RFCAST – MT300. Rev. 2: 05-17-04 1/17 OWNERS MANUAL Model MT300 (-E & -U) 300 WATT FM STEREO TRANSMITTER RFCAST – MT300. Rev. 2: 05-17-04 2/17 Table of Contents Table of Contents page 2 User Notices page 4 Warning page 5 Returns & Exchanges page 6 Unpacking page 6 Technical Support page 6 1.0 Overview page 7 2.0 MT300 Basic Block Diagram page 7 3.0 Subassemblies Description Page 7 3.1 MT300 AC/DC Power Supply page 7 3.2 MT300 DC/DC Power Supply page 8 3.3 FM Stereo Exciter page 8 3.4 MT300 RF Control Circuit page 8 3.5 MT300 RF Amplifier page 9 3.6 Low Pass Filter and Directional Coupler page 10 4.0 MT300 Technical Specifications page 10 5.0 Set up Procedure page 12 RFCAST – MT300. Rev. 2: 05-17-04 3/17 OME-1T Exciter Section 6.0 General / Front Panel Graphic Page 1 of 4 7.0 Physical Page 2 of 4 8.0 Monaural Operation Page 2 of 4 9.0 Wideband Stereo Operation Page 2 of 4 10.0 Built In Stereo Encoder Operation Page 3 of 4 11.0 SCA/RDS & AUX Inputs Page 3 of 4 12.0 OME-1T Component Layout Page 4 of 4 13.0 Jumper and Switch Setting guide Page 4 of 4 Schematic Diagrams and Components Locations 14.0 OME-1T Schematic Diagram 15.0 300W RF Module 16.0 Layout FM300-108SD 17.0 MOSFET FM 300W RF Amplifier Schematic 18.0 Layout MDL30 19.0 MDL30 Schematic 20.0 MT300 / MT250 Logic Control Board Layout 21.0 Logic Control Board MT250 / MT300 Schematic 22.0 300W Low Pass Filter Layout – MT100/250/300 Low Pass Filter 23.0 300W Low Pass Filter Schematic 24.0 300W Directional Coupler Layout 25.0 300W Directional Coupler Schematic 26.0 DC/DC Converter Layout 27.0 DC/DC 90W Converter Schmatic 28.0 JWS300 – 600 Series Instruction Manual RFCAST – MT300. Rev. 2: 05-17-04 4/17 USER NOTICES IT IS VERY IMPORTANT TO READ THE FOLLOWING MANUAL SECTIONS PRIOR TO OPERATION OF THIS TRANSMITTER! Notice 1 The transmitter main operating voltage setting is marked on the rear of the MT300 chassis. It may be necessary to change this setting for your operating condition. Please refer to AC Main Voltage Setting in section 6.0 Set Up Procedure. Notice 2 The transmitter operating frequency from the factory may not be set for your authorized frequency as it is normally set for a mid band value such as 98.0 MHz. Please refer to Frequency Of Operation Change in section 6.0 Set Up Procedure. Notice 3 For adjusting the RF output power setting a qualified technician should employ the use of an RF Wattmeter and a calibrated dummy load. Please refer to the section entitled RF Power Control in section 3.4 of this manual. Notice 4 The factory settings of this manual for such this as Input Selection, preemphasis, and input sensitivity may not be correct for your application or installation requirements. Please refer to the other exciter settings in section 6.0 Set Up Procedure where you will be directed where else to reference in this manual. GENERAL COMMENTS THIS PRODUCT DOES NOT INCLUDE A DETAILED TECHNICAL MANUAL, RATHER AN ENHANCED OPERATORS MANUAL. WHAT THIS DOCUMENTATION IS INTENDED TO DO IS TO GIVE THE USER THE CORRECT INSTRUCTIONS AND INDICATIONS ABOUT HOW TO OPERATE AND PERFORM PERIODIC CHECKS AND DETERMINE IF THE TRANSMITTER IS FUNCTIONING PROPERLY. WE ARE AWARE THAT THE TRANSMITTER DOCUMENTATION MAY PRESENT SOME SMALL AMBIGUITIES AND IMPERFECTIONS, MANY OF WHICH HAVE ALREADY BEEN NOTED AND RESOLVED IN THE NEXT RELEASE AND PRODUCTION. FOR THIS REASON, EVERY OBSERVATIONS/SUGGESTIONS OR PARTICULAR COMMENTS ARE WELCOME. ELECTRONIC FILES OF THE SCHEMATIC DIAGRAMS IN THIS MANUAL ARE AVAILABLE. SHOULD A LARGER MORE VIEWABLE VERSION OF ANY DIAGRAM BE REQUIRED NOTIFY RICHARDSON ELECTRONICS, LTD. TO CALL OUR TECHNICAL SUPPORT CENTER OR FOR OTHER CUSTOMER SERVICE ISSUES AT RICHARDSON ELECTRONICS IN LA FOX, ILLINOIS REFER TO THE FOLLOWING NUMBERS: TECHNICAL SUPPORT: 630-208-2790 CUSTOMER SERVICE: 630-208-2304 RFCAST – MT300. Rev. 2: 05-17-04 5/17 WARNING! THE VOLTAGES AND CURRENTS IN THIS EQUIPMENT ARE DANGEROUS. PERSONEL MUST, AT ALL TIMES, OBSERVE SAFETY WARNINGS, INSTRUCTIONS, AND ANY REGULATIONS. This owner’s manual is intended as a general guide for trained and qualified personnel who are aware of the dangers that are inherent in the handling and operation of potentially hazardous electrical and electronic circuits. It is not the intent of this manual to provide a complete set of safety instructions or precautions that should already be understood by trained or experienced personnel in using this or other types of electronic equipment. The installation, operation, and maintenance of this equipment involves risks to personnel and