NVZ98031100NMicrowave Oven

Compliance Certification Services 10/21/1998 RADITATION TEST DATA SHEET Juan Martinez(1Meter) GUANGDONG GALANZ ENTERPRISE CO.1100W OUTPUT MICROWAVE(WP1100A, WP1100, AG-7W) F(MHz) READING AF CL A MP DIST OTHER TOTAL LIMIT MARGIN dBuV (dB) (dB) (dB) (dB) (dB) (dBuV/m) (dBuV/m) (dBuV/m) 1189 69.8 24.6 2.1 -34 -49.5 0 13 28.6 -16 1645 58.7 25.2 2.1 -34 -49.5 0 2.5 28.6 -26 2378* 62.1 28 3.1 -34 -49.5 1 10.7 28.6 -18 2452* 62.5 29 3.3 -34 -49.5 1 12.3 28.6 -16 2485* 58.7 29.2 3.4 -34 -49.5 1 8.8 28.6 -20 2514* 65.8 29.2 3.4 -34 -49.5 1 15.9 28.6 -13 2587* 58.7 29.2 3.6 -34 -49.5 1 9 28.6 -20 4432# 56.8 32.3 5.7 -34 -49.5 1 12.3 28.6 -16 4878# 45.8 33 5.7 -34 -49.5 1 2 28.6 -27 4978# 52.8 34.3 5.7 -34 -49.5 1 10.3 28.6 -18 7528# 50.8 36.5 6.8 -34 -49.5 1 11.6 28.6 -17 9800# 53.7 38.2 8.2 -34 -49.5 1 17.6 28.6 -11 12250# 40.5 39.3 8.8 -34 -49.5 1 6.1 28.6 -23 14700# 49.8 40 9.2 -34 -49.5 1 16.5 28.6 -12 NOTE: ALL MEASUREMENTS ARE VERTICAL.AF: Antenna Factor DIST: Distance Correction(-49.5dB, 1M) SPECTRUM ANALYZER SETTINGS AMP: Pre-amp gain 20*LOG(d/300M) RES V B W CL: Cable loss OTHER: High pass filter insertion loss PEAK: 1MHz 1MHz *FSY Microwave high pass filter ( f o=1.082GHz) A VG: 1MHz 10Hz #FSY Microwave high pass filter ( f o=4GHz)
