilation. To ensure reliable operation and to protect it from overheating, the gaps and openings should never be blocked or covered by placing the product on a bed, sofa, rug, or other similar surface. 8. Do not place this product near or over a radiator or heat register. 9. Refer to rating plate for voltage and check the appliance voltage corresponds to the supply voltage. 10. The appliance must be grounded. This product is equipped with a 3wire grounding-type power cord, this power cord will only fit into a groundingtype power outlet. IImmppoorrttaanntt!! SSaaffeettyy IInnssttrruuccttiioonnss,, CCaarree aanndd HHaannddlliinngg 11. If an extension cord or a power center is used with this product, make sure that the total of all products plug into the wall outlet does not exceed the ampere rating. 12. Do not place the Disk Array where the cord will be walked on. 13. Never push any kind of object into this product through cabinet gaps and openings, they may touch dangerous voltage points cause a risk of fire or electric shock. 14. Unplug the power cord from the wall outlet before cleaning. Keep the Disk Array dry. Do not use liquid cleaners, aerosol cleaners, or a wet cloth. Use a damp cloth for cleaning. 15. Except as specifically explained in this User’s Manual, please do not attempt to service this product by yourself. Opening or removing the covers may expose you to dangerous voltages. 16. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions : zIf this product has been exposed to water or any liquid. zIf the product has been dropped or the cabinet damaged. When selecting a suitable working location, please consider : zVentilation zTemperature zDust and dirt zElectromagnetic and Radio Frequency Interference. zSecurity The selected location should provide at least six inches of open space around the Disk Array cabinet for proper air flow. Your Disk Array functions best at normal room temperature. Choose a location free from extreme heat or cold. Your Disk Array should be used in a clean environment that is free from airborne contaminants such as dust, dirt, and smoke. Excessive moisture or oil particles in the air can also hinder your system’s performance. To reduce the possibility of data errors caused by electromagnetic interference, locate your Disk Array at least five feet away from electrical appliances and equipment that generates magnetic fields. OOppeerraattiinngg EEnnvviirroonnmmeenntt The Disk Array’s LCD Panel may be damaged by exposure to intense sunlight. Limit exposure to indirect or subdued sunlight only. Warning!! This manual serves as a useful guide you can refer to when you wish to install and operate your Disk Array. It includes the following information : z Chapter 1 : “ Introduction “ Introduces you to your new Disk Array’s features and general RAID concepts. z Chapter 2 : “ Getting Started “ Describes general information about this Disk Array. z Chapter 3 : “ Configuration “ Provides a Quick and Easy way to setup this Disk Array. z Chapter 4 : “ Advanced Information “ Describes information in more detail. z Chapter 5 : “ Hot-Swap “ Describes Hot-Swap components. z Appendix A : “ Technical Specification “ AAbboouutt TThhiiss MMaannuuaall CChhaapptteerr 11 :: IInnttrroodduuccttiioonn Features.......................................................................... 1-2 General RAID concepts.....................................................1-4 RAID Level 0 .....................................................1-5 RAID Level 1 .....................................................1-6 RAID Level 3 .....................................................1-7 RAID Level 5 .....................................................1-8 Summary Comparison of RAID Levels............................... 1-10 Supported RAID Levels.....................................................1-11 Multi-SCSI Format support .....................................................1-12 Contents CChhaapptteerr 22 :: GGeettttiinngg SSttaarrtteedd General Overview ............................................................... 2-1 Unpacking & Checklist.................................................... 2-2 Choosing a place for Disk Array .......................................... 2-3 Identifying Parts of Disk Array Front View .....................................................2-4 Rear View .....................................................2-5 Power Source................................................................2-6 Installing the Hard Disk Drive.......................................... 2-7 How To Setup Active Terminator .......................................... 2-11 Host Linkage .................................…

Text truncated - open the document above for the full version.

