NYOSAKS-02RXRemote Keyless Entry System

Information Document(5 sheets: including this sheet) Attachment 1 - diagram(1 sheet) Attachment 2 - view(1 sheets) Attachment 3 - Circuit Diagram(1 sheets) Attachment 3 - Part List(2 sheets) Page 1 of 10 CONTENTS LIST AS SEPARATE TECHNICAL UNIT INFORMATION DOCUMENT NO. SCE-0512 OF VEHICLE RF REMOTE KEYLESS ENTRY RELATING TO FCC/IC APPROVAL Shinchang Electrics Co.,Ltd. - 01.Dec. 2005 - NO. : SCE-0512 Date : 01. Dec. 2005 . 1. GENERAL 1.1. Make SHINCHANG ELECTRICS Co., Ltd. 1.2. Name and address of manufacturer SHINCHANG ELECTRICS CO., LTD. 734-2, Wonshi-dong, Ansan-si, Gyungki-do, Korea. 1.3. Model NO. REMOTE KEYLESS ENTRY SYSTEM FOR VEHICLE - TRANSMITTER : SAKS-01Tx - RECEIVER : SAKS-02Rx 1.4. Address of assembly plant SHINCHANG ELECTRICS CO., LTD. 734-2, Wonshi-dong, Ansan-si, Gyungki-do, Korea. Page 2 of 10 Information Document SHINCHANG ELECTRICS NO. : SCE-0512 Date : 01. Dec. 2005 2. PRODUCT SPECIFICATION 2.1 SCOPE 2.1.1 KEY PART : TRANSMITTER is inside of the FOLDING KEY, and it sends the ROLLING CODE to the RECEIVER by Radio Frequency. 2.1.2 RECEIVER : It receives the ROLLING CODE and decodes that, and sends the DATA to ATAS. *ETACS : Electronic Time & Alarm Control System. 2.2 SPECIFICATIONS 2.2.1 TRANSMITTER 2.2.2 RECEIVER Page 3 of 10 Frequency 315MHz Code Rolling Code(Hopping Algorithm) OPERATING VOLTAGE RANGE DC 2.5 ~ 3.2V OPERATING TEMPERATURE RANGE -20 ~+60°C STORAGE TEMPERATURE RANGE -30 ~ 85°C Modulation AM Electric field strength - 28 ±5dBm (433.92MHz) SPURIOUS RADIATION -36dBm (MAX) StandBy Current 3.5mA (max) ITEM BATTERY LIFE 2 YEAR(Lithium 3V 1EA) Operating Temperature DC 9 ~ 16V Operating Voltage Storage Temperature - 40 ~ + 85°C Sensitibity ITEM RATED SUPPLY VOLTAGE SPECIFICATION DC 3V SPECIFICATION Min -98dBm DC 12V Rated Supply Voltage - 30 ~ + 80°C Information Document SHINCHANG ELECTRICS NO. : SCE-0512 Date : 01. Dec. 2005 3. USER MANUAL 3.1 NAME : REMOTE KEYLESS ENTRY SYSTEM - This system is ATAS and inculdes RKE. - RKE in ATAS system is intended for auto door lock or unlock in vehicle. - This ATAS system is to be installde on motor vehicles as *OE item. *OE : Original Equipment. *ATAS : Anti Theft Alarm System. *RKE : Remote Keyless Entry. 3.2 SYSTEMS CONSTRUCTION SYSTEM IN VEHICLE SYSTEM FOR TEST * Through the use of LED, operating state is displayed by LED. LED 'ON' means that DATA is sended to the ATAS. Page 4 of 10 Information Document SHINCHANG ELECTRICS ROLLING CODE ANTENNA BATTERY DOOR ACTUATOR ROLLING CODE ANTENNA RECEIVER BATTERY LED RECEIVER LOCK or UNLOCK DATA NO. : SCE-0512 Date : 01. Dec. 2005 3.3 OPERATING SUMMARY ① TRANSMITTER's button is pushed. ② TRANSMITTER sends the code by radio frequency. ③ RECEIVER gets the code and decodes it. ④ Receiver judges the code whether it is right code or not. ⑤ Receiver checks door lock or unlock state. ⑥ Receiver drives the actuator. 