also to the equipment. Broadcast Richardson or Richardson Electronics, Ltd. shall not be responsible for injury or damage that is the result of improper procedures or use by persons improperly trained or lacking the knowledge to perform associated tasks. All local codes for building, safety, fire, or related standards must be observed. Consult local authorities for the standards for the area or region where the equipment will be installed and put in use. WARNING! AT ALL TIMES DISCONECT AC/MAINS POWER BEFORE OPENING COVERS, DOORS, ENCLOSURES, PANELS, OR PROTECTIVE SHIELDS THAT EXPOSE LIVE CIRCUITS. USE ANY GROUNDING STICKS OR OTHER SHORTING PROBES TO DRAIN ENERGY FROM CIRCUITS BEFORE SERVICING. NEVER PERFORM MAINTENANCE, MAKE ADJUSTMENTS, OR SERVICE THE EQUIPMENT WHEN ALONE OR FATIGUED. WARNING! IF ELECTROLYTIC OR OIL FILLED CAPACITORS ARE UTILIZED IN THE EQUIPMENT AND THE COMPONENT APPEARS LEAKY, OR IS BULGING, OR IF THE CASE OR COVERING OF THE COMPONENT APPEARS DAMAGED OR DISTRESSED ALLOW SUFFICIENT TIME FOR THE UNIT TO COOL OR FULLY DISCHARGE BEFORE SERVICING. SERVICING HOT OR LEAKY CAPACITORS CAN CAUSE A RUPTURE OF THE CASE AND POSSIBLE INJURY. Should accident or injury occur personnel engaged in the installation, operation, or service of the equipment should seek proper medical attention. It is advisable that such personnel have familiarity with first-aid practices. RFCAST – MT300. Rev. 2: 05-17-04 6/17 Retur…

Text truncated - open the document above for the full version.

The MT300 RF Module, Final Power Stage The final RF power section on MT300 transmitter is composed by: 1. RF Driver: model MDL30. 2. 90 deg. 2-way hybrid splitter. 3. A pair of final stage amplifiers mounting SD2931- 10 devices. 4. Second; 90 deg. 2-way hybrid splitter. The MDL30 provides the first step of amplification of minimum 17dB gain in order to correctly drive the final stage. It is composed by a stage operating in class AB. Below the technical specifications: Vcc 28 volts Idq 200mA typ. Frequency range 87.5 – 108 MHz Power Gain >17dB typ. Output Power >25 W The 2-way splitter is made by a 90 deg. Hybrid structure and provides to split in quadrature the input signal. Below the technical specifications: Frequency Range 87.5 – 108 MHz Input Power 50 W max. Return Loss, (s11) <17dB Return Loss, (s22 and s33) <15dB Isolation, (s32) >15dB Insertion Loss, (s21=s31) <0.6dB The final stage is an amplifier for FM Broadcast band, (87.5Mhz to 108MHz), with nominal output power or 300 watt CW, that also can operate at 390 watt CW. Normally it works compensating the losses of the passive and linear circuitry that follows the amplifier, the directional coupler and the low pass filter. The necessary typical pre-gain compensation is about 0.9dB. This means the RF amplifier output runs at 370 watt for a nominal 300 watt at the output connector. The amplifier topology is a balanced amplifier, including a pair of single ended sections, each one using a high power MOSFET with the input/output matching network printed on the PCB. The choice of using two RF devices has been decided in order to improve the raggedness of the amplifier in case of strong mismatched load at the output network. Thanks to the 90 deg. Hybrid isolation, the amplifier stages are not influenced by operational conditions changes of the load (antenna, filter, transmission line and so on). Moreover, the amplifier is more stable and because of that more immune to the self-oscillations. The two hybrid RF devices allow the amplifier to produce output power (-6dB) even if one of them breaks or damages. Below the technical specifications: VCC nominal 48V IDC (@ Full Power) 11A typ. Idq 180Ma typ. Frequency Range 87.5 – 108 MHz. Power Gain 18dB, typ. Output Power 280 w - 370 w. Polarization Class B The 2-way combiner is a quadrature structure, and it provides the sum of each two final stage sections to have the max RF power at the common port. One unbalanced 50 Ohm RF resistor warranties the isolation between the input ports, in order to maintain the transmitter on duty in case one of the final stages will be on fault. Below the technical specifications: Frequency Range 87.5 – 108 MHz Power Handling 400 W Max. Return Loss, (s11) <-18dB Return Loss, (s22 and s33) <-18dB Isolation, (s32) >+18dB Insertion Loss, (s21=s31) <0.4dB The low pass filter has a particular elliptic configuration; this configuration has been chosen to guarantee the values of the harmonic components levels. Below the technical specifications: In band insertion loss <0.5dB Insertion loss @ 175Mhz >55dB In band Return Loss <-20dB The directional coupler is a block composed by 2 directional couplers and a quarter wave delay line. Both ports of each directional coupler are used. Two of them detect the reflected power, one detects the FWD power and the one is used for RF monitor. The function of the delay line is to have the reflected power signal detected at 90 deg. of electrical angle. In this way, it is possible to have a constant reflected power level versus the phase angle of that signal. The RF monitor is connected to the front panel to have a 0dBm nominal signal. Below we can see a photo of the MT300 RF Module Amplifier

