O4GPM90R2Digital HRM Watch

heart rate monitor herzfrequenz pulsuhr Operating Instructions Gebrauchsanleitung german |engineering PM 90 1 G B TABLE OF CONTENTS Scope of delivery ............................................................................. 3 Important Notes ............................................................................... 4 General Information for Training.................................................... 6 Functions of the HR monitor .......................................................... 8 Transmission of signal and methods of Devices Measurement . 9 Getting started ............................................................................... 12 General operation of the HR monitor........................................... 17 Buttons on the HR monitor ....................................................... 17 Display...................................................................................... 18 Menus....................................................................................... 19 Basic settings ................................................................................ 21 Overview .................................................................................. 21 Enter personal data .................................................................. 22 Set training zone ...................................................................... 23 Set units of measure ................................................................ 24 Set the LightManager ............................................................... 24 Pairing the signals from the device .......................................... 26 Watch settings ............................................................................... 27 Overview .................................................................................. 27 Set time of day and date .......................................................... 28 Set alarm clock ......................................................................... 29 Display speed and distance ..................................................... 30 Recording of training .................................................................... 31 Overview .................................................................................. 31 Stop run times .......................................................................... 34 Record laps .............................................................................. 34 Display speed and distance ..................................................... 35 2 Stop and store recording ..........................................................36 Delete all recordings.................................................................37 Analyzing memory messages...................................................38 Speed and distance .......................................................................39 Overview...................................................................................39 Set the speed unit and automatic lap function..........................40 Calibrate the Speedbox ............................................................42 Display speed and distance......................................................44 Altitude, air pressure and temperature........................................46 Overview...................................................................................46 Set reference altitude, altitude and temperature units..............46 Display altitude profile, temperature and air pressure ..............48 Results............................................................................................51 Overview...................................................................................51 Display training data .................................................................51 Transmit weight management data to the monitor ...................53 Lap results......................................................................................55 Overview...................................................................................55 Display lap results ....................................................................55 Fitness test.....................................................................................56 Overview...................................................................................56 Conduct fitness test ..................................................................57 Display fitness values ...............................................................59 EasyFit software ............................................................................60 Technical specifications, batteries ..............................................61 List of abbreviations......................................................................63 Index ...............................................................................................66 3 G B SCOPE OF DELIVERY Heart rate monitor with wrist band Chest strap and elastic tension strap (adjust- able) Bike mount Storage box PC Software EasyFit (CD) and PC interface cable (USB) In addition: Operating instructions and separate short instructions. Beurer accessories are available from specialised stores: Accessory Function Beurer Speedbox (I or II) You can have your speed and dis- tance values displayed on the HR monitor. Beurer scale (e.g. Scale BG56, Item Number 750.30). You can measure your weight and your body fat with the scale and transmit them to the HR monitor. 4 IMPORTANT NOTES Please carefully read through these operating instructions, keep it for future reference and also make it available to others. Training „ This product is not a therapeutic device. It is a training instrument, which was developed for the measurement and representation of the human heart rate. „ With high-risk sports, please note that the use of the heart rate monitor can represent an additional source of injury. „ If in …

Text truncated - open the document above for the full version.

Report Number: 60/760.11.245.01Page 1 of 28 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 FCC – Test report Report Number: 60/760.11.245.01 Date of Issue: 25 November 2011 Model: PM90 Product Type:Digital HRM Watch Applicant:Dayton Industrial Co., Ltd. Address:2-12 Kwai Fat Road, 11-A Kwai Chung, : New Territories, Hong Kong Production Facility:Kendy Enterprise Ltd. Address:2-12 Kwai Fat Road, 11-A Kwai Chung, : New Territories, Hong Kong Test Result: „Positive†Negative Total pages including Appendices: 28 TÜV SÜD Hong Kong Ltd. is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO 17025. TÜV SÜD Hong Kong Ltd. reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Hong Kong Ltd. shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Hong Kong Ltd. issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Report Number: 60/760.11.245.01Page 2 of 28 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 1 Table of Contents 1 Table of Contents.............................................................................................. 2 2 Details about the Test Laboratory......................................................................... 3 3 Description of the Equipment Under Test................................................................ 4 4 Summary of Test Standards/ Results..................................................................... 5 5 General Remarks.............................................................................................. 6 6 Emission Test Results........................................................................................ 7 6.1 Radiated Emission Test.............................................................................. 7 6.2 Conduct Emission Test............................................................................... 12 7 Appendix A....................................................................................................... 15 Photographs of EUT 8 Appendix B....................................................................................................... 23 Photographs of Test Set Up 9 Appendix C....................................................................................................... 28 Product Information Report Number: 60/760.11.245.01Page 3 of 28 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 2 Details about the Test Laboratory Details about the Test Laboratory Company name: TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin HK. Telephone:852 2776 1323 Fax:852 2776 1372 Company name: CMA Industrial Development Foundations Limited 1302, Yang Hing Centre, 9-13 Wong Chuk Yueng Street Fo Tan, Shatin, N.T. Hong Kong FCC Registered Test Site Number 552221 Report Number: 60/760.11.245.01Page 4 of 28 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 3 Description of the Equipment Under Test Description of the Equipment Under Test Product:Digital HRM Watch Model no.:PM90 Serial number:NIL Options and accessories: NIL Rated Voltage:3 VDC Rated Current:NIL Rated Power:NIL Frequency:NIL Description of the EUT:Operate by 3 V battery (1 x 3 VDC “CR2032“battery) 2.4 GHz Receiver with PC connect function. FCC ID:O4GPM90R2 Report Number: 60/760.11.245.01Page 5 of 28 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 4 Summary of Test Standards and Results Emission Tests Test Condition Test Requirement Test MethodPagesTest Result PassFailN/A Radiated Emission FCC Part 15 ANSI C63.4:2003 7-11 Conducted Emission on AC FCC Part 15 ANSI C63.4:2003 12-14 Report Number: 60/760.11.245.01Page 7 of 28 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 6 Emission Test Results 6.1Radiated Emission Test30MHz–1000MHz Date of test: 24 October 2011Test Result Passed Test requirement : FCC Part 15 Section 15.109 Not Passed Test method: ANSI C63.4:2003 Operating mode : PC Connect Antenna Polarity : Horizontal Remarks: NIL Freq.Ant.Pol.Ant./CF (MHz)H/VCF(dB) 206.54H12.32X/F 245.34H12.08X/F 276.38H11.91X/F 18.97 QP (dBuV /m) QP (dBuV/m ) 31.2943.50 QP (dBuV/m) 21.6333.5446.00 Note Readin gAct.Lim it 22.2834.3643.50 Remark:The EUT was placed on the top of the turntable in test site area. The resolution bandwidth setting on the test receiver was 120 KHz , Detector function peak (30 MHz焍1000MHz). The resolution bandwidth setting on the test receiver was 1MHz, Detector function peak (1 GHz焍26.5GHz). The test shall be made in the operation mode. The turntable was rotated by 360 degrees to determine the position of the highest radiation. For emissions measurement, the receiving antenna was placed 3 meter…

Text truncated - open the document above for the full version.

Radiated Emission Test Set Up 9kHz-30MHz 9kHz-30MHz 30MHz-1GHz 30MHz-1GHz 1GHz -18GHz 1GHz -18GHz 18GHz above 18GHz above Conduct Emission Test Set Up