3.3.1 LOCK & UNLOCK If LOCK or UNLOCK button is pushed for less than 1 sec, then TRANSMITTER sends the LOCK or UNLOCK DATA. 3.3.2 TRUNK OPEN If TRUNK button is pushed for more than 0.6 sec, then TRANSMITTER sends the 'TRUNK OPEN' DATA Page 5 of 10 Information Document SHINCHANG ELECTRICS NO. PART NAME Q'TY REMARKS ① ATAS 1 ② TRANSMITTER 1 Page 6 of 10 NAME RKE SYSTEM TITLE SYSTEM DIAGRAM SCALE FREE LOCKBUTTON UNLOCKBUTTONTRUNKBUTTON 315.00MHz ① ② NO. PART NAME Q'TY REMARKS Page 7 of 10 SCALE FREE NAME RECEIVER TITLE EXTERIOR LAYOUT NO. PART NAME Q'TY REMARKS Page 8 of 10 NAME RECEIVER TITLE CIRCUIT DIAGRAM SCALE FREE 도면 첨부 (1/2) Bills of Material 2005-12-16 lev part number part name q'ty material surf comment maker 0 301CA10000 CONTROL UNIT A-RKE & ATAS 1 1 1073A21230 NAME PLATE 1 TEXT:BLACK 색상:ORANGE 1 3017A17100 CONTROL UNIT A-RKE & ATAS SUB ASS'Y 1 2 3017A10010 CASE 1 SR 0330M BLACK 2 3010A11120 COVER 1 SR 0330M BLACK 2 3017A17300 PCB ASS'Y 1 3 1090A12050 ANTENNA JACK 1 JAS-004D 3 0004490410 VARISTOR 2 SIOV-S14K14AUTOG5 V1,2 EPCOS 3 0003500360 RELAY 1 JJM1A-12V(AJJM331 M06) RLY1 DENKI SHOJI 3 0008500360 RELAY 1 JJM2W-12V H48 RLY2 DENKI SHOJI 3 0002470220 RF MODULE 1 ENW19B03R 315MHz ASK 3 0003530080 CONNECTOR 1 MG641791 J1 한국단자공업 3 3017A10020 PCB 1 FR-4 T1.6 1ONZE 3 3017A10030 CPU 1 ST72334J4T6 U1 THOMSON 3 0010340210 VOLTAGE REGULATOR 1 TLE4269G U2 INFINEON 3 0015340140 K LINE SERIAL INTERFAC E 1 MC33290DR2 U5 MOTOROLA 3 0046340280 WATCH DOG IC 1 MB3793-42PNF U6 FUJITSU 3 0006320190 TRANSISTOR CHIP 2 DTC114EKA-T146 Q1,16 ROHM 3 0032320160 TRANSISTOR CHIP 2 2SC2712Y Q10,12 TOSHIBA 3 0024320230 TRANSISTOR CHIP 1 2SC3392-6-TB Q11 SANYO 3 0011320210 TRANSISTOR CHIP 2 BC807-40 Q4,15 INFINEON 3 0001330210 FET CHIP 2 BSP75N Q2,7 INFINEON 3 0000330210 FET CHIP 1 BTS134D Q9 INFINEON 3 0012310180 ZERNER DIODE CHIP 1 Z02W24V ZD1 KEC 3 0005310120 ZERNER DIODE CHIP 1 RD5.6MB ZD2 NEC 3 0015310490 DIODE CHIP 5 S1G - 13 D1,2,5-7 DII 3 0020310160 DIODE CHIP 4 1SS306 D3,4,9,10 TOSHIBA 3 4725105610 RESISTOR CHIP 4 ERJ3GEYJ472V R5,27,42,62 MATSUSHITA 3 4735105610 RESISTOR CHIP 3 ERJ3GEYJ473V R6,9,18 MATSUSHITA stfs-??-??-?(031208) STF CO., LTD a4(297*210) (2/2) Bills of Material 2005-12-16 lev part number part name q'ty material surf comment maker 3 2715105610 RESISTOR CHIP 3 ERJ3GEYJ271V R7,8,40 MATSUSHITA 3 1825105610 RESISTOR CHIP 2 ERJ3GEYJ182V R45,46 MATSUSHITA 3 1035105610 RESISTOR CHIP 3 ERJ3GEYJ103V R44,47,48 MATSUSHITA 3 2025105610 RESISTOR CHIP 1 ERJ3GEYJ202V R41 MATSUSHITA 3 0000105610 RESISTOR CHIP 2 ERJ3GEY0R00V R50,98 MATSUSHITA 3 0000104510 RESISTOR CHIP 1 ERJ6GEY0R00V R49 MATSUSHITA 3 1035104510 RESISTOR CHIP 3 ERJ6GEYJ103V R1,2,43 MATSUSHITA 3 1045104510 RESISTOR CHIP 14 ERJ6GEYJ104V R11,19-25,30,34,36-39 MA TSUSHITA 3 1545104510 RESISTOR CHIP 5 ERJ6GEYJ154V R28,29,31-33 MATSUSHITA 3 3335104510 RESISTOR CHIP 2 ERJ6GEYJ333V R4,60 MATSUSHITA 3 2015104510 RESISTOR CHIP 1 ERJ6GEYJ201V R96 MATSUSHITA 3 4735104510 RESISTOR CHIP 1 ERJ6GEYJ473V R97 MATSUSHITA 3 4725103410 RESISTOR CHIP 1 ERJ8GEYJ472V R3 MATSUSHITA 3 1225103410 RESISTOR CHIP 6 ERJ8GEYJ122V R12-16,63 MATSUSHITA 3 162510221…