1.0 OVERVIEW MT300 is a 300 Watt FM Low Power Transmitter. It is very simple and easy to use. It is composed by a mechanical frame (19 inches std., 3 HU high and 500mm depth), an exciter (OME-1T), a RF section, which comprises a RF control board and an amplifier section, a directional coupler and a low pass filter, a display, a power supply with a AC/DC converter and a DC/DC converter. 2.0 BASIC BLOCK DIAGRAM OF MT300 The RF section part number is GR00232ASE. FANS FUSE 48 Vdc -V +V LED (DISPLAY) ENABLE 110/220V L.P.F. Delay line RF out LOW PASS FILTER and DIRECTIONAL COUPLER RF AMPLIFIER SECTION REFL1 REFL2 FWD RF PROTECTION DRIVER (MDL30) TEMPERATURE RF CONTROL CIRCUIT RF Monitor AC/DC CONVERTER DC/DC CONVERTER 4 8 V i n 2 8 V d c 1 5 V d c F A N s EXTERNAL ENABLE OME-1T FM Exciter RFout 1Wmax Left Rigth Ext/MPX SCA/RDS AUX 15Vdc FINAL STAGE 3.0 SUBASSEMBLIES DESCRIPTION 3.1 MT300 AC/DC Power Supply This power supply is a purchasing product. It has a wide range with an input voltage of 85/265V and an output voltage of 48V. Below, the technical specifications: Nominal Output Voltage 48V Max Output Current 13A Max Output Power 624 Watt Efficiency 83% typ. Input Voltage Range 85-265VAC (47-63Hz) PFHC Built to meet EN61000-3-2 Power Factor(100/200VAC) (typ) 0.99/0.95 Output Voltage Range 43.2-52.8V Over Voltage Protection 55.2-64.8 3.2 MT300 DC/DC Power Supply The MT300 uses a DC/DC converter. It provides a voltage of 28V to the fans and a voltage of 15V to the exciter. In addition, it supplies a voltage of 28V to the driver (MDL30). Below, the technical specifications: Vdc Input 20 up to 53 Vdc Output 1 15 Vdc/1.5 A Output 2 28 Vdc/3 A 3.3 FM Stereo Exciter The exciter is a OME-1T model. The declared nominal RF output power is 1 Watt; this signal arrives to the RF final stage through the RF protection circuit. All the input connections are arranged on the front panel. (See the annex datasheet). 3.4 MT 300 RF Control Circuit The RF input circuit has 3 main functions: 1) RF power control 2) RF protection 3) Measurement/status indication RF Power Control. A pin diode attenuator manages the RF input power coming from the exciter (OME-1T). This attenuator can be manually controlled by RT3 trimmer, in order to adjust the right output power. The AGC control regulates the power, manually set, versus frequency and/or temperature changes. Moreover, the input attenuator includes a soft start, activated at the switching on or after any RF protection intervention. When the MT300 works at a very high temperature and/or high reflected output power, a derating circuit provides to decrease the output power in order to maintain the equipment on duty, even at low power. RF Protection. A fast comparator switches when the output detected reflected power exceeds a pre-set threshold. The regulation of this threshold is made by RT2 trimmer, adjusted in factory at a value of 40 Watt reflected power. When the protection is switched on, the protection circuitry cuts the RF signal applied to the final stage amplifier very quickly, in about 1 micro second. Measurement/status indication. The two main measurements, FWD and REF power, are displayed by two BAR LEDS. The MT300 status is indicated with 3 leds: RF nominal, RF fault, RF derating. The RF fault is on when the output power is lower than 3 dB related to the nominal output power. If the power decreases in derating conditions, the fault is off in all cases. The enable SW1 switch is on the front panel. It is possible to operate on the enable using the contacts on the rear panel, too. The enable of the amplifier is realized when the SW1 is on and the rear panel enable is closed. WARNING: with enable off, there is no RF out but all the internal circuits are supplied (stand by condition). So, switch off the mains before operating inside. 