NT8-J1ABNavigation Display module with BT connectivity

Visteon Corporation

Click to zoom

Application Details

Equipment Class: JAB - Part 15 Class B Digital Device
Date of Grant: Jul 12, 2021
Application Purpose: Original Equipment
Date of Application: Jul 11, 2021
Equipment Note: Navigation Display module with BT connectivity
Company: Visteon Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Visteon Electronics Germany GmbH Address: An der RaumFabrik 33b City: Karlsruhe Country: Germany To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: NT8-J1AB Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 06/29/2021 Name and signature of applicant: Imad Hjije Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

ID Label/Location Info

B B B B A A A A 1.7() 13.1()9.1() HW & SW VERSION DATE& TIME QR CODE (10X5) CUSTOMER PART NUMBER 15() 25() MODEL:J1AB MODEL:J1AB C

Test Report

Test Laboratory: 7layers GmbH Borsigstrasse 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7layers GmbH Geschäftsführer/ Borsigstraße 11 Managing Directors: Registergericht/registered: a Bureau Veritas 40880 Ratingen, Germany Frank Spiller Düsseldorf HRB 75554 Group Company T +49 (0) 2102 749 0 Bernhard Retka USt-Id.-Nr./VAT-No. DE203159652 F +49 (0) 2102 749 350 Alexandre Norré-Oudard Steuer-Nr./TAX-No. 147/5869/0385 www.7layers.com Commerzbank AG Account No. 303 016 000 Bank Code 300 400 00 IBAN DE81 3004 0000 0303 0160 00 Swift Code COBADEFF FCC Measurement/Technical Report on Navigation display module with BT connectivity J1AB FCC ID: NT8-J1AB IC: 3043A-J1AB Test Report Reference: MDE_VIS_2017_FCC_04 TEST REPORT REFERENCE: MDE_VIS_2017_FCC_04 Page 2 of 30 Table of Contents 1 Applied Standards and Test Summary 3 1.1 Applied Standards 3 1.2 FCC-IC Correlation Table 4 1.3 Measurement Summary 5 2 Revision History / Signatures 6 3 Administrative Data 7 3.1 Testing Laboratory 7 3.2 Project Data 7 3.3 Applicant Data 7 3.4 Manufacturer Data 7 4 Test object Data 8 4.1 General EUT Description 8 4.2 EUT Main components 8 4.3 Ancillary Equipment 9 4.4 Auxiliary Equipment 9 4.5 EUT Setups 9 4.6 Operating Modes / Test Channels 9 4.7 Product labelling 10 5 Test Results 11 5.1 Conducted Emissions at AC mains 11 5.2 Radiated Emissions 14 6 Test Equipment 19 7 Antenna Factors, Cable Loss and Sample Calculations 23 7.1 LISN R&S ESH3-Z5 (150 kHz – 30 MHz) 23 7.2 Antenna R&S HFH2-Z2 (9 kHz – 30 MHz) 24 7.3 Antenna R&S HL562 (30 MHz – 1 GHz) 25 7.4 Antenna R&S HF907 (1 GHz – 18 GHz) 26 7.5 Antenna EMCO 3160-09 (18 GHz – 26.5 GHz) 27 7.6 Antenna EMCO 3160-10 (26.5 GHz – 40 GHz) 28 8 Measurement Uncertainties 29 9 Photo Report 30 TEST REPORT REFERENCE: MDE_VIS_2017_FCC_04 Page 3 of 30 1 APPLIED STANDARDS AND TEST SUMMARY 1.1 APPLIED STANDARDS Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 2 and 15 (10-1-19 Edition). The following subparts are applicable to the results in this test report. Part 2, Subpart J - Equipment Authorization Procedures, Certification Part 15, Subpart B – Unintentional Radiators § 15.107 Conducted limits § 15.109 Radiated emission limits; general requirements Applicable ISED Standards ICES-Gen, Issue 1 ICES-003, Issue 6 Note: ANSI C63.4–2014 is applied. TEST REPORT REFERENCE: MDE_VIS_2017_FCC_04 Page 4 of 30 1.2 FCC-IC CORRELATION TABLE Correlation of measurement requirements for Information Technology Equipment (ITE) from