Text truncated - open the document above for the full version.

Block Diagram Frequency Input 315 MHz Battery AMP Horn Output H/Lamp CPU Oscillation Part (SAW Fillter)

SHINCHANG ELECTRICS CO., LTD. 734-2, Wonshi-Dong, Ansan-Si, Gyunggi-Do, 425-090, Korea Tel: +82-41-9010-463, Fax: +82-41-9010-419 Power of Attorney Date: December 16, 2005 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize ONETECH Corp., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by ONETECH Corp on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing ONETECH Corp., as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, _________________________ Mr. Seungchul, Choi / Research Engineer SHINCHANG ELECTRICS CO., LTD. Tel: +82-41-9010-463 Fax: +82-41-9010-419 E-Mail: [email protected]

FCC ID.: NYOSAKS-02RX File No.: E05DR-023 Testing & Evaluation Lab. FCC ID.: NYOSAKS-02RX File No.: E05DR-023 Testing & Evaluation Lab.

FCC ID.: NYOSAKS-02RX File No.: E05DR-023 Testing & Evaluation Lab. IDENTIFICATION LABEL: PROPOSED FCC ID LABEL Due to the product size, only the FCC ID shall be permanently affixed to the rear side of the equipment and other information shall be placed in the instruction manual. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations. Made in Korea FCC ID : NYOSAKS-02RX FCC ID AREA

FCC ID.: NYOSAKS-02RX File No.: E05DR-023 Testing & Evaluation Lab. FCC ID.: NYOSAKS-02RX File No.: E05DR-023 Testing & Evaluation Lab. FCC ID.: NYOSAKS-02RX File No.: E05DR-023 Testing & Evaluation Lab. FCC ID.: NYOSAKS-02RX File No.: E05DR-023 Testing & Evaluation Lab. FCC ID.: NYOSAKS-02RX File No.: E05DR-023 Testing & Evaluation Lab.

