NNHDTR1Access Control System

SWITCHPLATE INSTALLATION DIAGRAM Mounting Plate Reader Housing Mounting Surface ¿ ¿ Use appropriate Fastener ¿ Use supplied screw ¿ 3/4” diameter through hole for cables. ¿ ¿ ¿ 3.28 3322252 7472 1. If mounting the unit outdoors, especially on a rough surface like masonry, we recommend that you seal the reader with silicone caulking. 2. Drill holes as needed per installation diagram shown to the left or install a single gang j-box. 3. Run field wiring to reader location and feed into j-box or through cable hole. 4. Attach the mounting plate to the mounting surface or j-box with the appropriate fasteners. 5. Splice the connector pigtail to field wiring. Insert the connector into the back of the reader. 6. Attach the housing to the mounting plate by inserting the two tabs inside the top of the housing into the two slots at the top of the mounting plate. 7. Secure by installing supplied screw into the hole at the bottom of the reader. INSTALLATION STEPS FOR RKDT-SA-S/PPLX: ¿ 3.20 4.50 ¿ ¿ ¿ RKDT-PPLX Family Installation Instructions 1. If mounting the unit outdoors, especially on a rough surface like masonry, we recommend that you seal the reader with silicone caulking. 2. Drill a hole for the field wiring. Remove decorative cover from reader. Using the reader as a template, mark the location of the two mounting holes. Drill two 1/8” pilot holes for the mounting screws. 3. Run field wiring to reader location and feed through cable hole. 4. Splice the connector pigtail to field wiring. Insert the connector into the back of the reader. 5. Attach the reader to the surface using the two machine screws provided. These may be replaced with tamper proof screws (customer supplied). 6. Slip on the decorative cover (if used) until both tabs snap into place. MULLION INSTALLATION DIAGRAM 4.38” 1.74” 3.14” .90” 4.38” 1.74” 3.14” .90” Use supplied screws 1/2” Diameter hole in mounting surface for wiring l Mounting Surface l INSTALLATION STEPS FOR RKDT-SA-M 20301 Nordhoff Street, Chatsworth, CA 91311 PHONE (818) 882-0020 • FAX (818) 882-7052 TOLL-FREE (800) 891-0020 Website: www.securakey.com • E-mail: [email protected] 1. Drill holes as needed per installation diagram shown to the left. 2. Feed cable through 3/4” hole. 3. Attach reader to any flat surface with two #6 screws. 4. Snap label insert into front of reader to cover screws. 3.50 1.60 Label Tabs Insert Here LED ¿ ¿ ¿ ¿ ¿ ¿ MULLION INSTALLATION DIAGRAM 1.0” l l l l 1.3” Use appropriate #6 Fastener 3/4” Diameter through hole for cable and buzzer. l l INSTALLATION STEPS FOR RKDT-WM RKDT/PPLX WIRING CONNECTIONS WIRE COLORREMOTE OPEN STANDALONE LED CONTROL WIEGAND GREENDATA-0 DATA-0 WHITEDATA-1DATA-1 VIOLETRXDN/A GRAYTXDN/A ORANGEGREEN LED INPUT (3, 1)GREEN LED INPUT (3, 1) BROWNREX LATCH + TIMER (2, 1)RED LED INPUT (3, 1) YELLOWBEEPER INPUT (1)BEEPER INPUT (1) BLUEHOLD (1)HOLD (1) RED5-14 VDC +5-14 VDC + BLACKGROUND --- GROUND --- WHITE/BLACKRELAY +NA WHITE/BROWNRELAY -NA (1) Connect to GROUND to activate (2) Input Programmed for Remote Open (3) Input Programmed for LED/Beeper Control SPECIFICATIONS: POWER REQUIREMENTS 5-14 VDC, 150 mA Max. OUTPUTS SPST Solid State Relay, 1A max. @60 VAC or DC Normally open or normally closed (field programmable) (See Operating Guide). INPUTS Default is Remote Open (requires contact closure). Also programmable as Red LED Control for online systems (see Operating Guide). Additional inputs for Green LED, Beeper and HOLD are available in Wiegand mode. WIEGAND OUTPUT Any Wiegand Format up to 40 bits Maximum Distance: 500 ft. - 5 or 8 conductor 20 gauge cable ENVIRONMENT Access Control Unit, Key Tags and Cards Ambient Temperature -40° to +70°C (-40° to +158°F) Humidity 0 to 95% (non-condensing) PARTS SUPPLIED: Access Control Unit MOV Operating Guide Installation Instructions Log Sheet RKDT-SA-S/RKDT-WM/PPLX RKDT-SA-M Mounting Plate 2, #6 Mounting Screws 2, #6 Mounting Screws Cable Assembly 1, 4x40 Screw Decorative Cover 1, Security Screw 1, Cable Assembly 1, Snap-In Labels (RKDT-WM Only) ACCESSORIES (NOT INCLUDED): RK-HHP Hand-Held Programmer RK-PS: 9VDC Plug-in Power Supply. It is designed to power the RKDT-SA-M/SA-S. Requires 110 Volts AC power. SK-SR SecuRelay™ - Smart Relay Module DPDT. 3322252 7472 20301 Nordhoff Street, Chatsworth, CA 91311 PHONE (818) 882-0020 • FAX (818) 882-7052 TOLL-FREE (800) 891-0020 Website: www.securakey.com • E-mail: [email protected] INSTRUCTION TO THE USER FCC ID: NNHDTR1 This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more or the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet of a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. In order to maintain compliance with FCC regulations, unshielded cables must be used with this equipment. Operation with non-approved equipment or shielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user’s authority to operate this equipment. “This device complies with Part 15 of the FCC rules. Operation is subject to …

