O3ZHOBTL100IRETRO PHONE BLUETOOTH

iRetroPhone ™ Scan Me ! Instruction Manual 1 3 2 Earpiece Pickup/Hang-up button Microphone Status Indicator iRetroPhone handset Volume control WELCOME Thank you for buying the iRetroPhone Bluetooth Handset, you will love this new experience of wireless, comfortable and radiation safe talk. For the most up-to-date information, be sure to check our Web site at www.konnext.com HAT YOU GET IN THIS PACKAGE 1. One iRetroPhone Bluetooth Handset 2. One instruction manual 3. USB charging cable 4. Silicone Pad LOCATION OF CONTROLS Download the Konnext™ iRetroPhone™ App from iTunes Store & Android Market: iTunes Store - http://itunes.apple.com/us/app/iretrophone/id463261513?mt=8 Android Market - https://market.android.com/details?id=com.softembed.iretrophone 1 CONNECTING YOUR iRetroPhone Bluetooth TO YOUR MOBILE PHONE PAIRING STEP1 Turn on the Bluetooth feature of the device which you wish to pair with (for information enabling the Bluetooth feature on your device, please read the instructions provided by the manufacturer of the device.) STEP2 Setting the Bluetooth iRetroPhone Handset in pairing mode: • Press and hold down the Pick up/Hang up button for 2 seconds as shown. A blue indicator light shall start to flash, continue to hold down the button then release the button until a red and blue indicator light starts flashing. • Release the button Pick up/Hang up. Follow the pairing instructions for your cell phone or other Bluetooth device. If your device prompts for passkey, please enter “0000” (four zeros). TURNING OFF Press and hold down the button for 5 seconds until the light turns off. TURNING ON Press and hold down the Pickup/Hang up button for 2 seconds until the light turns on. CHARGING To Charge the iRetroPhone Bluetooth Handset, please connect the handset with the micro USB charging cable as shown. The status indicator shall light in red indicating the handset is charging, the indicator light shall turn off when the handset is fully charged.. 3 BE CAREFUL not to force the adaptor into your mobile phone, you could damage it. We can not be held responsible for any damage you will do to your mobile phone while trying to plug your iRetroPhone Bluetooth Handset. Depending on your brand and model of mobile phone, a message or logo may now appear to your screen indicating that the iRetroPhone Bluetooth Handset have been detected. MAKING A CALL Once your iRetroPhone Bluetooth Handset is connected to your mobile phone, you can make a call as you normally do it. ANSWERING AN INCOMING CALL Most mobile phone will support the iRetroPhone answer button function. Just press the central button on the handle of the handset and it will work as your mobile phone answer button. If your mobile phone doesn’t support the answer button function, you can then answer the call by pressing the regular answer button on your mobile phone. DISCONNECTING A CALL Once you have terminated your conversation, simply press the answer button of the iRetroPhone Bluetooth Handset again and you will be disconnected. If your mobile phone doesn’t support the answer button function, you can then disconnect the call by pressing the regular disconnect button on your mobile phone. LAST NUMBER DIALLED Depending on your mobile phone brand and model, you may be able to redial the last number called by simply pressing the iRetroPhone Bluetooth Handset answer button TWICE while phone in standby. 4 VOICE ACTIVATED DIALING The iRetroPhone Bluetooth Handset also supports “voice activated dialing” with certain brand and model of mobile phones. Before you can use this function, you need to set up voice tags on your mobile phone (please check your mobile’s phone instruction manual for more details). To make a voice activated call, hold down the answer button of the iRetroPhone Bluetooth Handset until you hear a “bip”. You must then pronounce the name of the contact you wish to call. TROUBLE SHOOTING If you are having problems using your iRetroPhone Bluetooth Handset, please go to www.konnext.com for further help and information, or consult your local retailer. LIMITED WARRANTY If the product appears to be damaged or does not function properly, please follow the advice in this booklet. If you can not find any solution in this booklet, please go to www.konnext.com for instructions about how to obtain warranty service. 5 6 How to use the iRetroPhone Bluetooth Handset: PLEASE READ THESE INSTRUCTIONS CAREFULLY before using your new handset. IMPORTANT SAFETY INSTRUCTIONS READ BEFORE OPERATING EQUIPMENT This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of: 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 8. Only use attachments/accessories specified by the manufacturer. 2 Press and hold for 2 seconds and release Blue indicator flashing slowly Connect to USB charger or computer USB port Bluetooth Passkey 0000 4 FCC WARNING This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However…

Text truncated - open the document above for the full version.

Ant. 2402-2480MHz

Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 EUT View 3 EUT View 4 (Pink) Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 EUT View 5

Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 EXHIBIT 1- PRODUCT LABELING Proposed FCC ID Label Format FCC ID: O3ZHOBTL100 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specifications : Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 EXHIBIT 1- PRODUCT LABELING Proposed FCC ID Label Format FCC ID: O3ZHOBTL100 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specifications : Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 Solder Board-Component View 1 Solder Board-Component View 2 Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 Solder Board-Component View 3 Solder Board-Component View 4

Circuit Description Model no.:HO-BTL-100 Operation Descriptions The transmitter is a Bluetooth radio operating at 2400MHz ISM band, operating frequency of 2.402-2.480GHz. The transmitter is powered by a 3.7V battery and the transmitting frequency is controlled by a crystal of 16MHz. The operation is achieved by different combinations of form pulse / amplitude / frequency modulating signal on the 1MHz carrier frequency. Remarks: The transmitter is a iRetro Phone Bluetooth, The modulation is GFSK for 1M data rate, 1/4-DQPSK for 2M data rate, and 8DPSK for 3M data rate. Fast frequency hopping (1600 hops/s) is used over a total of 79 channels between 2.402 GHz up to 2.480 GHz. The channel bandwidth is 1 MHz.

