NTHES1215NSELF-BALLASTED LAMP

KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 1 of 1 External photo

Korea Technology Institute Co., Ltd. Page 1 of 1 FCC ID Sample Label LABELLING REQUIREMENTS PER ∫∫ ∫∫2.928 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. Model Number: ES1215N FCC ID : NTH ES1215N Jung Woo International Inc. Made in Korea Korea Technology Institute Co., Ltd. Page 1 of 1 Label location FCC ID LABEL LOCATION

KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 1 of 2 Internal photo KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 2 of 2 Internal photo

KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 1 of 13 Test Report Test Report No.: KTI02EF05006 Registration No.: 99058 Applicant: Jung Woo International Inc. Applicant Address: 495-4, Chowonjee-Ri, Daegoc-Myun, Kimpo-City, Kyunggi-Do, Korea Product: SELF-BALLASTED LAMP FCC ID: NTHES1215N Model No. ES1215N Receipt No.: 02-0273 Date of receipt: March 23, 2002 Date of Issue: May 28, 2002 Testing location Korea Technology Institute Co., Ltd. 51-19, Sanglim3-Ri, Docheok-Myeun, Gwangju-Shi, Gyeungki-Do, Korea Test Standards: FCC/OET MP-5 Rule Parts: FCC Part 18, Equipment Class: RF lighting devices (Consumer Equipment) Test Result: The above mentioned product has been tested and passed. Tested by: M. H. Jang/ Engineer Approved by: G. C. Min/ President Signature Date Signature Date Other Aspects : Abbreviations : • OK, Pass=passed • Fail=failed • N/A=not applicable  ▪ This test report is not permitted to copy partly without our permission. ▪ This test result is dependent on only equipment to be used. ▪ This test result is based on a single evaluation of one sample of the above mentioned. ▪ This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. ▪ We certify this test report has been based on the measurement standards that is traceable to the national or international standards. KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 2 of 13  Contents  1. 2. 3. 4. 5. 6. Annex1 Annex2 Contents List of Tables List of Figures List of Photographs General Test Site 2.1 Location 2.2 List of Test and Measurement Instruments 2.3 Test Data 2.4 Test Environment Description of the tested samples 3.1 Rating and Physical characteristics 3.2 Submitted documents Measurement conditions 4.1 Modes of operation 4.2 Additional equipments 4.3 Uncertainty 4.4 Test Setup Emission Test 5.1 Conducted Emissions 5.2 Radiated Emissions Photographs of the Test Set-up Label Photographs of EUT 2 2 2 3 3 3 4 4 4 5 5 5 6 6 6 6 6 7 8 11 12 14 15 16~19  List of Tables Table 1 List of test and measurement equipment Table 2 Test Data. Conducted Emissions Table 3 Test Data. Radiated Emissions  List of Figures Figure 1 Spectral Diagram, LINE-PE Figure 2 Spectral Diagram, Neutral-PE  List of Photographs Photograph 1 Setup for Conducted Emissions Photograph 2 Setup for Radiated Emissions 4 11 13 9 10 16 17 KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 3 of 13 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by Korea Technology Institute Co., LTD. And were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site Korea Technology Institute Co., LTD 2.1 Location 51-19, Sanglim3-Ri, Docheok-Myeun, Gwangju-Shi, Gyeungki-Do, Korea The Test Site is in compliance with ANSI C63.4/1992 for measurement of radio Interference. KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 4 of 13 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment • Conducted Emissions Kind of Equipment Type S/N Calibrated until Spectrum Analyzer R3261C 61720417 11.2002 Field Strength Meter ESPC 832827/011 9.2002 LISN KNW407 8-1157-2 10.2002 LISN ESH2-Z5 8254601019 6.2002 Conducted Cable N/A N/A 11.2002 • Radiated Emissions Kind of Equipment Type S/N Calibrated until Field Strength Meter ESPC 832827/011 9.2002 Spectrum Analyzer R3261C 61720417 11.2002 Pre Amplifier HP 8447D 2944A06874 11.2002 BiconiLog Antenna EMCO 3142B 1705 12.2002 Bilog Antenna SchaffnerCBL6140A 1217 5.2002 Open Site Cable N/A N/A 11.2002 Antenna Mast DETT-03 N/A N/A Antenna & Turntable controller DETT-04 91X519 N/A 2.3 Test Date Date of Application : March 23, 2002 Date of Test : May 23, 2002 2.4 Test Environment See each test item’s description. KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 5 of 13 3. Description of the tested samples The EUT is SELF-BALLASTED LAMP 3.1 Rating and Physical Characteristics •Consumption Power: 15W •Input Voltage: AC 120V •Frequency of input line: 60Hz •Life: 10,000Hrs 3.2 Submitted Documents • User’s Guide • Block Diagram KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 6 of 13 4. Measurement Conditions Testing Input Voltage: AC 120V. 4.1 Modes of Operation The EUT was in the following operation mode during all testing; After warming up time of 30 minutes, Testing in mode of Lamp on. 4.2 Additional Equipment DEVICE TYPE Manufacturer M/N S/N FCC ID 4.3 Uncertainty 1) Radiated disturbance Uc (Combined standard Uncertainty) = ± 1.8dB Expanded uncertainty U=KUc K = 2  U = ± 3.6dB 2) Conducted disturbance Uc = ± 0.88dB U = KUc=2xUc = ± 1.8dB KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 7 of 13 4.4 Test setup EUT KTI02EF05006 FCC ID: NTHES1215N Korea Technology Institute Co., Ltd. Page 8 of 13 5. EMISSION Test 5.1 Conducted Emissions Result : Pass The line-conducted facility is located inside a 2.3M x 3.5M x 5.5M shielded closure. The shielding effectiveness of the shielded room is in accordance with MIL-Std-285 or NSA 605-05. A 1m x 1.5m wooden table 40cm high is placed 40cm away from the conducting ground plane and 40cm away from the sidewall of the shielded room. Kyoritsu Model KNW-407 (10kHz-30MHz) 50ohm/50 uH Line-Impedance Stabilization Networks (LISN) are bonded to the shielded room. The EUT is powered from the R&S LISN and the support equipment is powered from the Kyoritsu LISN. Power to the LISN are filtered by a high-current high-insertion loss shield enclosures power line filters (100dB 14kHz-1GHz). The purpose of the fi…