Text truncated - open the document above for the full version.

Smart. Reliable. Secure. 20301 Nordhoff Street, Chatsworth, CA 91311-6112 Phone: 818-882-0020 Fax: 818-882-7052 E-mail: [email protected] Website: www.securakey.com Sep. 07, 2010 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Secura Key 20301 Nordhoff Street Chatsworth, CA 91311-6112, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Secura Key product: Access Control System Under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither Secura Key nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, Secura Key will notify the Federal Communications Commission if, at any time, the situation changes causing Secura Key to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 818-882-0020. Sincerely, Frank Tajbakhsh Senior Electronic Design Engineer

Smart. Reliable. Secure. 20301 Nordhoff Street, Chatsworth, CA 91311-6112 Phone: 818-882-0020 Fax: 818-882-7052 E-mail: [email protected] Website: www.securakey.com Sep. 07, 2010 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Secura Key, would like to declare that the application being submitted for the device with FCC ID: NNHDTR1 has not been, submitted to another TCB or FCC for certification. If you have any questions, please do not hesitate to contact us at 818-882-0020. Sincerely, Frank Tajbakhsh Senior Electronic Design Engineer

Smart. Reliable. Secure. 20301 Nordhoff Street, Chatsworth, CA 91311-6112 Phone: 818-882-0020 Fax: 818-882-7052 E-mail: [email protected] Website: www.securakey.com Sep. 07, 2010 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, Secura Key, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457 (d) of the Commission’s Rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any questions, please do not hesitate to contact us at 818-882-0020. Sincerely, Frank Tajbakhsh Senior Electronic Design Engineer

Correspondence by Project Project Number: Correspondence NumberMemo NNHDTR1-1 1) The TCB certification contract is not entirely filled out, please provide a completed TCB certification contract. Answer: A revised TCB certification contract will be submitted. 2) The confidentiality letter needs to be addressed to CETCB. Please provide a corrected and signed confidentiality letter. Answer: A revised confidentiality letter will be submitted. 3) Please provide a letter that states that this device has not been submitted to another TCB or FCC for certification. Answer: A letter will be submitted regarding that the device has not been submitted to another TCB or FCC for certification. 4) The address of the applicant does not match the address on file with the FCC. Please update the address on file with the FCC or correct the application. Answer: The client made the necessary changes to address to match what is on file with the FCC. 5) Please provide a correct authorization letter. Answer: A revised authorization letter will be submitted. 6) Please provide an Anti-Drug Abuse attestation letter. Answer: The Anti-Drug attestation statement is on the authorization letter. 7) The block diagram submitted is not sufficient. As per section 2.1033(b)(5) of the FCC rules, the block diagram must show "the frequency of all oscillators used in the device. The signal path and frequency shall be indicated at each block. The tuning range(s) and intermediate frequency(ies) shall be indicated at each block." Answer: A revised block diagram will be submitted. 8) Please provide corrected schematics. The schematics provided don't match the internal photos and they do not have any component values. Answer: Revised schematics will be submitted. 9) The operational description does not describe the device that was tested. Please provide another operational description. Answer: A revised operational description will be submitted. 10) Please provide clarification regarding the test distance. The test setup photos show ten meters, but the data shows a three meter test distance. Answer: A revised test report will be submitted to show the data and photos were at a 3 meters distance. 11) For the test report, please provide the information for the cable that was connected to the EUT during testing. A revised test report will be submitted to show the cable information. 12) The Instruction to the User Statement is incorrect. Please provide a user manual with the corrected statement. Answer: A revised instruction to the user statement will be submitted. *Additional notes mentioned over the phone: 1) Above 1 MHz data was verified. 2) Pre amp chart serial number now matches with equipment list. 3) Loop antenna information is in the test report. 4) Additional models with metal enclosures were removed from the additional models list. 5) I was told by the client the device is DC power only. No conducted emissions. 6) Revised internal pictures will be submitted. Correspondence NumberMemo NNHDTR1-1 1) Revised schematics (Rev2) 2) Revised internal photos (Rev2) Correspondence NumberMemo NNDTR1-1 1) Updated FCC label for models: RKDT-PPLX-COMBO (RKDT-SR), PPLX, RKDT-SA-S & AM-DPR (RKDT-W) 2) Updated label location pictures

