NKS-PA1Trimble Gateway NA

PeopleNet Communications Corporation
Trimble Gateway NA - FCC ID NKS-PA1 - PeopleNet Communications Corporation
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Nov 24, 2020
Application Purpose
Original Equipment
Date of Application
Nov 24, 2020
Equipment Note
Trimble Gateway NA
Frequency Range
2402.00000000 - 2480.00000000
Company
PeopleNet Communications Corporation
Country
United States

Documents & Files

Select a file to view

Users Manual

β†—

Attestation Statements

β†—

Cover Letter(s)

β†—
β†—
β†—

External Photos

β†—

ID Label/Location Info

β†—
β†—

Internal Photos

β†—

RF Exposure Info

β†—

Test Report

β†—
β†—

Test Setup Photos

β†—

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Trimble Gateway Alpha Install Guide Install Overview ο‚§ The Trimble Gateway device includes internal Cellul ar, WiFi, and GPS antennas. – Mount the module in or on the dash with a clear vie w of the sky unobstructed by metals, with the top pointing to the sky. – Attach the module securely using the screws provide d, strong two-sided tape, or plastic ties. – Be sure the module is clear of driver activities an d potential environmental hazards. ο‚§ Connect to the vehicle Power and Engine Data using the cables and adapters noted in the following pages. – The main cable includes an RP1226 connector for mos t late-model vehicles. – Adapters are available to connect at the diagnostic port if needed, as well as a 2-pin cable for in- dash installations. ο‚§ The optional white Ignition lead is available if ne eded, but most vehicles will boot normally using the J1939 Engine Data signal. ο‚§ The display will power from the three-pin Power/Ign ition/Ground connector, while all Display communications take place over WiFi. Vehicle-Specific Install Guides ο‚§ The page below includes install guides and videos c overing most Makes and Models. ο‚§ No Trimble Gateway-specific guides exist at this ti me, but the guides can be used as references, as the vehicl e connection points are the same. – See the PCG tab for diagnostic port and RP1226 inst alls. – See the PMG tab for 2-pin installs. ο‚§ https://transportation.trimble.com/installations/ Additional Install Notes ο‚§ Trimble Gateway supports power inputs from 12 or 24 volt vehicles (6-36 volt functional range). ο‚§ Trimble Gateway includes internal antennas, but an external antenna is also available if needed. – Part H-055-0519 – The module will automatically detect an external an tenna and switch to it. ο‚§ Trimble Gateway will automatically adjust to the ba ud rate of the vehicle J1939, whether 250k or 500k. Standard Kit M-010-0728 ο‚§ Trimble Gateway Module E-006-0638 ο‚§ L-016-0728 Trimble Gateway RP1226 Main Cable – Trimble Gateway 44-Pin Head. – RP1226 for Power/Engine Data Connection to newer tr ucks or adapters for older vehicles. – Power/Ignition/Ground Connector for Displays. – Two RS232 Connections. – Two discrete inputs. ο‚§ H-048-0526 #8 x ¾” Mounting Screws Adapters and Accessories ο‚§ M-010-0741 9-Pin Kit – L-016-0737 – RP1226 to 9-Pin Adapter – Connection to any approved 9-Pin Diagnostic Port ο‚§ M-010-0743 Volvo/Mack Kit – L-016-0737 – RP1226 to Volvo/Mack OBD-style Adapter – Connection to Volvo/Mack diagnostic port on pre-201 8 Volvo/Mack trucks with Volvo/Mack engine ο‚§ L-016-0727 Trimble Gateway/PMG Adapter – Connects a Trimble Gateway device to an existing PM G Main Cable, replacing the PMG ο‚§ L-016-0734 Trimble Gateway/PMG Dual Adapter – A β€œY” connector to plug both a Trimble Gateway and a PMG into an existing PMG Main Cable Trimble Gateway Box Ethernet Currently Not Used Optional External Antenna Main Cable Mount Flanges LED Indicators ο‚§ LED1 – Solid Red = ON and Charging – Off = Powered Off ο‚§ LED2 – Solid Green = Cell Connected – Off = No Cell Connection ο‚§ LED3 – Rapid Blue Flash = Engine Data Connected – Off = No Engine Data ο‚§ LED4 – Solid Amber = GPS Fixed – Blinking Amber = No GPS Fix 1 2 3 4 Main Cable Pin-out AB CD 1 10 40 31 PinA and B Input Power C and D Ground 31 Ignition Sense 6 J1708 High 7 J1708 Low 36 J1939 High 35 J1939 Low Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ⚫ Reorient or relocate the receiving antenna. ⚫ Increase the separation between the equipment and receiver. ⚫ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ⚫ Consult the dealer or an experienced radio/TV technician for help. FCC Caution: ➒ Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. ➒ This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Attestation Statements

