Kalenji CW 500 Play SD EN EN This Starter guide gives a quick and easy introduction to using your CW 500 Play SD watch. To find out about all the features and functions of your product, please refer to the full notice available on www.Kalenji.com / assistance section. 1. Composition of your product. Watch Accelerometer Heart rate belt 2. Starting out and settings. 2.1. Switch the product on. When using it for the first time, you must set it. Switch the watch on by pressing on one of its buttons. PRESS on one of the buttons 2.2. Setting your watch. Set your product by specifying in turn your language, units, sex, age, weight, height, time and date. Français Language Back Previous choice in the list Confirmation Next choice in the list 5 years Age Back Increase the value Confirmation Lower the value If your watch has already been switched on, access these settings by pressing on OK then selecting “Settings” by pressing on then selecting “User” by pressing on OK. 2.3. Energy saver. The CW Kalenji 500 Play SD watch is delivered in “energy saving” mode for longer battery life. When this function is activated, the watch goes into stand-by after 5 minutes of inactivity: the screen switches off automatically. To display the time again or use the various functions of your watch, simply press on one of the buttons. If you prefer permanent time display, you can disactivate this function in Settings/watch (see chapter 4.2, Main modes to get to these settings). EN EN 3. Fitting the sensors. 3.1. Accelerometer (speed and distance). 1 2 3 - Slide the clip beneath the shoelaces, lengthwise, on the flattest part of the shoe (an angle of more than 30° from the ground may compromise measuring accuracy). - Clip the accelerometer (oval capsule) below the rear groove of the clip, with the notch of the accelerometer towards the toes. - Press on the tip of both clip and accelerometer to clip the accelerometer notch into the clip slot. - Tighten your laces to make sure the accelerometer stays in place. - To release the accelerometer, press on the front tab of the clip. 3.2. Heart rate belt. Setup 1 sensors 23 Reception cone *118.08 inches 4. Using the watch. 4.1. Button functions. 1. : Back to previous menu, note intermediate times manually. 2. : previous choice in the list, increase a value, choose one of the predefined displays during the run. 3. OK: To access the menu, confirm your choice or start/stop the stopwatch during a session. 4. : next choice in the list, lower a value, choose one of the predefined displays during the run. EN EN 4.2. Main modes. There are four modes. Simply press on OK to choose one. To change from one mode to another, use the up and down arrows. To select the mode you want, simply confirm by pressing on OK. To display the time again, press on the button . Activities: Sports mode: free, training, challenge. Data: Viewing last exercises, personal statistics, memory management. Stopwatch functions: Stopwatch, countdown. Settings: Various user settings, activities, watch, sensors, display, return to default settings. Home HomeHome Home Activities Settings Data Stopwatch functions 4.3. How the various activity modes work. In Activities mode, you can choose from three different activities: free, training and challenge... For each activity, you have to define information for the watch to suggest a suitable exercise in line with your demand (target zone, exercise intensity, duration etc.). Free mode: Run at your own pace and regulate your speed based on speed, heartbeat or lap information (distance or time). Training mode: Enjoy various training programmes according to your aim, heart rate training, fitness or losing weight. Challenge mode: Set yourself a challenge with the option of running to outstrip a virtual competitor, to beat your own record or assess your MAS or Maximum Aerobic Speed. For each type of exercise, an “Info” section sets out the underlying principle and its benefits. Once you have configured the exercise, select OK to start. The watch will detect the sensors available (heart rate belt and accelerometer) then suggest you start the exercise. It issues a report at the end of each run. Scroll the information with the button . When you’ve finished reading the report, press on OK to then “save” or “delete” the session you have just completed. For a full report of your runs, go to Data mode. For your watch to detect your sensors (heart rate belt and accelerometer) properly, they must not be in stand-by mode. To make sure of this: - The heart rate belt sensors must be humidified and properly positioned on the chest. - The accelerometer must be shaken. 4.4. Free mode Activity Free • Free mode is recommended for your first session, since it is easy to use and you’ll get used to how the watch works quickly.

EN EN You can set: Free OK Autolap Target zone • A target zone (heartbeat or speed) with alerts if you leave this zone. To configure this information, select zone and press on OK. Free OK Autolap Target zone Free OK Autolap Target zone • Regular lap information, at a pace to be determined (for example: every Km or every 5 min). The watch recaps your performance for each lap. Free OK Autolap Target zone • Then select “OK” to continue. Search Searching sensors • The watch detects the sensors (accelerometer and cardiofrequencemeter). Once the sensors have been detected, you can start running, pressing on OK to start the stopwatch. • When running, you can choose between three predefined displays. To change the current display, press on “ ” or “”. For a customised display, please refer to the full instructions. Press on OK again to put an end to your session. Continue Stop • You may choose to start running again, go to Settings mode to modify your settings or confirm the end of your run. Should you choose the latter, the watch displays a short report of your run and then asks whether you want to save the data. 5. Recommendations for use. See the full instructions in the support section on kalenji.com. Find your rhythm, enjoy your run. FR : Par la présente OXYLANE déclare que l’appareil CW 500 Play SD est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. EN : Hereby, OXYLANE, declares that this CW 500 Play SD is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. ES : Por medio de la presente OXYLANE declara que el CW 500 Play SD cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. DE : Hiermit erklärt OXYLANE, dass sich das Gerät CW 500 Play SD in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/ EG befindet. IT : Con la presente OXYLANE dichiara che questo CW 500 Play SD è conforme ai requisiti essen- ziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. NL : Hierbij verklaart OXYLANE dat het toestel CW 500 Play SD in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. PT : OXYLANE declara que este CW 500 Play SD está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. PL : Niniejszym OXYLANE oświadcza, że urządzenie CW 500 Play SD spełnia najważniejsze wymogi i jest zgodne z przepisami dyrektywy 1995/5/WE. HU : Alulírott, OXYLANE nyilatkozom, hogy a CW 500 Play SD megfelel a vonatkozó alapvetõ köve- telményeknek és az 1999/5/EC irányelv egyéb elõírásainak. RU : Настоящим компания OXYLANE заявляет, что аппарат CW 500 Play SD соответствует основным требованиям и иным относящимся к нему положениям директивы 1999/5/CE. RO : Prin prezenta, OXYLANE declară că aparatul CW 500 Play SD este conform cu exigenţele esenţiale şi cu celelalte dispoziţii pertinente ale directivei 1999/5/CE. SK : OXYLANE týmto vyhlasuje, že CW 500 Play SD spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES. CS : Tímto OXYLANE prohlašuje, že přístroj CW 500 Play SD splňuje základní požadavky a ostatní nařízení směrnice 1999/5/CE. SV : Härmed intygar OXYLANE att denna CW 500 Play SD står I överensstämmelse med de väsent- liga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. BG : С настоящия документ OXYLANE декларира, че уредът CW 500 Play SD отговаря на основните изисквания и другите действащи разпоредби на Директива 1999/5/ЕО. TR : OXYLANE İşbu yazı ile, CW 500 Play SD cihazının 1999/5/CE direktifinde belirtilmiş olan temel gerek ve şartlara uygun olduğunu beyan eder. UK : Цім документом OXYLANE затверджує, що апарат CW 500 Play SD відповідає основним вимогам та іншим критеріям устаноленим директивою 1999/5/CE. ZH : OXYLANE 在此声明 CW 500 Play SD 型器材符合1999/5/CE的基本标准以及其他相关指导标 准。 ZT : OXYLANE 在此聲明，CW 500 Play SD 儀器符合1999/5/CE指導標準中的基本要求及其他相關 條款規定.