SECURA KEY EXTERNAL FRONT VIEW FCC ID: NNHDTR1 AM-DPR (RKDT-WM) SECURA KEY EXTERNAL REAR VIEW FCC ID: NNHDTR1 AM-DPR (RKDT-WM)

SECURA KEY EXTERNAL FRONT VIEW FCC ID: NNHDTR1 SECURA KEY EXTERNAL REAR VIEW FCC ID: NNHDTR1

SECURA KEY EXTERNAL FRONT VIEW FCC ID: NNHDTR1 PPLX SECURA KEY EXTERNAL REAR VIEW FCC ID: NNHDTR1 PPLX

SECURA KEY EXTERNAL FRONT VIEW FCC ID: NNHDTR1 RKDT-SA-S SECURA KEY EXTERNAL REAR VIEW FCC ID: NNHDTR1 RKDT-SA-S

3059349 7554 3322288 FCC ID: NNHDTR1 5-14VDC@150mA Max Freq. 125 kHz 5718-DTR1 IP64

3059349 7479 RKDT-WS ETL LABEL - CHINA 9/8/10 Model: Radio Key ® RKDT-WS Freq. 125kHz, 5-14VDC@70mA Max. FCC ID: NNHDTR1 3322266 7479

RKDT-PPLX-COMBO, PPLX & RKDT-SA-S LABEL LOCATION RKDT-W LABEL LOCATION AM-DPR LABEL LOCATION

SECURA KEY INTERNAL FRONT VIEW TOP FCC ID: NNHDTR1 AM-DPR (RKDT-WM) SECURA KEY INTERNAL FRONT VIEW BOTTOM FCC ID: NNHDTR1 AM-DPR (RKDT-WM) SECURA KEY INTERNAL REAR VIEW TOP FCC ID: NNHDTR1 AM-DPR (RKDT-WM) SECURA KEY INTERNAL REAR VIEW BOTTOM FCC ID: NNHDTR1 AM-DPR (RKDT-WM)

SECURA KEY INTERNAL FRONT VIEW TOP FCC ID: NNHDTR1 PPLX SECURA KEY INTERNAL FRONT VIEW BOTTOM FCC ID: NNHDTR1 PPLX SECURA KEY INTERNAL REAR VIEW TOP FCC ID: NNHDTR1 PPLX SECURA KEY INTERNAL REAR VIEW BOTTOM FCC ID: NNHDTR1 PPLX

SECURA KEY INTERNAL FRONT VIEW TOP FCC ID: NNHDTR1 SECURA KEY INTERNAL FRONT VIEW BOTTOM FCC ID: NNHDTR1 SECURA KEY INTERNAL REAR VIEW TOP FCC ID: NNHDTR1 SECURA KEY INTERNAL REAR VIEW BOTTOM FCC ID: NNHDTR1

SECURA KEY INTERNAL FRONT VIEW TOP FCC ID: NNHDTR1 RKDT-SA-S SECURA KEY INTERNAL FRONT VIEW BOTTOM FCC ID: NNHDTR1 RKDT-SA-S SECURA KEY INTERNAL REAR VIEW TOP FCC ID: NNHDTR1 RKDT-SA-S SECURA KEY INTERNAL REAR VIEW BOTTOM FCC ID: NNHDTR1 RKDT-SA-S