3.5 MT300 RF Amplifier The RF amplifier section provides to amplify the RF signal coming from the RF control circuit. It is composed by: • MDL30 (Driver) • 90 deg. 2 way hybrid splitter • a pair of final stage amplifiers mounting SD2931-10 devices • 90 deg. 2 way hybrid combiner The MDL30 provides the first step of amplification of minimum 17dB gain in order to correctly drive the final stages. It is composed by a stage operating in class AB. Below, the technical specifications: VCC 28V Idq 200 mA typ. Frequency range FM ( 87.5-108 MHz ) Power Gain > 17 dB typ. Output Power > 25 W The 2way splitter is made by a 90 deg. Hybrid structure and provides to split in quadrature the input signal. Below, the technical specifications: Frequency 87.5 – 108 MHz Input power 50W Max Return Loss (S11) <-17 dB Return Loss (S22 ed S33) <-15 dB Isolation (S32) >15 dB Insertion Loss (S21=S31) <0.6 dB The final stage is an amplifier for FM signal operating in band II (87.5 – 108 MHz), with nominal output power of 300 Watt CW. Normally it works up to 370 Watt, in order to win the Insertion loss of the circuitry that follows the amplifiers, as the Directional couplers and Low Pass Filter. It is a balanced amplifier, including a pair of single end sections, each one using a high power MOSFET, SD2932, with the input / output matching network printed on the pcb. The RF MOSFET‘s bias are integrated on this printed circuit board. The polarization is in class B, with a 10 mA quiescent current per section. The two sections are split and combined by 90 deg. hybrid. VCC nominal 48V IDC (@ Full Power) 10 A typ. Idq 20 mA typ. Frequency range FM ( 87.5-108 MHz ) Power Gain Typ. 16 dB Output Power 300 W min The 2 way Combiner is a 2 way in quadrature structure, and it provides to sum each two final stage sections to have 337 W power at the common port. One unbalancing 50 Ohm resistor warranties the isolation between the input ports, in order to maintain the Transmitter on duty, in case one of the final stages will be on fault (- 6dB derating). Below, the technical specifications: Frequency 87.5 – 108 MHz Power handling 400 W Max Return Loss (S11) <18 dB Return Loss (S2…

Text truncated - open the document above for the full version.

MT300 ii WARNING: RF Hazard Information THE ANTENNA(S) USED FOR THIS TRANSMITTER MUST BE FIXED-MOUNTED ON OUTDOOR PERMANENT STRUCTURES. RF EXPOSURE COMPLIANCE IS ADDRESSED AT THE TIME OF LICENSING, AS REQUIRED BY THE RESPONSIBLE FCC BUREAU(S) INCLUDING ANTENNA CO-LOCATION REQUIREMENTS OF PARA. 1.1307(B)(3). WARNING! THE VOLTAGES AND CURRENTS IN THIS EQUIPMENT ARE DANGEROUS. PERSONEL MUST, AT ALL TIMES, OBSERVE SAFETY WARNINGS, INSTRUCTIONS, AND ANY REGULATIONS. This owner’s manual is intended as a general guide for trained and qualified personnel who are aware of the dangers that are inherent in the handling and operation of potentially hazardous electrical and electronic circuits. It is not the intent of this manual to provide a complete set of safety instructions or precautions that should already be understood by trained or experienced personnel in using this or other types of electronic equipment. The installation, operation, and maintenance of this equipment involves risks to personnel and also to the equipment. Broadcast Richardson or Richardson Electronics, Ltd. shall not be responsible for injury or damage that is the result of improper procedures or use by persons improperly trained or lacking the knowledge to perform associated tasks. All local codes for building, safety, fire, or related standards must be observed. Consult local authorities for the standards for the area or region where the equipment will be installed and put in use. WARNING! AT ALL TIMES DISCONECT AC/MAINS POWER BEFORE OPENING COVERS, DOORS, ENCLOSURES, PANELS, OR PROTECTIVE SHIELDS THAT EXPOSE LIVE CIRCUITS. USE ANY GROUNDING STICKS OR OTHER SHORTING PROBES TO DRAIN ENERGY FROM CIRCUITS BEFORE SERVICING. NEVER PERFORM MAINTENANCE, MAKE ADJUSTMENTS, OR SERVICE THE EQUIPMENT WHEN ALONE OR FATIGUED. MT300 iii WARNING! IF ELECTROLYTIC OR OIL FILLED CAPACITORS ARE UTILIZED IN THE EQUIPMENT AND THE COMPONENT APPEARS LEAKY, OR IS BULGING, OR IF THE CASE OR COVERING OF THE COMPONENT APPEARS DAMAGED OR DISTRESSED ALLOW SUFFICIENT TIME FOR THE UNIT TO COOL OR FULLY DISCHARGE BEFORE SERVICING. SERVICING HOT OR LEAKY CAPACITORS CAN CAUSE A RUPTURE OF THE CASE AND POSSIBLE INJURY. Should accident or injury occur personnel engaged in the installation, operation, or service of the equipment should seek proper medical attention. It is advisable that such personnel have familiarity with first-aid practices.