FCC and IC Measurement FCC reference IC reference Conducted Emissions (AC Power Line) §15.107 ICES-003 Issue 6: 6.1 Radiated Spurious Emissions §15.109 ICES-003 Issue 6: 6.2 Remarks: 1. FCC Part 15 subpart B, ICES 003 and CISPR 22 contain different definitions of Class A and Class B limits, i.e. which class is applicable to which kind of EUT. ICES 003 and CISPR 22 distinguish between the location where the EUT is intended to operate whilst FCC refers to the method of commercial distribution (distributive trades). 2. The correct assignment of the appropriate class to the concrete EUT is not scope of this test report! 3. A radio apparatus that is specifically subject to an Industry Canada Radio Standard Specification (RSS) and which contains an ITE is not subject to ICES-003 provided the ITE is used only to enable operation of the radio apparatus and the ITE does not control additional functions or capabilities. 4. ISM (Industrial, Scientific or Medical) radio frequency generators, though they may contain ITE, are excluded from the definition of ITE and are not subject to ICES-003. They are instead subject to the Interference-Causing Equipment Standard ICES-001, which specifically addresses ISM radio frequency generators. TEST REPORT REFERENCE: MDE_VIS_2017_FCC_04 Page 5 of 30 1.3 MEASUREMENT SUMMARY 47 CFR CHAPTER I FCC PART 15 Subpart B § 15.107 / Class B Conducted Emissions at AC mains The measurement was performed according to ANSI C63.4 Final Result OP-Mode AC mains connection, Test setup Setup Date FCC IC via auxiliary equipment, stand-alone S01_AT01 2021-04-01 Passed Passed 47 CFR CHAPTER I FCC PART 15 Subpart B § 15.109 / Class B Radiated Emissions The measurement was performed according to ANSI C63.4 Final Result OP-Mode AC mains connection, Measurement range, Test setup Setup Date FCC IC via auxiliary equipment, 1 GHz - 18 GHz, stand-alone S01_AT01 2021-03-26 Passed Passed via auxiliary equipment, 30 MHz - 1 GHz, stand-alone S01_AT01 2021-03-24 Passed Passed N/A: Not applicable N/P: Not performed TEST REPORT REFERENCE: MDE_VIS_2017_FCC_04 Page 7 of 30 3 ADMINISTRATIVE DATA 3.1 TESTING LABORATORY Company Name: 7layers GmbH Address: Borsigstr. 11 40880 Ratingen Germany The test facility is accredited by the following accreditation organisation: Laboratory accreditation no: DAkkS D-PL-12140-01-01| -02 | -03 FCC Designation Number: DE0015 FCC Test Firm Registration: 929146 ISED CAB Identifier DE0007; ISED#: 3699A Responsible for accreditation scope: Dipl.-Ing. Bernhard Retka Report Template Version: 2021-01-13 3.2 PROJECT DATA Responsible for testing and report: M.Sc. Joel Asongwe Employees who performed the tests: documented internally at 7Layers Date of Report: 2021-06-02 Testing Period: 2021-03-24 to 2021-04-01 3.3 APPLICANT DATA Company Name: Visteon Corporation Address: One Village Center Drive Van Buren Township, MI, 48111, U.S.A Contact Person: Heidi Sepanic, Corporative Secretary 3.4 MANUFACTURER DATA Company Name: please see Applicant Data Address: Contact Person: TEST REPORT REFERENCE: MDE_VIS_2017_FCC_04 Page 8 of 30 4 TEST OBJECT DATA 4.1 GENERAL EUT DESCRIPTION Kind of Device product description A 1.49" TFT with TBT (Turn By Turn navigation) and FOTA feature for 2 wheeler products. The module is customized to …

Text truncated - open the document above for the full version.

Test Setup Photos