5 5 4 4 3 3 2 2 1 1 DD CC BB AA MINI USB BH-1110 BLUERED LED2 <Doc> <Title> Custom 12Monday, March 12, 2012 Title SizeDocument NumberRev Date:Sheetof Charge LED1 Charge_DET Charge LED0 Charge_DET VBAT VBAT VBAT 3.3V VBAT 3.3V R151K R14 100K C15 0.1uF Q1 2N3904 3 2 1 C9 NC R647R R8 100K M MIC1 MIC R747R R54.7K R2 330R R347kR R10 200R ANT1 1 C18 0.1uF C2 0.1uF C19 0.1uF Q2 RT9161 1 23 GND 3.3VBAT C4 10uF R1 2.4Ω C7 1uF C16 10uF C81uF C11 0.1uF C12 0.1uF C10 0R PAIR1 12 R12 2K2 U2 BC5 1 10 131214 6 4 3 11 5 20 8 27 28 29 26 232221 25 24 17161918 9 15 31 30 7 2 32 PIO2 RX PIO12PIO11PIO13 SPKR_A_P PIO1 PIO3 PIO9 SPKR_A_N MISO SPKR_B_P MICB-P MICB-N MICA-P MIC-BIAS VREGLED1LED0 VBAT 1.8V MOSIPIO15CSBCLK TX PIO14 GND MICA-N SPKR_B_N PIO0 ANT C1 0.1uF C3 10uF R4 10R LS1 SPEAKER U3 1 6 3 84 5 27 SD VDD IN+ UOT-IN- OUT+ CNGND LED6 3 21 4 C14 NC U1 2 3 4 5 1 GND BAT Vcc PROG C C5 0.1uF ZD1 5V6/0.5W L10R c6 22UF L20R BT1 BATTERY 1 2 R11 15NH JP3 8 HEADER 12345678 BT2 1 2 3 4 5 1 2 3 4 5 MIC-BLACK MIC-BLACK LED1LED0 UnRegistered BC5 MOD.sch-1 - Fri Nov 11 16:04:18 2011 UnRegistered

Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I PAGE 1 OF 57 FCC PART 15.247 FCC Part 15C Measurement and Test Report For Konnext Corporation Limited Flat A, 5/F Contempo Place, 81 Hung To Road, Kwun Tong, Kowloon, Hong Kong. FCC ID: O3ZHOBTL100 Report Concerns: Original Report Equipment Type: iRetro Phone Bluetooth Model: HO-BTL-100 Report No.: STRD1203009I Test Date: 2012-03-27 to 2012-05-07 Issue Date: 2012-05-21 Tested By: Susan Su / Engineer Reviewed By: Lahm Peng / EMC Manager Approved & Authorized By: Jandy so / PSQ Manager Prepared By: SEM.Test Compliance Service Co., Ltd. 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, P.R.C.（518101） Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by SEM.Test Compliance Service Co., Ltd . Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I PAGE 2 OF 57 FCC PART 15.247 TABLE OF CONTENTS 1. GENERAL INFORMATION ...................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)...............................................................................4 1.2 TEST STANDARDS...................................................................................................................................................5 1.3 TEST METHODOLOGY.............................................................................................................................................5 1.4 TEST FACILITY.......................................................................................................................................................5 1.5 EUT SETUP AND TEST MODE.................................................................................................................................6 2. SUMMARY OF TEST RESULTS ...........................................................................................................................7 3. §15.203 - ANTENNA REQUIREMENT..................................................................................................................8 3.1 STANDARD APPLICABLE.........................................................................................................................................8 3.2 EVALUATION INFORMATION..................................................................................................................................8 4. FREQUENCY HOPPING SYSTEM REQUIREMENTS .....................................................................................9 4.1 STANDARD APPLICABLE.........................................................................................................................................9 4.2 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE......................................................................................9 4.3 FREQUENCY HOPPING SYSTEM.............................................................................................................................10 5. NUMBER OF HOPPING CHANNELS AND CHANNEL SPACING ...............................................................11 5.1 STANDARD APPLICABLE.......................................................................................................................................11 5.2 TEST EQUIPMENT LIST AND DETAILS...................................................................................................................11 5.3 TEST PROCEDURE.................................................................................................................................................11 5.4 ENVIRONMENTAL CONDITIONS............................................................................................................................11 5.5 SUMMARY OF TEST RESULTS/PLOTS....................................................................................................................12 6. DWELL TIME OF A HOPPING CHANNEL ......................................................................................................14 6.1 STANDARD APPLICABLE.......................................................................................................................................14 6.2 TEST EQUIPMENT LIST AND DETAILS...................................................................................................................14 6.3 TEST PROCEDURE.................................................................................................................................................14 6.4 ENVIRONMENTAL CONDITIONS............................................................................................................................14 6.5 SUMMARY OF TEST RESULTS/PLOTS....................................................................................................................15 7. 20-DB BANDWIDTH ..............................................................................................................................................31 7.1 STANDARD APPLICABLE.......................................................................................................................................31 7.2 TEST EQUIPMENT LIST AND DETAILS...................................................................................................................31 7.3 TEST PROCEDURE.................................................................................................................................................31 7.4 ENVIRONMENTAL CONDITIONS............................................................................................................................31 7.5 SUMMARY OF TEST RESULTS/PLOTS..............................................................................................................…

Text truncated - open the document above for the full version.

Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission Test Setup (Below 30MHz) Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 Radiation Emission Test Setup (30MHz to 1GHz) Konnext Corporation Limited Model: HO-BTL-100 REPORT NO.: STRD1203009I FCC PART 15.247 Radiation Emission Test Setup (Above 1GHz)
