6. Measurement Data (continued) 6.7. Public Exposure to Radio Frequency Energy Levels 27.52 per 1.1307 (b)(1) Power Density Channel MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2) (W/m2) Limit (mW/cm2) Result (1) (2) (3) (4) (5) Low 20.0 20.51 3.0000 0.0446406 0.4464061 1 Compliant Mid 20.0 18.71 3.0000 0.0294938 0.2949376 1 Compliant High 20.0 18.51 3.0000 0.0281663 0.2816632 1 Compliant All 20.0 21.42 3.0000 0.0550466 0.5504656 1 Compliant Low 20.0 21.61 3.0000 0.0575082 0.5750825 1 Compliant Mid 20.0 21.97 3.0000 0.0624784 0.6247844 1 Compliant High 20.0 21.87 3.0000 0.0610563 0.6105625 1 Compliant All 20.0 22.02 3.0000 0.0632019 0.6320190 1 Compliant Low 20.0 20.5 3.0000 0.0445379 0.4453794 1 Compliant Mid 20.0 20.48 3.0000 0.0443333 0.4433331 1 Compliant High 20.0 19.51 3.0000 0.0354593 0.3545930 1 Compliant All 20.0 20.99 3.0000 0.0498575 0.4985746 1 Compliant Low 20.0 16.09 3.0000 0.0161336 0.1613356 1 Compliant Mid 20.0 22.24 3.0000 0.0664860 0.6648599 1 Compliant High 20.0 20.52 3.0000 0.0447435 0.4474352 1 Compliant All 20.0 20.82 3.0000 0.0479435 0.4794355 1 Compliant 1. Reference CFR 2.1093(b): For purposes of this section, a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Actual separation distance was calculated for outdoor applications. 2. Section 6.1.2 of this test report. Note that the value has been adjusted to include the cable insertion loss. 3. Data supplied by the client. 3 dBi for Indoor, 14 dBi for Outdoor Applications 4. Power density is calculated from field strength measurement and antenna gain. 5. Reference CFR 1.1310, Table 1: Limits for Maximum Permissible Exposure (MPE), Section (B): Limits for General Population/Uncontrolled Exposure. PD = OP + AG (4 x π x d²) 6. Measurement Data (continued) 6.7. Public Exposure to Radio Frequency Energy Levels 27.52 per 1.1307 (b)(1) Power Density Channel MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2) (W/m2) Limit (mW/cm2) Result (1) (2) (3) (4) (5) Low 20.0 20.51 14.0000 0.5619920 5.6199201 1 Compliant Mid 20.0 18.71 14.0000 0.3713044 3.7130444 1 Compliant High 20.0 18.51 14.0000 0.3545930 3.5459299 1 Compliant All 20.0 21.42 14.0000 0.6929951 6.9299507 1 Compliant Low 20.0 21.61 14.0000 0.7239860 7.2398596 1 Compliant Mid 20.0 21.97 14.0000 0.7865569 7.8655690 1 Compliant High 20.0 21.87 14.0000 0.7686527 7.6865268 1 Compliant All 20.0 22.02 14.0000 0.7956648 7.9566480 1 Compliant Low 20.0 20.5 14.0000 0.5606995 5.6069947 1 Compliant Mid 20.0 20.48 14.0000 0.5581233 5.5812329 1 Compliant High 20.0 19.51 14.0000 0.4464061 4.4640612 1 Compliant All 20.0 20.99 14.0000 0.6276682 6.2766823 1 Compliant Low 20.0 16.09 14.0000 0.2031095 2.0310946 1 Compliant Mid 20.0 22.24 14.0000 0.8370090 8.3700903 1 Compliant High 20.0 20.52 14.0000 0.5632875 5.6328754 1 Compliant All 20.0 20.82 14.0000 0.6035735 6.0357347 1 Compliant Note: For outdoor installations, users must be instructed to be at least 23 cm away from the high gain antenna when the device is in operation. 1. Reference CFR 2.1093(b): For purposes of this section, a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Actual separation distance was calculated for outdoor applications. 2. Section 6.1.2 of this test report. Note that the value has been adjusted to include the cable insertion loss. 3. Data supplied by the client. 3 dBi for Indoor, 14 dBi for Outdoor Applications 4. Power density is calculated from field strength measurement and antenna gain. 5. Reference CFR 1.1310, Table 1: Limits for Maximum Permissible Exposure (MPE), Section (B): Limits for General Population/Uncontrolled Exposure. PD = OP + AG (4 x π x d²)

Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.complianceworldwide.com COMPLIANCE WORLDWIDE INC. TEST REPORT 349-12 In Accordance with the Requirements of FCC PART 27:2011 Subparts C & L Issued to Cellular Specialties, Inc. 670 North Commercial Street Manchester, NH 03010 (603) 626-6677 for Co-Pilot Beacon AWS Model: CSI-CPBH-MG-AW4 FCC ID: NVRCSICPBHMG-AW4 Report Issued on November 28, 2012 Tested by This test report shall not be reproduced, except in full, without written permission from Compliance Worldwide, Inc. Test Number: 349-12 Issue Date: 11/28/2012 Page 2 of 55 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com Table of Contents 1. Scope ......................................................................................................................................... 3 2. Product Details ........................................................................................................................... 3 2.1. Manufacturer ........................................................................................................................ 3 2.2. Model Number...................................................................................................................... 3 2.3. Serial Number ...................................................................................................................... 3 2.4. Description ........................................................................................................................... 3 2.5. Power Source....................................................................................................................... 3 2.6. EMC Modifications ............................................................................................................... 3 3. Product Configuration................................................................................................................. 3 3.1. Support Equipment .............................................................................................................. 3 3.2. Cables .................................................................................................................................. 3 3.3. Operational Characteristics & Software ...............................................................................4 3.4. Block Diagram ...................................................................................................................... 4 4. Measurement Parameters.......................................................................................................... 5 4.1. Measurement Equipment Used to Perform Test ................................................................. 5 4.2. Measurement & Equipment Setup ....................................................................................... 5 4.3. Test Procedure..................................................................................................................... 5 5. Measurement Summary ............................................................................................................. 6 6. Measurement Data ..................................................................................................................... 7 6.1. Power and Antenna Height Limits 27.50 (d) ....................................................................... 7 6.2. Bandwidth Limitations (FCC Part 2.1049) ........................................................................16 6.3. Spurious Emissions at the Antenna Terminals 27.53 (h) ................................................. 25 6.4. Field Strength of Spurious Emissions 27.53 (h) .............................................................. 42 6.5. Frequency Stability 27.54 ................................................................................................. 47 6.6. Public Exposure to Radio Frequency Energy Levels 1.1307 (b)(1).................................. 48 7. Test Site Description ................................................................................................................ 49 8. Test Setup Photographs........................................................................................................... 50 Appendix A ................................................................................................................................... 54 Test Number: 349-12 Issue Date: 11/28/2012 Page 3 of 55 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com 1. Scope This test report certifies that the Cellular Specialties Co-Pilot Beacon CPBH-MG-AW4, as tested, meets the FCC Part 27 Subparts C & L requirements. The scope of this test report is limited to the test sample provided by the client, only in as much as that sample represents other production units. If any significant changes are made to the unit, the changes shall be evaluated and a retest may be required. 2. Product Details 2.1. Manufacturer: Cellular Specialties 2.2. Model Number: Co-Pilot Beacon CSI-CPBH-MG-AW4 2.3. Serial Number: C1E20008 2.4. Description: The Co-Pilot Beacon AWS is the first viable location based solution for simulcast CDMA Distributed Antenna Systems (DASs). It is designed to improve location accuracy of cell phones and wireless devices outdoors and within buildings. 2.5. Power Source: 120 VAC, 60 Hz 2.6. EMC Modifications: None 3. Product Configuration 3.1. Support Equipment Device Manufacturer Model Serial No. Comment Power Supply APX Technologies SP130P954ER 06502248 Notebook PC Dell Latitude D610 19472301901 Configuring Unit 3.2. Cables Cable Type LengthShieldFrom To RF, 50 Ω, SMA male – SMA male 1M Yes DUT AWS Antennas Pulse In 1M Yes DUT Unterminated EST Out 1M Yes DUT Unterminated GPS 5M No DUT Garmin GPS Antenna Power Supply 2M + 2MYes DUT 120 VAC, 60 Hz Serial 1 2…

Text truncated - open the document above for the full version.

8. Test Setup Photographs Antenna Port Conducted Emissions 8. Test Setup Photographs (cont) Radiated Emissions (Front) 8. Test Setup Photographs (cont) Radiated Emissions (Rear)