                                ! !"# $%!&' ( )!!* +$,-$!$% )%% !. "%&'/+$ (  /+$ !/++0          !"# $%!%! +1!!* +$ ! )+**  0! !" "% ( /)/ ! 1% **%$ 02! /) $$"%  + $ "- / "## !*#!+0   /# +!(#3+ 1 1!+! 4  *% ,! $ $+0 2!# +5  $%## +  6 (-"   &%" 178%$$%811 1 . *%6 --+$  *   2%99 :99 8-%) 1;* *% %0$ - We, PeopleNet Communications Corporation, hereby declare that although the product hardware supports WiFi 802.11ah, it has been disabled via software for this original application. The software is not accessible to end users and cannot be modified by any other party than us.

Cover Letter(s)

PeopleNet Communications Corporation 4400 Baker Road, Minnetonka Minnesota 55343-8684 United States Date: 2020-11-09 FCC ID: NKS-PA1 To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description Software Operational Description Part list Tune-up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------- Albert Wong / Electrical Engineering Manager PeopleNet Communications Corporation Tel: 952-908-1832 Fax: 952-908-6130 E-mail: [email protected]

Cover Letter(s)

PeopleNet Communications Corporation 4400 Baker Road, Minnetonka Minnesota 55343-8684 United States Date: 2020-11-09 FCC ID: NKS-PA1 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ------------------------------------------------------- Albert Wong / Electrical Engineering Manager PeopleNet Communications Corporation Tel: 952-908-1832 Fax: 952-908-6130 E-mail: [email protected]

Cover Letter(s)

PeopleNet Communications Corporation 4400 Baker Road, Minnetonka Minnesota 55343-8684 United States Date: 2020-11-09 FCC ID: NKS-PA1 A UTHORIZ A TION LETTER To whom it may concern: I, the undersigned PeopleNet Communications Corporation hereby authorize Amanda Wu / Senior Specialist of Bureau Veritas Consumer Products Services Services to act on my behalf in all matters relating to all processes required in FCC and any communication needed with the national authority. Any and all acts carried out by Amanda Wu / Senior Specialist on my behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------------- Albert Wong / Electrical Engineering Manager PeopleNet Communications Corporation Tel: 952-908-1832 Fax: 952-908-6130 E-mail: [email protected]

External Photos

Reference No.: BGSN-WTW-P20080589 1 of 7 CONSTRUCTION PHOTOS OF EUT Brand: Trimble / Model: Trimble Gateway-PA1 Reference No.: BGSN-WTW-P20080589 2 of 7 Reference No.: BGSN-WTW-P20080589 3 of 7 Reference No.: BGSN-WTW-P20080589 4 of 7 Reference No.: BGSN-WTW-P20080589 5 of 7 Reference No.: BGSN-WTW-P20080589 6 of 7 Reference No.: BGSN-WTW-P20080589 7 of 7

ID Label/Location Info

Label Location FCC ID:NKS-PA1 Bottom view of EUT

Internal Photos

Reference No.: BGSN-WTW-P20080589 1 of 9 CONSTRUCTION PHOTOS OF EUT Brand: Trimble / Model: Trimble Gateway-PA1 Reference No.: BGSN-WTW-P20080589 2 of 9 Reference No.: BGSN-WTW-P20080589 3 of 9 Reference No.: BGSN-WTW-P20080589 4 of 9 Reference No.: BGSN-WTW-P20080589 5 of 9 Reference No.: BGSN-WTW-P20080589 6 of 9 Reference No.: BGSN-WTW-P20080589 7 of 9 Reference No.: BGSN-WTW-P20080589 8 of 9 Reference No.: BGSN-WTW-P20080589 9 of 9