A A B B C C D D E E 44 33 22 11 x1MHz 16 1 F/64 Prescaler 14 x 47k Ingenium - Pianopoli - Italy 2 - Synthetizer Stereo Coder PMBT 2222A PMBT 2222A 3 "100MHz" 15Vcc VCO & Buffer 1-2=Stereo 2-3=Mono x10MHz 3 PMBT 2222A "Lock" x100kHz RF OUT Peak Detector Loop Filter Led Bar #B Indicator Phase Comparator L&R Input and Preemphasis + 1 Reference Oscillator Virtual Ground Limiter 12.8MHz 2 Led Bar #A Indicator RF Power Amplifier PMBT 2222A Audio Filter 4x BAT46 L Input Sensitivity 1-2 = 6..9 dBm 2-3 = 3..6 dBm 3-4 = 0..3 dBm 1234 2134 2134 213 1 2 3 Preemphasis 1-2 = 75 uSec 2-3 = Linear 3-4 = 50 uSec Sensitivity See Left Ch. Preemphasis See Left Ch. R Input 0..3dB Fine Adj. 0..3dB Fine Adj. RDS 0dBm AUX 0dBm Mpx Ext +3..+9 dBm Limiter 1-2 =On 2-3 =Off Input selector 1-2 = Ext Mpx/Mono 2-3 = Int. Mpx 1-2 = +50kHz 2-3 = 0 Sync 1 2 17T/ 0C315/ 3D0 "Limit" 1-2 = RF Inhibit 2-3 = Lock Detector Inh. No Jumper= Normal Operation MonoStereo 4 MPX Adj Input |JP6|JP5 Mono |1-2|2-3 Mpx Int |1-2|1-2 Mpx Ext |2-3|2-3 123 1 23 1 2 3 MPN10 MPN10 A3 11 Wednesday, September 29, 1999 00 SE99012.DSN SizeDocument NumberRev Date:Sheetof App.DateApp.Sig.Dwg.Sig.Dwg. Date P7V5 P15V P7V5 P15V P15V P15V P15V P15V P7V5 P7V5 P7V5 P15V P15V P15V P15V P15V P15V P15V P15V P15V P15V P15V P15V P15V P15V P15V P7V5 P7V5 P7V5 LD13 Red R21 2k2 C76 100n R64 470k R125 2M2 R126 R109 2M2 C77 470p R119 Q4 BFR96S Q10 BC807 R143 1M0 R52 220 JP9 +- IC13A LM339 54 2 312 R43 470 L3 150n C32 220p2% C17 4p7 R29 2k2 R3 150 TP5 LD6 Green R138 C43 470p L8 150n R7533k R57 10R L1 R30 47R R814k7 DV6 BB153 R135 1k0 R114 47R T2 13 4 25 R27 1k8 T1 13 4 25 R324k7 C10 220n D10LL4148 C79 100u 35V C58 47p C57100p R11R0 C28 10n 2% R15 470k D16 LL4148 C4 2n2 C91 47p R176 470 C2 100n R10418k C74100n R155 2k2 CV1 5-20p D3 LL4148 R50 1k0 R161 6k8 H3 TCXO 1 2 3 Vdd Out Gnd R35 1k8 JP10 D4 LL4148 C5 10n 2% Vss IC10B 40107B 6 57 4 C20100p R89 TBD +- IC14D LM339 1110 13 Q6 BC817 R5633k JP1 L14 1T/0C5/3D0 Q7 BC807 IC8 SAB6456A 26 4 5 3 8 79 R68 150 D1 LL4148 R103 820 R6533k R145 10k LD4 Green JP7 D7 LL4148 CN4 +- IC13C LM339 98 14 R170TBD D9 SW3 321 5 4 BCD Com A JP2 R1746k8 IC5A 4027B 61 3 52 7 48 16 JQ CLK KQ S RVss Vdd JP6 C84 100n R19 1k8 R106 33k C86 10u 35V R13 150 +- IC13D LM339 1110 13 RT4 1k0 C49 2n2 C102 100n C94100n C15 6p8 R159 6k8 C39 47p R151 10k RT1 5k0 R428k2 R2 10k C44 47p LD7 Green R110 220 CN2 R121 2k2 CN1 C7 100n DZ1 9V1 C27 2n2 C53 470n R100 2k2 R882k C2910u25V Q19 BC807 R84 4k7 D12 C72 10u 35V R96 560 C100 10u 35V R1893k3 R2027k C65 100n C75 10u 35V C78 22n R123 2M2 L9 150n LD9 Red H2CTC30_01 1413121110987654321 27262524232221201918171615 m/sCTGndSync1216kGndGndLLeft inGndVssGndRight inR MPU 19k in CR CL Comp RComp C GndGnd C int MPX Vdd 19k out C trim R94 560 C70 100n R169 680 L20 Bead Neosid XT1 6400k Q17 BC817 C1 100u 35V R45 1M0 C87 47p R79 560 CN5 C83 100n C48 470p IC5B 4027B 1015 13 1114 9 12 JQ CLK KQ S R L11 220n R636k8 R51 22k CN8 C85 470n R191TBD R162 6k8 R80 1k0 C33 100n J3 BNC R556k8 L10 3u3 C50 100u 35V R177 10k R1576k8 