Block Diagram

block diagram FCC ID: NKF-DESKFORCEII

Cover Letter(s)

FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. To whom it may concern: I, hereby, declare that the following EMI suppression components on the EUT, FCC ID: NKF-DESKFORCEII, will be added or layout on the mass production products. 1. For HDD, used aluminum foil to contact iron panel with the slot of iron case. 2. Added core (LF-65) to RS232 and LAN with one turn. 3. Stuck RS232 and LAN on the inside of iron panel, the power cable of front panel was stuck on the inside of case. 4. Used Gasket to strengthen the contact of the mechanism. 5. Added 2 cores (LF-65) on LED and the cable of control panel. 6. Added core (LF-100) to SCSI cable. MaxTronic International Co., Ltd. 4F, No. 529, Chung Cheng Rd., Hsin Tien City, Taipei Hsien, Taiwan, R.O.C. Engineer: Air Kao Date: Jul. 7, 2003

External Photos

FCC ID : NKF-DESKFORCEII Number1 FRONT SIDE OF EUT FCC ID : NKF-DESKFORCEII Number2 BOTTOM SIDE OF EUT FCC ID : NKF-DESKFORCEII Number3 REAR SIDE OF EUT FCC ID : NKF-DESKFORCEII Number4 CLOSER LOOK OF REAR INTERFACE PORT

ID Label/Location Info

FCC ID: NKF-DESKFORCEII Label Location

ID Label/Location Info

MODEL:DeskForce II FCC ID:NKF-DESKFORCEII This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions(1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: AC INPUT 115V/230V 60/50Hz 6/3A

Internal Photos

FCC ID: NKF-DESKFORCEII Number 1 Mechanical construction FCC ID: NKF-DESKFORCEII Number 2 Mechanical construction 5 5 4 2 4 FCC ID: NKF-DESKFORCEII Number 3 Mechanical construction 4 4 FCC ID: NKF-DESKFORCEII Number 4 Mechanical construction 3 2 FCC ID: NKF-DESKFORCEII Number 5 Mechanical construction FCC ID: NKF-DESKFORCEII Number 6 Mechanical construction 4 44 4 FCC ID: NKF-DESKFORCEII Number 7 Mechanical construction FCC ID: NKF-DESKFORCEII Number 8 Mechanical construction FCC ID: NKF-DESKFORCEII Number 9 Mechanical construction of HDD case FCC ID: NKF-DESKFORCEII Number 10 Mechanical construction of HDD case 1 1 1 1 FCC ID: NKF-DESKFORCEII Number 11 Mechanical construction of HDD case FCC ID: NKF-DESKFORCEII Number 12 Front side of LCD module FCC ID: NKF-DESKFORCEII Number 13 Rear side of LCD module FCC ID: NKF-DESKFORCEII Number 14 Front side of module board FCC ID: NKF-DESKFORCEII Number 15 Rear side of module board FCC ID: NKF-DESKFORCEII Number 16 Front side of main board FCC ID: NKF-DESKFORCEII Number 17 Rear side of main board FCC ID: NKF-DESKFORCEII Number 18 Front side of memory FCC ID: NKF-DESKFORCEII Number 19 Rear side of memory FCC ID: NKF-DESKFORCEII Number 20 Front side of RS-232 to RJ-45 connector board FCC ID: NKF-DESKFORCEII Number 21 Rear side of RS-232 to RJ-45 connector board FCC ID: NKF-DESKFORCEII Number 22 Front side of SCSI daughter board FCC ID: NKF-DESKFORCEII Number 23 Rear side of SCSI daughter board FCC ID: NKF-DESKFORCEII Number 24 Front side of back plane FCC ID: NKF-DESKFORCEII Number 25 Rear side of back plane FCC ID: NKF-DESKFORCEII Number 26 Front side of HDD FCC ID: NKF-DESKFORCEII Number 27 Rear side of HDD FCC ID: NKF-DESKFORCEII Number 28 Front side of power FCC ID: NKF-DESKFORCEII Number 29 Front side of power FCC ID: NKF-DESKFORCEII Number 30 Rear side of power FCC ID: NKF-DESKFORCEII Number 31 Front side of module power FCC ID: NKF-DESKFORCEII Number 32 Rear side of module power FCC ID: NKF-DESKFORCEII Number 33 Front side of module power FCC ID: NKF-DESKFORCEII Number 34 SCSI cable 6 FCC ID: NKF-DESKFORCEII Number 35 SCSI cable 6 FCC ID: NKF-DESKFORCEII Number 36 RS232 cable