RF Exposure Info

Report No.: SABGSN-WTW-P20080589 Page No. 1 / 7 Report Format Version: 6.1.1 RF Exposure Report Report No.: SABGSN-WTW-P20080589 FCC ID: NKS-PA1 Test Model: Trimble Gateway-PA1 Received Date: Aug. 29, 2020 Date of Evaluation: Oct. 28, 2020 Issued Date: Nov. 03, 2020 Applicant: PeopleNet Communications Corporation Address: 4400 Baker Road, Minnetonka Minnesota 55343-8684 United States Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SABGSN-WTW-P20080589 Page No. 2 / 7 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 General Information .............................................................................................................................. 5 3 RF Exposure .......................................................................................................................................... 6 3.1 Limits for Maximum Permissible Exposure (MPE) ................................................................................... 6 3.2 MPE Calculation Formula ........................................................................................................................ 6 3.3 Classification ............................................................................................................................................ 6 3.4 Calculation Result of Maximum Conducted Power .................................................................................. 7 Report No.: SABGSN-WTW-P20080589 Page No. 3 / 7 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SABGSN-WTW-P20080589 Original Release Nov. 03, 2020 Report No.: SABGSN-WTW-P20080589 Page No. 4 / 7 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Trimble Gateway NA Brand: Trimble Test Model: Trimble Gateway-PA1 Sample Status: Engineering Sample Applicant: PeopleNet Communications Corporation Date of Evaluation: Oct. 28, 2020 Standards: FCC Part 2 (Section 2.1091) References Test Guidance : KDB 447498 D01 General RF Exposure Guidance v06 IEEE C95.3 -2002 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Prepared by : , Date: Nov. 03, 2020 Vera Huang / Specialist Approved by : , Date: Nov. 03, 2020 Dylan Chiou / Senior Project Engineer Report No.: SABGSN-WTW-P20080589 Page No. 5 / 7 Report Format Version: 6.1.1 2 General Information 1. The information of module collocated in this EUT is listed as below. Product Brand Name Model Name BT/WLAN Module msi BM25 WWAN Module Quectel EC25-A AH Module silex SX-NEWAH 2. The antenna information is listed as below. WWAN Antenna Ant. Brand Model Antenna Type Antenna Gain (dBi) Remark WDMA II/LTE 2 WCDMA IV/LTE 4 WCDMA V LTE 12 1 TAOGLAS PCS.06.A SMD Antenna 3.58 3.82 0.53 -0.03 Internal, Main Antenna 2 TAOGLAS PCS.06.B SMD Antenna 3.81 4.04 0.75 0.06 Internal, Aux. Antenna 3 TAOGLAS MA240.LBI.001 Adhesive Mount Combination Antenna 2.51 1.93 0.94 1.6 External, Main Antenna 4 TAOGLAS MA240.LBI.001 Adhesive Mount Combination Antenna 1.77 1.2 1 1.2 External, Aux. Antenna *the maximum antenna gain is chosen for final test. WLAN Antenna Brand Model Antenna Type Antenna Gain (dBi) BT/WLAN 2.4 GHz WLAN 5.15~5.35 GHz WLAN 5.47~5.725 GHz WLAN 5.725~5.85 GHz TAOGLAS FXP826.07.0120C FPC Antenna 0.75 1.22 3.58 3.52 3. The above Antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Report No.: SABGSN-WTW-P20080589 Page No. 6 / 7 Report Format Version: 6.1.1 3 RF Exposure 3.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 61…

Text truncated - open the document above for the full version.

Test Report

Report No.: RFBGSN-WTW-P20080589-8 Page No. 1 / 35 Report Format Version: 6.1.1 FCC Test Report (Co-Located) Report No.: RFBGSN-WTW-P20080589-8 FCC ID: NKS-PA1 Test Model: Trimble Gateway-PA1 Received Date: Aug. 29, 2020 Test Date: Oct. 22, 2020 Issued Date: Nov. 03, 2020 Applicant: PeopleNet Communications Corporation Address: 4400 Baker Road, Minnetonka Minnesota 55343-8684 United States Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: RFBGSN-WTW-P20080589-8 Page No. 2 / 35 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ........................................................................................................................... 4 2 Summary of Test Results ........................................................................................................................... 5 2.1 Measurement Uncertainty ...................................................................................................................... 5 2.2 Modification Record ................................................................................................................................ 5 3 General Information ................................................................................................................................... 6 3.1 General Description of EUT .................................................................................................................. 6 3.2 Description of Test Modes ..................................................................................................................... 9 3.2.1 Test Mode Applicability and Tested Channel Detail .................................................................. 12 3.3 Description of Support Units ............................................................................................................... 13 Configuration of System under Test .................................................................................................... 13 3.4 General Description of Applied Standards .......................................................................................... 14 4 Test Types and Results ............................................................................................................................ 15 4.1 Radiated Emission Measurement ....................................................................................................... 15 4.1.1 Limits of Radiated Emission Measurement .............................................................................. 15 4.1.2 Test Instruments ....................................................................................................................... 17 4.1.3 Test Procedures ........................................................................................................................ 18 4.1.4 Deviation from Test Standard ................................................................................................... 19 4.1.5 Test Set Up ............................................................................................................................... 20 4.1.6 EUT Operating Conditions ........................................................................................................ 21 4.1.7 Test Results .............................................................................................................................. 22 5 Pictures of Test Arrangements................................................................................................................ 34 Appendix – Information of the Testing Laboratories ................................................................................. 35 Report No.: RFBGSN-WTW-P20080589-8 Page No. 3 / 35 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued RFBGSN-WTW-P20080589-8 Original Release Nov. 03, 2020 Report No.: RFBGSN-WTW-P20080589-8 Page No. 4 / 35 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Trimble Gateway NA Brand: Trimble Test Model: Trimble Gateway-PA1 Sample Status: Engineering Sample Applicant: PeopleNet Communications Corporation Test Date: Oct. 22, 2020 Standards: 47 CFR FCC Part 15, Subpart C (Section 15.247) 47 CFR FCC Part 15…

Text truncated - open the document above for the full version.