C13 2n2 R168 3k3 C21 10u 35V R17 1M0 C59 10u 35V L12 180n C31 100n R12 10R C41 TBD C37 100u 63V C63 100n SW2 321 5 4 BCD Com A TP4 Q14 BC807 IC2A TL072 2 3 8 4 1 CN7 LD11 Green C12 100u 35V R173 470 C25 10u 35V R28 6k8 R40 150 R93 10R R147 470k DZ4 5V1 R172 10k DZ8 5V1 R77 2k2 Q12 BC817 C16 6p8 C24 10u 35V IC3A TL072 2 3 8 4 1 Q20 IC7B LM833 6 5 7 R6710k R113 1k8 R134 L15 150n IC4A OP275 2 3 1 IC9A 4027B 61 3 52 7 48 16 JQ CLK KQ S RVss Vdd R16 820 Q16 CN11 R5433k J5 R182 1k0 R166220 C30 10u 35V H1 FTC30_01 10987654321 16151413121117181920 Input A GndGnd -Vs GndGnd Output A GndGnd +Vs GndGndOutput BGndGnd+Vs-VsGndGndinput B IC4B OP275 6 5 7 R7610k SW1 321 5 4 BCD Com A L16 1u0 D6 LL4148 R41 22k R921M0 CN3 IC9B 4027B 1015 13 1114 9 12 JQ CLK KQ S R R610R R137 470k R2322k DV4 BB153 C101 2n2 J1 BNC C3 100n R108 2M2 TP3 R66 100 1W0 R59 6k8 DZ6 3V9 R122 2M2 C98 10u 35V D11 R105 33k C6 100n R911M0 IC7A LM833 2 3 1 R85 82k D13 JP5 R117 2k2 C67 2n2 R129 C80 100p L2 150n Q1 2 31 R190 1k0 LD3 Green R183 22R R181 33k LD10 Green R118 2k2 R180 33k R131 R5 4k7 R128 47k DZ2 3V9 LD2 Red R132 Q2 2 31 C60 1p0 R73 150 LD8 Yellow R98 82k R9 270 R4 47R R87 470k DZ3 3V9 C9 220p 2% R187150 R10 820 L5 DV1 BB153 C38 100u 35V C18 2n2 R163 6k8 R160 6k8 R78470 C69470n IC11A LM358 2 3 8 4 1 Vss IC10A 40107B 2 31 J4 R186 39R R33 47R DV2 BB153 C55 100n CN12 C34 100n R4627k CN10 R167 150 R185 150 +- IC14B LM339 76 1 DV3 BB153 C19 470p CN14 C54 10u 35V C81 100n JP8 R38 820 R60 47k L4 150n RT2 5k0 C97 10u 35V C71 10u 35V R31 10k R3647k R144 10k D15 R112 2k2 L7 2T/0C5/3D0 R39 220 R25 82k C62 15p C35 100n Q11 BC817 R10110k R175 10k C45 22n R37 270 R111 22k C96 470n R34 1M0 R49 1k0 C64 22n R47 2k2 R53 1k8 IC11B LM358 6 5 7 IC1 LM723 5 4 2 3 137 12 10 911 6 Pos In Neg In ILim ISen CompGnd Pwr Vout VZVC Vref IC6 4059B 345622212019181716151098712141311 231224 J1J2J3J4J5J6J7J8J9J10J11J12J13J14J15J16CLKLENKAKBKC NOUT VSSVCC R70 2k2 R188 3k3 J7 BNC R44 68R R133 R8822k L19 470n R901M0 C73 100n C90 47p +- IC14C LM339 98 14 R71 82k C40 6p8 C42 1p0 R61 47k R82 22R R136 R102 10k C36 2n2 R241M0 CN13 JP4 LD1 Green JP3 D14 C92 100n IC2B TL072 6 5 7 +- IC14A LM339 54 2 312 C89 470n R146 2k2 LD12 Yellow R171 560 R116 22R R139 470k J6 IC3B TL072 6 5 7 R62470 TP2 R127 47R R154 220k C68 470n DZ5 3V9 C51 2n2 C99 22n R178 1k0 CN9 L131u0 TP1 C14 470p CN15 R156 220k L18 220n C52 22n Q13 BC807 C82 100u 35V R164 6k8 R18 330 C11 47p R142 R95 560 C47 470p R165 6k8 Q21 BC807 C56 560p Q18 BC807 R22 1k8 C93 10u 35V L6 22u R149 18k L17150n R8333k C23 1u0 63V C88 470n Led Circuit Board R140 C8 100n +- IC13B LM339 76 1 D8 J2 BNC RT5 5k0 C46 22n R69 TBD R150 2k2 Q9 C61 8p2 R141 R179 10k R115 1k0 C22 1u0 63V CN6 DZ7 3V9 R48 2k2 IC12 4060B 1112 7546141315123910 8 PIRST Q4Q5Q6Q7Q8Q9 Q10Q12Q13Q14 POPO VSS R26 6k8 R130 22k LD5 Red R99 82k C66 2n2 DV5 BB153 R184 82k R148 18k C95 2n2 R74 39R RT3 10k Q22 BC817 R158 5M6 R97 470 R120 R58 470 Q8 D17 LL4148 R107 22k R86 82k Q5 BFG135 R148k2 Q3 …

Text truncated - open the document above for the full version.

