O4GREE-bike control unit with BLE function

FCC/ISED Compliance Information Model E41230Model E41227Central FCC IDO4GARFCC IDO4GREFCC IDtbd IC 7666A-ARIC 7666A-REIC tbd 1. FCC Statement ENG | This device complies with Part 15 of the FCC Rules. Caution: If any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Operation is subject to the following two conditions: (1) This device may not cause harmful interfe- rence, and (2) This device must accept any interference received, including interference that may cause undesired operation. The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifica- tions could void the user’s authority to operate the equipment. The RF Exposure Compliance distance is 5 mm. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal- lation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica- tions. However, there is no guarantee that interfe- rence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ›Reorient or relocate the receiving antenna. ›Increase the separation between the equipment and receiver. ›Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ›Consult the dealer or an experienced radio/TV technician for help. 2. ISED Statement ENG | This device complies with Innovation, Science and Economic Development Canada licence‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. CAN ICES-3(B)/NMB-3(B) The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 5 millimeters between the radiator and your body. FR | Le présent appareil est conforme aux CNR Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L‘exploitation est autorisée aux deux condi- tions suivantes: (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fomctionnement du dispositif. CAN ICES-3(B)/NMB-3(B) Le dispositif rencontre l‘exemption des limites courantes d‘évaluation dans la section 2.5 de RSS 102 et la conformité à l‘exposition de RSS-102 rf, utilisateurs peut obtenir l‘information canadienne sur l‘exposition et la conformité de rf. Cet émetteur ne doit pas être Co-placé ou ne fonc- tionnant en même temps qu‘aucune autre antenne ou émetteur. Cet équipement devrait être installé et actionné avec une distance minimum de 20 millimètres entre le radiateur et votre corps.

Appendix Model: E41227

Appendix Model: E41227

Report Number: 60.790.19.048.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page36of36 Radiofrequency radiation exposure evaluation This exposure evaluation is intended forFCC ID: O4GRE According to KDB 447498 D01v06 section 4.3.1, For frequencies between 100 MHz to 6GHz and test separation distances ≤ 50 mm, the Numeric threshold is determined as: Step a) [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR >> The fundamental frequency of the EUT is 2402-2480MHz, the test separation distance is ≤ 50mm. (Manufacturer specified the separation distance is: 5mm) Step a) >> Numeric threshold (2402MHz), mW / 5mm * √2.402GHz ≤ 3.0 Numeric threshold (2402MHz) ≤ 9.678mW >> Numeric threshold (2440MHz), mW / 5mm * √2.440GHz ≤ 3.0 Numeric threshold (2440MHz) ≤ 9.602mW >> Numeric threshold (2480MHz), mW / 5mm * √2.480GHz ≤ 3.0 Numeric threshold (2480MHz) ≤ 9.525mW >> The power of EUT measured (2402MHz) is: -0.85dBm = 0.822mW The power of EUT measured (2440MHz) is: -0.48dBm = 0.895mW The power of EUT measured (2480MHz) is: -0.56dBm = 0.879mW Which is smaller than the Numeric threshold. Therefore, the device is exempt from stand-alone SAR test requirements. 9AppendixA-General Product Information

Report Number: 60.790.19.048.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page1of36 FCC - TEST REPORT Report Number:60.790.19.048.01R01Date of Issue:January 31, 2020 Model:E41227 Product Type:E-Bike HMI Applicant: DAYTON INDUSTRIAL CO., LTD Address:2-12 Kwai Fat Road, 11-A Kwai Chung, New Territories, Hong Kong Production Facility:KENDY ENTERPRISE LTD Address: 2-12 Kwai Fat Road, 11-A Kwai Chung, New Territories, Hong Kong Test Result:nPositiveoNegative Total pages including Appendices : 36 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval Report Number: 60.790.19.048.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page2of36 1 Table of Contents 1 Table of Contents ............................................................................................................ 2 2 Description of Equipment Under Test ............................................................................. 3 3 Summary of Test Standards ........................................................................................... 4 4 Details about the Test Laboratory ................................................................................... 5 4.1 Test Equipment Site List ................................................................................................... 6 4.2 Measurement System Uncertainty .................................................................................... 7 5 Summary of Test Results ................................................................................................ 8 6 General Remarks ............................................................................................................ 9 7 Test Setups ................................................................................................................... 10 7.1 Radiated test setups 9kHz-30MHz .................................................................................. 10 7.2 Radiated test setups Below 1GHz................................................................................... 10 7.3 Radiated test setups Above 1GHz .................................................................................. 10 7.4 AC Power Line Conducted Emission .............................................................................. 11 7.5 Conducted RF test .......................................................................................................... 11 8 Emission Test Results .................................................................................................. 12 8.1 Spurious Radiated Emission ........................................................................................... 12 8.2 Conducted Emission at AC Power line ............................................................................ 16 8.3 6dB & 99% Bandwidth .................................................................................................... 17 8.4 Peak Output Power ......................................................................................................... 20 8.5 Spurious Emissions at Antenna Terminals ...................................................................... 23 8.6 100kHz Bandwidth of band edges................................................................................... 29 8.7 Power Spectral Density ................................................................................................... 32 8.8 Antenna Requirement ..................................................................................................... 35 9 Appendix A - General Product Information ................................................................... 36 Report Number: 60.790.19.048.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page3of36 2 Description of Equipment Under Test Description of the Equipment Under Test Product: E-Bike HMI Model no.: E41227 FCC ID: O4GRE Rating: 12V DC (E-Bike battery) Frequency: 2402MHz-2480MHz (Tx and Rx) Antenna gain: 0 dBi Number of operated channel: 40 Modulation: GFSK Auxiliary Equipment and Software Used during Test: DESCRIPTION MANUFACTURERMODEL NO.S/N ComputerLenovoX2200A72168 Auxiliary Software Used during Test: DESCRIPTION SOFTWARE NAME VERSIONREMARK RF Test Mode Software nRFgo1.16Provided by applicant Report Number: 60.790.19.048.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park…