Page 1 of 9 FCC ID. : NYOSAKS- 02RXSAKS-02RX File No. : E05DR-023 This report shall not be reproduced except in full without our written approval. FCC-004 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: 82-31-746-8500 FAX: 82-31-746-8700) EMC Testing Dept : 307-51 Daessangryung-Ri, Chowol-Eup Kwangju-Kun, Kyunggi-Do 464-860 Korea. (TEL: 82-31-765-8289 FAX: 82-31-766-2904) Testing & Evaluation Lab. ELECTROMAGNETIC EMISSION C OMPLIANCE REPORT FOR SUPERHETRODYNE RECEIVER Test Report No. : E05DR-023 Applicant : SHINCHANG ELECTRICS CO., LTD. Address : 734-2, Wonshi-Dong, Ansan-Si, Gyunggi-Do, 425-090, Korea Manufacturer : SHINCHANG ELECTRICS CO., LTD. Address : 734-2, Wonshi-Dong, Ansan-Si, Gyunggi-Do, 425-090, Korea Type of Equipment : REMOTE KEYLESS ENTRY SYSTEM FCC ID : NYOSAKS-02RX Model / Type No. : SAKS-02RX Serial number : N/A Total page of Report : 9 pages (including this page) Date of Incoming : December 06, 2005 Date of issuing : December 10, 2005 SUMMARY The equipment complies with the regulation; FCC PART 15 SUBPART B §15.101 This test report contains only the result of a single test of the sample supplied for the examination. It is not a general valid assessment of the features of the respective products of the mass-production. Prepared by: Reviewed by: G. W. Lee/ Chief Engineer Y. K. Kwon/ Director EMC Div. EMC Div. ONETECH Corp. ONETECH Corp. Page 2 of 9 FCC ID. : NYOSAKS- 02RXSAKS-02RX File No. : E05DR-023 This report shall not be reproduced except in full without our written approval. FCC-004 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: 82-31-746-8500 FAX: 82-31-746-8700) EMC Testing Dept : 307-51 Daessangryung-Ri, Chowol-Eup Kwangju-Kun, Kyunggi-Do 464-860 Korea. (TEL: 82-31-765-8289 FAX: 82-31-766-2904) Testing & Evaluation Lab. CONTENTS Page 1. VERIFICATION OF COMPLIANCE ............................................................................................................................3 2. GENERAL INFORMATION...........................................................................................................................................4 2.1 PRODUCT DESCRIPTION................................................................................................................................................4 2.2 RELATED SUBMITTAL(S) / GRANT(S)...........................................................................................................................4 2.3 TEST SYSTEM DETAILS.................................................................................................................................................5 2.4 TEST METHODOLOGY...................................................................................................................................................5 2.5 TEST FACILITY..............................................................................................................................................................5 3. SYSTEM TEST CONFIGURATION..............................................................................................................................5 3.1 JUSTIFICATION..............................................................................................................................................................5 3.2 EUT EXERCISE SOFTWARE...........................................................................................................................................5 3.3 EQUIPMENT MODIFICATIONS.......................................................................................................................................5 3.4 CONFIGURATION OF TEST SYSTEM..............................................................................................................................6 4. PRELIMINARY TEST .....................................................................................................................................................6 4.1 AC POWER LINE CONDUCTED EMISSIONS TESTS........................................................................................................6 4.2 RADIATED EMISSIONS TESTS........................................................................................................................................6 5. FINAL RESULT OF MEASURMENT ...........................................................................................................................7 5.1 RADIATED EMISSION TEST...........................................................................................................................................7 6. FIELD STRENGTH CALCULATION ...........................................................................................................................8 7. LIST OF TEST EQUIPMENT.........................................................................................................................................9 Page 3 of 9 FCC ID. : NYOSAKS- 02RXSAKS-02RX File No. : E05DR-023 This report shall not be reproduced except in full without our written approval. FCC-004 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: 82-31-746-8500 FAX: 82-31-746-8700) EMC Testing Dept : 307-51 Daessangryung-Ri, Chowol-Eup Kwangju-Kun, Kyunggi-Do 464-860 Korea. (TEL: 82-31-765-8289 FAX: 82-31-766-2904) Testing & Evaluation Lab. 1. VERIFICATION OF COMPLIANCE APPLICANT : SHINCHANG ELECTRICS CO., LTD. ADDRESS : 734-2, Wonshi-Dong, Ansan-Si, Gyunggi-Do, 425-090, Korea CONTACT PERSON : Seungchul, Choi / Research Engineer TELEPHONE NO : 82-41-901-0463 FCC ID : NYOSAKS-02RX MODEL NO/NAME : SAKS-02RX SERIAL NUMBER : N/A DATE : December 10, 2005 DEVICE TYPE UNINTENTIONAL RADIATOR E.U.T. DESCRIPTION REMOTE KEYLESS ENTRY SYSTEM -SUPERHETRODYNE RECEIVER THIS REPORT CONCERNS ORIGIN…

Text truncated - open the document above for the full version.

FCC ID.: NYOSAKS-02RX File No.: E05DR-023 Testing & Evaluation Lab.
