O4GRS1Ant+/BLE Combo

(iii) The RF exposure compliance distance: 20mm

Date 01 st June 2015 BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, DAYTON INDUSTRIAL CO., LTD 2-12 Kwai Fat Road, 11-A Kwai Chung, New Territories, Hong Kong hereby authorize Name: Xavier, TSENG Company:TÜV SÜD Hong Kong Ltd (E&E – EMC) 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, Hong Kong. Tel : (852) 3728 6231 E-mail: :[email protected] to act as our agent in all matters relating to applications for equipment authorization , including the signing of all documents relating to these matters the authorization expires on 31 st December 2015. Sincerely, Project Manager:LAP FAI WONG Telephone Number: (852) 2422 4404 Fax: (852) 2480 4627 e-mail: [email protected]

Appendix B Date: 2015-08-24 Report Number: 60.790.15.016.01 Model No.: Ridesense Page 1 of 1 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Hong Kong Science Park, Shatin, Hong Kong

Appendix C Date: 2015-08-24 Report Number: 60.790.15.016.01 Model No.: Ridesense Page 1 of 3 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Hong Kong Science Park, Shatin, Hong Kong Appendix C Date: 2015-08-24 Report Number: 60.790.15.016.01 Model No.: Ridesense Page 2 of 3 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Hong Kong Science Park, Shatin, Hong Kong Appendix C Date: 2015-08-24 Report Number: 60.790.15.016.01 Model No.: Ridesense Page 3 of 3 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Hong Kong Science Park, Shatin, Hong Kong

Date: 2015-08-24 Report Number: 60.790.15.016.01 Model No.: Ridesense Radiofrequency radiation exposure evaluation According to KDB 447498 D01v05r02 section 4.3.1, >> The 1-g SAR test exclusion thresholds for 100MHz to 6GHz, at test separation distances ” 50 mm are determined by: Power at 2457GHz = 0.1931 mW EIRP Power at 2402GHz = 0.0612 mW EIRP Power at 2440GHz = 0.0571 mW EIRP Power at 2480GHz = 0.0580 mW EIRP [(0.1931 mW) / (50 mm)] · [sqrt (2457 GHz)] = 0.1914 which is ” 3.0 for 1-g SAR. [(0.0612 mW) / (50 mm)] · [sqrt (2402 GHz)] = 0.0599 which is ” 3.0 for 1-g SAR. [(0.0571 mW) / (50 mm)] · [sqrt (2440 GHz)] = 0.0564 which is ” 3.0 for 1-g SAR. [(0.0580 mW) / (50 mm)] · [sqrt (2480 GHz)] = 0.0577 which is ” 3.0 for 1-g SAR. Therefore the device is exempt from stand-alone SAR test requirements. >> The fundamental frequency of the EUT is 2457MHz and 2400-2483.5MHz; the test separation distance is < 50mm. >> The power of EUT measured is: - For 2457MHz: 0.1931mW = 10 log (0.1931) dBm ~ -7.14dBm - For 2402MHz: 0.0612mW = 10 log (0.0612) dBm ~ -12.13dBm - For 2440MHz: 0.0571mW = 10 log (0.0571) dBm ~ -12.43dBm - For 2480MHz: 0.0580mW = 10 log (0.0580) dBm ~ -12.36dBm Page 1 of 1 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Hong Kong Science Park, Shatin, Hong Kong

Report Number: 60.790.15.016.01 EMC_SZ_FR_22.00 FCC Release 2014-03-20 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park W est Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 1 of 21 FCC - TEST REPORT Report Number: 60.790.15.016.01 Date of Issue:August 24, 2015 Model: Ridesense Product Type: Ant+/BLE Combo Applicant: DAYTON INDUSTRIAL CO., LTD Address: 2-12 Kwai Fat Road, 11-A Kwai Chung, New Territories, Hong Kong Production Facility : KENDY Enterprise Ltd Address: 2-12 Kwai Fat Road, 11-A Kwai Chung, New Territories, Hong Kong Test Result: „Positive†Negative Total pages including Appendices : 21 TÜV SÜD HONG KONG LTD. is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD HONG KONG LTD. reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations TÜV SÜD HONG KONG LTD. shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD HONG KONG LTD. issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Report Number: 60.790.15.016.01 EMC_SZ_FR_22.00 FCC Release 2014-03-20 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park W est Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 2 of 21 1 Table of Contents 1 Table of Contents ............................................................................................................ 2 2 Description of Equipment Under Test ............................................................................. 3 3 Summary of Test Standards ........................................................................................... 4 4 Details about the Test Laboratory ................................................................................... 5 4.1 Test Equipment Site List ................................................................................................... 6 4.2 Measurement System Uncertainty .................................................................................... 7 5 Summary of Test Results ................................................................................................ 8 6 General Remarks ............................................................................................................ 9 7 Emission Test Results .................................................................................................. 10 7.1 Radiated Emission .......................................................................................................... 10 7.2 20dB & 99% Bandwidth .................................................................................................. 12 7.3 Bandedge Emission ........................................................................................................ 14 8 Appendix A - Photographs of EUT ................................................................................ 16 9 Appendix B - Setup Photographs of EUT ...................................................................... 20 10 Appendix C - General Product Information ................................................................. 21 Report Number: 60.790.15.016.01 EMC_SZ_FR_22.00 FCC Release 2014-03-20 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park W est Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 3 of 21 2 Description of Equipment Under Test Description of the Equipment Under Test Product:Ant+/BLE Combo Model no.:Ridesense FCC ID:04GRS1 Rating:3.0VDC (1 x 3.0VDC size “CR2032“ batteries) Frequency:2457MHz Antenna gain:0 dBi Number of operated channel: 1 Modulation:GFSK Report Number: 60.790.15.016.01 EMC_SZ_FR_22.00 FCC Release 2014-03-20 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park W est Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 4 of 21 3 Summary of Test Standards Test Standards FCC Part 15 Subpart C 10-1-13 Edition Federal Communications Commission, PART 15 — Radio Frequency Devices, Subpart C — Unintentional Radiators Report Number: 60.790.15.016.01 EMC_SZ_FR_22.00 FCC Release 2014-03-20 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park W est Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 5 of 21 4 Details about the Test Laboratory Site 1 Company name:TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, Hong Kong Site 2 Company name:TÜV SÜD China Ltd. Building 12&13 Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Shenzhen 518052, P.R.China FCC Registration Number: 502708 EmissionTests Test ItemTest Site FCC Part 15 SubpartC FCC Title 47 Part 15.249 & 15.209 Radiated EmissionSite 2 FCC Title 47 Part 15.249 & 15.207 Conduct EmissionNIL FCC Title 47 Part 15.215 20dB & 99% BandwidthSite 2 FCC Title 47 Part 15.249 Bandedge EmissionSite 2 Report Number: 60.790.15.016.01 EMC_SZ_FR_22.00 FCC Release 2014-03-20 TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park W est Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Page 6 of 21 4.1 Test Equipment Site List Radiated emission Test, Bandedge Emission – Site 3 DESCRIPTIONMANUFACTURER MODEL NO.SERIAL NO.CAL. DUE DATE EMI Test ReceiverRohde & SchwarzESR 2610126917-Aug-15 Trilog Super Broadb…

Text truncated - open the document above for the full version.

Appendix A Date: 2015-08-24 Report Number: 60.790.15.016.01 Model No.: Ridesense Page 1 of 1 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Hong Kong Science Park, Shatin, Hong Kong