8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 1 DD CC BB AA +40..48VRF INH (-5V) RF IN RF OUT FM300-108SD GR00232ASE.dsn 00 MOSFET FM 300W RF AMPLIFIER RF GAIN LTD A3 11Friday, February 22, 2002 Title SizeDocument NumberRev Date:Sheetof DWG.Sig.Dwg. DateApp.Sig.App.Date CC2 RG316/25 L=46mm su ferrite 12 L2 1T0 Teflon Blu L=90mm (83) Su Ferrite Neosid F08 C13 10n C10 100n 100V R6 10k R2 470k R3 10R R8 4R7 2W0 RT1 10k R1 10R DZ1 3V9 C4 10n C7 4n7 R5 3k3 2W C1 18p DZ2 3V9 CC1 RG178BU L=115mm .. CC3 RG316/25 L=46mm su ferrite 12 L1 2T/1C0/10D C6 4n7 CC4 RG316/25 L=105mm .. R9 10R 1W0 C9 470p ATC L4 0T5/0C8/7D FB1 Yellow Balun Core FT8/F40 CB1 CS96022 FB2 Yellow Balun Core FT8/F40 C12 470p ATC C8 10u 63V 1 2 US1 1T/1C5/5DC11 470p ATC D1 BAS32 C2 1n0 C16 3p3 C15 470p ATC R7 3k3 R10 10R C3 1n0 CB1 CS96022 US2 1T/1C5/5D L3 1T0 C5 10n Q1 SD2932 3 41 2 6 5 C14 470p ATC R11 10R CC6 RG316U L=125mm .. CC5 RG316/25 L=105mm ..

A A B B C C D D E E 44 33 22 11 RG316/25 L=120mm 25 Ohm RF IN INH. +28V RF OUT SE9900901 MDL30 INGENIUM S.r.l - Italy A4 11Monday, September 20, 1999 Title SizeDocument NumberRev Date:Sheet of DWG.Sig.Dwg. DateApp.Sig.App.Date C11 1n C16 47n R3 12R L2 VK200 Q1 BLF245 2 31 L1 14T/0C5/4D0 DZ2 3V9 DZ1 3V9 J1 CC1 TR1 RT1 10k C1 15p C17 4u7 50V R7 1k8 R6 1k8 R4 12R C12 1n C5 4u7 35V D1 BAS32 C18 82p MST6 C19 18p R5 220R C2 39p R8 5R6 MST2 C3 82p C4 22n R1 10k C7 22n R9 5R6 C8 22n C9 120p C13 4n7 500V C10 100n MST1 C6 22n R2 6k8 C15 47n

5 5 4 4 3 3 2 2 1 1 DD CC BB AA Refl Threshold DERATINGRF NOMINALFAULT Refl. Level Setting ENABLE MAIN 7- Refl2 1- V_ADJ CN1 pins description function 3- REfl1 2- GND 10- +15V 6- Main_Led 4-T_Sensor 5- FWD 9- +15V 8- GND lefty lefty right right Forward Power Reflected Power 5k 5k Power Control GR00194CSE C LOGIC CONTROL BOARD MT250 INGENIUM A3 11Thursday, January 31, 2002 Title SizeDocument NumberRev Date:Sheet of DWG.Sig.Dwg. DateApp.Sig.App.Date +15V +15V +15V RF INPUT +10V +15V +10V +10V +15V +15V +15V +15V +15V +10V+10V +10V+15V +10V +10V +10V +15V +15V+15V +15V 10k R72 270 R31 BAT46 D10 100n C19 390 R82 470p C24 6k8 R86 D16 BAT46 BAT46 D13 RT1 5k0 1 3 2 2k2 R71 100n C9 BC817 Q1 1 2 3 C36 100u 25V 1 2 BAT46 D6 LD19 LED 10k R20 220p C4 12k R87 1k0 R41 22p C13 220p C11 10kR39 IC5A LM358 2 3 8 4 1 IC6A LM358 2 3 8 4 1 100k R75 2V7 DZ5 100n C29 IC1LM3916 1 2 3 4 5 6 7 8 910 11 12 13 14 15 16 17 18 1 2 3 4 5 6 7 8 910 11 12 13 14 15 16 17 18 220p C53 1k0 R35 33k R89 220p C6 220k R45 IC8B LM358 6 5 7 2V7 DZ3 IC4LM3916 1 2 3 4 5 6 7 8 910 11 12 13 14 15 16 17 18 1 2 3 4 5 6 7 8 910 11 12 13 14 15 16 17 18 + - LM311 U1 2 3 4 1 7 85 6 LD2 LEDHSMP3810 D1 x 2 C35 10u 25V 1 2 270 R23 220p C5 470 R59 100n C25 LD3 LED 330 R34 CONFLAT_10 CN1 12345678910 HSMP3810 D2 D18 BAT46 CN2 BARST M2 5k6 R26 22p C22 RT3 1 3 2 BAT46 D5 HSMP3810 D3 47k R84 xx R47 LD4 LED 10u L2 680 R58 2k2 R76 100u C32 1 2 1k0 R96 390 R50 4k7 R93 470p C44 LD15 LED LD5 LED 100n C48 470 R64 BC817 Q2 1 