Report No.60/790.15.004.03 Rev:00 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 1 of 16 FCC/ICTEST REPORT Report Number : 60/790.15.004.03 Date of Issue: April 1, 2015 Model : Joule GPS Plus Product type : GPS Bike Computer Applicant : DAYTON INDUSTRIAL CO.,LTD Address : 2-12 Kwai Fat Road,11-A Kwai Chung,New Territories,Hong Kong Production Facility : KENDY ENTERPISE LTD Address : 2-12 Kwai Fat Road,11-A Kwai Chung,New Territories,Hong Kong Test Result :  Positive  Negative Total Pages: 19 TÜV SÜD Hong Kong Ltd. is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO 17025. TÜV SÜD Hong Kong Ltd. reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented.It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Hong Kong Ltd. shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Hong Kong Ltd. issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Prepared by: Reviewed by: __________________________________________ __________________________________________ CHAN KwongNgai Edmond FUNG Report No.60/790.15.004.03 Rev:00 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 2 of 16 TABLE OF CONTENTS 1 General Information ......................................................................................................................................... 3 1.1 Summary of Test Result ................................................................................................................... 3 1.2 Measurement Uncertainty ................................................................................................................ 3 1.3 Details about the Test Laboratory .................................................................................................... 3 2 EUT Description............................................................................................................................................... 4 3 Test Methodology ............................................................................................................................................ 5 3.1 Decision of Test Mode ...................................................................................................................... 5 3.2 Configuration of Test System Details ............................................................................................... 5 3.3 Test Site Environment ...................................................................................................................... 6 4 Emission Test .................................................................................................................................................. 7 4.1 Conducted Emission Measurement ................................................................................................. 7 4.2 Radiated Interference Measurement .............................................................................................. 11 Report No.60/790.15.004.03 Rev:00 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 3 of 16 1 General Information 1.1 Summary of Test Result FCC Rules IC Rules Description of Test Result Remark FCC§15.107 ICES-003§6.1 AC Line Conducted Emissions PASS Meet Class B limit FCC§15.109 ICES-003§6.2 Radiated Emission PASS Meet Class B limit Remark: 1. EUT is battery operated only. 2. The test results of this report relate only to the tested sample(s) identified in this report. Manufacturer or whom it may concern should recognize the pass or fail of the test result. 1.2 Measurement Uncertainty Conducted Emission The measurement uncertainty is evaluated as ± 2.26 dB. Radiated Emission The measurement uncertainty is evaluated as ± 3.19 dB. 1.3 Details about the Test Laboratory Test site 1 Company name: TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin HK. Telephone: 852 2776 1323 Fax: 852 2776 1372 Test site 2 Company name: Shenzhen Academy of Metrology and Quality Inspection No.4 TongFa Road, Xili Town Nanshan District, Shenzhen, China Report No.60/790.15.004.03 Rev:00 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 4 of 16 2 EUT Description Product Joule GPS Plus Model Number GPS Bike Computer Applicant DAYTON INDUSTRIAL CO.,LTD 2-12 Kwai Fat Road,11-A Kwai Chung, New Territories, Hong Kong Manufacturer KENDY ENTERPISE LTD 2-12 Kwai Fat Road,11-A Kwai Chung,New Territories,Hong Kong Power Supply Internal 3.7V battery I/O Port Description： I/O Port Types Q’TY Test Description 1). USB 1 Connected to PC for data transmitting 2). - - - Report No.60/790.15.004.03 Rev:00 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 5 of 16 3 Test Methodology 3.1 Decision of Test Mode Pre-Test Mode EMC Mode 1:Normal working 3.2 Configuration of Test System Details Mode 1 Signal Cable Type Signal Cable Description A AC Power Cable Non-Shielded, 2.0m B AC Power Cable N…

Text truncated - open the document above for the full version.

1 Test Photograph Test Mode: Mode 1 Description: Conducted Emission Test Mode: Mode 1 Description: Conducted Emission Test Mode: Mode 1 Description: Radiated Emission Test (30MH-1GHz) Test Mode: Mode 1 Description: Radiated Emission Test(1GHz-18GHz) Test Mode: Mode 1 Description: Radiated Emission Test (30MH-1GHz) Test Mode: Mode 1 Description: Radiated Emission Test(1GHz-18GHz)