FCC ID: NNHDTR1 Report Number: A00825F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301  PH: (818) 597-0600 FX: (818) 597-1187 Page 1 of 20 FCC PART 15, SUBPART C & RSS-210 ISSUE 7 DATED JUNE 2007 TEST REPORT for ACCESS CONTROL SYSTEM M/N: RKDT-PPLX-COMBO (RKDT-SR) FCC ID: NNHDTR1 Prepared for SECURA KEY 20301 NORDOFF ST. CHATSWORTH, CA 91311 Prepared by: _____________________ REYNALD O. RAMIREZ Approved by: ____________________ RUBY A. HALL COMPATIBLE ELECTRONICS INC. 2337 TROUTDALE DRIVE AGOURA, CALIFORNIA 91301 (818) 597-0600 DATE: MARCH 21, 2011 REPORT APPENDICES TOTAL BODY A B C D E PAGES 20 2 2 2 26 25 77 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. FCC ID: NNHDTR1 Report Number: A00825F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301  PH: (818) 597-0600 FX: (818) 597-1187 Page 2 of 20 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. Description of Test Configuration 8 4.1 Description of Test Configuration - EMI 8 4.1.1 Photograph of Test Configuration - EMI 8 4.1.2 Photograph of Test Configuration – EMI (continued) 9 4.1.3 Photograph of Test Configuration – EMI (continued) 10 4.1.4 Photograph of Test Configuration – EMI (continued) 11 4.1.5 Cable Construction and Termination 12 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 13 5.1 EUT and Accessory List 13 5.2 EMI Test Equipment 14 6. TEST SITE DESCRIPTION 15 6.1 Test Facility Description 15 6.2 EUT Mounting, Bonding and Grounding 15 7. Test Procedures 16 7.1 RF Emissions 16 7.1.1 Conducted Emissions Test 16 7.1.2 Radiated Emissions Test 17 7.1.3 RF Emissions Test Results 18 7.1.4 Sample Calculations 19 8. TEST PROCEDURE DEVIATIONS 20 9. CONCLUSIONS 20 FCC ID: NNHDTR1 Report Number: A00825F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301  PH: (818) 597-0600 FX: (818) 597-1187 Page 3 of 20 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts and Photos  Test Setup Diagrams  Antenna and Amplifier Gain Factors  Radiated and Conducted Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Test Setup 2 Plot Map And Layout of Test Site FCC ID: NNHDTR1 Report Number: A00825F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301  PH: (818) 597-0600 FX: (818) 597-1187 Page 4 of 20 GENERAL REPORT SUMMARY This electromagnetic emission report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced in any form except in full, without the written permission of Compatible Electronics. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Access Control System Model Number: RKDT-PPLX-COMBO (RKDT-SR) SN: None Product Description: This is a low frequency card reader. Modifications: The EUT was not modified during the testing. Manufacturer: Secura Key 20301 Nordoff St. Chatsworth, CA 91311 Test Dates: Aug. 25, 2010 & Mar. 4, 2011 Test Specifications: EMI requirements FCC CFR Title 47, Part 15 Subpart A, B and C sections 15.31 (e), 15.109, 15.205, 15.207 & 15.209 RSS-210 Issue 7 dated June 2007 Test Procedure: ANSI C63.4: 2009. Industry Canada Lab Code 2154B SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz. Complies with the limits of FCC CFR Title 47, Part 15 Subpart C 15.207. Highest Reading in relation to spec. limit: 50.50 dBuV/m @ 0.183 MHz (*u c = 0.42dB) 2 Radiated RF Emissions, 9 kHz – 1000 MHz. Complies with the limits of FCC CFR Title 47, Part 15 Subpart C 15.205, 15.209 and RSS-210 Issue 7 dated June 2007 Highest Reading in relation to spec. limit: 30.13 dBuV/m @ 32.00 MHz (*u c = 2.09dB) FCC ID: NNHDTR1 Report Number: A00825F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301  PH: (818) 597-0600 FX: (818) 597-1187 Page 5 of 20 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Access Control System Model Number: RKDT-PPLX-COMBO (RKDT-SR). The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 2009. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the specification limits defined in FCC CFR Title 47, Part 15 Subpart A (15.31e), Subpart B, 15.109 Subpart C 15.205, 15.207, 15.209 and RSS-210 Issue 7 dated June 2007. FCC ID: NNHDTR1 Report Number: A00825F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301  PH: (818) 597-0600 FX: (818) 597-1187 Page 6 of 20 2. ADMINISTRATIVE DATA 2.1 Location of Testing The EMI tests described herein were performed at the test facility of Compatible Electronics, 2337 Troutdale Drive, Agoura, California 91301. 2.2 Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST). 2.3 Cognizant Personnel Secura Key Frank Tajbakhsh Senior Electronic Design Engineer Compatible Electronics Inc. Reynald O. Ramirez Sr. Test Engineer Ruby A. Hall Lab Manager 2.4 Date Test Sample was Received The test sample was received on Aug. 25, 2010. 2.5 Disposition of the Test…