23 4k7 R88 12k R77 3k9 R70 22p C49 390 R48 33k R30 LD6 LED 2k2 R14 470 R67 9V1 DZ1 2 1 100n C50 9V1 DZ25k0 RT2 13 2 330 R28 12k R100 220p C14 10u C28 1 2 470p C47 BAT46 D7 LD17 LED LD7 LED 10u L1 2V7 DZ4 LD8 LED 470p C1 220p C15 8k2 R95 100n C37 470p C42 680 R49 470p C46 LD11 LED LD9 LED 51R 1W0 R3 3k9 R68 22p C43 BAT46 D17 220p C16 22p C41 10u C17 1 2 0R0 DZ7 1n C20 IC3B LM358 6 5 7 2k2 R60 IC7B LM358 6 5 7 22p C45 BAS16 D24 LD10 LED 51R 1W R7 470p C2 1k0 R42 9V1 DZ6 12k R81 2k7 R17 470p C40 9V1 DZ10 D20 RA-LED 330k R92 1k0 R22 2k2 R24 LD13 LED LD1 LED 220k R32 12kR46 D22 RA-LED 4k7 R13 100n C27 10k R61 IC3A LM358 2 3 8 4 1 LD14 LED IC7A LM358 2 3 8 4 1 SW1 SW KEY-Y1011 1 23 IC6B LM358 6 5 7 470p C8 D21 RA-LED IC5B LM358 6 5 7 470 R66 BAT46 D8 LD18 LED 6k8 R97 1k0 R63 100n C3 6k8 R54 51 1WR44 6k8 R37 D19 RA-LED 4k7 R27 220p C10 xx R53 4k7 R25 680 R55 D15 BAT46 4k7 R91 xx R83 100n C34 4k7 R101 51 1WR43 470p C7 100n C51 220p C21 100n C26 100 R10 3k3 R36 4k7 R65 xx R11 D14 BAT46 100n C38 SW277 IC2 3 5 76 8 2 14 3 5 76 8 2 14 CN3 8k2 R62 3k9R38 22p C18 C54 470u 35V 1 2 12k R73 470 R8 10u L3 BAT46 D11 J1 1 2 220 R18 LD20 LED 5k6 R51 220p C52 51 1WR1 100 R9 470p C39 1k0 R90 220 R15 LD12 LED 10k R16 150k R74 51 1WR2 22 R4 10k R40 33k R85 100n C33 12k R69 xx R6 Q13 BC807 12k R80 2k2 R57 RT1 1 3 2 10k R94 10k R12 390 R19 100 R78 100u C23 1 2 BAT46 D9 220 R33 BC817 Q3 1 2 3 IC8A LM358 2 3 8 4 1 470p C31 22k R79 4k7 R5 BAT46 D4 56k R98 BC817 Q12 1 2 3 220 R99 100n C12 LD16 LED 10k R52 33 R29 10u C30 12 6k8 R56

5 5 4 4 3 3 2 2 1 1 DD CC BB AA GR00260ASEA 300W Low Pass Filter A4 11Wednesday, February 20, 2002 INGENIUM Title SizeDocument NumberRev Date:Sheet of DWG.Sig.Dwg. DateApp.Sig.App.Date L10 2T0/0C5/3D0 L11 2T0/0C5/3D0 L4 2T0/2C0/18D0 L6 2T0/0C5/3D0 C11 15p CN1 L8 2T0/1C5/5D0 SOLDER_POINT1 L7 2T0/0C5/3D0 C9 12p C2 15p L1 2T0/2C0/18D0 C10 15p C3 15p L2 2T0/2C0/15D0 C8 15p L3 2T0/2C0/15D0 C4 12p C5 15p L5 2T0/0C5/3D0 L9 2T0/0C5/3D0 C1 6p8 C7 3p3 C6 15p C12 15p

5 5 4 4 3 3 2 2 1 1 DD CC BB AA GR00257ASEC 300W Directional Coupler A4 11Friday, March 01, 2002 INGENIUM Title SizeDocument NumberRev Date:Sheet of DWG.Sig.Dwg. DateApp.Sig.App.Date +15V +15V RF OUT (to Filter) RF IN RF MONITOR C3 6p8 L1 68n R21 2k2 R15 2k2 R17 120 RT1 10k R14 47R C10 47p C4 27p D3 MA4CS103A CC2 100 cm . . L3 68n C14 8p2 R8 330 D6 MA4CS103A R27 0R0 C22 100p L6 47n C30 100p D2 MA4CS103A C19 39p D1 MA4CS103A C34 100p R25 4k7 C26 100p C13 47p R9 270 C32 100p L8 47n C18 ? R10 68 D4 MA4CS103A C2 2p2 ATC C8 15p R4 82 C33 100p C7 12p R7 220 L5 68n C16 27p C31 100p CN2 1 2 3 4 5 6 7 8 9 10 C24 100p C6 56p R3 390 R2 390 LM358 IC1 2 3 8 4 1 CC1 .. C29 100p C28 100p R5 82 R24 180 C15 56p R20 0R0 C5 6p8 R19 470 C11 47p D5 MA4CS103A L2 68n L7 68n R6 180 R11 100 C20 100p C9 8p2 C35 100p L4 68n R26 120 R12 56R C12 12p C36 100n L9 47n R18 56R C25 27p R13 82R C17 47p R23 10k R22 10k C23 33p C1 22p C27 100n C21 100p C37 68p R16 10k

5 5 4 4 3 3 2 2 1 1 DD…