Test Report

FCC TEST REPORT Report No. : F342504 SPORTON International Inc. TEL : 886-2-2696-2468 FAX : 886-2-2696-2255 FCC TEST REPORT for 47 CFR, Part 2, Part 15 Subpart B and CISPR PUB. 22 Equipment : Disk Array Model No. : DeskForce II FCC ID : NKF-DESKFORCEII Filing Type : Certification Applicant : MaxTronic International Co., Ltd. 4F, No. 529, Chung Cheng Rd., Hsin Tien City, Taipei Hsien, Taiwan, R.O.C. The test result refers exclusively to the test presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. Certificate or Test Report must not be used by the applicant to claim the product in this test report endorsement by NVLAP or any agency of U.S. government. SPORTON International Inc. 6F, No.106, Sec. 1, Hsin Tai Wu Rd., Hsi Chih, Taipei Hsien, Taiwan, R.O.C. FCC TEST REPORT Report No. : F342504 SPORTON International Inc. FCC ID : NKF-DESKFORCEII TEL : 886-2-2696-2468 Page No. : i FAX : 886-2-2696-2255 Issued Date : Jun. 03, 2003 Table of Contents History of this test report....................................................................................................................................ii CERTIFICATE OF COMPLIANCE........................................................................................................................1 1. General Description of Equipment under Test.............................................................................................2 1.1 Applicant..........................................................................................................................................................................................2 1.2 Manufacturer ...................................................................................................................................................................................2 1.3 Basic Description of Equipment under Test ....................................................................................................................................2 1.4 Feature of Equipment under Test ...................................................................................................................................................2 2. Test Configuration of Equipment under Test ...............................................................................................3 2.1 Test Manner ....................................................................................................................................................................................3 2.2 Description of Test System .............................................................................................................................................................3 2.3 Connection Diagram of Test System ..............................................................................................................................................5 3. Test Software ...................................................................................................................................................6 4. General Information of Test............................................................................................................................7 4.1 Test Facility .....................................................................................................................................................................................7 4.2 Test Voltage ....................................................................................................................................................................................7 4.3 Standard for Methods of Measurement...........................................................................................................................................7 4.4 Test in Compliance with ..................................................................................................................................................................7 4.5 Frequency Range Investigated .......................................................................................................................................................7 4.6 Test Distance ..................................................................................................................................................................................7 5. Test of Conducted Powerline .........................................................................................................................8 5.1 Major Measuring Instruments..........................................................................................................................................................8 5.2 Test Procedures ..............................................................................................................................................................................9 5.3 Typical Test Setup Layout of Conducted Powerline .....................................................................................................................10 5.4 Test Result of AC Powerline Conducted Emission .......................................................................................................................11 6. Test of Radiated Emission............................................................................................................................15 6.1 Major Measuring Instruments........................................................................................................................................................15 6.2 Test Procedures ............................................................................................................................................................................16 6.3 Typical Test Setup Layout of Radiated Emission............................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC TEST REPORT Report No. : F342504 SPORTON International Inc. FCC ID : NKF-DESKFORCEII TEL : 886-2-2696-2468 Page No. : 1 of 3 FAX : 886-2-2696-2255 Issued Date : Jun. 03, 2003 1.1. Photographs of Conducted Emission Test Configuration The photographs show the configuration that generates the maximum emission. FRONT VIEW REAR VIEW FCC TEST REPORT Report No. : F342504 SPORTON International Inc. FCC ID : NKF-DESKFORCEII TEL : 886-2-2696-2468 Page No. : 2 of 3 FAX : 886-2-2696-2255 Issued Date : Jun. 03, 2003 SIDE VIEW FCC TEST REPORT Report No. : F342504 SPORTON International Inc. FCC ID : NKF-DESKFORCEII TEL : 886-2-2696-2468 Page No. : 3 of 3 FAX : 886-2-2696-2255 Issued Date : Jun. 03, 2003 1.2. Photographs of Radiated Emission Test Configuration The photographs show the configuration that generates the maximum emission. FRONT VIEW REAR VIEW
