PROPOSED FCC ID LABEL FORMAT AND LOCAITON APPLICANT: GUANGDONG GALANZ ENTERPRISE (GROUP) CO., LTD. FCC ID: NVZ9803550N This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: NVZ9803550N FCC ID LABEL

FCC CFR47 PART 18 SUBPART C ISM EQUIPMENT TEST REPORT FOR MICROWAVE OVEN MODEL: WP550L12, WP550J12, WP550SJ12, WP550SL12, WP550AL12, WP550ASL12 FCC ID: NVZ9803550N REPORT NUMBER: 98C0096-1 ISSUE DATE: FEBRUARY 05, 1999 Prepared for GUANGDONG GALANZ ENTERPRISE (GROUP) CO., LTD. 328 GUIZHONG ROAD SHUNDE, GUANGDONG P.R.C. 528305 CHINA Prepared by COMPLIANCE CERTIFICATION SERVICES, INC. 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO: 98C0096-1 DATE:FEBRUARY 05, 1999 FCC ID:NVZ9803550N EUT: MICROWAVE OVEN 0OF10 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002C 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE..............................................1 2. PRODUCT DESCRIPTION.....................................................2 3. TEST FACILITY...........................................................2 4. ACCREDITATION AND LISTING...............................................2 5. RADIO NOISE EMISSIONS MEASURMENTS PROCEDURE/RESULTS.............................2 5.1 RADIATION HAZARD MEASUREMENT............................................2 5.2 INPUT POWER ......................................................................................................... 3 5.3 RF OUPUT POWER MEASUREMENT................................................3 5.4 OPERATING FREQUENCY MEASUREMENTS........................................4 5.5 VARIATION IN OPERATING FREQUENCY WITH TIME..............................5 5.6 VARIATION IN OPERATING FREQUENCY WITH VOLTAGE...........................5 5.7 RADIATION EMISSIONS .............................................................................................6 6. EUT SETUP PHOTOS..........................................................8 7. MEASUREMENT EQUIPMENT LIST.......... ..............................................9 ATTACHMENTS: .RADIATED EMISSION DATA .VARIATION IN OPERATING FREQUENCY WITH TIME PLOTS .VARIATION IN OPERATING FREQUENCY WITH VOLTAGE PLOTS .USER MANUAL AND SCHEMATICS .PROPOSED FCC ID LABEL .EUT PHOTOGRAPHS REPORT NO: 98C0096-1 DATE:FEBRUARY 05, 1999 FCC ID:NVZ9803550N EUT: MICROWAVE OVEN 1OF9 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME : GUANGDONG GALANZ ENTERPRISE(GROUP) CO., LTD. 328 GUIZHONG ROAD SHUNDE, GUANGDONG P.R.C. 528305 CHINA CONTACT PERSON : HU YANG / MANAGER TELEPHONE NO : 765-888-6389 EUT DESCRIPTION: MICROWAVE OVEN MODEL NO/NAME : WP550AL12, WP550L12, WP550J12, WP550SJ12, WP550SL12 and WP550ASL12 DATE TESTED : FEBRUARY 05, 1999 TYPE OF EQUIPMENT: CONSUMER ISM EQUIPMENT TECHNICAL LIMIT: SUBPART C FCC RULES: PART 18 MEASUREMENT PROCEDURE FCC/MP-5/1986 EQUIPMENT AUTHORIZATION PROCEDURE CERTIFICATION MODIFICATIONS MADE ON EUTYESNO The above equipment was tested by Compliance Certification Services for compliance with the requirements set forth in the FCC CFR 47, PART 18. This said equipment in this configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. Approved By MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE CERTIFICATION SERVICES REPORT NO: 98C0096-1 DATE:FEBRUARY 05, 1999 FCC ID:NVZ9803550N EUT: MICROWAVE OVEN 2OF9 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION The equipment under test is a microwave oven sold for consumer use. Models: WP550L12, WP550J12, WP550SJ12, WP550SL12, WP550AL12 and WP550ASL12 are 550W microwave oven. Model with A or B is a digital control, with S is rust proof, with L is to pull handle to open door and with J is no window on door. Magnetron: Toshiba, Type: 2M231H(JT). 3. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at 561F Monterey Road, Morgan Hill, California, USA. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 4. ACCREDITATION AND LISTING The test facilities used to perform radiated and conducted emissions tests are accredited by National Voluntary Laboratory Accreditation Program for the specific scope of accreditation under Lab Code:200065-0 to perform Electromagnetic Interference tests according to FCC PART 15 AND CISPR 22 requirements. No part of this report may be used to claim or imply product endorsement by NVLAP or any agency of the US Government. In addition, the test facilities are listed with Federal Communications Commission (reference no: 31040/SIT (1300B3) and 31040/SIT(1300F2)) 5. RADIO NOISE EMISSION MEASUREMENTS PROCEDURES/RESULTS 5.1 RADIATION HAZARD MEASUREMENT NARDA/8721 FI/EFS-5 Radiation Hazard Measurements A 1000-ml water load was placed in the center of the oven. The power setting was set to 10(100%) maximum power. While the oven REPORT NO: 98C0096-1 DATE:FEBRUARY 05, 1999 FCC ID:NVZ9803550N EUT: MICROWAVE OVEN 3OF9 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. was operating, the STE probe was moved slowly around the door seams to check for leakage. .239 mW/cm ² fig.1.239 mW/cm² LOCATION MAXIMUM LEAKAGELIMIT (mW/cm²) (mW/cm²) Fig.1 shows the locations of maximum leakage .239 1.0 All others .068 1.0 Power density is calculated from field strength E, V/m using the relationship. S, mW/cm² = (E, V/m)² / 3770 5.2 INPUT POWER Input power and…