Test Report

Report No.: RFBGSN-WTW-P20080589-4 Page No. 1 / 49 Report Format Version: 6.1.1 FCC Test Report Report No.: RFBGSN-WTW-P20080589-4 FCC ID: NKS-PA1 Test Model: Trimble Gateway-PA1 Received Date: Aug. 29, 2020 Test Date: Sep. 10, 2020 ~ Oct. 23, 2020 Issued Date: Nov. 03, 2020 Applicant: PeopleNet Communications Corporation Address: 4400 Baker Road, Minnetonka Minnesota 55343-8684 United States Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: RFBGSN-WTW-P20080589-4 Page No. 2 / 49 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ........................................................................................................................... 5 2 Summary of Test Results ........................................................................................................................... 6 2.1 Measurement Uncertainty ..................................................................................................................... 6 2.2 Modification Record .............................................................................................................................. 6 3 General Information ................................................................................................................................... 7 3.1 General Description of EUT .................................................................................................................. 7 3.2 Description of Test Modes ..................................................................................................................... 8 3.2.1 Test Mode Applicability and Tested Channel Detail .................................................................... 9 3.3 Duty Cycle of Test Signal .................................................................................................................... 10 3.4 Description of Support Units ................................................................................................................ 11 3.4.1 Configuration of System under Test .......................................................................................... 11 3.5 General Description of Applied Standards and References ............................................................... 12 4 Test Types and Results ............................................................................................................................ 13 4.1 Radiated Emission and Bandedge Measurement .............................................................................. 13 4.1.1 Limits of Radiated Emission and Bandedge Measurement ..................................................... 13 4.1.2 Test Instruments ....................................................................................................................... 14 4.1.3 Test Procedures ........................................................................................................................ 15 4.1.4 Deviation from Test Standard ................................................................................................... 15 4.1.5 Test Set Up ............................................................................................................................... 16 4.1.6 EUT Operating Conditions ........................................................................................................ 17 4.1.7 Test Results .............................................................................................................................. 18 4.2 Conducted Emission Measurement .................................................................................................... 26 4.2.1 Limits of Conducted Emission Measurement ........................................................................... 26 4.2.2 Test Instruments ....................................................................................................................... 26 4.2.3 Test Procedures ........................................................................................................................ 27 4.2.4 Deviation from Test Standard ................................................................................................... 27 4.2.5 Test Setup ................…

Text truncated - open the document above for the full version.

Test Setup Photos

Reference No.: BGSN-WTW-P20080589 1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Reference No.: BGSN-WTW-P20080589 2 RADIATED EMISSION TEST BELOW 1GHz Mode A (X-Plane) Reference No.: BGSN-WTW-P20080589 3 (Y-Plane) Reference No.: BGSN-WTW-P20080589 4 (Z-Plane) Reference No.: BGSN-WTW-P20080589 5 RADIATED EMISSION TEST BELOW 1GHz Mode B (X-Plane) Reference No.: BGSN-WTW-P20080589 6 (Y-Plane) Reference No.: BGSN-WTW-P20080589 7 (Z-Plane) Reference No.: BGSN-WTW-P20080589 8 RADIATED EMISSION TEST ABOVE 1GHz Mode A (X-Plane) Reference No.: BGSN-WTW-P20080589 9 (Y-Plane) Reference No.: BGSN-WTW-P20080589 10 (Z-Plane) Reference No.: BGSN-WTW-P20080589 11 RADIATED EMISSION TEST ABOVE 1GHz Mode B (X-Plane) Reference No.: BGSN-WTW-P20080589 12 (Y-Plane) Reference No.: BGSN-WTW-P20080589 13 (Z-Plane) Reference No.: BGSN-WTW-P20080589 14 DFS

Contact Information

Applicant

Alan Johnson(Director, Hardware Engineering)
[email protected]612-816-2128Fax: 612-816-2128

Test Firm

Bureau Veritas CPS(H.K.) Ltd., Taoyuan BranchLiu Ken
[email protected]+886-3-2600609Fax: +886-3-2115834

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz4.00 mW
Confidentiality
Long Term
Grant Notes
Power listed is maximum conducted output power. The product must be installed such that its antenna(s) can provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other transmitter, except in accordance with FCC multi-transmitter product procedures or as described in this filing. End-users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance.
